GF Machining Solutions FORM 300

Condition: as good as new (ex-display), Year of construction: 2015, operating hours: 985 h, travel distance X-axis: 905 mm, travel distance Y-axis: 705 mm, travel distance Z-axis: 455 mm, workpiece weight (max.): 3,000 kg, EDM314MF30 - SLM (second-live-machine) General overhaul Travel paths X x Y x Z 900x705x455mm Machine table 1150x850mm Container size 1200x900mm Distance table/chuck 260/710mm Electrode weight 50/500kg Workpiece weight max. 3000kg Overall dimensions of machine 2210x3450x3250mm Power supply 400V/DS/50/60Hz Container height 750mm Equipment: MF30 user interface Movable control panel Touch screen Lift speed 15000mm/min (high jump) Eroding generator 60A Integrated cooling unit Itodpfx Ahohfaizs Uor Cartridge filter system Tool changer 8-fold C-axis with direct measurement, resolution 0.0001 degrees C-axis as positioning - rotation - and erosion axis C-axis 100 rpm. Automatic container tracking Filling, filter and rinsing pump Transport IB Training 12 month warranty

Condition: new, Experience unparalleled precision and performance with the surface grinding machines from PERFECT. Now even supported by BAFA! Our machines offer grinding lengths from 500mm to 4000mm and grinding widths from 150-1000mm available, also available as controlled variants. Partially available from stock! Discover our extensive range of special accessories that make your surface grinding machine even more versatile. Whether for complex workpieces or demanding tasks, our machines always deliver the best results for you. Trust in our many years of experience and let us optimize your machining processes together. Invest in quality and precision - contact us today! Our selection of conventional or controlled machines (further models available on request): Model FSM 2550 FSM 3060 FSM 4080 Grinding Length 500 mm 600 mm 800 mm Grinding Width 250 mm 300 mm 400 mm Distance Table Surface/Spindle Center 500 (Option 600) mm 500 (Option 600) mm 550 (Option 650) mm Itjdpfxsdzk T Rs Ah Usr Table Size 250×500 mm 300×600 mm 400×800 mm Max. Table Load 250 kg 300 kg 400 kg Model FS-NC-50AHR FS-NC-60AHR FS-NC-70AHR Grinding Length 1020/1520/2020 mm Grinding Width 500 mm 600 mm 700 mm Distance Spindle Center to Table 600 (Option 800, 1000) mm Table Clamping Surface 500×1000/500×1500/500×2000 mm 600×1000/600×1500/600×2000 mm 700×1000/700×1500/700×2000 mm Table Load 800/1000/1000 kg 1200/1400/1400 kg 1500/1700/1700 kg ACCESSORIES: Grinding wheel, Grinding wheel flange, Grinding wheel dresser, Grinding wheel puller, Assembly elements, Machine tool, Balancing mandrel, Machine light, Hydraulic unit with cooling fan, Technical documentation in German, CE design CURRENT STOCK MACHINES (see pictures): New machines with grinding area 250x500mm, 300x600mm, 400x800mm, 700 x 1520mm Overhauled machines with grinding area 250x500mm, 300x600mm, 400x800mm Furthermore, we have access to various used machines with large grinding areas. Contact us! For more technical data, description, and accessories, please refer to the PDF file below. By the way, in addition to inexpensive new machines and tested used ones, you can expect even more from us: • Consultation and solutions at your location • Organization of the transport of your machine to your factory • Installation, assembly, commissioning, and ready-to-use handover, and more.

Condition: used, Year of construction: 2015, TAKISAWA TS4000YS year 2015 CNC control FANUC 32i-MODEL B Max. turning diameter 315 [mm] Max. swing over bed 600 [mm] Max. Turning length 735 [mm] Stroke X axis 267 [mm] Stroke Z axis 840 [mm] Stroke Y axis -50 [mm] / +70 [mm] Stroke A axis 780 [mm] Rapid traverse rate X axis 30000 [mm/min] Rapid traverse rate Z axis 30000 [mm/min] Rapid traverse rate Y axis 10000 [mm/min] Rapid traverse rate A axis 30000 [mm/min] Spindle nose A2-8" Max. bar diameter 82 [mm] Spindle throughbore 94 [mm] Max. spindle speed 4200 [rpm] Spindle power 22 [kW] Counter spindle nose F140 Counter spindle throughbore 53 [mm] Max. counter spindle speed 6000 [rpm] Counter spindle power 11 [kW] Max. tool holder cross-section 25 [mm] Number of tool stations 15 Number of tool stations driven 15 Max. speed driven tools 6000 [rpm] Lubrication tank capacity 370 [l] Total power required 37 [kVA] Supply voltage 400 [V] Iedpfx Aewq Sf Toh Uetr Chip conveyor with machine 5 live tool holders Weight 6700 [Kg]

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, travel distance X-axis: 1,500 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 610 mm, nominal power (apparent): 37 kVA, torque: 236 Nm, controller manufacturer: Heidenhain iTNC530, controller model: iTNC530, table width: 700 mm, table length: 1,700 mm, table load: 700 kg, rotational speed (max.): 12,000 rpm, overall weight: 9,000 kg, spindle speed (max.): 12,000 rpm, operating hours of spindle: 16,580 h, spindle motor power: 37 W, number of spindles: 1, number of slots in tool magazine: 48, Equipment: chip conveyor, documentation/manual, Heidenhain iTNC530 3-axis CNC machining center Stroke x 1500 mm Stroke Y 700 mm Stroke Z 610 mm Table dimensions: 1700x700mm SK40 tool holder Magazine 48 tools Rapid feed 36m/min Table load: 700 kg Spindle center coolant 20 bar Chip conveyor Crank Iodpfx Ahevz Tyus Uotr

Condition: used, TECHNICAL DETAILS - Table dimensions : 700 x 480 [mm] - Dielectric capacity : 600 [l] TRAVELS - Travels on X/Y/Z axes : 350 x 250 x 250 [mm] - Travels on U/V axes : +/- 90 [mm] - Max. taper : [°/mm] PART - Max. part dimensions : 900 x 680 x 250 [mm] - Max. part weight : 400 [kg] - Finishing quality : 0.125 [μm] WIRE GUIDE - Wire diameter : 0.15 - 0.30 [mm] - Coil weight : 5 - 8 [kg] - Speed : 30 - 270 [mm/sec] POWER SUPPLY - Supply voltage : 380 [V] Itedpfx Ahsuhq Rlj Uor - Total installed power : 11 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2500 x 2500 [mm] - Machine height : 2200 [mm] - Machine weight : 2890 [kg] MACHINE HOURS - Number of working hours : 1266 [h] EQUIPMENT - CNC : Charmilles Pentium III CPU - Remote control - Cooling unit

Condition: good (used), Year of construction: 1997, Parts shown by hand not come. Ijdpfx Ajpy Errjh Uetr

Condition: excellent (used), Year of construction: 2023, Electrode changer: X-Axis Travel (mm): X-Axis Travel (mm): X-Axis Travel (mm): CNC Type: Worktank length: Worktank width: Worktank height: Table length: Table width: Max. workpiece length: Max. workpiece width: Max. workpiece height: Max. workpiece weight (kg): Max. machining current (A): Length x width x height: Weight (kg): Itedpewnfcgsfx Ah Uor Worked power hours: The technical data and illustrations are not binding. They are not warranted characteristics and are subject to change.

Condition: like new (used), Year of construction: 2020, operating hours: 1,500 h, functionality: fully functional, USED Akira Seiki 1600XP Fanuc 0iMF Open Fronted Vertical Machining Centre with Fanuc Ex Stock - Subject to Prior Sale. YOM 2020, Machine with Very Low Hours Usage. Approx 1500 Hours  12,000 RPM Spindle with Refrigeration System  36 Station Arm Type ATC  Full Splash Guard  Fully Integrated Detron GXA-255h 4th Axis Nc Rotary Table with SR255H Tailstock Support Unit  Chip Conveyor & Chip Bin (Scraper Type)  Chip Flushing System Including Coolant Wash Gun  Through Spindle Coolant System - 35 Bars with Filter  Fanuc Memory Extension - 2 Mb  Fanuc 10.4 “ Screen with Manual Guide-I  Coolant Tank Capacity - 640 Litres  THK Heavy Duty Linear Guideways  Manual Pulse Generator  3 Colour Signal Lamp  Automatic Lubrication System  Rigid Tapping & Helical Interpolation Function TABLE Iedpeu A U Nkofx Ah Ustr Working Surface 1,750 X 800 MM Tee Slots 18 x 125 x 6.0 MM Spindle Nose to Table 100 ~ 915 MM Spindle Centre to Column 865 MM Table Load Capacity 2,300 KGS TRAVEL X-Axis Travel 1,630 MM Y-Axis Travel 850 MM Z-Axis Travel 815 MM SPINDLE Spindle Nose Taper BT-40 Spindle Speed - Max 12,000 RPM FEED Rapid Traverse (X & Y-Axis) 33 M / MIN Rapid Traverse (Z-Axis) 25 M / MIN Cutting Feedrates - Max 12 M / MIN ACCURACIES Positioning 0.01 MM Repeatability + - 0.003 MM ATC Tool Storage Capacity ARM TYPE - 36 STATIONS Maximum Tool Weight 7.0 KGS Tool Diameter - Max 75 MM Tool Length - Max 250 MM Tool Shank BT-40 Tool Exchange Time 2.2 SEC MOTOR Spindle Drive Motor (FANUC) 18.5 KW POWER SUPPLY Voltage 415V / 3PH / 50HZ Power Requirement 30.0 KVA MACHINE DIMENSIONS Machine Floor Space Requirement 4,820 x 3,576 MM Machine Weight 12,600 KG

Condition: like new (used), Year of construction: 2006, Technical data Manufacturer: KENT Model: VK 1600MC Year : 2.006 Serial number: 2200139 Control unit: FANUC 18 iMD Location: Tabaza (Asturias - Spain) Table Dimensions Working Surface: 1700 x 810 mm. T-Slot ( Size x Number x Center distance): 22 x 5 x 160 mm. Max. Table Load: 2.000 kg. Travel X axis traverse: 1600 mm. Y axis traverse: 815 mm. Z axis traverse: 815 mm. Distance from Spindle nose to table: 220 ~ 1035 mm. Distance from Spindle center to Column: 865 mm. Spindle Taper: BT50 Spindle speed (Gear type): 30 – 6000 rpm. ZF GEAR BOX (2 ranges): Yes Max. Tool Weight: 15 kg. Max. Tool Size (Diameter x Length): 125 x 300 mm. ATC Max. tool Ø x L: Ø125 x L250 Max. tool weight: 15 kg. Number of tools: 32 Feedrates Cutting Feed Rate: 1 – 10.000 mm./min. Rapid Traverse: 18/18/18 mm./min. Motor Iodpfxoqwyzfj Ah Uetr Spindle Drive Motor (30 Min Rating): 15/18,5 Kw. X,Y,Z Axis Drive Motor: X: 5.5 | Y: 5.5 | Z:5.5 Coolant Pump CTS: One air & two coolants – 4 bar. + 6 bar / 20 bar Weight and dimensions Machine weight: 16.150 kg Machine dimens: 4.488 x 3.448 x 3.250 mm. Base space: 5.000 x 3.500 mm.

Year of construction: 2022, operating hours: 108 h, condition: refurbished (used), machine/vehicle number: SN2120, EDM312MF30-SLM (second-live machine) Technical data: Adjustment travel: 450x300x300mm workpiece clamping table 820x400mm tank size 900x520mm filling height 300mm distance table/electrode holder 150/450mm workpiece weight max. 800Kg Dielectric max. 700l dimensions WxDxH 2700x1800x2350mm Machine weight 2500kg Mains connection 3/N/PE 400/230 50Hz power consumption 6,7 KVA Equipment: Color: new painting light grey + telegrey New control cabinet New control APC910/2 (win10) User interface MF30 V 2.8 New drives B&R with Endat interface Screen touch screen Ijdpfxohtrdye Ah Uotr Generator exopuls+ 60A Rev.4 WZW 5-fold Touch protection operable via push button Linear scales in all axes X, Y, Z (Fagor) cartridge filter 2 pieces Cooling unit Termogamma Complete new machine installation New ball screw, bearing, coupling Maintenance unit with digital pressure switch Valve island Co² extinguishing system C-axis Hirschmann 50/min., holding brake Refurbished Manual control bar with enabling button Lowering tank automatic tracking chuck Erowa IST, Hirschmann, 3R Warranty 12 months Transport commissioning on site training
