Planers Offers
CATTELAN heavy duty moulder, type KSA 320/S
Manufacture year 2000, CE
Planing width 20 – 300 mm
Planing height 15 – 310 mm (2-sides)
Planing height 15 – 130 mm (4-sides) can be modified up to 300 mm
Feed speed 10 – 60 m/min, motor power 7.5 kW
F8vb9wfry
Spindle lay-out:
1. Horizontal bottom spindle, motor power 15 kW
2. Horizontal top spindle, motor power 18.5 kW
3. Vertical right spindle, motor power 11 kW
4. Vertical left spindle, motor power 11 kW
## Chamfering unit, each 2.2 kW
5. ...
Weinig hydro planer block.
50mm bore
Z=12
n max 7500rpm
Iekx7nr
195mm block dia.
230mm wide block.
shipping weight of 42kg
Complete and original .
Excellent condition, surplus to requirements. Can be packaged on a small pallet and loaded onto courier.
Technical specifications:
Obyll
Infeed table: 2000 mm
Max. planing thickness: 10 mm
Infeed fence: 10 mm
Infeed fence speed: 12 – 260 mm
Planing thickness: 8 – 160 mm
Spindle power: 7.5 KW
Engine power: 6000 Rpm
Feed speed: 4 – 25 m/min
Vertical spindles diameter: 12 mm
Horizontal spindles diameter: 8,5 mm
Cutterheads: ø125 mm
Min. product length: 380 mm
Dimensions:
Length: 3420 mm
Height: 1530 mm
Width: 830 mm
Weight: 2400 Kg Approx.
Notes:
Availability immediately
Surface planer, dresser, dresser
-Working width: 120 mm
Qkq88moki
-Table length: approx. 1700 mm
-2 knife shaft
Centrofix planer shaft,
noise-insulated table lips,
Auxiliary fence
----- Technical data -----
Planing width: 510 mm,
table length: 2.860 mm,
Bpfdjzrbcx
number of knives: 4 pieces,
motor power: 5,5 kW,
suction nozzle: 160 mm,
dimensions (LxWxH): 2.860 x 1.450 x 1.000 mm,
weight: 1.010 kg
WEINIG Unimat 23E Moulder (7 Spindles)
On9tv
Description:
Infeedtable 2.5 mtr.
Working width 20 - 230mm
Working height 8 - 120mm
Spindle arrangement bottom-right-left-right-top-bottom-uni (sawing)
Motor power or 7.5 -11 (L + R) - 7.5 - 11 - 11kW
Feed 4kW 5-24 mtr./min.
Spindle diameter 40mm
Manual Waxilite pump
Safety hood
CE
(All changes, mistakes in technical data, info and prices reserved. Availability subject to prior sales. No guarantee on printed data!)
(Alle aenderungen und Irrtuemer i...
ZIMAC de-stacking, infeed and stacking system
Manufacture year 2000
Specifications:
- For wood length 600 – 2000 mm
- Max. wood width 200 mm
- Max. wood height 100 mm
- Max. packages dimension 1200 x 1200 mm
Consisting of:
1. ZIMAC vacuum de-stacking and infeed, TS1000
- roller conveyor for wood packages
- Bolzoni hydraulic lifting table with roller conveyor
- vacuum lifting system, type TS1000
2. ZIMAC infeed system, type CN/2
- cross chain transport
- 2x bottom/top heavy duty feed roller
...
Planing width 510 mm
Bpyq2iylqj
Mechanical digital display working height SIKO
Motorized thicknessing table stroke
Fine adjustment by hand wheel
Diameter planing shaft 100 mm, 4 knives
Planing table 1050 x 510 mm
Passage 250 mm
2 infeed speeds 8 + 16 m/min
weight 540 kg
motor 400 V, 7 kW ( 9,5 PS)
equipped with two sliding rollers in the thicknessing table
Technical specifications:
Table front surface: 2000 mm
Planing width: 8 - 180 mm
Planing thickness: 5 - 120 mm
Spindle diameter: 40 mm
Chisel axis: ø 125 mm
Steel retraction: ø 140mm
Cup size: Min. 5 - 8 mm Max. 120 - 180 mm
Spindle motors: 4 Kw - 5 Kw
Spindle speed: 6000 Rpm
Voltage: 380 V / 50 Hz
Dimensions:
Length: 3000 mm
Width: 1800 mm
Height: 1700 mm
Weight: 1400 kg
Jwp2s3
More info:
Machine with continuous speed regulation of 8 m / min - 1.5 kW, Ø 140mm steel retraction and rubber fee...
Surface planer, dresser, dressing machine
-Working width: 450 mm
-Table length: 4200 mm
-4 Knife shaft: carbide
-Dimensions: 4300/1100/H1000
-Transport length: 3300 mm
-Weight: 1030 kg
Cb9iaco3
Jointly opening dressing tables,
table opening to the rear,
electric height adjustment,
dust-tested
----- Technical data -----
Planing width: 510 mm,
table length: 2.040 mm,
number of knives: 4 pieces,
swivelling range of planing fence: 45 °,
passage height: 220 mm,
feed speed: 6/12 m/min.,
G7tcpnp
suction nozzle: 120 mm,
motor power: 4 kW
WEINIG Hydromat 23C Moulder (5-Spindles)
Description:
Spindle sequence: bottom, right, left, top, bottom
1rst Spindle 15 kW (with backpressure bearing)
2nd Spindle 7.5 KW
3rd Spindle11 kW
4th Spindle15 kW (with backpressure bearing)
5th Spindle11 kW (with backpressure bearing)
Feed 7.5 KW 6-36 mtr./min. mechanical
Adjustment of the feed rollers 35mm to 150mm with extension
Shortened roller distance
Hour counter
Separate switch box and separate control panel
Short table 1.2 m long
Chromed mac...
CATTELAN - ZIMAC planing and profiling line
For pallet wood with jumping spindle, chamfering units, automatic de-stacking and stacking automatization.
Consisting of:
- ZIMAC vacuum de-stacking
- ZIMAC automatic infeed system, type CN\2
- CATTELAN moulder, type KSA 320
with jumping spindle and chamfering units
6 spindles with 2 pc. chamfering units
Max. feed speed 60 m/min
- Transport belt
- CATTELAN double en tenoning machine
2 x 3 working spindles
- ZIMAC transport belt and ...
sliding table length 2360 mm
Diameter planing shaft 90 mm
4 knives
max. chip removal 4 mm
dressing fence 45° and 90
Bpyrbrbbu8
autom. star-delta switch
weight 515 kg
motor 400 V, 4,5 kW ( 6,6 PS)
Four-side planer Weinig type Unimat 22 N,
Bra8z3xa
spindles: 6,
spindle arrangement: bottom (4 kW) - right (3 kW) - left (4 kW) - right (4 kW) - top (5,5 kW) - bottom (4kW),
mobile spindle,
working width: 220 mm, working height: 120 mm,
groove bed,
feed rate: max. 36 m/min.
Working width:410 mm
Working height:240 mm
Oyaqd
Motor output:5 kW
jointly opening dressing tables,
inclined toothed infeed roller,
under table roller,
noise-insulated
----- Technical data -----
Planing width: 510 mm,
table length: 2.130 mm,
planing shaft Ø: 110 mm,
number of knives: 4 pieces,
swivelling range of planing fence: 0 - 45 °,
passage height: 225 mm,
min. workpiece thickness: 6 mm,
feed speed: 8 / 14 m/min.,
suction nozzle: 120 mm,
motor power: 5,5 kW,
weight: 800 kg
=====
Quality - Info:
=====
- Dressing tables adjusted
- Infeed and outfeed rolle...
WEINIG UNIMAT 23 EL Spindle moulder 9 + Uni axis
Description:
Infeed table 2.5 m length
Working width 20- 230mm
Working height 8-120mm
Feedmotor with mechanical brake 5.5 kW
Mechanical feed infinitely variable 5-24 m./min
Spindle diameter 40mm
9 spindles + 1 Uni spindle
Spindle arrangement Bottom-Right-Left-Right-Left-Top-Bottom-Top-Bottom-Uni
Bs7hwhcawl
Motors 7.5-7.5-7.5-7.5-11-11-11-15-15-15 kW
Hardened machine table (except for infeed table)
Automatic waxilite pump
Driven roller in the disc...
LEADERMAC moulder, type Thundermac 523
Manufacture year 2007
Machine specifications:
- Planing width 20 – 230 mm
- Planing height 10 – 150 mm
- Cardan driven feeding system, motor 22 kW
- Feed speed 6 - 120 m/min
Spindle lay-out:
1. Horizontal spindle bottom, motor 22 kW
2. Vertical spindle right, motor 15kW
3. Vertical spindle left, motor 15 kW
4. Horizontal spindle top, motor 22 kW
5. Horizontal spindle bottom, motor 30 kW
- Front bearing for spindle 1, 4 and 5
- Digital positioning contr...
Surface planer
with 3-blade shaft
Planer fence 90° to 45
Bq3mkxaect
planing tables 1800 x 410 mm
max. chip removal 4 mm
passage thickness planer 230 mm
planing fence 1500 x 150 mm
weight 325 kg
motor 4,4 kW ( 6,6 PS ) 3 x 400 V
basic machine price : 3.100,00 Euro
equipped with:
1 Tersa planing cutter ( 240,00 Euro )
1 dial gauge in the hand wheel for thickness adjustment ( 150,00 Euro )
- NEW -
Main features:
Quick changeover system for opening the tables,
Speed, ergonomics and safety
Work table adjustment via parallelogram
lasting precision
Technical specifications:
usable working width 520 mm
total table length 2310 mm
Knife shaft D 120 mm
Planer shaft speed 5000 rpm.
4 knives 35 mm x 3 mm x 520 mm
Aluminum planing fence 1200 mm x 190 mm
Planing fence inclination from 90 ° to 45 °
min./max. Planing height 3/250 mm
Feed speed thickness 5-8-12-18 m / min.
Suction hood diame...
4-sided planer SCM compact P
-In excellent condition
-extended blade 250cm
-planing width 230mm
-planing height 120mm
-power of planer motor = 5,5kW
-power of the vertical spindle motor = 7,5kW
Fuvwyxs0g
-power output horizontal axis = 7,5 kW
-power supply = 1,3 kW
- exhibition machine -
----- Technical data -----
Plane width: 410 mm,
Thicknessing table dimensions: 775 x 410 mm,
Table length: 2,200 mm,
Bn00dkeyke
max. chip removal: 5 mm,
Planer shaft Ø: 95 mm,
Number of blades: 4 pieces,
Passage height: 240 mm,
min. workpiece thickness: 3 mm,
Feed speed: 6 / 12 m/min.,
rotational speed: 5,000 rpm..,
suction nozzle Ø: 120 mm,
Engine output 400 V: 6.6 PS / 5.0 kW kW,
Weight: 450 kg
- special offer price -
Working width:520 mm
Brzi3mgpu3
Working height:250 mm
Motor output:5,5 kW
A.COSTA moulder, type Mondial 300 Hydro
Manufacture year 1990
Boonhtnsko
Machine specifications:
- Max. planing width 300 mm
- Max. planing height 170 mm
- Hydraulic feeding, motor 15 kW
- Feed speed 0 – 60 m/min
- Heavy duty infeed section
- Feeded table rollers
Spindle layout:
1. Horizontal bottom spindle, motor 11 kW
2. Horizontal top spindle, motor 15 kW
3. Vertical spindle right, motor 7,5 kW
4. Vertical spindle left, motor 11 kW
5. Horizontal bottom spindle, motor 15 kW
- Front bearing ...
Surface planer, dresser, dresser
Hh8zktj3y
-Working width: 640 mm
-Table length: 2500 mm
-Knife shaft: 4
-Dimensions: 2600/950/H1000 mm
-Weight: 880 kg
- NEW -
- With TERSA cutter block for seconds
Change planer knives
- TERSA planing knife system enables particularly
Bn0o3zoiir
quiet running
- Helical-toothed steel feed roller for
constant and even wood intake
- The particularly long planing tables from one
Piece allow easy dressing of the
Work pieces
- Large planing fence can open when opening
the planing tables remain in position
- Planing tables that open to the rear
- The high machine weight ensures the highest
Precision and smoot...
Fabr. Casadei
Type. C-4
Year 1994
Working width. 220mm
Working height. 120mm
Engines. 4kW
Dmlgdvt
Infeed table length. 2000mm
Spindle diameter. 40mm
Rotation per min. 6000
weight. 1300kg
- Exhibition machine -
Gxedxc
TERSA planer shaft,
electric height adjustment,
digital display for planing thickness
----- Technical data -----
Planing width: 520 mm,
Thickness table dimensions: 850 x 520 mm,
table length: 2.250 mm,
max. chip removal: 5 mm,
planing shaft Ø: 120 mm,
number of knives: 4 pieces,
passage height: 240 mm,
min. workpiece thickness: 3 mm,
feed speed: 5 / 8 / 12 / 18 m/min.,
speed: 5.000 rpm,
suction nozzle Ø: 120 mm,
motor power 400 V: 9,5 PS / 7,0 kW,
weight: 695 kg
Technical specifications:
Working width: 230 mm
Working height: 140 mm
Feeding table length: 2000 mm
Spindle diameter: 40 mm
Feed speed: 6 - 36 m/min
Spindle speed: 8000 Rpm
Engine power: 5.5 kW
Dimensions:
Length: 4600 mm
Width: 4900 mm
Height: 2000 mm
Weight: 4000 Kg
X7zl8
More info:
7-axis machine with long infeed table. The ATS system works very conveniently and quickly.
Includes 7 cutting heads*
Spindle position:
Below
Correct
Left
Correct
Until
Until
Below
Notes:
Availability immediat...
LEADERMAC moulder, type Maximac 930
Manufacture year 2006
Machine specifications:
- Planing width 20 – 300 mm
- Planing height 10 – 150 mm
- Cardan driven feeding system, motor 15 kW
- Feed speed 6 - 60 m/min
Spindle lay-out:
1. Horizontal spindle bottom, motor 15 kW
2. Vertical spindle right, motor 11 kW
3. Vertical spindle left, motor 11 kW
4. Horizontal spindle top, motor 15 kW
5. Vertical spindle right, motor 11 kW
6. Vertical spindle left, motor 11 kW
7. Horizontal spindle bottom, moto...
catwalk
Pos - No. 85
manufactured by Weinig
Bn0ijznzcn
catwalk 1 piece
360 x 27 x 23 mm
located in 97447 Gerolzhofen
sale in current condition. as seen. Without examination.
- free on truck -
Working width:510 mm
Length of the planing table:2600 mm
Bng0uxylep
Cutterblock diameter:125 mm
TERSA- Planer Shaft
Bsjiw2bsoj
----- Technical data -----
Planing width: 520 mm,
Thicknessing table dimensions: 520 x 850 mm,
table length: 2.250 mm,
max. chip removal: 5 mm,
planing shaft Ø: 120 mm,
number of knives: 4 pieces,
passage height: 240 mm,
min. workpiece thickness: 3 mm,
feed speed: 5 / 8 / 12 / 18 m/min.,
speed: 5.000 rpm,
suction nozzle Ø: 120 mm,
motor power 400 V: 9,5 PS / 7,0 kW,
weight: 695 kg
Passage width 220mm
Ff0xszgao
Height of passage 120mm
Composition 4 tool holders
Variable speed drive
Electric lowering and raising
Voltage 380V
LEADERMAC moulder, type Speedmac 623
Manufacture year 2011
Machine specifications:
- Planing width 20 – 230 mm
- Planing height 10 – 150 mm
- Cardan driven feeding system, motor 11 kW
- Feed speed 6 - 60 m/min
Spindle lay-out:
1. Horizontal spindle bottom, motor 15 kW
O0avh
2. Vertical spindle right, motor 15kW
3. Vertical spindle left, motor 15 kW
4. Horizontal spindle top, motor 18,5 kW
5. Horizontal spindle top, motor 18,5 kW
6. Horizontal spindle bottom, motor 18.5 kW
- Front bear...
Hobelmaschinen Duo bevertical aus:
1. FIMAL surface planer type PF 530 N,
Partnership Edition
Technische Daten:
Abrichttischabmessung: 3.000 x 530 mm
Aufgabetischlänge: 1.800 mm
Abrichtanschlagabmessung: 1.500 x 175 mm
tilting range fence: 0 - 45 °
4-knife-Hobelwelle System TERSA d=120mm: 5.000 UpM
max. chip removal surface planer to CE: 8 mm
motor 380 Volt / 50 Hz.: 5,5 kW
Schallpegel to EN 27960: 82,9 - 88,9 dB(A)
Grundausstattung:
Elektrik to CE-Norm
Magnetbremse
suction nozzle d=150mm
pr...
Surface planer, dresser, dresser
-Working width: 520 mm
Bgfjwjkka
-Table length: 2555 mm
-Motor: AEG type DB 22/2 Kzs
-Power: 380 V 4 kW
-Speed: 2860 rpm
-Dimensions: 2620/660/H920 mm
-Weight: 630 kg
Feed rollers driven up and down, up to 20m / min
from 10mm to 150mm material thickness
Spindle Down 11.0KW above 11.0 KW
Bcauviqduo
2 Spare shafts prepared on carrier cart for short set-up time
Anlage ist mit Einlauf - und Außlaufmechanisierung !!!
Vorschubgeschwindigkeit von : 6 m/min
Vorschubgeschwindigkeit bis : 60 m/min
max. Spanabnahme Abrichte : 10 mm
max. Arbeitsbreite : 260 mm
max. Arbeitshöhe : 160 mm
Spindelanzahl : 6 Stk
1. Spindel : unten
Spindeldurchmesser 50 mm
Aufspannlänge 260 mm
Drehzahl 6000 U/min
Motorstärke 7.5 KW
2. Spindel : rechts
Spindeldurchmesser 50 mm
Aufspannlänge 160 mm
Drehzahl.6000 U/min
Motorstärke 7.5 KW
3. Spindel : links
Spindeldurchmesse...
feeder rolls
Pos - No. 158
manufactured by Weinig
feeder rolls 3 piece
gummed
roll diameter ca. 165 mm
Bn0kxsqvos
roll width ca. 24 mm
internal diameter 35 mm
keyway10 mm
located in 97447 Gerolzhofen
sale in current condition. as seen. Without examination.
- free on truck -
I sell a combined planer and thicknesser
630 mm planing width
4 cutterblocks
machine is very heavy duty
Btmplkb3cv
runs perfectly, complete with suction hood
For thicknessing and for planing
For sale due to new acquisition
Hundegger 4-sided planer.
-one feeding roller conveyor with clamping ruler, 6,50 m
-4 planing units (individually switchable)
-additional bevel planer (can be switched off)
-control unit can be mounted remotely
-outfeed roller conveyor 6,50 m
Btmefv837f
Feed rollers driven up and down, up to 20m / min
Bjhh3wzujb
from 10mm to 150mm material thickness
Spindle Down 11.0KW above 11.0 KW
2 Spare shafts prepared on carrier cart for short set-up time
Beschreibung : Rückführung für Vierseitenhobelmaschine
9337dep
- Werkstücklänge 200 - 1100 mm
- Werkstückbreite 20 - 150 mm
- Werkstückstärke 5 - 80 mm
- Bandlänge 3000 mm
- Bandbreite 250 mm
- Bandgeschwindigkeit 20 - 100 m / min.
- Antriebsmotor 0,25 kW
- Pneumatischer Druck 6 bar
- E. - Anschluss 400 V / 50 Hz / 1,1 A
Lagerort: Nattheim
Motorized thicknessing table stroke with two speeds
Numerical display for working height
Grey cast iron thicknessing table
The thicknessing table is mounted on four large trapezoidal thread spindles for maximum stability and precision
Four feed speeds
Optional with two rollers in the thicknessing table
Noise and chip protection curtain at workpiece infeed and outfeed as standard
Adjustable roller contact pressure
Front infeed roller with helical toothing
Pull-out roller with rubber coating
Power...
This may be of interest to you
Machineseeker becomes biggest sponsor of the 2nd Bundesliga in Germany
Morlock Motors official partner of Machineseeker and Truckscout24
Sample sales contract for used machines in nine languages
10 valuable tricks for buying used machines online
Photo gallery: the 10 strongest forklift trucks in the world
How to receive 100% of our e-mails
