Used Squeegee Grinding Machine for sale (65,268)

Condition: used, Year of construction: 2001, grinding length 4200 mm grinding width 1300 mm workpiece height 550 mm Control Siemens 840D passage width 1300 mm electro-magnetic table 4200 x 1300 mm grinding height 550 mm grinding motor 306 kW grinding motor turning speeds up to 370 U/min grinding motor feed, infinitely variable 0,5-35 m/min coolant flow rate 2000 l/min weight of the machine ca. 50 t dimensions of the machine ca. 11,21 x 5,25 x 3,85 m Equipment / Accessories: - segment head - diameter 1400 mm - for segment dimensions 120/106 x 41 x 250 mm Kedpfjthumujx Abvedi - number of segments: 1 set = 26 pieces - grinding motor adjustment - in steps: 0,002 - 1 mm - continuous: up to 5 mm/min stepless

Condition: new, Precision Heavy Duty Cylindrical Grinder Working Capacity: Max Length: 4000mm Max Diameter: 550mm Max Weight: 1,000kg Center Height: 280mm Grinding Wheel Size: φ710×50~100×φ203.2 Grinding Wheel Speed: 890 RPM Main Spindle (5 steps by belt): 25~165 RPM Main Spindle Taper: MT#5 Tailstock Quill Taper: MT#5 Kdedpfx Absytnh Isvji Tailstock Quill Stroke: 30mm Table Swing Angle: 1° 30' Power: Grinding Wheel + Inverter 15HP Main Spindle + Inverter 3HP Hydraulic Pump Motor 3HP Cooling Pump 1/4HP Lubricant Motor 1/2HP

Condition: used, Year of construction: 2012, Lot consists of: (1) CNC vertical grinding + hard turning center Technical Details: max. workpiece internal diameter 10 - 200 x 150 mm, 2 work spindles, 4 machining stations, CNC SIEMENS SINUMERIK 840D, tool turrets, chip conveyor, rapid traverse: X/Z: 90/30 m/min Kdsdpfx Asym Sazsbvji

Condition: used, Year of construction: 2001, Lot consists of: (1) CNC Vertical-Spindle Surface Grinding Machine Technical Details: X / Z 950 / 200 mm, grinding wheel diameter 400 mm, grinding spindle feed: 0 - 30 m/min, 10 kW, workpiece spindle 6.3 kW, CNC Siemens Sinumerik 840D, weight approx. 5 tons, dimensions (LxWxH) approx.: 2.4 x 2 x 2.3 m Kdsdpfx Abeym Rkfjvoi The machine is currently in storage. Images shown do not necessarily reflect its current condition while in storage.

Condition: used, CNC Universal Tool Grinding Machine SCHÜTTE Type BU 400 CNC 4 Machine - defective - without control system Machine not operational - electrically non-functional - without CNC controller Serial No.: Year of manufacture: 1990 4 axes (X, Y, Z, and R) Table clamping surface 1300 x 250 mm Distance between centers 700 mm Center height 155 mm Grinding length (X-axis) max. 400 mm Kjdpfxod Rmcmj Abvjdi Grinding width (Y-axis) max. 260 mm Grinding spindle speed max. 6000 rpm Grinding spindle drive 3 kW Power supply 380 Volt, 50 Hz, 25 Amp. - CNC control system removed Required space L x W x H 3800 x 2400 x 2300 mm Weight 3000 kg Machine not functional, CNC control is missing. Mechanically in good condition, ideal for control retrofit Suitable as a spare parts donor or for rebuild with new control system

Condition: used, Year of construction: 2016, Used machine Cross sanding machine Year of construction 2016 Product advantages Underneath perfectly lacquered, stained or oiled wood surfaces there is always a perfectly sanded surface! Felder sanding machines are characterized by solid construction, state-of-the-art machine technology and maximum productivity. The most important highlights at a glance: ? Sanding width 1350mm ? Sanding width 3-170mm ? Combined superfinishing unit ? Touch-screen control for work processes ? The Felder operating concept guarantees maximum process and work safety Your advantages at a glance: Time saving ? Motorized adjustment of the contact roller in the 1/100 mm range from the control panel ? Innovative unit arrangement for pre-sanding / fine sanding of veneered workpieces ? Brushing devices at the machine outlet ? Lacquer sanding against additional equipment ? comfort ? Fixed feed table height (machine head adjusts) ? Touch screen control with clear image display and program memory ? Machine data acquisition for sanding belt wear and much more. ? Tool-free handling when changing the sanding belt ? Large fold-down table extensions for the heaviest workpieces ? flexibility ? Units for calibration, fine sanding and lacquer sanding ? Variable feed speed up to 20 m/min by means of inverter Kdedpfx Abjw I Uv Usvsi Innovation ? Electronically segmented sanding pad with silicone technology for minimum air consumption ? Combined superfinishing unit incl. chevron sliding belt to compensate for oscillation marks ? quality ? Solid machine construction ? Durable machine components Basic equipment Control unit finish 1350 classic Control unit with 7" color touch screen 100 program memory locations Maintenance intervals Plain text error messages Ammeter for load monitoring Feed table fixed infeed height - fixed table, 900mm, electric height control of the units incl. fine adjustment from the control panel, V-speed infinitely variable from 2.8-20m/min. Adjustable via inverter from the control panel Manual protection and workpiece over-thickness protection Workpiece detection sensor with 25 sensors 55 mm segment width Endlessly manufactured belt conveyor with honeycomb structure Automatic feed carpet centering Cross sanding unit finish 1350C high gloss Segmented, electronic-pneumatic sanding pad ESC, segment width 25 mm, incl. quick-change system Chevron sliding belt between sanding pad Sanding belt for homogeneous sanding without oscillation marks Variable pressure control on the operating side Electro-pneumatic sanding belt oscillation Electronic sanding belt run-off protection 1 motor with 7.5 kW (10 hp) Star-delta start-up Cleaning fan with time control Cutting speed 12 m/sec Sanding belt 140 x 4560 mm Combined superfinishing unit 1350C: Rubberized, grooved contact roller with 85-90° Shore hardness and 142 mm diameter Electromot. Position-controlled grit compensation segment, electro-pneumatic sanding pad ESC, segment width 25 mm, incl. quick-change system Variable pressure control on the operating side Chevron sliding belt between sanding pad and sanding belt belt for homogeneous sanding without oscillation marks Mechanically pre-tensioned rubber pressure rollers Electro-pneumatic sanding belt oscillation Electronic sanding belt run-off protection

Condition: good (used), - All rubber rollers new or as good as new - Belt length 3000 mm - Year of manufacture - Price On request Kjdpfeulvipjx Abvsdi

Condition: good (used), Year of construction: 1994, completely overhauled in 1994 Table length: 450 mm Table width: 180 mm Execution: Hydraulic Maximum distance between table and spindle center: 400 mm Longitudinal travel (X-axis): 550 mm Cross travel (Y-axis): 200 mm Kodjw R Tl Hopfx Abvedi Automatic vertical feed Grinding wheel diameter: 200 mm Grinding wheel width: 25 mm Grinding wheel speeds: from 2800 rpm Digital display Weight: 1,000 kg

Condition: used, Year of construction: 2015, thread dia. 20 - 80 mm grinding length 3500 mm thread pitch . mm threading lenght min./max. 50/3500 mm centre height 400 mm workpiece length - max. 4000 mm control Siemens 840-Dsl feed speed u-axis 0 - 2500 mm/min feed speed w-axis 0 - 2500 mm/min feed speed b-axis 100 1/min total power requirement 45 kW weight of the machine ca. 24 t dimensions of the machine ca. 10,7 x 4,6 x 2,9 m Thread Grinding Machine / Profile Grinding Machine, suitable for: - the thread grinding of single and multi-start ball screws with gothic profiles and special profiles - Ø 20 to 80 mm with a grinding wheel Ø of 350 to 500 mm - length between the centers up to max. 4000 mm Equipment / Accessories: - grinding spindle: - capacity 14 kW - with a grinding wheel diameter range of 350-500 mm, cutting speeds between 20 and 75 m/s can be set. - grinding wheels: - diameter new 500 mm Kedpfx Abew Ed S Uevodi - diameter worn 350 mm - bore diameter 203.2 mm - shaped diamond roll: - diameter 121.3 mm - radius 0.5 mm - driver flange for workpiece diameter 15-70 mm - driver: - for 10-32 mm drive diameter on the workpiece - for 31-60 mm drive diameter on the workpiece - for 60-105 mm drive diameter on the workpiece

Condition: used, Year of construction: 2008, tip circle diameter 650/800 mm workpiece length - max. 1100 mm max. module 20 (25) mm min. module 0,5 mm control Siemens Sinumerik 840 D total connected load 62 kVA Kdjdpfsw Rrbyox Abvoi helical angle -45 / + 120 ° weight of the machine ca. 10 t

Condition: used, Year of construction: 1983, grinding length 8400 mm grinding width 1450 mm workpiece height 1250 mm Kdedpfjvr Hgvsx Abvsi surface area 8000 x 1250 mm table height over floor 920 mm distance between columns 1470 mm workpiece weight max. 59700 kg weight of the machine ca. 59,7 t dimensions of the machine ca. 22 x 5 x 5 m Adjustment ranges: -Crossbeam, vertical 1250 mm -Grinding support, horizontal 3100 mm Adjustment speeds: -Machine table (X-axis) infinitely variable 1-45 m/min Table creep speed 5 m/min -Grinding support, horizontal (Y-axis) Rapid traverse 3000 mm/min Feed, step 0.001-0.099 mm Feed rate, continuous 100-3000 mm/min Creep speed 18+1 mm/min Tip infeed 0.001-0.019 mm -Crossbeam (W-axis) Rapid traverse 410 mm/min Table drive: -Oil transmission, Type Iv4 -Cylinder-Ø 185 mm -Piston rod Ø 130 mm -Drive motor 22 kW

Condition: reconditioned (used), functionality: fully functional, Herminghausen SR2 Centerless Cylindrical Grinding Machine High-precision and conventional centerless cylindrical grinding machine. Suitable for grinding workpieces up to 40 mm in diameter. High machine and grinding stability due to a robust cast iron base and hydrodynamic segment jaw bearings. The low construction height provides excellent accessibility to all essential functions. Fast and simple conversion for different workpieces and materials. Kdjdpfsyvn Ubsx Abvei The machine has been disassembled, defective parts replaced, painted, and rebuilt. It is in very good mechanical and electrical condition, ready for immediate operation. Commissioning and training/instruction in machine operation and grinding technology are available.

Condition: good (used), Year of construction: 1994, Grinding length max. 650 mm Grinding width 390 (max. 450) mm Distance from spindle center to table 600 mm max. Workpiece weight 350 kg Grinding area 650 x 390 mm Travel paths: X-axis 840 mm Y-axis 500 mm Z-axis 410 mm Kdodpfx Ajvz A Stsbvji Total power requirement 15 kVA Machine weight approx. 3.0 t Space requirement approx. 4.0 x 3.0 x 2.5 m

Condition: like new (used), Year of construction: 2019, functionality: fully functional, Lizzini IG-FL in like-new condition: - Year of manufacture: 2019 - Siemens control Ksdpfx Ajyubc Uobvodi - 2 external grinding wheels - 1 internal grinding spindle - C-axis - controlled B-axis Suitable for non-cylindrical (Capto) grinding Distance between centers: 1000 mm Center height: 200 mm

Condition: used, Year of construction: 1998, Technical details: grinding diameter: 250 mm grinding length: 2710 mm max. module: min. module: total power requirement: 45 kW weight of the machine ca.: 15 t Kjdpfxsudf E As Abvsdi space required L x W X H: 7,1 x 4,7 x2,7 m max. wheel dia.: 450 mm Spindle drives Arena Siemens For Worm grinding we have not module, but pitch. Pitch is freely programmable from 0.001 to big value i.e. 500mm *

Condition: used, Year of construction: 1970, Technical details: grinding diameter max.: 400 mm Kedpfx Absypm Ifjvedi max. width of grinding wheel: 180 mm grinding range: 2-100 mm total power requirement: 24 kW weight of the machine ca.: 3,2 t Out of valve production *

Condition: ready for operation (used), Year of construction: 2013, total height: 1,900 mm, overall weight: 6,000 kg, controller manufacturer: FANUC, controller model: 21i-MB, General Data Measurements width 2400 mm Measurements depth 2000 mm Measurements height 1900 mm Machine weight 6000 kg Kdodpfjx D Nzcox Abvoi Control Unit Brand FANUC Model 21i-MB Additional Equipment Kraft & Bauer Fire extinguishing system, Type FB703S-UV3-TFM70°/KLA 6-S-MV / Knoll microfilter, Type Micro Pur 240 F / Streuli lifting station, Type SHSRT300-TL142/180 This TSCHUDIN ecoLine 400 centerless grinding machine was manufactured in 2013. It features a Fanuc 21i-MB control system, a grinding wheel with a max outer diameter of 400 mm, and a regulating wheel with a speed range of 0-265 rpm. Additional attachments include a Kraft & Bauer fire extinguishing system and a Knoll microfilter. Consider the opportunity to buy this TSCHUDIN ecoLine 400 centerless grinding machine. Contact us for more information about this machine. Application Types Grinding

Year of construction: 2012, condition: ready for operation (used), Main Drive Number of axis 3 Additional Equipment Sanding Unit/Sanding Belt: 120 x 2300 mm/Drive Power: 7.5 kW/Belt Tension: Pneumatic/Oscillation Range: 10 - 80 mm for optimum belt utilization and cooling/Removal Rate: Approx. 80 cm³/min Kdodpfxjx D Hkzj Abvsi This 3-axis KUHLMEYER Fasen Fix 4.1-1500 grinding machine was manufactured in 2012. It is designed for precision grinding applications, offering robust performance and reliability. If you are looking to get high-quality grinding capabilities, consider the KUHLMEYER Fasen Fix 4.1-1500 machine we have for sale. Contact us for more information. Application Types Grinding

Condition: ready for operation (used), Year of construction: 1985, A thread and worm grinding machine Reishauer AG is available. Grinding length: 450mm, clamping length: 700mm, max. grinding diameter: 200mm, max. pitch: 80mm, max. workpiece weight: 100g, max. lead angle: +/-25°, grinding wheel diameter: 275mm/350mm, speed: 1850rpm. Machine dimensions X/Y/Z: approx. 2600mm/1800mm/1600mm, weight: approx. 3400kg. Including oil centrifuge, hood, oil mist extraction and various accessories. The splash curtain is slightly hardened. Documentation available. An on site inspection is possible. Kdsdpfx Absx Dm Dnjvoi

Condition: used, Year of construction: 1982, grinding length: 600 mm, grinding width: 550 mm, total height: 2,490 mm, feed length X-axis: 600 mm, feed length Y-axis: 470 mm, feed length Z-axis: 600 mm, grinding height: 400 mm, grinding wheel diameter: 400 mm, table length: 1,100 mm, table load: 400 kg, table width: 450 mm, grinding wheel width: 100 mm, spindle speed (max.): 1,400 rpm, spindle speed (min.): 1,400 rpm, overall weight: 5,300 kg, travel distance X-axis: 600 mm, travel distance Y-axis: 470 mm, travel distance Z-axis: 600 mm, rotational speed (max.): 1,400 rpm, rotational speed (min.): 1,400 rpm, grinding spindle speed: 1,400 rpm, disc diameter: 400 mm, space requirement height: 2,490 mm, We are offering this used ELB-Schliff Oprimal 3 ND surface grinding machine, year of manufacture 1982. Maximum grinding length: 600 mm Maximum grinding width: 550 mm Working height with new grinding wheel: 400 mm Working height with worn grinding wheel: 600 mm Spindle taper ratio: 1:5 Manual vertical travel of grinding spindle: 600 mm Ksdpfx Aeyrn Sdjbvedi Manual horizontal travel of grinding spindle: 470 mm Swivel range grinding spindle: 1° Clamping table surface: 1100 x 450 mm Small table stroke: 80 mm Number of T-slots: 1 T-slot width: 16H7 mm Cross feed (table): 470 mm Longitudinal feed (table): 600 mm Table load capacity: 400 kg Outside diameter of grinding wheel: 400 mm Inside diameter of grinding wheel: 127 mm Grinding wheel thickness: 100 mm Recess 1 diameter: 190 mm Recess 1 thickness: 20 mm Recess 2 diameter: 190 mm Recess 2 thickness: 30 mm Machine height: 2.49 m Weight: 4700/5300 kg Direct spindle speed: 1400 min⁻¹ Continuous feed rate, grinding spindle carriage: 1.2 m/min Intermittent feed rate, grinding spindle carriage: 3–60 mm Hydraulic table feed speed: 1–30 m/min If you have any questions or require further information, please feel free to send us a message or call us.

Condition: used, Year of construction: 1989, Technical details: grinding length: 600 mm grinding width: 300 mm workpiece height: 550 mm Kdodpfx Ajynktiebvji base plate surface area: 1020x250 mm X-axis : 720 mm y-axis: 550 mm z-axis: 300 mm speeds:: 2900 rpm total power requirement: 8 kW weight of the machine ca.: 2,5 t

Condition: used, Year of construction: 1988, grinding diameter 250 mm grinding length 600 mm Kdedpfxsynnvbo Abvei max. dia. of grinding wheel 355 mm max. width of grinding wheel 50 mm peripheral speed 2.000 m/min In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Technical data and specifications are subject to change without notice and errors. Prior sale is reserved.

Condition: good (used), Year of construction: 2007, Kuehlmittelanlage 2.500l, Haftkraftregelung, halbautom. Wuchtsystem Schleiflaenge 3150 mm Schleifbreite 800 mm Werkstueckhoehe 650 mm Tischflaeche 3.150 x 600 mm Magnetspannplatte 3.000 x 600 mm Spindeldrehanzahl 1/min Kdodpfx Asdgk H Aebvei Schleifscheibenabmessung 450 x 100 x 127 mm Spindelleistung kW Gesamtleistungsbedarf 22 kW Maschinengewicht ca. t Raumbedarf ca. 11 x 3 x 2,4 m

Condition: used, Jung F 50 Surface Grinding Machine Condition: Used Technical Data Grinding Length: 500 mm Grinding Width: 200 mm Grinding Height to Spindle Center: 285 mm Table Size: 700 x 200 mm Spindle Speed: approx. 3000 rpm Kdedpfxeyuy Euo Abvei Grinding Wheel: 225 x 20 x 51 mm Feed: manual via handwheel Rapid Traverse Wheel Dressing Device Dimensions (L / W / H): approx. 1850 mm / 1300 mm / 1750 mm Weight: approx. 1400 kg

Condition: ready for operation (used), A conventional Schaudt external cylindrical grinding machine is available. Center distance: 1000mm, center height: 180mm, max. grinding diameter: 350mm, max. grinding length: 1000mm, plunge grinding length: 100mm, swivel range: 45°, machine dimensions X/Y/Z: approx. 3200mm/1700mm/1700mm, weight: approx. 4500kg. An on-site inspection is possible. Kjdpfxeyvixzs Abvodi
