Used Dowel Insertion for sale (2,161)

Condition: ready for operation (used), Technical characteristics Single column unloader with suction cups. It is suitable for unloading in machining lines requiring machines with reduced dimensions. BODY OF THE MACHINE The machine is composed of a vertical column, a horizontal bracket fixed to the carriage, a carriage fixed to the bracket and a suction cup holder frame unit. The carriage slides on linear guides equipped with ball bearings and is driven by a gear motor controlled by a frequency variator. SUCTION CUPS PANEL COLLECTION GROUP It consists of a suction cups row containing 10 suction cups with bellows to facilitate the separation of the panel. Suction cup diameter of 95 mm. The suction cups are operated by a vacuum pump with a flow rate of 22 m3/h. ELECTRICAL CABINET The machine is equipped with a separate electrical cabinet, managed by a PLC operating logic. PROTECTIONS FOR THE PREVENTION OF WORK ACCIDENTS The machine is protected on all the action perimeter of the suction cups group by protective panels. The battery insertion area is protected by a grid with button opening. DIMENSIONS OF THE WORKABLE PANELS : Length: 320 to 2700 mm Width : 250 to 700 mm Thickness : 12 to 50 mm Maximum weight : 50 kg Pneumatic brake idler roller LOAD TRANSFER IN SINGLE LONGITUDINAL ROW Transfer of introduction with inclined rollers to the left, covered in PVC. The rollers are driven by small belts activated by a gear motor under the control of a speed variator. The transfer is also equipped with a left hand guide adjustable by handwheel. Structure The structure is made of welded steel, reinforced to ensure maximum stability and precision during the operating phases. Work surface The worktop is made up of a transfer in four independent sections. The first section includes : An input transfer with flat belts driven by an asynchronous motor controlled by a frequency converter The second and third sections (drilling planes) each include: A belt transfer with: flat belts driven by asynchronous motor controlled by frequency converter A lateral reference guide, installed on the left side of the machine, with lateral stop function Pneumatic end stops for the positioning of right and left panels A lateral presser guide to guide and clamp panels of different widths against the lateral reference stop. The fourth section includes: a belt transfer for the evacuation of the panels with : flat belts driven by asynchronous motor controlled by frequency checker. Machining center The first center consists of a mobile carriage along the X axis on which two independent drilling heads are installed along the Y and Z axes. Each drilling head is composed as follows: In the X direction, 10 independent vertical chucks In the direction of the Y axis, 9 independent vertical mandrels The second center consists of a mobile carriage along the X axis on which two independent drilling heads are installed along the Y and Z axes. Each drilling head is composed as follows: In the X direction, 10 independent vertical chucks In the Y direction, 9 independent vertical spindles. Each operating head is suitable for the installation of an additional operating unit to be chosen as an option Axis movements Precision linear guides with circulating ball bearings and brushless motors for X,Y,Z axes. Rectified helical rack coupled to two pinions to allow the recovery of the play along the X axis. Hardened and ground ball screw (Y,Z axis). Pneumatic balancing device (Z axis) of the drilling unit. Numerical control XNC model bas Fpedsk Rticjpfx Ab Uor

Condition: reconditioned (used), Year of construction: 1997, functionality: fully functional, machine/vehicle number: 690924, Connected load 380V 1,84kW speed 2840 rpm number of spindles: 21 pieces, pitch 32 mm spindle distance 640 mm spindle rotation direction 11xright 10xleft M10 thread 2x safety clamps Fpjdpfeh U Damsx Ab Usr pneumatic foot valve table size 880 x 400 mm 1x side stop with 2 folding stops 1x basic fence 1x miter fence Unfortunately, we cannot answer inquiries without complete contact information.

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 1320x1220x1400 mm Weight 275 kg Total power requirement 1,5 kw Fpodovz Eibopfx Ab Uer

Condition: used, Year of construction: 1979, machine/vehicle number: 4015, Spiraleindrehmaschine - Spiral insertion machine Renz DPSTYear 1979 - Serial-No. 4015 Online-Video-Inspection by Skype-Video We would be very pleased with your visit - more machines on Stock Available Immediately - Can be inspect Fpjdpfx Absh Axnye Usr On Stock Emskirchen / Nürnberg - Can be test

Condition: new, Year of construction: 2025, Advantages of Pre-glued Dowels • No additional glue required when inserting dowels • No cleaning required for the water supply system Advantages of the DübelJet • Recoil-free gun • Simple handling • Mobile handheld device Fpjdpfx Abowu Dnnj Ujr • Universal application range Technical Data of the DübelJet Dowel system and water supply system designed for pre-glued dowels • Dowel diameter: 8 mm • Dowel length: 35 mm (default setting, adjustable from 30 to 40 mm) • Dowel projection: 12 mm (default setting, adjustable from 7 to 20 mm) Universal application • Insertion of pre-glued dowels (with water), especially in furniture manufacturing • Insertion of positioning dowels (without water) made of wood or plastic, e.g., in frame construction or in combination with screws or cabinet connectors

Condition: used, Year of construction: 2007, Gebhardt roller curve conveyor 45° 610-550 with inclined inlet 45° RA1279 The Gebhardt roller curve is from 2007 and in a good (used) condition. It has an engine of the brand SEW. Supports and side guides are not included in the scope of delivery. These are optionally available. Technical data: Manufacturer: Gebhardt Type: 314.01 Position: 010.05.1 Built: 2007 Fpsdpfsk Aa Rrex Ab Uor Condition: very good (used) Engine: fully functional Angle: 45° Nominal/outer width (NB):610mm Usable width (NUB): 550 mm Engine Type: SEW Gear Motor Engine Power: kW 0.37/S1 Hz 50 A 2.00/1.15 Funding speed: 0.35 m/sec Drive: Head drive Rolls: Type: G6/50 sliding bearing with conical plastic molded part Weight: 45 kg Scope of delivery: without supports and side guide (if necessary please enquiries) Optional Price plus VAT from central warehouse Dr. Sonntag KG 97076 Würzburg Payment: after invoicing with advance payment Delivery time: approx. 3 - 5 working days after receipt of payment Für eine individuelle, fachmännische Beratung setzten Sie sich einfach mit uns in Verbindung. Kontaktieren Sie uns einfach telefonisch oder per Mail. Wir helfen Ihnen gerne bei der Planung und Umsetzung Ihrer Projekte. Wir freuen uns darauf von Ihnen zu hören. Mit freundlichen Grüßen Ihr Team der Dr. Sonntag GmbH & Co. KG Ihr Spezialist und Ansprechpartner für Intralogistik

Condition: used, Year of construction: 1979, from school operationused, good conditionmake Ayentype DB 1000 K 23year of construction 1979machine no. 7SA740GS-testednumber of spindles 23 piecesnumber of drilling beams 1spindle distance / grid 32 mmdrilling from aboveswiveling pneumatichole line drilling devicestorage location 97447 Gerolzhofen, free loaded, unpackeddelivery in as-is condition as viewed,without warranty and guarantee Fjdpsvxr Rajfx Ab Uopr

Condition: reconditioned (used), Year of construction: 1990, Motors 2x1.85A 50Hz 380V 2800 rpm Air operating pressure 6 bar 30 spindles D=10 mm mount Combination foot switch Emergency stop switch Main switch Manual height adjustment Fpedpfsv Nptmox Ab Usr Manual side adjustment

Condition: refurbished (used), Year of construction: 1996, operating hours: 350 h, functionality: fully functional, Universal Dowel Hole Boring Machine DB 4 Fpedpfxewq S E Ho Ab Uor This used SCHEER Universal Dowel Hole Boring Machine DB 4 has been functionally tested (not newly painted). Worn parts/seals have been replaced, and the machine geometry was reset to ensure the highest precision. The SCHEER Universal Dowel Hole Boring Machine DB 4 is specifically designed for construction drilling, for series drilling in the 32 mm grid system, and for drilling fittings of various kinds; it enables all these tasks to be performed quickly, precisely, and with minimal setup times. Easiest operation via symbols and 4 program preselection controls for switching to new working processes in seconds. Central adjustment of the removable side stops always ensures flush alignment at the front edge for precise drilling of left and right workpieces. It does not matter whether the parts are cut to size or in square. The dowelled corner connection is always flush—both at the edge and at the CNC machines—just as simply and quickly as with a SCHEER DB 4. Safety clamping device across the entire table width, clamping of workpieces directly at the drilling bar. Stop rail with three adjustable flip-stops. Continuous table supports facilitate feeding and drilling of long workpieces; foldable workpiece support tables make series and fitting drilling easier. 2 drilling units Drilling motor Type BM 602-230/400 Volt, 50 Hz, n = 2860, 2.2 kW power 25-spindle attachment gearbox Spindle spacing 32 mm (other spindle spacings on request) For surface and face drilling. The vertical drilling unit is equipped with an oil brake for tear-free drilling of series holes. The control cabinet of the machine has been completely rebuilt and converted to the new SIEMENS LOGO control system. This ensures the operational safety of the machine for the future! Portal passage: max. 950 mm Working length: max. 2360 mm With pneumatic comb adjustment

Condition: reconditioned (used), Year of construction: 1997, functionality: fully functional, Schleicher 3 unit drilling machine after lignum renovation. Fedpfxot Ndzns Ab Uspr Machine equipped with upper units 3 pieces .Pneumatic pressure .Working realized by forcing the button unit the rest of the automatic .Choice of units possible each one or all .Speed and depth of drilling the possibility of setting .Machine after major repair .New electricity and driver .Net price vat invoice warranty one year .The machine can be additionally equipped with rulers bumpers pressures and drilling heads of any spacing .

Condition: used, HIGH SPEED DOWEL CROSS-CUT AND CHAMFERING MACHINE LOSER MOD. AA220 - Range of working diameter: 6 - 18 mm - Capacity: about 7,500 - 15,000 dowels/hour Fpsdpeqpdkcjfx Ab Uor

Condition: excellent (used), 19 Drill You can call or write to us. We can speak and write German and Russian. You can also send messages in English Fpedpoucqacefx Ab Uor 5.1.5

Condition: used, usedmanufactured by Gannertype Superdrillnumber of spindles 19 piecespindle distance / grid 32 mmhydraulic feeder brakeguide fences 2 piece length ca. 3,0 m / 1,5 mworking width 640 mmdrilling depth 95 mm / 110 mmdrill chuck D 10 mmpendulum fence 6 piececlamp 3 piecedrilling unitframe dowel unitrequired space ca. 1400 mm x 900 mm x 1200 mmtotal connected power 1,5 kWlocated in 97447 Gerolzhofen, free on truck, unpackedsale in current condition as seen,without revisionwithout guarantee and warranty Fpedpfx Absvwf R Ro Ujr

Condition: good (used), Year of construction: 1982, functionality: fully functional, Power 380V 3.3A Motor power 1.1kW 2800 rpm Automatic pneumatic control with control panel Drill head with 23 spindles, pitch 32 mm Drill hole depth adjustable drill shaft 10 mm Fsdpfxsq Auwtj Ab Uspr position adjustment 5-60 mm Clamping height 80 mm Passage width 800 mm Dimensions: 1200 x 900 mm Weight approx. 400 kg 1x setting gauge row bore 1x setting gauge side stop 1x stop ruler 1500 mm 1x fence 2000 mm

Condition: good (used), Year of construction: 1984, Dowel Drilling Machine AYEN SKB 50 Manufacturer AYEN Model SKB 50 Year of manufacture 1984 S/N 8411346 Total 50 spindles in (2) swivel heads with (25) spindles each drills vertically from above and horizontally from behind drills in any angle between 0° - 90° with a positive stop at 45° working width 768mm / passage 1000mm 50-spindle swivel head assembly quickly converts to (2) 25-spindle heads for double row drilling, 5-1/8" minimum distance between heads for row drilling. 3 HP - 3,450 RPM gear motor, 39" plate width with a 30-1/4" drilling width. Complete with: (2) 39" stops with flip stops, (3) pneumatic "Quick Set" hold-downs, Foot pedal control for drill cycle/head positioning. Fjdpfx Aokcfcaob Uepr Motors, 3 phases, 380 V / 50 Hz Compressed air consumption 9l / cycle Weight 490 Kg

Condition: good (used), Year of construction: 1989, functionality: fully functional, We sell an automatic hinge installation device. Device from 1989. Siemens controller and Simatic panel installed on the device in 2015. Hinges were installed on the outer frames of the Wood-Aluminum window with the device. Fpedpfxsu Hxtue Ab Uor Device is in good condition. The price of the device is to be offered by the buyer. Buyer is responsible for transportation and dismantling. If you have any further questions, please contact us about the production equipmen

Condition: good (used), Year of construction: 2003, BORING/DOWEL-INSERTING MACHINE WITH PANEL TURNER SYSTEM TECHNICAL FEATURES: BORING UNIT WITH 5 + 3 SPINDLES NR.2 AUTOMATIC HINGE FEEDERS NR.1 VERTICAL LOADER WORKING FIELD MIN/MAX X MM. 250/2500 WORKING FIELD MIN/MAX Y MM. 130/700 MIN/MAX WORKABLE THICKNESS MM. 15/50 SPINDLE ROTATION SPEED 4000 RPM Fpodpfxoiy D U Io Ab Uer WORKING AIR PRESSURE 6 BAR CONTROL: NC 1000 DIMENSIONS: MM. 7530 X 3500 WEIGHT KG. 2500

Condition: used, Year of construction: 1983, with 2 drilling beamused, good conditionmanufactured by Scheertype DB 3built in 1983Masch.-No. 83120number of spindles 25 piecenumber of drilling beams 2Spindelabstand / grid 32 mmdrilling from tophydraulic feeder brake 2 pieceguide fence 1 piece ca. 2500 mmworking width ca. 800 mm (768mm)drilling depth ca. 100 strokedrill chuck M 10pendulum fence 3 piececlamp 3 piecedrilling programs 4 piecerequired space ca. 1400 mm x 1300 mm x 1800 mmweight ca. 1000 kglocated in 97447 Gerolzhofen, free on truck, unverpacktsale in current condition as seen,without revision,without guarantee and Gewährleistung Fpjdpsvwf N Hsfx Ab Uer

Condition: good (used), Selection and feeding groups for zama Feeding, insertion/screwing, or free exit with or without the aid of a linear channel where they are presented to be taken by grippers or pick and place manipulators to be positioned on the system. Fedpevvh Enjfx Ab Ujpr composition: nr. 2 insertion groups nr. 4 magazines/vibrators Further information on request

Condition: used, Year of construction: 1977, used manufactured by Ayen type DB 1000 K2 built in 1977 Mach.-No. 751212 Fsdpevwgagsfx Ab Uopr number of spindles 23 piece number of drilling beams 1 drilling from top tiltable pneumatic comb lowering pneumatic drill chuck D 10 mm clamp 3 piece grid 32 mm required space ca. l x w x h mm 1200 x 800 x 1600 weight ca. 370 kg total connected power 2,2  kW located in  97447 Gerolzhofen sale in current condition as seen - free on truck -

Condition: used, Year of construction: 1980, second hand Make Scheer Type DB 5 Year of construction 1980 Machine no. 508054 Number of spindles 21 pieces Number of drilling beams 1 drilling from below pivoted manually Working width 800 mm Drilling depth 80 mm Tensioner 2 pieces Pitch 32mm Space requirement approx. LxWxH mm 1200x800x1300 Weight approx. 300 kg Total connection value 2.2 kW Storage location 97447 Gerolzhofen Handover in the current condition as seen - free loaded - Fpsdsvwfuvjpfx Ab Usr

Condition: used, Year of construction: 1989, with many drills used, top condition Make Hoffmann Type DB 23 Year of manufacture 1989 Machine no. 169 Number of spindles 23 Fodpfx Aovyurcsb Ujpr Number of drilling beams 1 Spindle spacing / grid 32 mm Drilling from below stroke 60 mm Stop rulers with central adjustment Working width 704 mm (1080 - portal passage) Drilling depth 70 mm horizontal Drill holder M 10 / cone 30° Space required approx. 1300 mm x 1000 mm x 1300 mm Weight approx. 500 kg Storage location 97447 Gerolzhofen, free loading, unpacked Handed over in the current condition as viewed, without guarantee and warranty

Condition: used, mileage: 85,000 km, power: 85 kW (115.57 HP), first registration: 08/2014, overall weight: 1,975 kg, fuel type: diesel, color: white, next inspection (TÜV): 08/2027, gearing type: mechanical, emission class: euro5, Year of construction: 2014, total length: 4,709 mm, total width: 1,823 mm, total height: 1,600 mm, number of seats: 5, Equipment: ABS, air conditioning, central locking, electronic stability program (ESP), soot filter, 1st owner. Emergency vehicle command car KdoW / operations command vehicle ELW ELF of a German aid organization. Only 85,000 total kilometers driven. With service booklet. Last service at 81,477 km. MOT (TÜV) recently renewed, valid until 08/2027. Special signaling system: HELLA RTK 7 blue lightbar with control unit and 2 front flashers. Fsdpfxjxfnbko Ab Uspr Technically, essentially a standard passenger car estate with 5 seats. Registered (previously tax exempt) as a "passenger car estate with fixed blue revolving beacon and audible warning system installed." Unladen weight: 1,367 kg. Permissible gross vehicle weight: 1,975 kg. Economical 1.6 TDCI Duratorq diesel engine with 1,560 cc, 115 hp, Euro 5. 6-speed manual transmission. Air conditioning. Central locking (2 remote keys). 2 x airbags. Heated windshield and washer jets. Heated seats for driver and front passenger. Radio. Fitted with good winter tires (front from 2024, rear from 2020) with snowflake symbol according to latest regulations. A second set of wheels complete with rims is included (however, this extra set is no longer in good condition). We drove the vehicle 700 km on the motorway without any issues. The Ford runs very reliably and quietly. Minor signs of use present. Ideal vehicle for an aid organization seeking an affordable used emergency vehicle with relatively recent year of manufacture in good condition. This Ford Focus emergency vehicle is available from us immediately. This offer is valid only for commercial customers and authorities or BOS organizations. Subject to prior sale and errors. The purchase price does not include 19% VAT, nor can this be deducted. Taxed under the margin scheme according to §25a UStG, final gross = net price.

Condition: excellent (used), Flexible N.C. automatic line for drilling, routing and inserting (hardware). Numerical control with Albatros software. Consisting of: KZ2046) Infeeder with hedgehog (buffer) store (18 positions) KZ2047) Transfer with motorised conveyoring belt KZ2048) CNC Mod. Vector GLR-X 30-13 KZ2049) Transfer with motorised conveyoring belt KZ2050) CNC Mod. Vektor XK 40-13 KZ2051) Transfer with motorised conveyoring belt Fpedpfxoidmkre Ab Usr KZ2052) CNC Mod. Idrak 3 KZ2053) Transfer with motorised carpet with 90° inclination on a rollers table KZ2054) Rollers conveyor with also motorised belts (to move panels at 180° to the assembly lines)

Condition: excellent (used), Double-sided machine, which can be placed in line after a through-feed Multi Borer for the automatic processing cycle of boring and dowels inserting - Electronic Programmer "CNI" NC 400 - Built-in command and electric cabinet - Max. distance between the horizontal heads mm 3200 approx Fpjdpfx Absw Ug A Hs Uer - Movable and adjustable right side of the machine (according to the width of the panels) - No. 2 motorized conveyoring belts (HP 0.25 x 2 motors) - No. 1+1 dowels storage tanks for the automatic feeding to the nozzles - No. 6+6 horizonal inseritng nozzles (Glue injectors and dowel drivers) - High-pressure Glue-feeding system - Total installed power KW 5 ca.
