Blue Diamond Machine Tools

Condition: refurbished (used), Straight Bed Machine Distance between centers: 50" Swing over bed: 15" Swing over cross-slide: 9" Spindle speeds: 25 to 2000 (16) Spindle bore: 2" clear Iaslev I Ddqshccqlor Full length screw cutting Chuck mounting: D16 Tailstock taper: No. 4 morse 3 and 4 jaw chuck and face plate Coolant 2 axis DRO Main motor: 7.5 hp Machine in good condition Approx weight: 1.5 tons Approx dimensions: 7 'x 4' x 5' Quick change tool post and 3 holders

Condition: used, Year of construction: 2001, YEAR – 2001 CONTROL – FANUC 18i-M TABLE SIZE – 840 x 420 mm TRAVLERS – X: 600 mm Y: 410 mm Z: 520 mm SPINDLE – BT 40 SPINDLE SPEEDS – 0-8000 rpm SPINDLE MOTOR – 11.5 Kw RAPID FEED RATED – X/Y AXES 40m/min RAPID FEED RATE – Z AXES 20m/min MAXIMUM TABLE LOAD – 500 KG Iajlhccqsv I A U Iolor ATC – 22 STATIONS

Condition: used, New 2000 Axis X – 600 mm Axis Y – 410 mm Ijlsv I A Uuehccqloar Axis Z – 520 mm Rotary table (4th axis) Heidenhain TNC 410P Table length – 840 mm Table width – 420 mm Max. part weight 500 kg Number of tool pockets 30 Spindle taper BT 40 Max. spindle speed 6000 rpm Spindle motor power 7.5 kW

Condition: used, Model: 6 PT 25-120 Ijlhccqov Aybuelear Serial No: P 36589 Year: 1980 SPECIFICATION Spindle speeds: 9.5 to 1560rpm Spindle taper: No 6 Morse Taper Spindle travel: 16” Feeds: 0.132mm to 3.21mm Working Area Base: 1360mm x 2700mm Column Diameter: 26" Main Motor 15HP Metric and Imperial Power Locking Safety brake Coolant

Condition: used, Total power requirement 12 kW weight of the machine ca. 4,1 t dimensions of the machine ca. 3,1 x 5,9 m saw band length 6300 mm capacity 90 degrees: round 410 mm capacity 90 degrees: flat 620 x 400 mm capacity 45 degrees: flat 450 x 400 mm cutting range 30° flat 300 x 300 mm cutting speed Islhccqjv Aya Rjlear 20 - 140 m/min feeding length 3000 mm Control unit NC Coolant Oil mist and not white water

Condition: used, YOM 2004 Ijlhccqjv Ax Uyjlsar Mazatrol PC Fusion 640 M Axis X 1660 mm Axis Y 510 mm Axis Z 510 mm Table length 2000 mm Table width 510 mm Max. part weight 1000 kg Number of tool pockets 30 Spindle taper CAT 40 Max. spindle speed 10000 rpm Spindle motor power 18.5 kW

Condition: used, 355mm Swing Over Bed 225mm Swing Over Cross Slide 1250mm Between Centres 52mm Spindle Bore 40-2200rpm Spindle Speeds hp Motor Equipment Proto TraK VL Control 3 Jaw Chuck Quick Change Toolpost and holders Coolant Iaolhccqov Ax S Solor Machine Light Interlocked Chuck Guard Swing over Door

Condition: used, grinding length: 1,100 mm, grinding width: 550 mm, overall weight: 5,700 kg, 500 x 1050mm Magnetic Chuck, 550mm Cross Traverse. 1100mm Long Traverese. 10HP Spindle Motor. Distance from Table to spindle Centre = 600mm. Iaslhsu D H Stsccqlor Coolant tank Weight 5700KG.

Condition: refurbished (used), Straight Bed Machine Distance between centers: 30" Swing over bed: 15" Swing over cross-slide: 9" Ijlhccqot Ifpqelear Spindle speeds: 25 to 2000 (16) Spindle bore: 2" clear Full length screw cutting Chuck mounting: D16 Tailstock taper: No. 4 morse New 3 Jaw Coolant New 2 axis DRO Main motor: 7.5 hp Machine fully refurbished (Reground slideways) Chuck guard TBC Approx weight: 1.5 tons Approx dimensions: 7 'x 4' x 5' Quick change tool post and 3 holders

Condition: excellent (used), Year of construction: 2011, New 2011 Axis X 785 mm Axis Y 470 mm Axis Z 530 mm Iaolhett Ivbsccqlsr CNC PROTOTRAK PMX Table length 900 mm Table width 500 mm Max. part weight 460 kg Number of tool pockets 16 Spindle taper BT40 Max. spindle speed 8000 rpm Spindle motor power 11 kW ----- Length x width x height 2870.0 × 2246.0 × 2743.0 Weight 3410 kg

Condition: good (used), Jones & Shipman 540 surface grinder Iajlhcerpi I Ejcqlor Power raise & lower C/w a 460 x 150 mm close pole magnet, Dust extraction Calibration : TBC execution.

Condition: excellent (used), Specification Spindle Speeds 9.5 to 1560 (18) Spindle taper No 5 morse Spindle travel 410mm Feeds 0.066 to 0.963 Max spindle height spindle to base 70” Column dia Graduations metric Power Locking Equipment Safety brake Box table Coolant Electrics 440 V 3 phase 50cycles Approx Dims 9’ x 5’ x 11’6” and weighs approx. 6 tons Iaolhccorpiy Teqler

Condition: excellent (used), New 2008 Swing over bed - 600 (Ø 23.62) Diameter × length - Ø 300 × 600 (Ø 11.81 × 23.62) Max. diameter - Ø 380 (Ø 14.96) Max. travel range of Z/X axis - 600 / 240 (23.62 / 9.44); Z-axis: FANUC 2.8 kW (4 HP) /3000 rpm; X-axis: FANUC 2.8 kW (4 HP) /3000 rpm Diameter of spindle bore/Draw bar bore - STD: Ø 77 / Ø 52 (Ø 3.03 / Ø 2.04); OPT: Ø 86 / Ø 77 (Ø 3.38 / Ø 3.03) Spindle speed - STD: 8” chuck 3500 rpm; OPT: 8” chuck 4500 rpm, 10” chuck 3500 rpm Chuck diameter - STD: Ø 8” ; OPT: Ø 10” Hydraulic Tailstock – travel 465 (18.3) MT. No.4 VDI Tool stations - OPT: 8 STD: 10 Coolant Chip conveyor Power requirement - 208-220 volts / 100 Amps / 3 Phases / 60 Cycles Floor area (L × W × H) - 4080 ×1675 × 1842 (160.62 × 65.94 × 72.51) Isljrfx Tnehccqloar Gross weight (approx.) - 5200 kg (11440 Ibs)

Condition: excellent (used), New 2006 Brother CNC-B00 Control Pallet Change time 3.4 seconds Pallet Size 600 x 425mm X axis 550mm Islhjrfxr Ueccqlear Y axis 400mm Z axis 415mm Spindle speed 12000rpm 40 Station ATC BT30

Condition: refurbished (used), Gap Bed machine Between centers: 60” Swing over bed: 22" Spindle speeds: 18 - 1400RPM Spindle bore: 3 1/2" Diameter 90mm Chuck mounting: D1 - 11 Tailstock taper: No 5 Morse Iajlhccqsq N Ay Ajlor Tool Post: Quick Change 4 holders & Keys New 3 Jaw Chuck Coolant New 2 Axis DRO System Chuck guard TBC 6-month warranty

Year of construction: 2012, Condition: excellent (used), Type of CNC HURCO ULTIMAX Turning length 483 mm Iaolhccqopiay Sjlsr Turning Ø 256 mm Ø above the bed 548.6 mm Ø above transversing slide 320 mm Length between centers 584.2 mm X-axis 203.2 mm Z-axis 508 mm Max workpiece weight kg Spindle bore 61 mm Number of turrets 1 Number of tools on turret 10 Number of rotating tools 10 Turning speed 4800 rpm Spindle motor power 11.2 kW Tailstock

Condition: excellent (used), Serial No. BO 94880 Capacity: 18" x 6" Wheel size: 8" Spindle speed: 3000 max Imperial calibration Opti-Dress Coolant or dust Lovo Light Machine in excellent condition Machine weight: 1 tons Machine Dimensions: 5' x 4' x 6' Ijlhccqophpfpoloar

Condition: good (used), Gap Bed machine 28” Between centers: 80” Swing over bed: 17" Swing over the saddle 10 ½” Spindle speeds: 20 - 2000RPM Vari speed Spindle bore: 3 ½” Diameter Chuck mounting: D1 - 8 Tailstock taper: No 6 Morse Execution: imperial Metric & Imperial screw cutting Tool Post: Quick Change 4 holders Used 3 and 4 Jaw Chucks Fixed steady Coolant, swarf tray and chuck guard Ijlhenr Nl Seccqljar

Year of construction: 2014, Condition: excellent (used), Machine travel (X-axis) 1020mm, (y axis) 540mm (z axis) 510mm X Axis Rapid Traverse 36 m/min Y Axis Rapid Traverse 36 m/min Z Axis Rapid Traverse 30 m/min Max. Spindle Speed 12000 r/min Ijlhccqjlz Nxhsloar Max. Spindle Power 18.5 kW Max. Spindle Torque 353.2 N·m Table Length 12000 mm Table Width 540 mm Max. Table Weight 800 kg No. of tool station 30 Machine Length 2412mm, Width 3110mm and Height 3143mm Weight 6500kg Spindle nose: MAS BT 40 Feed range 1 - 15000 mm/min Fanuc Doosan I Series control RenishawTouch Probe 4th axis ready

Year of construction: 2000, Condition: excellent (used), Workpiece size : 560mm – 615mm x 560mm Iaslhcoiwfpdscqlsr Blade size : L 6600mm x W 54mm x T 1.6mm Blade speed (M/Min) : 15 -80 weight 4500kg Machine weight : 4500kg Machine dimensions : L 3500mm x W 2200mm x H 2000mm

Year of construction: 2001, Condition: excellent (used), DOM: 2001 X - 548.6 mm, Y - 408.9 mm, Z - 459.7 mm Power - 5.6 kW RPM - 15000 rpm ATC - 30 Table - 599.4 mm x 378.5 mm Iaolhccogx Aafeqlor Taper - BT40 Control - CNC (Yasnac J300) Machine weight: 4 tons Machine Dimensions: 7' x 8' x 9'
