Table Type Boring and Milling Machine

WOTAN Rapid 1 R/6 (CNC)

Condition: excellent (used), Year of construction: 1998, functionality: fully functional, travel distance X-axis: 1,200 mm, travel distance Y-axis: 660 mm, spindle speed (max.): 80,000 rpm, CNC GE FANUC 16 - M GRINDING HEAD WORKING AREA: Grinding spindle speeds, continuously variable -With electric motors: rpm 4,500 – 80,000 -With air turbines: up to 100,000 and 160,000 rpm Grinding head rotation speed, continuously variable -With planetary movements: rpm 5 - 300 -With CN / C axis: rpm 0 – 20 Z travel speed -With Z stroke control, continuous variation: mm/min 0.5 – 14,000 -Max stroke frequency: Hz 5 Grinding spindle sleeve -Z stroke length, continuously variable: 170 mm -Z stroke length (manual service): 180 mm -Diameter: 100 mm -Weight compensation: pneumatic Radial increment of the grinding wheel, NC / U: 5.5 mm Capacity Cylindrical grinding (with Ø 100 mm wheel) -Without intermediate plate: Ø 230 mm -With intermediate plate: Ø 360 mm -Grinding length Z: 125 mm WORK FIELD: X axis travel (table slide): 1,200 mm Y axis travel (grinding head): 660 mm In the W axis (movable crosspiece): 635 mm FORWARD SPEED: In the X and Y axis (CNC command) Processing speed: mm/min 0 – 2,000 Rapid feed: mm/min 4,000 In the W axis: mm/min 800 ODDS DISPLAY: X and Y axis: 0.0001 mm Z axis: 0.001 mm C axis: mm 0.001° U axis: 0.0001 mm Point of origin: your choice TABLE: Useful table surface: 1,320 x 860 mm Allowed table load: 800 kg T-slot width: 14 mm Number of T-slots: 7 Distance between T-slots: 100 mm Bdjdpfx Acsv Ay E Hszjk TOOL WAREHOUSE: No. of warehouse spaces: 8 Max grinding wheel diameter: 50 mm Maximum complete length of the grinding wheel: 135 mm Conical seat: HSK 25 Machine complete with: • Tank with paper filter • MSS Multi – Sensoric – System • Fire prevention system • Oil mist extractor (oil separator) • Instruction manuals and CE declaration

Condition: like new (used), Year of construction: 2010, functionality: fully functional, travel distance X-axis: 9,000 mm, travel distance Y-axis: 4,000 mm, travel distance Z-axis: 1,000 mm, CME TRAVELING COLUMN MILLING / BORING MACHINE Bedpfx Aeu R Rk Hjczsdk CME TECHNICAL FEATURES - VISIBLE IN OPERATION Brand: CME Model: MB 9000 Year: 2007 CNC: Siemens Sinumerik 840D X-axis: 9000 mm Y-axis (Vertical): 4000 mm Z-axis: 1000 mm W-axis (Ø 150 mm): 700 mm 2 rotary translation tables (linear travel: 2000 mm) 2500 x 2500 mm (25 TN) capacity Heidenhain optical scales on all axes Direct spindle 90-position tool change ZF range change Internal coolant Chip extractors

Condition: good (used), Year of construction: 2005, functionality: fully functional, travel distance X-axis: 1,200 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 700 mm, - milling head/spindle retrofit in the year 2022 for 28.000 Euro - CNC control Heidenhain iTNC530 - NC swivable milling head: B-axis full NC-axis A-axis horizontal/vertical - NC-rotary table (C-axis) - tool changer for 72 tools Bdedpfxorz I Hbe Aczok - chip conveyor - electronical hand wheel - coolant device (coolant through spindle device 20bar) Technische Daten / technical details: Verfahrweg X längs / X-Travel longitudinal 1200 mm Verfahrweg Y quer / Y-Travel cross 600 mm Verfahrweg Z vertikal / Z-Travel vertical 700 mm C-Achse Rundtisch / C-axis rotary table 360 ° B-Achse / B-axis +-90 ° Rundtischgröße / rotary table size 800 mm Werkzeugschaft / spindle taper SK40 Drehzahlbereich / spindle speed 0-6300 UpM /rpm Anzahl der Werkzeugplätze / tool places in ATC 72 fach Antriebsleistung Spindel 100/40%ED / drive capacity spindle 100/40%ED 17/25 kW Gewicht der Maschine ca. / weight 9000 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: ready for operation (used), Year of construction: 2008, operating hours: 9,965 h, - USED - 3-AXIS VERTICAL MACHINING CENTRE WITH ROTO-PALLET X-AXIS TRAVEL: 560 mm Y-AXIS TRAVEL: 400 mm Z-AXIS TRAVEL: 570 mm DISTANCE SPINDLE NOSE-TABLE: 210 - 780 mm RAPID FEEDS X-Y-Z: 40 - 40 - 32 m/min SPINDLE: 80-10000 rpm; 15-18,5 kW; ISO 40 - BT Bedpfxoq Nqkxe Aczjdk PALLET: N.2 ; 712X475 mm MAX ADMITTED LOAD: 300X2 Kg HIGH PRESSURE COOLANT: 15 Bar TOOL MAGAZINE: CHAIN-TYPE ; 32 POS MAX TOOL DIAMETER: 90(150) mm MAX TOOL LENGHT: 300 mm MAX TOOL WEIGHT: 8 Kg CONTROL UNIT: FANUC 21i - MB WEIGHT: 7600 Kg OVERALL DIMENSIONS: 3010 x 3450 x 3145 mm

Year of construction: 1989, condition: excellent (used), Coming up for sale: 1 used clamping / boring mill table Manufacturer: Skoda Bjdpfxog Sbbmj Aczjdk Type: E20OB22875 year: 1989 dimensions 2.000 x 2.000 mm part weight: up to 25t electr. adjustable mass: 10t

Condition: used, Tool holder shaft type:HSK-A 100 Tool holder shaft type:Wohlhaupter Tool holder shaft type:Feindrehwerkzeuge Ausdrehkopf / Precision Turning Bdsdpfog Nqlijx Aczek Big selection of Wohlhaupter HSK-A 100 Tool holders / precision turning tools / adapters /extenders etc. for sale Sales list with prices upon request.

Condition: used, x-travel:600 mm y-travel:fest mm z-travel:650 mm Bjdpfx Acocxxrgezsdk weight of the machine ca.:ges. 0,124 t dimensions of the machine ca.:0,7 x 1,0 x 1,05 m surface measuring, testing and evaluating unit for roughness and unevenness parameters with measuring post and feed device, incl. data logger with profile memory and full digital measured-value processing, fully programmable, evaluation according to different evaluation programs with single measuring run, reference-plane measuring on badly aligned, curved and tilted surfaces, automatic correction of height offset and tilt, measuring program with permanent storage and quick access, clearly arranged control elements, universal by plug-in program module for special functions, measuring post PST-Se, large black granite base plate with a 14 mm T-slot, table 650 x 450 mm, PRK feed device, adaptable precision scanning device for roughness, unevenness and form measuring, tracing length 1,5-60 mm, guidance accuracy 2 µm, tracing speed 0,5 and 0,1 m/s, automatically adjustable, return speed 1,5 m/s, standard - interval and terminal contact operation, extensive accessories, exchange calliper, calliper height-adjustable, calliper holder, calliper, etc.

Year of construction: 1974, condition: used, Pressure: 340 T Length of stroke: 200 mm Down table size: 100x800 mm Distance between up-down: - open 510mm (daylight) - closed 310mm Bjdpfxs Du Uwo Aczjdk New hydraulic and electric systems

Condition: used, HWACHEON HVT2025M (C-axis) / Model 2012 Table diameter (mm): Ø2,000 Maximum swing over bed (mm): Ø2,650 Maximum turning diameter (mm): Ø2,500 Maximum cutting height (mm): 1,100 Number of tools (pcs): 14 (7 turning, 7 milling) Bdsdpfxexb N U Re Aczsk Fanuc 31i 2,797 hours (operating time)

Condition: good (used), turning diameter over cross slide: 870 mm, spindle bore: 162 mm, turning length: 3,000 mm, turning diameter: 870 mm, center width: 3,000 mm, Distance between centres: 3000 mm Swing: 870 mm over bed, 560 mm over cross slide Weight between centers: 3.600 kg without steady 4.400 kg with 1 steady 5.600 kg with 2 steadies Bdjdpsw Sm U Dofx Aczjk Spindle speeds: 0 - 900 Rpm Spindle bore: 162 mm CNC Controller: Fagor Featured with: - Additional chuck at back end of main spindle (oilcountry) - 1 fixed steady Ø420 mm - 1 moving steady - 4-jaw chuck Ø800 mm - 3-jaw chuck Ø 400 mm - 10 Toolholders - Coolingpump/chiptray at back end - Machine documentation Country of origin: Spain Motor power: 30 kW Machine weight: 9.000 kg Machine LxWxH: 5,1 x 2,4 x 2,0 mtr.
