AMADA EMZ 3610 NT

AMADA EMZ 3610 NT

Condition: ready for operation (used), Year of construction: 2011, punching force: 31 t, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,525 mm, overall weight: 21,000 kg, table load: 160 kg, controller manufacturer: FANUC, number of axes: 2, This AMADA EMZ 3610 NT CNC punching machine was manufactured in 2011. It features a Fanuc control system, a punching force of 300kN, and a working area of 2500 x 1525 mm, extendable to 5000 x 1525 mm with repositioning. The machine can handle sheet thicknesses up to 4.5 mm and supports a maximum table load of 160 kg. If you are looking to get high-quality punching capabilities, consider the AMADA EMZ 3610 NT machine we have for sale. Contact us for more information. • Working area with repositioning: 5000 x 1525 mm • Max. sheet thickness: 4,5 mm (mild steel) • Feed rate X/Y: 100 / 80 m/min (128 m/min simultaneous) • Positioning tolerance: +/- 0,1 mm • Z-turret stations: 45 • AutoIndex stations: 4 (2 x B, 2 x C) • Turret feed rate: 30 1/min • Max. number of hits: 1000/min • Machine frame: Bridge frame • Punching drive: Servo-electric Twin Drive • Drives (turret + table): AC-Servo motors • Clamps: Pneumatical • Electrical connection: 400V / 50Hz • Electrical consumption: 1 kW – 7 kW • Air consumption (machine): 250 l/min • Air consumption (Air Jet Vakuum): 250 l/min Additional equipment • Loading unit: Loader L III 300 • Sheet size min.: 1000 x 300 mm Blodpfxsx D Hpqo Al Isg • Sheet size max.: 3000 x 1500 mm • Material thickness: 0,5 – 8,0 mm • Max. loading weight: 300 kg • Max. stack height: 300 mm • Max. pallet weight: 4000 kg (2x2000 kg) • Max. feed rate (traverse): 70 m/min • Number of suction cups: 34 pieces • Double sheet control: Yes, with sheet thickness detector • Air consumption: 510 l/min, 6 bar inlet pressure • Electrical connection: 400V • Unloading unit with Parts Remover: PR 3 UL 300 P • Part size min./max.: 150 x 150 mm / 2500 x 1000 mm • Sheet thickness: 0,5 – 3,0 mm (4 mm for EM-Serie) • Max. part weight: 50 kg • Storage table size: 3400 x 1400 mm • Max. part size for unloading clamps: 3000 x 1500 mm • Max. stack height skeleton table: 450 mm • Max. weight skeleton table: 2000 kg • Max. stack height storage table: 450 mm • Max. weight storage table: 4000 kg • Max. feed rate X-/Y-direction: 180 / 90 m/min • Air consumption: 1000 l/min, 6 bar inlet pressure • Electrical connection: 400V

Condition: excellent (used), Year of construction: 2012, functionality: fully functional, punching force: 18 t, working range: 30,001,500 mm, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,600 mm, Very well maintained and fully serviced used Large format Trumpf 3000 cnc punch press for sale Manufacturer TRUMPF Type TruPunch 3000 (S11) Blodpoxrnggofx Al Ieg Year 11/2012 Working area 3000 x 1500 mm - without reposition Working range on cross-side (X-axes) 3000 mm Working range along (Y-axes) 1600 mm Large throat 1600 Complete with multi tool capability Type S11 Video available upon request

Year of construction: 2010, condition: ready for operation (used), A CNC turret punching machine Amada and an automatic loading and unloading unit LKI Käldman (Amada) are available. 1) CNC turret punching machine Amada EMZ3610, year of manufacture: 2010, pressing force: 300kN, travel X/Y: 2500mm/1525mm, travel X/Y with repositioning: 5000mm/1525mm, max. material thickness: 4.5mm, max. table load: 160kg. Traversing speed X/Y: 100m/80m/min, axis speed: 128m/min, positioning accuracy: +/-0.1mm. Turret stations 45, auto-index stations: 2xB/2xC, turret speed: 30rpm, stroke rate: 1000 strokes/min, machine weight: approx. 21000kg. 2) Loading and unloading system LKI Käldman (Amada) MP Sheetcat 3015, year of manufacture: 2017, min. sheet dimensions X/Y: 1000mm/300mm, max. sheet dimensions X/Y: 3050mm/1525mm, sheet thickness: 0.8mm-6mm, max. sheet weight per pallet: 3000kg, suction cups: 34, machine dimensions X/Y/Z: approx. 8400mm/3600mm/3100mm. Documentation available. On-site inspection is possible. Blsdpev Rp Tcofx Al Ieg

Year of construction: 2003, condition: reconditioned (used), Stock - No. 2651 1 used underwater pelletizing unit, partially overhauled in 2023 Throughput up to approx. 450 kg/h depending on the material, consisting of: Type BKG ( Nordson ) Start-up valve with hydraulic station Granulator type A300 including Blsdpfxoiyyf Io Al Iog die-plate and cutter bar, drive 4.4 kW by-pass system TVE 1000 ED pellet-dryer drive 4 kW incl. Agglomerate catcher Tempered water system with Water box 200 liters, installed heating capacity 9 kW Water pump 2.2 kW with 15³/h heat exchanger Control unit - NEW Further UWP pelletizing units are available ex workshop in Wuppertal-Germany ( as Gala, BKG Nordson, Econ ) Available from the Wuppertal warehouse: complete compounding, pelletizing extrusion lines, with single-screw or twin-screw extruder.

Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, The positions of the rotating tools are: T01-02-03-04 / T22-23 / T34-35 - equipped with Iemca Boss 332E/32 new in 2006 - lot of collets / guide bushes - MSC-501 Control - the machine has always worked with oil. Blodpfx Alswpu Ets Isg

Condition: used, TECHNICAL DETAILS - Number of axes : 4 MILLING SPINDLE - Tool holder type : BT40 BIG PLUS - Spindle power : 26 [kW] - Spindle speeds : 15000 [rpm] LINEAR AXES - Travels on X/Y/Z axes : 560/640/640 [mm] - Rapid traverses rates (X/Y/Z) : 60 [m/min] B ROTARY AXIS - Travel : 360 [°] - Indexing precision : 0.001 [°] TOOL CHANGER - Auto. Tool Changer type : Bras chargeur - Tool magazine capacity : 60 PALLET CHANGER - Pallet changing device type : Rotopalette - Pallet size : 400X400 [mm] - Pallets number : 2 - Maximum weight upon pallet : 400 [kg] - Maximum workpiece diameter : 630 [mm] - Maximum workpiece height : 900 [mm] Bljdpfx Aleuhbv Sj Isg POWER SUPPLY - Supply voltage : 400 [V] WEIGHT & DIMENSIONS - Machine floor space : 4100X2300 [mm] - Machine height : 2720 [mm] - Machine weight : 11000 [kg] MACHINE HOURS - Number of working hours : 3700 [h] EQUIPMENT - CNC : Fanuc 31 iB Interface : Ethernet / RS232 / USB / PCMCIA - Electronic handwheel - Linear scales - Rigid tapping - 3 colors status lamp - Coolant tank * with high-pressure pump : 25 [bars] * Coolant through spindle * With cabin washing - Chips conveyor : Arrière - Spindle cooling unit - Tool probe - Workpiece probe : Renishaw OMP60

Condition: excellent (used), Year of construction: 2012, Model Amada HFE M2 220t 4m, 8 axis Press Brake Year 2012 Tonnage 220 tonnes Max. Bend Length 4280 mm Blsdsv S U Izjpfx Al Isg Stroke Length 200 mm Approach Speed 1 - 100 mm/sec Bending Speed 1 - 10 mm/sec Return Speed 1 - 100 mm/sec Oil Capacity 195L Motor Power Weight 17450 Kg Dimensions Machine Length 5070 mm Machine Depth 2075 mm Machine Height 3085 mm Distance Between Side Frames 3760mm Beam width 180 mm Table height 960 mm Open Height 470 mm Throat Depth 420 mm

Condition: excellent (used), Year of construction: 2017, operating hours: 144 h, functionality: fully functional, machine/vehicle number: 694355, overall weight: 235 kg, load capacity: 16 kg, arm reach: 1,610 mm, This is a KUKA KR 16-2 R1610 industrial robot Year of manufacture 2017 We are also happy to offer you this robot overhauled! The robot includes the following options: BoardPackage EthernetKRL LoadDataDetermination Profinet KRC-Nexxt Bodpfx Alot N Szpo Islg RemoteService SafeOperation UserTech

Condition: good (used), Year of construction: 1994, functionality: fully functional, feed length X-axis: 1,050 mm, feed length Y-axis: 360 mm, feed length Z-axis: 500 mm, travel distance X-axis: 1,050 mm, travel distance Y-axis: 360 mm, travel distance Z-axis: 500 mm, overall weight: 3,000 kg, Equipment: documentation/manual, Tiger FO 135 universal milling machine Description of the machine The machine was purchased new in 1994 and has only been in operation for a few hours. The milling machine is fully functional. The axis movements are smooth and the guides are in good condition. good condition. These have an automatic lubrication system. Bljdpfxorqwbis Al Iog The table is in good condition and shows hardly any signs of wear. The machine also has a digital readout for the 3 axes, which makes it possible to work with cutter compensation and recurring measurement machining. Operating instructions are included with both the machine and the digital indicator. Technical specifications - Table dimensions 1,400 x 340 mm, 4 T-slots - Automatic traverse path: ➢ Longitudinal X 1,050 mm ➢ Transverse Y 360 mm ➢ Vertical Z 500 mm - Fixing the spindle cone: ➢ Vertical axis ISO 40, automatic locking ➢ Horizontal axis ISO 40, manual locking - Spindle speed range: ➢ Vertical axis 33 ÷ 1,560 rpm, 12 speeds ➢ Horizontal axis 35 ÷ 1,550 rpm, 12 speeds - Installed power: ➢ 5 kW vertical spindle motor ➢ 7.5 kW horizontal spindle motor ➢ Direct current motor 15 Nm - Variable power supplies Continuous speed 0 ÷ 1,500 mm/min - Fast feed ➢ Lengthwise and crosswise 3,000 mm/min Vertical 1,500 mm/min - Universal head with manual shaft lowering of 80 mm - Automatic lubrication with pump - Low-voltage electrical controls on the pushbutton panel of the side arm - Star/delta start - Magnetic thermal protection from Siemens - Net weight 3,000 kg - Machine dimensions (for transportation) ➢ Width 2,300 mm ➢ Depth 2,900 mm ➢ Height 2,400 mm Accessories - Counter supports for cutting shaft - Cutting shaft ø32 mm Tiger FO 135 universal milling machine Description The machine was purchased new in 1994 and has only had a few hours of operation. The milling machine is fully functional. Axis movements are smooth and the guides are in good condition. These have an automatic lubrication system. The table is in good condition and shows hardly any signs of wear. The machine also has a DRO for the 3 axes, which offers the possibility of working with milling compensation and recurring measurement processing. Both the machine and the DRO come with operating instructions. Technical specifications - Table dimensions 1,400 x 340 mm, 4 T-slots - Automatic travel: ➢ Longitudinal X 1,050 mm ➢ Transverse Y 360 mm ➢ Vertical Z 500 mm - Fixing the spindle cone: ➢ Vertical axis ISO 40, automatic locking ➢ Horizontal axis ISO 40, manual locking - Spindle speed range: ➢ Vertical axis 33 ÷ 1,560 rpm, 12 speeds Horizontal axis 35 ÷ 1,550 rpm, 12 speeds - Installed services: ➢ 5 kW vertical spindle motor ➢ 7.5 kW horizontal spindle motor ➢ DC motor 15 Nm - Variable power supplies Continuous speed 0 ÷ 1,500 mm/min - Fast forward ➢ Longitudinal and transverse 3,000 mm/min ➢ vertical 1,500 mm/min - Universal head with manual shaft lowering of 80 mm - Automatic lubrication with pump - Low voltage electrical controls on side arm push button panel - Star/delta start - Magnetic thermal protection from Siemens - Net weight 3,000 kg - Dimensions of the machine (for transport) Width 2,300 mm ➢ Depth 2,900 mm ➢ Height 2,400 mm Accesories - Counter supports for cutting shaft - Cutting shaft ø32 mm

Condition: excellent (used), Year of construction: 2017, operating hours: 6,473 h, functionality: fully functional, machine/vehicle number: 12780000173, DMG MORI NHX 5000 Bljdpoyhwpwsfx Al Ijg About the Machine: High-precision and reliable machine. Available immediately. Technical Data: - Control: Siemens 840D - Travel X-, Y-, Z-Axis: 730/730/880 mm - C-Axis Travel: 360° - Rotary Table Clamping Surface: 500x500 mm - Spindle Speed: 20-15,000 rpm - Tool Interface: SK40 - Tool Magazine with 60 positions - Pallet changer with 2 stations - Automation-ready Equipment: - Internal cooling, 70 bar with belt filter system - Work area rinsing - BLUM measuring probe - Rinse gun - Chip conveyor - Signal light - Handheld control device Inspection / test under power on site can be arranged by appointment. We are happy to offer you transport, installation, and commissioning at your location. Everything from a single source: We at Baumgärtner CNC GmbH specialize in: - Service - Maintenance - Overhauling - Automation for DMG machines and other renowned manufacturers. We accompany you—from the machine purchase, through transport and installation, all the way to commissioning and ongoing maintenance or repair work. You can rely on us.
