Bed milling machines with moving table & CNC

Kiheung U1000 X: 3600 - Y: 1000 - Z: 1600 mm CNC

Condition: good (used), Year of construction: 1988, Description: Heavy-duty, high-precision horizontal lathe with Rohm hydraulic clamping system, slide with two working positions, Sauter 4-position tool turret, circular turning unit, CNC 6 axes, tailstock, chip conveyor. Suitable for both high-volume material removal and high-precision turning. Machine modified with a 2000 mm face clamping plate and increased in size. Year of production: 1988 Made in: Germany Turning diameter over bed: 2500 mm Turning diameter over telescopic covers: 2200 mm Turning diameter over slide: 1400 mm Turning length: 6000 mm Three-jaw chuck table: 2000 mm Spindle bore: 200 mm Attachment for circular turning Iedpfx Adoxmb Adjdeht Workpiece weight: 4,500–40,000 kg Turret head: 4 positions Spindle speed range: 4 – 400 rpm Main motor Siemens 95.5 kW Maximum torque: 40,000 Nm Overall power requirement: 125 kW Control: CNC SIEMENS 8T, 6 controlled axes Machine weight: 43,000 kg Required space: 13,000 x 4,000 mm

Condition: used, Year of construction: 2001, functionality: fully functional, machine/vehicle number: 124, Price upon request Used CNC Vertical Lathe Manufacturer MORI SEIKI Model VL 55 Year of manufacture 2001 With MSC 518 CNC control, 12-tool turret, and chip conveyor Turning length = 653 mm Turning diameter = 550 mm X-axis = 350 mm Z-axis = 660 mm Speed up to = 2000 rpm Spindle power = 30 kW Approx. weight = 12.5 t Price upon request Specifications: Ihsdpewl An Iefx Addjt Used CNC Vertical Lathe Manufacturer MORI SEIKI Model VL 55 YOM 2001 With MSC 518 CNC control, 12-tool turret, and chip conveyor Turning dia. = 550mm Turning length = 653 mm X-Axis = 350mm Z – Axis = 660 mm Speed = 2000 rpm Spindle power = 30 kW Weight approx.. = 12.5 t

Condition: used, Year of construction: 2006, x-travel 600 mm y-travel 400 mm z-travel 400 mm control MSX 501 Mori Seiki table surface area 700 x 450 mm max. table load 350 kg number of T-slots 4 T-slot - width 18 mm T-slot - distance 100 mm Number of revolutions 12.000 U/min power capacity - main spindel 18,5 / 15 / 11 kW tool taper BT 40 max. Torque 110,5 Nm diameter of forward milling spindle bearing 70 rapid travel x/y/z 20.000 mm/min feed speeds 1 - 20.000 mm/min Tipp feed 15 Steps / 0 - 1.260 mm/min Isdpfsv Az Ucjx Addeht Number of Toolpositions in magazine 40 Pos. Max. mould width 80 mm max. tool-dia with free toolbox 125 mm max. tool length 250 mm max. tool weight 8 kg change-time chip to chip 2,8 sec change-time tool to tool 1,0 sec total power requirement 34 kVA weight of the machine ca. 7,2 t dimensions of the machine ca. 2,8 x 3,0 x 2,9 m Machining Center Vertical MORI SEIKI - NV 4000 DCG - ca. 14.000 Operating-Hours

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, travel distance X-axis: 1,500 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 610 mm, nominal power (apparent): 37 kVA, torque: 236 Nm, controller manufacturer: Heidenhain iTNC530, controller model: iTNC530, table width: 700 mm, table length: 1,700 mm, table load: 700 kg, rotational speed (max.): 12,000 rpm, overall weight: 9,000 kg, spindle speed (max.): 12,000 rpm, operating hours of spindle: 16,580 h, spindle motor power: 37 W, number of spindles: 1, number of slots in tool magazine: 48, Equipment: chip conveyor, documentation/manual, Heidenhain iTNC530 3-axis CNC machining center Isdpfx Ajvz Tyujddoht Stroke x 1500 mm Stroke Y 700 mm Stroke Z 610 mm Table dimensions: 1700x700mm SK40 tool holder Magazine 48 tools Rapid feed 36m/min Table load: 700 kg Spindle center coolant 20 bar Chip conveyor Crank

Condition: new, travel distance X-axis: 6,000 mm, travel distance Y-axis: 1,300 mm, travel distance Z-axis: 2,000 mm, position of the milling head: Universal-Diagonal-Fräskopf, rapid traverse X-axis: 30,000 m/min, rapid traverse Y-axis: 30,000 m/min, rapid traverse Z-axis: 30,000 m/min, spindle speed (max.): 6,000 rpm, pivoting range: 1 °, table length: 7,500 mm, table width: 1,100 mm, torque: 1,178 Nm, table load: 42,000 kg, coolant supply: 36 bar, spindle motor power: 53 W, Equipment: rotational speed infinitely variable, BRAND NEW GANTRY-TYPE MILLING MACHINE Control and Drives: Two HEIDENHAIN TNC 640 digital path controllers – one at the front of the machine and one at the rear in the cabin HEIDENHAIN package (motors, measuring systems, and handwheel) Additional equipment: Chain-type tool changer with dual gripper, 60-tool capacity Dual hinged belt chip conveyors (longitudinal), one at the front and one at the rear Accuracies: Positioning accuracy: ±0.040 mm Repeatability: ±0.008 mm Ijdpfxsvrv Sue Addeht Only inquiries from Germany will be answered.

Condition: ready for operation (used), Year of construction: 2005, - USED - TUBE BENDING MACHINE AXIS: 3 MAX TUBE DIAMETER: 30X2 mm WORKING LENGHT: 3000 mm X-AXIS POSITIONING SPEED: 900 mm/sec Y-AXIS BENDING SPEED: 200 °/sec Z-AXIS ROTATION SPEED: 360 °/sec MAX BENDING RADIUS: 20 A 170 mm Ihsdpfsvhc Uusx Addst CONTROL UNIT: DNC800

Condition: used, Year of construction: 1999, Technical details: Ihjdou Nc Emspfx Addot x-travel: 3 500 mm y-travel: 2 200 mm z-travel: 1 200 mm c-axis: +/- 200° control: Heidenhain TNC 426 spindle rpm - counter clockwise:: max. 10000 spindle rpm - clockwise:: max. 10000 distance between columns: 2 500 mm distance spindle /table: vertical: 1230 mm clamping surface area: Tisch: 3000 x 2000 mm table load: 10 t tool taper: HSK A 63 feed:: X/Y/Z: max. 20 m/min. compressed air: 8 bar total power requirement: ca. 100 kW weight of the machine ca.: 40 000 kg dimensions of machine: 18,0 x 6,0 x 5,8 m 5 axis Portal Milling Machine 5-axis portal milling machine Milling spindle: make Hauser type HS 256A-01 Uni, speed max. 10.000 rpm. direct drive Milling head: make Hamül, fork type, A-axis integrated = angle of rotation +/- 110°. Tool changer: Hamül make, rotary indexing table type with rotary table, for 32 tool positions chip conveyor: 2 pieces hinged belt conveyor make DGS with water tank, insertion length 8.500mm make BKW type DL 55V-2KK, capacity 2,41 l/min.; (combined for oil- water mixture for oil and spindle cooling) Cooling lubricant system: belt filter make DGS type SBF 150 Operation: via control panel type Heidenhain LE 426 X-, Y- and Z-axis with Heidenhain measuring rods. manual control unit HR 410 hydraulic counterbalance (Z-axis) Equipment: Enclosure (protective walls with viewing windows and protective doors) hydraulic system working area lighting *

Condition: good (used), Manufacturer ESTARTA Model 301 MV Condition Used Stock number 4576 Location Badajoz, Spain Dimensions 1520x1020x1260mm Weight 1550 kg Opening between grinding wheels 1,5/50mm Max. grinding wheel width in plunge grinding plunge 125mm Dimensions of the working wheel (od x id x width) 300x125x175mm Øext.min. working wheel working wheel 220mm Max. depth of profile of working profile depth 8mm Dimensions of the driving wheel (od x id x width) 220x125x125mm Øext.min. of driving wheel drive wheel 165mm Max. depth of profile of the driving wheel profile depth Ihodper Ezfpefx Addot 8mm Grinding wheel motor power motor power 7,5Kw Motor power of grinding wheel driving motor power 0.75Kw Tilting angle angle of working working +/- 5º

Year of construction: 1990, condition: reconditioned (used), tangential grinding machine Brand: Jakobsen Model: 1432 Year: 1990 rpm: 1400 Ihodpfoiv S Avox Addet Grinding area: 800x400mm Table size: 1000x350mm Maximum load on table: 400kg Maximum piece height: 475mm Grinding wheel size: 350x50x127mm Heidenhain ND 221B height indicator. Magnet table 800x350mm electronic Selter with magnetization regulator. Maximum distance between table and grinding wheel: 650mm MONNET brand filter of the year 2007 Includes sets of wheels (See photos).

Condition: reconditioned (used), Year of construction: 2009, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,000 mm, spindle speed (max.): 3,500 rpm, workpiece weight (max.): 8,000 kg, overall weight: 13,500 kg, Equipment: rotational speed infinitely variable, x-travel 3.000 mm y-travel 1.000 mm z-travel 1.000 mm control iTNC 530 HEIDENHAIN table-size 3.230 x 1.050 mm table load 8,0 t spindle taper ISO 50 tool change unit 24 Pos. spindle turning speed range 30 - 3.500 U/min drive capacity - spindle motor 25 kW feed stepless 1 - 5.000 mm/min rapid traverse 10,0 m/min chip conveyor Spiralförderer voltage 380 V total power requirement 35 kVA weight of the machine ca. 13,5 t dimensions of the machine ca. 7,40 x 3,65 x 3,60 m hydraulic power unit 1,40 x 0,50 x 0,60 m 0,45 x 0,70 x 0,85 m - Serial No.: VH-30041 - Maschine ON 23.724 h - Spindel ON 7.968 h - CNC-Control: iTNC 530 HEIDENHAIN - Universal Milling Head (Huron-Type), manual - 2x Screw type chip conveyor at front and back of table - Oil chiller unit Ihodpfx Adovlzznsdet - Y-Axis guitde ways with new TURCITE - Ball screws and bearings in X/Y/Z axis renewed
