Machining center

KDT Machinery KN-3710DE

Condition: used, Year of construction: 1987, Technical details: x-travel: 700 mm y-travel: 500 mm z-travel: 600 mm table swivelling +/-: A-Achse: 20° / 60° Grad table rotating: B-Achse: 360° Grad control: Maho 432 (3-D Bahnsteuerung) Max. Milling-capacity: ST: 60 und GG: 22 mm tool changer with: 24 Plätze number of spindle speeds: 20 - 6300 U/min. max. table load: 200 kg spindle taper MT: ISO 40 (hydr. Spannung) spindle head swivable left - right: 90° (manuell) ° Gbedpeu Idbyjfx Aayet quill stroke: 80 mm feed range: X/Z: 1 - 3000 und Y: 1 - 4000 und B: 0,1 - 3000°/min. mm/min rapid traverse:: X/Z: 10 und Y: 8 und B: 20 U/min. m/min control voltage: 110/220 V total power requirement: ca. 20 kVA Weight approx.: 5,5 t dimension machine xH: 3,0 x 2,4 x 2,25 m space requirements of the machine approx.: 5,2 x 5,0 x H: 2,3 m NC rotary table Ø 520 mm with A and B axes Adjustable three-phase motor with 4-stage reduction gear Working spindle can be swiveled out for horizontal spindle Equipment: -manual control unit -coolant device -machine ilumination *

Condition: good (used), Year of construction: 2019, Throughfeed CNC machine FELDER GROUP FORMAT4 CREATOR 950 (year 2019) with glue and dowel insertion, 12 kW HSK-F63 milling unit, integrated Ø 120 mm saw, dowel unit, and feed speeds up to 90 m/min represents a compact solution for precise milling, drilling, and panel sizing of wood. Key Technical Advantages - Occupies only 5 m² of space Ideal for workshops with limited space. - Easy clamping and programming Fast and intuitive operation, even for less experienced users. - Compact, powerful, and fast Perfect for smaller workshops seeking professional results. Advanced Features - Glue and dowel insertion unit - 12 kW milling unit (up to 24,000 rpm) - Automatic workpiece length measurement - Automatic tool changer (linear tool magazine with 4 positions) - Drilling from all five sides - Groove cutting with integrated saw blade - Processing from all four sides of the workpiece - Door panel machining Drive Unit - Spindle: HSK F63 - Number of axes: 3 Travel Distances - X-axis travel: 3000 mm - Y-axis travel: 950 mm - Z-axis travel: 80 mm Tools - Maximum tool weight: 7.5 kg Worktable - Table load capacity: 130 kg Additional Equipment Gbodpfx Ajwyvgaoayot - Online remote service support package - Automatic central lubrication PRICE EXCLUDES VAT.

Condition: excellent (used), Year of construction: 2001, Technical specifications: 5-axis machine: X, Y, Z, C, A Gbodpfx Aozl S Uzeayet Travel ranges (X/Y/Z): 500 / 450 / 400 mm Travel range A-axis: +108 / -5° Travel range C-axis: 360° CNC control: HEIDENHAIN Table diameter: 500 mm Table adjustable in degrees Maximum workpiece weight: 200 kg Number of positions in the tool changer: 30 Spindle speed: 20 – 30,000 rpm Motor power: 15 kW Dimensions (length x width x height): approx. 3700 x 2850 x 2800 mm Machine weight: approx. 5.8 tons Additional equipment: Chip conveyor Various tools Condition: Very good condition, little used Operating hours: 2,700 Machine is still in operation The seller is not liable for typing or data transmission errors. The machine's appearance, technology, and wear correspond to its age; used machines are sold without any warranty.

Condition: good (used), Year of construction: 2000,  Printing technologies installed: • 3 x Flexographic printing units • 3 x Screen printing units • Gravure capability (cylinder formats available) Maximum mechanical speed: 150 m/min Maximum web width: 417 mm Minimum web width: 166 mm Maximum print width: 407 mm Substrate thickness range: approx. 0.008 – 0.18 mm  Repeat ranges Flexo: 228.6 mm (Z72) up to 609.6 mm (Z192) Screen: 269.875 mm (Z85) up to 533.4 mm (Z168) Gravure: 304.8 mm (Z96) up to 609.6 mm (Z192)  Die Cutting Section Flat die cutting: Die cutting width: 407 mm - Repeat: 254 mm (Z80) up to 609.6 mm (Z192) Rotary die cutting capability installed. Unwind / Rewind Section Unwinder: • Martin nonstop unwinder • Core diameters: 76 / 152 mm Gbsdpfx Ajylypusayet • Maximum unwind diameter: 1000 mm • Maximum roll weight: approx. 485 kg Rewinder system installed. Electrical Data Nominal current: 500 A Connected load: 275 kW General Condition The machine is designed for web label production and represents a robust hybrid combination press with flexo and screen printing capability. The press is available for inspection by appointment.

Condition: good (used), Year of construction: 2000, working width: 900 mm, total width: 1,800 mm, total length: 12,000 mm, total height: 3,550 mm, overall weight: 8,000 kg, For sale: Gjdpfx Aaexnb Iisysbt Konig combi bread line 8/7/6/4 rows Includes: - TRO 240 hopper with oiling system - Konig Industrie Rex head machine Model A - Spreading conveyors - Proofing cabinet model: KGV V L Type: (900/500) K8 - V0 - (W) - R - RR900 - SCHN7/B - MO(WB) 1000 - STb8/7/4 - Stamping unit - Long roller - Seed station - Drop tables (8/7/6/4) (4 different drop tables with various belts included) - Storage trolley for the drop tables - Storage trolley for the flour sprinklers - Spare parts - Control cabinet - All documents and electrical diagrams Weight range: 20 to 30 grams up to 110 grams Output: 18,000 / 24,000 pcs per hour Working width: 900 mm New drum in the Industrie Rex Many spare parts such as spreading belts, etc. It is possible to inspect the line on site. We can carefully load the line onto a truck/container. Do you have comments or questions? Please feel free to contact us. Best regards, Leo Holland

Condition: used, CNC machining center BIESSE Rover C 6.50 CONF.2, year 2007 Working area: approx. 140 × 460 cm Machine dimensions: 300 × 650 cm Weight: approx. 6,100 kg Two working heads Tool magazine: 22 positions Vertical drilling spindles: 28 pcs Horizontal drilling spindles: 12 pcs Price negotiable, available immediately. Price is without VAT. Gbodpfow Rpd Sjx Aayjt

Condition: used, Year of construction: 2018, Startech cn MAIN FEATURES FLEXIBLE AND CUSTOMIZED PRODUCTION COMBINED WITH SPEED AND PRECISION DRILLING FROM ABOVE WITH REFERENCE TO THE TOP OF THE PLATE ALLOWS ABSOLUTELY PRECISION MACHINING NUMERICAL CONTROL WITH 7" COLOR SCREEN: SIMPLE AND INTUITIVE TECHNICAL DATA Startech CN AXES Max. workpiece dimensions X-Y-Z mm 3050 x 800 x 50 Min. workpiece dimensions X-Y-Z mm 300 x 90 x 10 Drilling/slotting work area mm 0 x 800/0 x 800 X-axis stroke mm 750 Max. travel speed of the X-Y axes m / min 25 DRILLING UNIT Vertical spindles number 7 (4X-4Y one of them common) Horizontal spindles (along the Y axis) Number 2 (1+1) Horizontal spindles (along the X axis) Number 1 Fixed groove saw (direction) X Diameter of the groove saw mm 100 Max. thickness of the groove saw mm 5 Motor power kW (HP) 1.5 (2) Spindle speed rpm 3350 Speed of the groove saw rpm 4300 INSTALLATION Power supply V (Hz) 380 / 400 (50 / 60) Installed power KVA 4.5 Compressed air demand bar 6 Compressed air consumption Nl/cycle 90 Extraction demand m3 / h 1200 Extraction air speed m / sec 20 Extraction nozzle diameter mm 120 GENERAL CHARACTERISTICS Universal CNC drilling machine with work table with fixed gantry and movable workpiece for performing the following machining operations: - Vertical drilling on the panel surface - Horizontal drilling on all four sides of the workpiece - Groove Milling with integrated groove saw in the "X" direction. Self-supporting structure. Machine frame made of tubular steel to provide a large base for the work table. The structure is positioned on three self-leveling feet. The electrical control cabinet is integrated into the machine frame. "Easy Motion" central Bakelite support table: - an MDF sector for through-hole drilling, automatically pivoting for horizontal drilling - an infeed roller that facilitates panel loading - a rear roller conveyor that facilitates panel sliding - left and right stops - a central aligner with manual adjustment. The left and right stops are required to drill the two opposite sides of the panel horizontally in the "X" direction. Panel positioning along the X axis is achieved by means of suction cups. Unit support. This is a gantry structure made of tubular steel. The main machining unit is installed on the gantry. F10L drilling unit includes: - 7 independent vertical spindles - Drill chuck D10 mm - Distance between spindles 32 mm - 2 horizontal drilling heads, 1 in X direction with a single drill, 1 double drilling head in Y direction (1 + 1 drill chuck D10 mm) - Speed 3350 rpm - 1 integrated sawing unit in X (max. diameter 100 mm) - Saw blade speed 4300 rpm - Motor power 1.5 kW - Vertical pneumatic travel per spindle 70 mm - Horizontal pneumatic travel of the drilling unit Positioning of the workpiece and drive of the machining unit A CNC-controlled suction cup clamps the workpiece and positions it sequentially under the machining unit during machining. The movement in X and Y axis is carried out on THK guides with transmission on reinforced toothed Movement in Z axis is carried out pneumatically on "ball-bushing" guides with positioning on stop adjustable via the positioning of the working units is carried out via technology and drives with -CONTROL The control was specially developed for use Gbjdpjvwbp Aofx Aayjt

Condition: used, Year of construction: 2008, · Working area X-Y-Z: 3,660 x 1,550 x 130 mm · Travel length X-Y: 4,200 x 2,000 mm Description of the units and accessories (base) The structure of the base body is a monolithic construction made of thick-walled steel. It is stiffened by welded triangular plates across the entire machine bed, making it extremely stable. The triangular shape used for load-bearing parts, with a large base, is the secret to ensuring lasting precision and stability. The machine layout allows the user an optimal workflow despite minimal space requirements. The base body constructed in this way therefore offers the machining unit a balanced and secure base with particularly good load distribution. The mobile unit carrier in gantry design is made of a solid monoblock. It is positioned in the X direction on prismatically ground guides via recirculating ball slides. The work unit is mounted on this mobile unit carrier on prismatic, ground guides and a recirculating ball slide. Axis movement: The drive system in the Y and Z axes is provided by ground, high-precision recirculating ball screws. The X-axis is driven by a backlash-free, preloaded precision rack and pinion drive. This ensures balanced load distribution during the positioning process. This characteristic is important for ensuring balanced movement even in more complex tasks. The various axes are driven by brushless three-phase servo motors/brushless AC motors. These offer excellent positioning speeds thanks to very short ramp times. Furthermore, the measuring system is fully integrated into these motors. These properties make this type of drive completely maintenance-free. · Rapid traverse in X: 40 m/min · Rapid traverse in Y: 60 m/min · Rapid traverse in Z: 22.5 m/min Vacuum system (basic) · Vacuum pump: 100 cbm/h · Power: 2.5 kW · Max. negative pressure (connection) 0.9 bar Control / control cabinet · Office PC or industrial PC (see options) · Basic NC control: ESA-GV KVARA 6.0 · Cable remote control with the most important functions ELECTRIC/ELECTRONIC CNC CONTROL Universal is equipped with a powerful NC control. The integrated office PC gives the NC control an unparalleled level of familiarity: the software runs on Windows XP and allows quick and easy programming, which is easy to learn even for inexperienced users. The system is open and allows the connection of CD-ROM drives, audio cards, barcode readers, modems, printers, scanning systems, etc. Furthermore, the installation of all network systems, as well as all commercially available CAD programs, is possible. To reduce space, the control cabinet is located under the machine table, and the operator works at a separate terminal on casters, which can be freely positioned. XILOG PROGRAMMING SYSTEM Software features: - Import of DXF files - Import of ASCII files - User interface in the operator's native language (available for languages I - GB - F - D - E) - Linear and circular interpolation in three axes, linear in space, spiral in the selected plane - Assisted programming - Calculator for direct transfer of calculated data - Graphic and syntax aids for drilling and milling operations - Parametric programming to perform the same panel machining on different Gjdpfxovvi Rfj Aayjbt

Condition: good (used), Year of construction: 2016, spindle speed (max.): 3,500 rpm, overall weight: 6,000 kg, Equipment: documentation/manual, rotational speed infinitely variable, Main parameters: Controller: FANUC 0iD/31iA Chuck.: SAMCHULLY 10" Spindle bore: 86mm With jacket tube.:78mm Turret head: 12 main positions 12 secondary positions, BMT65 connection, Programmable hydraulic tailstock: MT5 Main spindle power: 22kW S1max=3500 1/min Living tool power: 5.5kw S2max=5000 1/min X movement range: 260mm Gjdpfswtg Injx Aaysbt Z axis movement range: 830mm Y axis movement range: + - 52mm (104mm) C axis Maximum turning length: L=760 Largest turning diameter: D=376mm Fast travel speed: 30m/min Automatic tool measurement with probe arm Weight: 6000 kg

Condition: used, Year of construction: 2016, Angular panel saw with automatic pre-loading and twin pusher system for optimised cutting Osi Plus Numerical Control Os Labelling labelling machine with on-board graphic labelling with part drawings Label printing management software Optiplanning Cutting Optimizer Cutting length mm 4500 Cutting width mm 2200 Blade projection 95 mm Motorized rollers for lateral loading on lifting table 4500 x 2200 mm. The translation speed is 10.8 m\min (50hz) - 13.1 m\min (60hz) Automatic recognition of the lost panel (martyr panel) based on the thickness specified in the machine data Low battery stop Automatic side loading buffer. Includes: perimeter nets, double photocell, push-button panel, predisposition electric for the two motorized pre-rollers and the amplification of 4 rollers in place of the fork passages in the pre- intermediate roller conveyor Pre-loading side roller conveyor dim 3800 x 2200 mm with motorized rollers (height from the ground 325 mm) Gedpfxouc Idxe Aaysbt Inertial conveyor for conveying longitudinal trimmings for angular systems 4500 mm (total length 7295 mm) 3000 mm extension to the inertial conveyor to also convey transverse trimmings Long chute for manual conveying of cross-cut trimmings to the centralized inertial conveyor 2050 x 850 mm air curtain discharge table with wheels at the front Air generator up to 6 floors with air curtain MULTIPUSHER 2.4 system with automatic lubrication Additional mobile lateral aligner on the transverse plane. The presence of this device allows to reduce from 1830 to 1220 mm is the minimum length of the panels that must be sent for cross-sectioning. Automatic blade shaft bending detection device for angular systems (longitudinal and transversal) consisting of a sensor that detects the deflection directly on the blade shaft and a device that detects the revolutions blade directly on the spindle. Remote cycle start button panel Automatic panel loading via rear lifting table Automatic double aligner with pneumatic cylinders Additional movable lateral aligner on the transverse plane Main blade, max diameter mm, KW 15 Scoring blade, max diameter mm, KW 2.2 Blade carriage speed 1-140 m/min. – BRUSHLESS motors Longitudinal pusher carriage speed 90 m/min. Cross pusher carriage speed 135 m/min. Double pusher carriage with 6 grippers on the longitudinal carriage + 10 grippers on the transverse carriage (8 fixed grippers + 2 on the multi-push system) Cutting system for thin panels
