Machining center

Emmegi Phantomatic M3

Year of construction: 2014, condition: used, Machining center with 3 CNC-controlled axes and automatic tool rotation to three fixed positions, enabling 3-sided machining of the workpiece. For processing bars or pieces made of aluminum, PVC and general lightweight metal alloys and steel up to a thickness of 2 mm. Max. travel path X-axis: 3,000 mm Rjdpfxsygkhdj Agyjn Max. travel range Y-axis: 274 mm Max. travel range Z-axis: 390 mm Spindle speed: 20,000 RPM. 2 tool changers with 4 slots on the left and 4 slots on the right Windows operating system Pneumatic material stop on the right and left side Automatic belt tensioner displacement Only 3710 spindle hours Cam Plus Accessories as per photo Weight: approx. 1600 kg Operating Instructions

Condition: ready for operation (used), Year of construction: 2020, operating hours: 1,621 h, functionality: fully functional, machine/vehicle number: C124963, travel distance X-axis: 3,000 mm, travel distance Y-axis: 274 mm, travel distance Z-axis: 390 mm, spindle speed (max.): 20,000 rpm, number of slots in tool magazine: 9, Machining center with only 1,621 spindle hours! TECHNICAL DETAILS Travel distances X-axis (longitudinal): 3,000 mm Y-axis (cross): 274 mm Z-axis (vertical): 390 mm Automatic positioning: -90° | 0 | +90° Positioning speeds X-axis: 56 m/min Y-axis: 22 m/min Z-axis: 22 m/min Spindle Maximum power in S1: 4 kW Maximum speed: 20,000 rpm Tool holder: HSK-50F Tool positions: 9 MACHINE DETAILS Weight: 1,700 kg Operating hours Spindle hours: 1,621 h Operating hours: 3,440 h Redpfxjxwnhzs Agyen EQUIPMENT - Milling cutter head 80 mm - Collets: 5 mm: 1 piece 9 mm: 1 piece 2.5 mm: 1 piece 8 mm: 3 pieces 16 mm: 1 piece 10 mm: 3 pieces 7 mm: 1 piece 12 mm: 1 piece 6-5 mm: 2 pieces 4 mm: 1 piece Note: The machine will be available from 01/12/2025.
