SHW Werkzeugmaschinen GmbH

Condition: used, Year of construction: 2013, machine/vehicle number: 5279, travel distance X-axis: 8,000 mm, travel distance Y-axis: 1,600 mm, travel distance Z-axis: 1,300 mm, spindle speed (max.): 4,000 rpm, spindle speed (min.): 22 rpm, Year of construction 2013 Control system: SIEMENS Sinumerik 840D pl Bsnow07Ua3S HSK 100-A tool holder TRAVEL horizontal-longitudinal X = 8,000 mm Vertical headstock slide Y = 1,600 mm Headstock horizontal-transverse Z = 1,300 mm FUNCTIONAL PROBE: m&h HSK 100 SIEMENS B-MPI HAND-HELD CONTROL UNIT TRAVELING WORK PLATFORM 3-SIDED SPRAY AND CHIP PROTECTION WALL CHIP CONVEYOR SPRAYING PLATE Sizes: Length: 10,000 mm Width: 2,500 mm WASHING GUN IN THE WORKROOM REINFORCED COOLANT SYSTEM Pump capacity: 32 l/min at max. 20 bar Coolant tank: 2000 l COLLISION MONITORING SYSTEM 2 CHANNEL pcs. 2 monitoring channels: - 1st collision monitoring orthogonal milling head (channel 1) - 2nd collision monitoring fork head (channel 2) PENDULUM MACHINING 3 WORK AREAS MILLING SURFACE INTERPOLATION (TRAORI, 3D tool radius compensation, spline interpolation) ROTATED AXIS COORDINATE SYSTEM 2 PICK-UP STATION For fork head, arranged on clamping plate Storage positions 10 Maximum tool weight kg 12.5 Maximum tool length mm 200 Maximum tool diameter mm 63 Maximum tool diameter when free mm 250 Neighboring position Tool holder HSK 6 AUTOMATIC TOOL CHANGER Number of tools in chain magazine 48 Maximum tool diameter with magazine filled to mm 125 Maximum tool diameter with mm 250 free adjacent positions Maximum tool length mm 500 - Maximum tool weight kg 25 Maximum tool load torque Nm 40 Tool holder HSK 100-A HEAD CHANGE MAGAZINE 1 pc.FORK HEAD WITH HIGH FREQUENCY SPINDLE AUTOMATIC FORK HEAD WITH INTEGRATED HIGH-FREQUENCY SPINDLE - High-frequency milling spindle: - Integrated high-frequency spindle - Tool holder HSK - A 63 DIN 69893 - Main drive power 20 kW at 100 % ED or 25 kW at 40 % ED - Speed range up to 20,000 1/min - Motor spindle bearing with permanent grease lubrication - Sealing air seal - Torque: 40 Nm at 100% ED, 50 Nm at 40% ED - Automatic tool clamping - Power transmission according to speed-performance diagram GMN HCS 170 - Technical data according to data sheet E 745.1467.00 UNIVERSAL MILLING HEAD IN ORTHOGONAL DESIGN - Liquid-cooled milling head - Cast construction made of GGG 60 - Milling head, automatically swivels 180 x 1 degree - The resulting positions can therefore not only be approached via the CNC control, but also programmed and processed - Repeat accuracy at the spindle nose ±0.002 mm, part accuracy thus ±3 sec - HSK 100-A tool holder - The milling spindle is equipped with a hydromechanical quick tool clamping system - Tool pull-in force: 45 kN - Internal coolant supply form A-D - External coolant supply via shower ring - Speed range 22- 4,000 1/min MAIN DRIVE by a frequency-controlled liquid-cooled AC motor with - 32 kW drive power at 100% duty cycle, 46 kW at 40% duty cycle. Direct power transmission WITHOUT gearbox, therefore no heating or wear of a gearbox. - 637 Nm torque at 100% ED, 875 Nm at 40% ED

Condition: used, Year of construction: 2006, Functionality: fully functional, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,300 mm, travel distance Z-axis: 1,300 mm, Basic machine with the travel paths: Buolj7Wt Machine column horizontal-longitudinal X = 2,000 mm Vertical headstock slide Y = 1,300 mm Headstock horizontal-transverse Z = 1,300 mm Machine stand In compact, torsion-resistant welded construction. Three hardened compact roller guides guarantee the transmission of high cutting performance with consistent quality. Protected against chips and cooling water with covers. Motor-driven CNC built-in rotary table - Clamping surface mm Ø 1,600 - 8 longitudinal grooves mm 22 H12 DIN 650 - 2 alignment grooves lengthwise and crosswise through center mm 22 H7 x 10 deep - T-slot distance mm 160 - Centering bush mm Ø 50 H7 x 20 deep - Speed max. 1/min 5 - Tilting moment clamped Nm 60,000 - Tangential torque clamped Nm 26,000 for circular milling Nm 5,000 - Table load (centric) max. kg 6,000 - Max. swing diameter of the workpiece 2300 mm 320 mm above the table top - Table top may show normal wear Automatic tool changer - Chain magazine for tools 48 - Max. tool diameter with filled magazine mm 125 - with free neighboring slots mm 250 - Max. tool length mm 400 - Max. tool weight kg 25 - Max. tool load torque Nm 40 - Tool holder SK 50 DIN 69871 - Horizontal spindle position for tool change - Fixed position coding Headstock with automatic universal milling head (UFK) consisting of - Milling head holder, automatically swiveling 360 x 1 degree - Milling head, automatically swiveling 180 x 1 degree - Tool holder SK 50 DIN 69871 - Tool pull-in force: 20 kN - Main drive power provided by a frequency-controlled, liquid-cooled AC motor with 30 kW at 100% ED or 41 kW at 40% ED - at 36 to max. 4,000 rpm Digital individual feed drives for contour-accurate work via AC motors with constant torque, feed and rapid traverse range in all 3 axes infinitely variable from 2- 30,000 mm/min. Acceleration behavior of the individual axes 2 m/s² CNC control Heidenhain iTNC 530 Reinforced coolant device For coolant supply via nozzle ring, switchable to internal coolant supply for tools with steep taper DIN 69871 AD, incl. compact paper belt filter system for cleaning the coolant. Adjustable pressure-quantity control via bypass valve, two-stage switchable via CNC control. Pump capacity: 32 1/min at max. 20 bar Coolant tank, capacity 500 l Chip conveyor For travel path X = approx. mm 2000 Feed width approx. mm 350 Discharge height approx. mm 1,250 External electronic handwheel (HR 410) Switchable to 3 axes (with corresponding machine guidance up to 5 axes, not for uni-head axes) 1-channel collision monitoring system Monitors machine and conditional tool collision

Condition: ready for operation (used), Table top Ø2,500 mm with M 56 transport threads. 14 T-slots 22 H12 DIN 650. spacing 160 mm, symmetrically arranged S9V0J 1 flat groove 22 H7x10 deep lengthwise through centre Ø100 H7x20 deep 1 flat keyway 22 H7x10 deep crosswise through centre Ø100 H7x20 deep Version with INA YRT axial/radial bearing Permissible transport load 20,000 kg (horizontal position) Speed 4/min (maximum 6.25 = 3.00/480) Axial run-out accuracy of table top 0.020 mm (Ø1.000) Concentricity of the centre centring 0.015 mm Partial accuracy ±3 angular seconds through direct path measurement in the table axis Incremental rotary encoder HEIDENHAIN ROD 880 C (reference distance-coded) Measuring system with coupling is included in the scope of delivery! Hydraulic power unit for table clamping (63 bar) with control and top pressure valve mounted on the rotary table base body with unhindered access to the fixators! Two pressure switches for monitoring the table clamping (clamped/released) Permissible tilting moment 13,000 Nm (clamped) Permissible tangential torque 4,000 Nm (clamped) SIEMENS feed motor 1FT6105-8AF71-4AL1 with 31 Nm, 3,000/min (Mo/100=50 Nm) Version with brake, smooth shaft (SHW 0287.0222) Length 416 mm from flange Existing output torque with 1FT6105 is max. 6,000 Nm (50x480x0.25) SIEMENS feed motor is included in delivery! Cables for motor are routed directly to the control unit. All electrical cables are wired to a central terminal box with cover for attachments to protect against coolant and chips!
