Used Cylinder Grinding Machine for sale (87,174)

Condition: used, Year of construction: 1968, Technical details: x-travel: 400 mm y-travel: 250 mm workpiece height: 500 mm Gbedpfxsvbzwzs Abdeg grinding diameter: 220 mm table surface area: 600 x 320 mm throat: 310 mm range of angles: 12 ° grinding wheel stroke - vertical: 110 mm stroke speeds: 0 - 6 m/min grinding spindle speed: bis 50000 U/min peripheral speed: max. 35 m/sec capacity: ca. 7 kVA power capacity: 6 kW weight of the machine ca.: 2 t dimensions of the machine ca.: 3 x 3 x 3 m rotary table d = 300 mm frequency changer *

Condition: new, The RSM 1500 C, a precision cylindrical grinder from KNUTH, is designed for long and heavier workpieces within the Conventional Cylindrical Grinders category. This robust machine features a large machine bed that supports workpieces up to 2000 mm in length and 320 mm in diameter, ensuring maximum accuracy and stability. Wide, precision-ground guideways contribute to reliable performance, while the grinding spindle with hydrostatic bearings guarantees high precision and surface quality. The powerful motor allows for continuous operation, making it ideal for both individual parts and small series production. Operators can benefit from adjustable dwell times and precise micro-feed control, enhancing the grinding process. With an integrated internal grinding device, the RSM 1500 C offers exceptional flexibility. If you're looking for a reliable solution for cylindrical grinding, request a quote or buy now to experience the efficiency of this powerful Conventional Cylindrical Grinder from KNUTH. Godpsu E N Dnefx Abdsbg

Condition: ready for operation (used), Year of construction: 1988, Horizontal surface grinding machine Okamoto Model PSG 63 – UAN Year of manufacture 1988 Grinding length 600 mm Grinding width 320 mm Maximum workpiece height 500 mm Table longitudinal travel 750 mm Table cross travel 340 mm Grinding wheel diameter 350 mm Grinding wheel width 40 mm Spindle speed 1,500 rpm Rapid vertical traverse 400 mm/min Gsdpox Tqxkofx Abdjbg Power 3.7 kW Automatic feed Magnetic chuck Coolant system Weight 2,500 kg Price: €2,500 plus VAT, ex-site

Condition: ready for operation (used), Year of construction: 2021, functionality: fully functional, total length: 23,080 mm, total height: 3,530 mm, input frequency: 50 Hz, type of input current: three-phase, input voltage: 400 V, Forel automatic vertical CNC glass edging/polishing line including tilting loading table and vertical glass washing machine. This high-end machine is in excellent working shape and is very well maintained, year of construction is 2021. The complete processing line can be sighted in working condition. The line will be available in March 2026. Components of the line are: TP04020ES, EM04020HT, VW00020HT. Godpfox S Izgox Abdebg

Condition: used, Year of construction: 2006, functionality: unexamined, machine/vehicle number: 200665, total length: 8,932 mm, total width: 8,075 mm, input current: 220 A, input frequency: 50 Hz, type of input current: three-phase, input voltage: 380 V, Bavelloni double edging machine VX8, year 2006, 88 KW, max glass dimension 2600/1600mm, with 90° transfer. Gbsdsw I Dz Tepfx Abdog

Condition: good (used), Year of construction: 2002, operating hours: 9,999 h, functionality: fully functional, machine/vehicle number: 120231, Cylindrical Grinding Machine SCHAUDT / Mikrosa PS 51 N 600 Technical Data – Schaudt / Mikrosa PS 51 N 600 Machine type: Universal / External Cylindrical Grinding Machine Year of manufacture: 2002 Control: Siemens 840D Gbedpfxjxdb R No Abdeg Grinding length (between centers): 600 mm Center height / Height over bed: 180 mm Maximum grinding diameter over bed: approx. 300–360 mm Max. workpiece weight (between centers): approx. 150–200 kg, depending on configuration Grinding spindle power: approx. 22 kW Grinding wheel width: e.g., 220 mm on premium versions; diameter depending on equipment approx. 400–500 mm Grinding wheel speed / surface speed: On some versions approx. 45 m/s; variable depending on equipment Total weight: approx. 10 t

Condition: used, Year of construction: 1982, Technical details: grinding diameter: 600 mm grinding length: 3000 mm centre height: 315 mm workpiece weight max.: 3000 kg work piece spindle speed: 8 - 120 U/min grinding wheel motor: 25 kW grinding wheel speed: 45 m/sec grinding wheel width x diameter: 750 x 80 mm table speeds: 30 - 4500 mm/min feeds of grinding head: 0 - 5 mm/min table swivelabel +/-: 7,5 ° total power requirement: 55 kVA weight of the machine ca.: 18 t dimensions of the machine ca.: 11,5 x 4 x 2,2 m - Internal grinding device - taper grinding up to 10,1° based on diameter - automatic grinding cycle - grinding wheels and flanges - dressing device Gjdpjvb Dl Uefx Abdobg - coolant attachment - dust exhauster, various steady rests *

Condition: used, Year of construction: 1989, Used, well-maintained GEIBEL+HOTZ surface grinding machine Model FS 50 SA Gsdjwq Nc Nepfx Abdsbg Grinding area 500x250x375mm, Vertical automatic with fine-pole electro-magnetic chuck, Grinding wheel diameter 300x50x76.2mm, with paper band filter system, with manual dresser on top. various wheels and flanges Weight: approx. 2400 kg Space requirement approx. 2500x1800xHeight 2500mm Machine is located with us in 71334 Waiblingen-Beinstein and can of course also be inspected. Please contact us.

Condition: ready for operation (used), Year of construction: 2000, Immediately available ex location: Horizontal Surface Grinding Machine ABA Type ECOLINE L 1006 Gedpfxsx Tqw Ts Abdsbg Year of manufacture: 2000 Control: Abamatic – 1 Operator Table: 1000 x 600 mm Table load capacity: 1000 kg Grinding length: 1000 mm Grinding width: 700 mm Installation height: 700 mm Grinding wheel: 400 x 100 x 127 mm Grinding wheel speed steplessly adjustable up to 2600 rpm Drive power: 11 kW Grinding wheel speed steplessly adjustable up to 2600 rpm Feed rates, X axis: steplessly adjustable up to 10,000 mm/min Feed rates, Z axis: steplessly adjustable up to 10,000 mm/min Feed rates, Y axis: steplessly adjustable up to 10,000 mm/min Magnetic chuck Belt filter system Weight: 6 t Price: EUR 9,500 – plus VAT, ex foundation

Condition: excellent (used), Year of construction: 1998, operating hours: 50,000 h, functionality: fully functional, Technical Data – Gear Grinding Machine Reishauer RZ 362A Machine type Gear Grinding Machine Manufacturer Reishauer AG, Wallisellen, Switzerland Model RZ 362A Year of manufacture 1998 Machine number 73889 Commission number 309 CE compliant Yes Electrical data Mains connection 3 x 400 V, 50 Hz Gjdex Sxbdepfx Abdebg Machine voltage 3 x 400 V, 50 Hz Control voltage 1 x 230 V, 50 Hz / 1 x 24 V DC Contactor voltage 1 x 24 V DC Valve voltage 1 x 24 V DC Electrical diagrams standard Grinding wheel dimensions Minimum / maximum outside diameter 280 / 350 mm Maximum width with limitations 84 / 104 mm Number of starts with limitations up to 3 Maximum usable width (with shifting motion) 90 mm For module > 7 or more than 3 starts, Reishauer guidelines apply Grinding wheel speeds During grinding 1,100 – 2,300 rpm During profiling 50 – 95 rpm During setup (special mode) max. 200 rpm Grinding infeed In grinding mode per grinding stroke 0.01 – 1.0 mm Total infeed (fx tot) 9.99 mm In setup mode (special mode) max. 2 m/min Grinding stroke Maximum grinding stroke 175 mm Automatic grinding wheel return stroke for workpiece change 65 mm Shifting movement Maximum shifting travel continuous shifting per 1 mm grinding stroke 0 – 1.0 mm Workpiece data Minimum workpiece pitch diameter depending on grinding wheel diameter Grinding wheel Ø 280 mm: 50 mm Grinding wheel Ø 320 mm: 10 mm Grinding wheel Ø 350 mm: 10 mm Automatic centering with sensor (RZ 362A only): 20 mm Maximum workpiece outside diameter 360 mm With “Felsomat” loader (optional, RZ 362A only): 300 mm With automatic centering using sensor (RZ 362A only): 320 mm Minimum distance from grinding wheel center to workpiece center 165 mm Maximum face width 175 mm For pitch diameters < approx. 150 mm, face width is reduced due to clamping chuck and tailstock design Maximum workpiece weight 60 kg With “Felsomat” loader (optional, RZ 362A only): 4 kg Center distance Fixed manual tailstock (optional): 645 mm Special manual tailstock (optional): 745 mm Hydraulic tailstock (optional, RZ 362A only): 515 mm (645 mm with reduced grinding stroke) Gear data Number of teeth minimum 6, maximum 600 Module without automatic centering minimum module 0.5 (DP 48) Module with automatic centering minimum module 0.8 (DP 32) Maximum module 7.0 (DP 3.5) Helix angle Minimum 10° Maximum 40° Maximum inclination angle left and right 45° Shifting limitations apply for large helix angles, especially above 30° Crowning and profile modification Tip relief and crowning height Crowning length and taper Maximum modification depends on profiling tool and process data Weights (without oil filling) Machine weight approx. 5,000 kg Electrical cabinet approx. 1,100 kg Hydraulic unit approx. 600 kg Grinding oil unit RTO 100 (optional) approx. 1,600 kg Grinding oil unit RTM 100 with magnetic pre-filter (optional) approx. 1,650 kg Grinding oil unit RTA 150 (optional) approx. 2,500 kg “Felsomat” gantry loader (optional, RZ 362A only) approx. 1,600 kg Loading unit approx. 1,000 kg Workpiece storage approx. 400 kg

Condition: used, Year of construction: 2002, operating hours: 65,434 h, General Specifications Gsdpevzriuofx Abdsbg Machine Type: Universal Cylindrical Grinding Machine Year of Manufacture: 2002 Control System: SIEMENS 840D Grinding Length: 600 mm (between centers) Max. Swing Over Bed: ~300 mm (approximate, depending on configuration) Max. Workpiece Weight: ~150 kg (depending on setup) Grinding Wheel Grinding Wheel Diameter: ~400-500 mm (standard) Grinding Wheel Width: ~50-100 mm (depending on application) Grinding Wheel Speed: ~30-60 m/s (adjustable) Workhead Workhead Spindle Speed: ~10-500 rpm (variable, depending on workpiece material and grinding requirements) Workhead Spindle Taper: Typically Morse taper or custom taper for specific applications Tailstock Tailstock Quill Travel: ~50-100 mm (adjustable) Tailstock Taper: Morse taper (e.g., MT4 or MT5, depending on configuration) CNC System Control Type: Siemens, Fanuc, or other CNC systems (depending on configuration) Axes: Typically 2-4 axes (X, Z, U, and optionally B-axis for angular grinding) Positioning Accuracy: ~0.001 mm (1 micron) or better Coolant System Coolant Tank Capacity: ~200 L Coolant Pump Power: ~1-2 kW Power Requirements Main Motor Power: ~10-15 kW (grinding spindle) Total Power Consumption: ~20-30 kW Dimensions and Weight Machine Dimensions (L x W x H): ~3000 x 2000 x 2000 mm (approximate) Machine Weight: 5000 KG Applications Precision grinding of cylindrical and non-cylindrical workpieces Suitable for small to medium-sized components in industries like automotive, aerospace, and tool manufacturing

Condition: good (used), Year of construction: 2000, Ref. -No.: 10609 Manufacturer: GLEASON - PFAUTER Type: P 2400 G Year of construction: 2000 Type of control: CNC Control: Siemens 840 D Storage location: Halberstadt Country of origin: Germany Machine length: 1100 mm Machine width: 6585 mm Machine Height: 5200 mm Max. Workpiece Diameter: 2640 mm Weight Of The Machine Ca.: 23 t Grinding Wheel Diameter: 400 mm Spindle Speeds (Infinitely Variable): 600 bis 6000 mm Grinding Wheel Width: 80 mm X-Axis: 1200 mm Y-Axis: 300 mm Z-Axis: 1000 mm Z2 - axis: 150 mm Sandable profile depth: 80 mm Workpiece table: 0 bis 5 1 / min Feed rate X-axis: 3000 mm Feed rate Y-axis: 5000 mm Z-axis feed rate: 6000 mm Further information: - Fully automatic centering device Gjdpfx Abex R R Exedebg - Oil mist separation - Gear tooth measurement - “Profile grinding” software package - Error diagnosis - IFK2 internal milling head - Milling mandrel with spacer discs - Chip conveyor - Oil mist extraction - Technical documentation

Condition: used, Year of construction: 1975, Technical details: grinding length: 600 mm grinding width: 300 mm workpiece height: 450 mm total power requirement: 8 kW weight of the machine ca.: 2,2 t dimensions of the machine ca.: 2,8 x 3,0 x 2,0 m grinding spindle speed: 1440 / 2905 U/min with magnetic plate 600 x 200 mm autom. vertical feed coolant attachment * Gbedpfx Ajvb Dmlsbdog

Condition: as good as new (ex-display), Year of construction: 2024, High-quality spindle with precision tapered roller bearings Hardened and ground table guideways Turcite-B coated counter guides for high wear resistance and low friction Integrated grinding wheel removal device Machine base made of sturdy, torsion-resistant cast iron for maximum rigidity and stability Backlash-free V-flat guide in the Z-axis and flat guides in the X- and Y-axis Trapezoidal threaded spindle in the Y-axis Manual central lubrication All flat guides are finely scraped, guaranteeing high precision of all manual movements LED lamp Safety electrics with 24 V DC voltage Sanding accuracy: 0.005 mm Grit 46 corundum grinding wheel for all common steels included as standard Two-channel safety electrics Gbodpfx Ajw Eay Iobdog EMC filter class Significant energy savings thanks to IE3 motor Coolant system with external coolant tank Dimensions and weights Length approx. 1970 mm Width/depth approx. 1300 mm Height approx. 1700 mm Weight approx. 850 kg Electrical data Power drive motor 1.5 kW Supply voltage 400 V Mains frequency 50 Hz Surface grinding table Clamping surface length 200 mm Clamping surface width 500 mm Grinding wheel(s) Outer diameter 200 mm Width 20 mm Bore 31.75 mm Peripheral speed 33 m/s Spindle Speed 2850 min¯¹ Concentricity 0.005 mm X-axis Feed speed Manual

Condition: ready for operation (used), Year of construction: 1990, Immediately available ex location: Gbsdpfex Tqw Hex Abdjg Horizontal surface grinding machine ELB Type: Optimal 6375 ND Year of manufacture: 1990 Table: 1000 x 370 mm Grinding length: 1000 mm Grinding width: 375 mm Installation height: 375 mm Table load: 300 kg Automatic feed Magnetic chuck Drive: 3.7 / 4.7 kW Coolant system Weight: 4 t Price: EUR 3,750.-- plus VAT ex location.

Year of construction: 1973, condition: good (used), 1 used spline shaft grinding machine make Fritz Werner type FKR 16 year 73 No. 5275/8012 technical data Gbodpfxsn Atche Abdeg center height 185 mm max.grinding length1600 mm passage diameter 55 mm pitches 4-32 L 5900 x W 2300 x H 2000 mm weight 7 to

Condition: excellent (used), Year of construction: 1983, Model: Fortuna F23 S1000 ASW 45 Manufacturer: Fortuna-Werke Maschinenfabrik GmbH Origin: Stuttgart-Bad Cannstatt, Germany Year of Manufacture: 1983 Machine Type: Universal external cylindrical grinding machine Control Type: Not CNC – semi-automatic with digital position indicators Workholding: Grinding between centers with headstock and tailstock Max. Grinding Length: 1000 mm Main Motor Power: 26 kW Voltage: 380 V Frequency: 50 Hz Connected Load: 50 A Machine Weight: Approx. 4900 kg Grinding Wheel & Spindle: Wheel Diameter Options: 400 mm, 450 mm, 500 mm, 600 mm, 750 mm, 900 mm Wheel Bore Diameter: 127 mm / 203 mm / 305 mm Spindle Speeds (depending on wheel size): From 930 rpm to 1870 rpm Surface Speed Compatibility: 35 m/s and 45 m/s Gbjdew Avhpjpfx Abdog Spindle Design: Combined axial-radial bearing system for high rigidity Oscillating Grinding Support: Yes – for improved surface finish and cooling Grinding Functions: External cylindrical grinding only (not centerless) Longitudinal feed (table movement) Plunge feed (cross movement) Oscillation grinding (with adjustable stroke) Digital input system (non-CNC but programmable logic based) Manual fine adjustment via micrometer and scale plate Notes: Machine is designed for roughing and finishing of steel, cast iron, and aluminum Built-in charts and formulas provided in the manual for infeed rates, stock removal, overspark passes, and optimal feed per material Extremely rigid German construction, ideal for toolrooms or production environments seeking repeatable precision without CNC control Equipped with electronic displays and control panel (not G-code programmable) Power panel and internal logic controlled through Fortuna's relay/PLC interface

Condition: used, Technical details: grinding length: 12000 mm grinding width: 2800 mm workpiece height: 2510 mm max. workpiece weight: 24.000 kg table surface area: 11990 x 2500 mm distance between columns: 2820 mm cross rail adjustment: 2510 mm table feed: 1 - 40 m/min total power requirement: 110 kW weight of the machine ca.: 151 t dimensions of the machine ca.: 32,5 x 9 x 6,73 m .....machine is in top condition for high precision work! Gedpfx Abowc A Snjdebg with CNC SIEMENS 840 D 1 universal grinding head, 22 kW swivelling of the grinding spindle +/-110° grinding wheel dimension 700 x 130 mm vertical stroke 1000 mm with dressing unit 1 surface grinding head, 30 kW grinding wheel dimension 600 x 150 mm vertical stroke 230 mm with dressing unit coolant and filtering unit diverse grinding wheel flanges *

Condition: as good as new (ex-display), Year of construction: 2025, GT 30 - The OPTIMUM premium NC sanding machine with Siemens touch screen. - Electromagnetic clamping plate for fixing the workpiece with automatic demagnetization function - High-quality spindle with precision tapered roller bearings - Hardened and ground table guideways - Turcite-B coated counter guides for high wear resistance and low friction - Grinding spindle with high-quality precision bearings - Grinding wheel can be resharpened directly on the machine using a sharpening device - Digital position indicator - Machine base made of sturdy torsion-resistant cast iron for maximum rigidity and stability - Guideways for longitudinal, transverse and vertical movements are backlash-free and self-centring as V and flat tracks - Precision recirculating ball screws - Guideways and transport spindle with central lubrication - All flat guides are finely scraped and thus guarantee maximum precision of all manual movements - Safety electrics with 24 V DC voltage - Large decoupled handwheels in all three axes - Hydraulic lines according to DIN EN 853 - Sanding accuracy: 0.005 mm - Grain 46 corundum grinding wheel for all common steels - Swivel-mounted control panel makes work considerably easier - Separate hydraulic unit with heat exchanger, avoids vibrations and thermal stress - Two-channel safety electronics - Grinding table splash guard - EMC filter class - With IE3 motor - consumes considerably less energy, resulting in significant cost savings Dimensions and weights Length approx. 3200 mm Width/depth approx. 2200 mm Height approx. 2100 mm Weight approx. 3000 kg Electrical data Total connected load 6.5 kW Supply voltage 400 V Mains frequency 50 Hz Surface grinding table Clamping surface length 300 mm Clamping surface width 600 mm Grinding wheel(s) Outer diameter 350 mm Width 40 mm Bore 127 mm Peripheral speed 27 m/s Spindle Speed 1450 min¯¹ Concentricity 0.005 mm Gbedpjw Eazfjfx Abdsg X-axis Feed speed 5 - 25 m/min Scope of delivery Unit of measure: piece Packaging unit: 1 Digital position indicator Coolant device Balancing mandrel Grinding wheel grit 46 Diamond pin Operating tool Manual oil pump LED lamp Electromagnetic clamping plate Demagnetizing function Equipment Electromagnet clamping plate Splash guard table enclosure Automatic demagnetizing device Parallel dressing device ✔ Coolant device 125 W Work light LED lamp Alignment feet ✔

Condition: good (used), Year of construction: 2007, 1 used CNC tool grinding machine Make: Schneeberger Model: Corvus GDS 650 Year of manufacture: 2007 CNC Control: FANUC 160i Software: Quinto 4.3 Activated software options (option numbers): 1, 2, 19, 21, 22, 30, 31, 32, 35 - Fanuc loading robot - Coolant system Travel: X-axis: 650 mm Y-axis: 300 mm Z-axis: 300 mm C-axis swivel range: +150°/ -60° C’-axis swivel range: +/- 180° Grinding spindle: Wheel diameter up to 250 mm Speed: 0 – 10,000 rpm Max spindle power: 26 kW HSK 80 interface Max. number of wheels: 6 Workpiece spindle head: Vmax: 180°/s Drive power: 1.6 kW ISO 50 interface Precision (resolution): Linear axis resolution: 0.001 mm C-axis: 0.001° Dimensions: Length: 3,100 mm Width: 1,915 mm Height: 2,190 mm Weight: 8,500 kg U-axis is integrated with steady rest, clamping cylinder, and tailstock Gbjdpfju A Dn Nox Abdog 6-pallet loader (diameter 3 to 32 mm) 64 plastic collets Technical data subject to change without notice

Condition: like new (used), Year of construction: 2010, Machine Type: CNC Cylindrical Grinding Machine Manufacturer: Fritz Studer AG Model: S22 Year of Manufacture: 2010 Control System: FANUC 31i-A CNC Machine Base: Granitan® S103 mineral casting Configuration: Fixed straight wheelhead for external (OD) grinding Automation: Automatic loading system with FANUC robot integration Distance Between Centers: 650 mm (25.6”) Center Height: 175 mm (6.9”) Max. Workpiece Weight: 150 kg (330 lbs) Max. Workpiece Length: 700 mm Max. Workpiece Diameter: 449 mm Grinding Wheel Diameter: 610 mm Grinding Wheel Width: 160 mm Grinding Wheel Speed: Up to 3,200 rpm Spindle Power: 15 kW (20.5 hp) Wheelhead Type: Fixed straight X-Axis Travel: 310 mm Z-Axis Travel: 850 mm X-Axis Max. Speed: 15,000 mm/min Z-Axis Max. Speed: 30,000 mm/min C-Axis: Full rotation capability for workhead Programming Interface: StuderWIN with FANUC 31i-A Additional Software: StuderGRIND Automation Interfaces: Standard interfaces for loaders and peripherals Other Equipment: Rotary dresser, Heidenhain scales, various clamping fixtures Godpfxswl Uvkj Abdobg

Condition: as good as new (ex-display), Year of construction: 2025, GT 40 - The OPTIMUM premium NC sanding machine with Siemens touch screen. - Electromagnetic clamping plate for fixing the workpiece with automatic demagnetization function - High-quality spindle with precision tapered roller bearings - Hardened and ground table guideways - Turcite-B coated counter guides for high wear resistance and low friction - Grinding spindle with high-quality precision bearings - Grinding wheel can be resharpened directly on the machine using a sharpening device - Digital position indicator - Machine base made of sturdy torsion-resistant cast iron for maximum rigidity and stability - Guideways for longitudinal, transverse and vertical movements are backlash-free and self-centring as V and flat tracks - Precision recirculating ball screws - Guideways and transport spindle with central lubrication - All flat guides are finely scraped and thus guarantee maximum precision of all manual movements B9errbkz8v - Safety electrics with 24 V DC voltage - Large decoupled handwheels in all three axes - Hydraulic lines according to DIN EN 853 - Grinding accuracy: 0.005 mm - Grain 46 corundum grinding wheel for all common steels - Swivel-mounted control panel makes work considerably easier - Separate hydraulic unit with heat exchanger, avoids vibrations and thermal stress - Two-channel safety electronics - Grinding table splash guard - EMC filter class - With IE3 motor - consumes considerably less energy, resulting in significant cost savings Dimensions and weights Length approx. 3600 mm Width/depth approx. 2400 mm Height approx. 1900 mm Weight approx. 3600 kg Electrical data Total connected load 7.5 kW Supply voltage 400 V Mains frequency 50 Hz Surface grinding table Clamping surface length 400 mm Clamping surface width 800 mm Grinding wheel(s) Outer diameter 350 mm Width 40 mm Bore 127 mm Peripheral speed 27 m/s Spindle Speed 1450 min¯¹ Concentricity 0.005 mm X-axis Feed speed 5 - 25 m/min Digital position indicator Coolant device Balancing mandrel Grinding wheel grit 46 Diamond pin Operating tool Manual oil pump Gbodexyhvkopfx Abdog LED lamp Electromagnetic clamping plate Demagnetizing function Equipment Electromagnet clamping plate Splash guard table enclosure Demagnetizing device Parallel dressing device ✔ Coolant device 125 W Work light LED lamp Alignment feet ✔

Condition: good (used), Year of construction: 2008, 1 used surface grinding machine Manufacturer: Elb Type: Smart NG STC SN: 511210608 Control: Siemens, type: Simatic Multipanel Touch Magnetic clamping table, 400 x 600 mm Hydraulic table drive, table speed 2 - 30 m/min Table load on magnetic plate: 400 kg Grinding area (L/W/H): 600 x 400 x 475 mm Grinding wheel dimensions: 300 x 50 x 76.2 mm Grinding spindle output: 4.3 kW Grinding spindle taper: 36 mm Max. vertical travel: 475 mm Max. transverse travel: 370 mm Machine weight: 3,800 kg Machine dimensions: L/W/H 2,750 x 2,050 x 2,150 mm, Electronic handwheel for Y/Z axis, Gbjdpov T Rhajfx Abdeg Dressing unit with dressing compensation/diamond dressing, height adjustable by 22 mm, Wet grinding unit with 50 l cooling pump, 60 l automatic paper belt filter, Distance measurement in the Y/Z axis via rotary encoder

Condition: good (used), Year of construction: 1992, Favretto MB 130 – Technical Specifications Machine type: tangential (horizontal) surface grinding machine Year of manufacture: 1992 Table size: 1700 × 400 mm Magnetic chuck size: approximately 1300 × 400 mm Magnetic plate height: 40 mm Longitudinal travel (X-axis): 1380 mm Cross travel (Y-axis): 450 mm Vertical travel (Z-axis): 550 mm Distance between spindle center and table surface: 203 mm (min) to 753 mm (max) Grinding wheel dimensions: 400 mm diameter × 152 mm width × 100 mm bore Gbedet Rwvzopfx Abdeg Spindle speed: approximately 1400 rpm Longitudinal feed rate: 2000 to 40000 mm/min Cross feed rate: 50 to 3000 mm/min Vertical feed rate: 700 mm/min Grinding head motor power: approximately 15 kW Total installed power: approximately 25 kW Maximum table load without magnetic chuck: approximately 1500 kg Maximum table load with magnetic chuck: approximately 1205 kg Overall grinding capacity (L × W × H): approximately 1500 × 600 × 550 mm Machine weight: approximately 7100 kg

Condition: as good as new (ex-display), Year of construction: 2025, GT25 - The OPTIMUM premium NC sanding machine with Siemens touch screen. - Electromagnetic clamping plate for fixing the workpiece with automatic demagnetization function - High-quality spindle with precision tapered roller bearings - Hardened and ground table guideways - Turcite-B coated counter guides for high wear resistance and low friction - Grinding spindle with high-quality precision bearings - Grinding wheel can be resharpened directly on the machine using a sharpening device - Digital position indicator - Machine base made of sturdy torsion-resistant cast iron for maximum rigidity and stability - Guideways for longitudinal, transverse and vertical movements are backlash-free and self-centring as V and flat tracks - Precision recirculating ball screws - Guideways and transport spindle with central lubrication - All flat guides are finely scraped and thus guarantee maximum precision of all manual movements - Safety electrics with 24 V DC voltage - Large decoupled handwheels in all three axes - Hydraulic lines according to DIN EN 853 - Sanding accuracy: 0.005 mm - Grain 46 corundum grinding wheel for all common steels - Swivel-mounted control panel makes work considerably easier - Separate hydraulic unit with heat exchanger, avoids vibrations and thermal stress - Two-channel safety electronics - Grinding table splash guard - EMC filter class - With IE3 motor - consumes considerably less energy, resulting in significant cost savings Technical data: Dimensions and weights Length approx. 2300 mm Width/depth approx. 1600 mm Height approx. 1675 mm Weight approx. 1700 kg Electrical data Total connected load 3 kW Supply voltage 400 V Gbjdpfxew Eayhe Abdeg Phase(s) 3 Ph Oc8fv Current type AC Mains frequency 50 Hz Surface grinding table Length 254 mm width 508 mm Grinding wheel(s) Outer diameter 200 mm width 20 mm Bore 31.75 mm Peripheral speed 33 m/s Spindle Speed 2850 min¯¹ Concentricity 0.005 mm X-axis Feed speed 5 - 25 m/min PU 1 Scope of delivery Unit of measure: piece Packaging unit: 1 Digital position indicator Coolant device Balancing mandrel Grinding wheel grit 46 Diamond pin Operating tool Manual oil pump LED lamp Electromagnetic clamping plate Demagnetizing function Equipment Electromagnet clamping plate Splash guard table enclosure Automatic demagnetizing device Parallel dressing device Coolant device 40 W Work light LED lamp Alignment feet
