Console milling machine

Fritz Heckert FW 315/S

Condition: new, Year of construction: 2026, Through our many years of experience in service, we have decided to develop and produce our own milling machines. The FPS 500M is a conventional milling machine perfect for training and production. Through the Heidenhain Positip 8016 active digital display positioning and for example the creation and approach of a bolt hole circle is possible. Control Heidenhain Positip 8016 Active - Digital display Speed 0 - 3000 rpm geometrically stepped direct gear with 16 gear steps for maximum torque / milling power Feed rate 0 to 500 mm/min, infinitely variable rapid traverse 1,5 m/min quill extendable quill, vertical 80 mm SK40 optional: horizontal work spindle or horizontal quill (approx. 100mm extendable) Pulling system: hydraulic tightening system - DIN 69872 optional: DIN 2080 Axes X/Y/Z 500/400/400 mm Table Rigid angular table 800x480mm Equipment - Vertical and horizontal spindle - Milling head manually tiltable +/- 90 °. - Travelling chip tray - Machine light Gisdpfxeh Su Ipe Aadsn - Central lubrication - Z-axis bellows Options - universal table - rotary table - Shaper head - dividing head - counterholder - etc. Further technical data can be found in the attached data sheet.

Condition: used, Year of construction: 2001, DAEWOO - DOOSAN PUMA 400 LB CNC LATHE MAKE DAEWOO - DOOSAN, MADE IN KOREA MODEL PUMA 400 LB Gsdpfx Ajxp Nfxjadein YEAR 2001 CONTROL FANUC 18 iT CHUCK SIZE 450.0 mm SWING OVER THE BED 700.0 mm SWING OVER SADDLE 480.0 mm MAX TURNING DIA. 380.0 mm BETWEEN CENTRES 2100.0 mm DRAW TUBE DIA. 117.5 mm TRAVELS: X AXIS: 362.0 mm Z AXIS: 2155.0 mm TURRET 10 STATIONS SPINDLE SPEED 20 - 2,000 rpm SPINDLE BORE 132.00 mm SPINDLE NOSE A2 - 11 BEARING DIA. 180.0 mm TURRET TOOL HEIGHT 25.0 mm TURRET BAR DIA. 50.0 mm TURRET INDEXING TIME 0.25 sec FEEDRATE RAPID TRAVERSE X: 16,000 mm/min Z: 18,000 mm/min FEEDRATE CUTTING FEED X , Z: 0,001 ~ 500.000 TAILSTOCK QUILL DIA. 120.0 mm TAILSTOCK QUILL BORE TAPER MT#6 TAILSTOCK QUILL TRAVEL 120.0 mm PLUS HYDRAULIC STEADY TOOL SETTING ARM SWARF CONVEYOR TURRET TOOLING FULL SET OF MANUALS

Condition: used, Year of construction: 2001, Deckel Maho DMC 60U Hi-dyn Machining Center Condition: Used Year of manufacture: 2001 Operating hours: 56,376 Spindle hours: 26,451 Technical specifications: Travel X/Y/Z: 600 / 700 / 600 mm Motor power: 15 kW (40% duty cycle); 10 kW (100% duty cycle) Spindle speed: 18,000 rpm Tool holder: SK 40 Magazine positions SK 40: 60 Equipment: - 3D path control MillPlus IT Gjdpju Rnlujfx Aadjin - Horizontal double-arm tool changer - Automatic swivel milling head - Rotating safety glass - NC rotary table with pallet carrier - Rotary pallet changer - 2 pallets 630 x 500 mm - Universal milling head with controlled B axis SK 40 (only in combination with SK 40 motor spindle) - Tool holder for HSK-A63 according to DIN 69893 - Electronic handwheel - Operating mode 4 extended manual intervention - Rinse gun with pump - Tool breakage control SK 40 mechanical version, range: 63...310 mm / +/- 3 mm - Intermittent chip conveyor operation - Internal coolant supply switchable from 40 bar to 80 bar

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 650 mm, total length: 6,500 mm, table length: 2,000 mm, table width: 1,000 mm, total width: 3,600 mm, spindle speed (max.): 12,000 rpm, total height: 4,000 mm, overall weight: 14,000 kg, Equipment: rotational speed infinitely variable, Milling machine retrofitted in 2024 CNC TNC 530 HEIDENHAIN Distance between columns 1250 mm HSK 63 ELECTROMANDRINO spindle 12.000 rpm Gjdpfx Aeul Txzsadein INTEGRAL fairing

Year of construction: 1969, condition: ready for operation (used), Max. grinding depth: 80mm, distance spindle table: 145mm, spindle bore: 28mm, connected load: 7kW, length: 2100mm, width: 1400mm, height: 950mm, weight: 1.6t, with documentation, an inspection is possible. Gsdpfeqzkdmex Aadsin

Condition: good (used), Universal milling head, milling adapter, milling extension, angle milling head -Manufacturer: Waldrich -Spare part: comes from a milling machine -Milling head: swiveling -quill stroke: 150 mm -Spindle mount: SK50 -Motor: 11 kW 1470 rpm Gisdpfefxlf Ajx Aaden -Spindle speed: 25 - 560 rpm -Transport dimensions: 1550/600/H460 mm -Weight: 636 kg

Condition: excellent (used), Year of construction: 1994, functionality: fully functional, travel distance X-axis: 10,000 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 2,500 mm, Equipment: documentation/manual, Zayer mobile column milling machine, horizontal stroke 10000, vertical stroke 2500, slide stroke 1250, spindle 1800n, tool magazine 30 positions, year 1994, Heidenhain 415b control with 15" LCD display replaced last year, cone grinding October 2024 (iso50), always serviced. Currently in use. Gijdpswhd Aljfx Aadsn

Condition: good (used), Year of construction: 1963, Vertical lathe JUNGENTHAL Type: DK 1400 built in 1963 with 1 axis digital readout. Gisdevi Hryjpfx Aadjn turning diameter max : 1400 mm face plate : 1250 mm Automatic turret head spindle speed : 3,5-180 rpm feeds : 0,063 - 3,15 mm/rev rapid traverse : 1800 mm/min Further data see data sheet Machine documentation available . Dimensions : Length 4 m Width 2,4 m Height 3 m Weight 16t Good general condition .

Condition: used, Technical details: turning diameter over bed: 350 mm turning diameter over support: 200 mm turning length: 560 mm centre height: 170 mm spindle bore: Ø 32 mm range of revolution per miute: 36...1.800 / 8 step U/min range of feed in x - axis: längs: 0,02..0,8 m/min range of feed in y - axis: plan: 0,01..0,4 m/min tailstock quill taper MT: MK 4 tailstock quill adjustment:: 140 mm total power requirement: 5,5 kW weight of the machine ca.: 2,0 t dimension machine xH: 2,1x 1,1 x 1,4 m -Working stroke longitudinal support=580mm; plan support=170mm; top support 130mm; -Workpiece support via 3-jaw chuck Niles Ø 160mm, speed 2,800 rpm. -Tool holder quick change steel holder Multifix. Gedpevadd Ijfx Aadoin Equipment: Cooling water pump 4 pieces machine feet Copying device *

Condition: used, Year of construction: 2004, MORI SEIKI MT 2000 SZ TURN MILL CENTRE MAKE MORI SEIKI MODEL MT 2000 YEAR 2004 CONTROL MSG 501 SWING OVER CROSS SLIDE 599.5 mm SWING 749.0 mm CHUCK SIZE 250.0 mm DISTANCE BETWEEN CENTRE 1280.0 mm MAX. CUTTING DIAMETER 548.6 mm MAX. CUTTING LENGTH 1018.0 mm BAR CAPACITY 63.5 mm C AXIS 0.001 DEGREE SPINDLE RANGE 4500 rpm SPINDLE MOTOR 20 hp Gedpfx Aouq Iwpeadjin SPINDLE NOSE A2-6 SUB SPINDLE BAR CAPACITY 43.18 mm SUB SPINDLE MOTOR 10 hp SUB SPINDLE SPEED 6000 RPM TOOL CHANGE CAPACITY 60 STATION TURRET 12 STATIONS TRAVEL B AXIS +/- 120 DEGREE Y AXIS +/- 78.7 MM PLUS CNC BARFEED PART CONVAYOR TOOL SETTING PROBE Y AXIS HIGH PRESSURE SWARF CONVAYOR FULL SET OF MANUALS GOOD RANGE TOOLING
