Used Heavy Drill Machine for sale (67,890)

Condition: ready for operation (used), type of input current: three-phase, spindle mount: MK 4, total width: 920 mm, total length: 2,310 mm, total height: 2,590 mm, overall weight: 3,962 kg, Kitchen and Walker Radial Drill Model: E2 5’-0” Spindle Taper: No 4 Morse Spindle Speeds: 25-1560 RPM Radius Of Spindle: Max: 1575mm Min: 430mm Traverse Along Arm: 1170mm Hsdpfx Aez S Nndjndenu Spindle To Base Plate: Max: 1257mm Min: 152mm Machine With: Coolant and Fittings Safety Brake Box Table Ammeter Dimensions: 2310 x 940 x 2590mm Weight: 3962 Kgs

Condition: used, Column drilling machine ALZMETALL, type AB 3 ESV Machine no. 15967, year of manufacture 1977 Drilling capacity 32 mm Spindle mount MK 3 – short quill Distance from spindle nose to table 545 mm (short quill) Distance from spindle adapter to table 395 mm (MK adapter) Overhang 290 mm Quill stroke 160 mm Table size Ø 545 mm Column diameter 220 mm Spindle speed 55 – 1450 rpm, continuously variable Motor power 1 / 1.6 kW Power connection 380 volts, 50 Hz - Spindle speed controlled via 2 gear stages, 2 motor speeds, and continuously variable via a variator gearbox - Pre-selection stage for high torque at low speeds - MK adapter from MK3 to MK4 Hedpfx Aoharwvjndsnu - Automatic feed 0.1 - 0.2 - 0.3 mm/rev - Rotatable drilling table - Table height adjustment via hand crank - Heavy machine base with machined workpiece support surface (not original Alzmetall) - Lighting for the work area Space requirement L x W x H 1150 x 650 x 2000 mm Weight 850 kg Good condition

Condition: used, Year of construction: 1956, total width: 900 mm, total length: 2,050 mm, total height: 2,100 mm, Colour: Green Empty weight: 2.400 kg - Year: 1956 - Serial number: 3706 - Drive system: Conventional - Drive system: Gear drive - Number of drills [pcs]: 4 - Power [kW]: 6 - Table type: Fixed table - Table length [mm]: 1800 - Table width [mm]: 350 - Drilling depth [mm]: 160 - Drilling capacity [mm]: 25 - Reach [mm]: 275 Hodjz R Dt Eepfx Andsnu - Main spindle power [kW]: 6.0 - Min. spindle speed [rpm]: 180 - Max. spindle speed [rpm]: 2000 - Options: Tapping function - Transport dimensions: 2050mm x 900mm x 2100mm (l x w x h) - Transport weight [kg]: 2400kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: used, Box column drilling machine WEBO Series- No 132 Machine No: 9 Drilling capacity 50 mm Spindle cone MK 5 - long quill throat 430 mm spindle stroke 280 mm Height adjustment of drill head 500 mm Table size Ø 725 mm Distance between drill spindle and table max. 740 mm Distance between drill spindle and clamping surface on machine base max. 1240 mm Spindle speed 55-820 rpm Feed rate level 1 0.13 - 0.2 - 0.27 - 0.4 mm/rev. Feed rate stage 2 0.6 - 0.83 - 1.17 - 1.8 mm/rev. Column diameter 300 mm Motor power 2.8 / 3.6 kW pole-changing Mains connection 380 Volt, 50 Hz - Spindle speed via 2 motor speeds and infinitely variable via variator Hodpfsqa Txqjx Andsnu - Manual drill head height adjustment via hand crank, clamping with clamping screws - Rotatable drill table with mechanical clamping - Table height adjustment via hand crank - Clamping surface on machine base 600 x 550 mm Top height of drill head 3020 mm Overall height drill head bottom 2520 mm Space requirement L x W x H 1400 x 780 x 2520 mm Weight 1600 kg good condition

Condition: good (used), Year of construction: 2001, bore capacity in steel (diameter) 40.0 mm bore capacity in cast iron 55.0 mm throat 335 mm bore stroke 200 mm bore spindles - Morse Taper MK 4 turning speeds 60 - 1.530 U/min table: 740 x 620 mm feed 0.15/0.2/0.3/0.36 mm/U total power requirement 2.6 / 3.1 kW weight of the machine ca. 850 kg range L-W-H 800 x 1150 x 2040 mm Machine comes from a vocational training workshop Good condition (!!) Features: - Heavy-duty/robust bench-mounted drill press - Drive: "VARIO" V-belt - Automatic spindle feed (0.15/0.2/0.3/0.36 mm/rev) - Stepless speed adjustment - 2 work tables with T-slots * Height-adjustable via hand crank - Adjustable drilling depth stop Hjdpfx Anjz S N Dxsdenu - Pole-changing motor - Machine light - Emergency stop button, front - Operatorâ??s manual

Year of construction: 2003, condition: not inspected (used), functionality: unexamined, clamping length: 3,200 mm, pipe diameter (max.): 30 mm, HEBÖ RBV 12 Pipe Drilling Machine - Through-hole diameter of the chuck: 30 mm Hnedpfx Ajz Spx Ajndou FCA D-35614 Aßlar - loaded onto a truck.

Condition: good (used), Year of construction: 2009, bore capacity in steel (diameter) 40.0 mm Hodpez R D Icofx Andonu thread cutting attachment M 30 spindle taper MT 4 MK table surface area 1200 x 500 mm turning speeds 50 - 2000 U/min arm length 1050 mm column diameter 220 mm spindle stroke - max. 200 mm feed range 0.08 - 0.50 mm/U distance spindle /table 760 mm weight 2740 kg range L-W-H 2450 x 2450 x 2800 mm Original price approx. 20.000 Euros Special price on request Equipment: - Robust electro-hydraulic radial drilling machine - Sturdy construction ensures vibration-free operation - Compact design with electro-hydraulic quick-clamping system - Infinitely variable speed adjustment (50–316 + 316–2000 rpm) - Digital speed display - Motorized height adjustment of the drill head - Drill head swivels 180° - Arm movable forwards/backwards and swivels horizontally - Clockwise/counter-clockwise spindle rotation - Manual & automatic spindle feed - Large work table with 3 T-slots - 1x heavy-duty machine vice * STANKO IMPORT "200-0225C" * Jaw width: 250 mm * Jaw height: 60.0 mm * Opening width: approx. 300 mm - Thread-cutting attachment - Separate coolant system - Front-mounted emergency stop button - T-slots for mounting on the side and rear of the machine - Operating manual

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, input voltage: 400 V, spindle mount: MK 4, drilling depth: 150 mm, total width: 500 mm, total length: 700 mm, overall weight: 290 kg, Equipment: documentation/manual, 3-phase 400V, 2-speed motor is running smoothly! Geared head with 8 spindle speeds. Spindle RPM adjustable from 75 to 3010. Motor runs in both left and right directions. Spindle power downfeed. 8 feed rates adjustable from 0.004 to 0.30 mm/revolution. Adjustable drilling depth. Maximum drilling depth: 150mm Hnodpfx Aezycqcendou MT4 spindle mount. Tool ejector. E-Off switch. Head and table are height-adjustable. Table size: 500x400mm Good overall condition. Made in Sweden. Year of manufacture: 2008 Weight: 290KG Overall dimensions: 70x50x180CM Contact us for shipping options! €2,850.00

Condition: new, Year of construction: 2025, Heavy-duty, solid cast-iron construction High running smoothness due to ground, oil-bath lubricated gears Right-hand/left-hand operation Automatic quill feed with manual fine feed Motorized positioning of the Z-axis Motorized table feed of the X-axis Coolant system Machine lamp Hedjg U Uv Uepfx Andjnu Gear head can be swiveled ± 60° Adjustable wedge strips Solid dovetail guide for the column, hand-scraped, for maximum stability and precision Height-adjustable, large-sized protective shield with microswitch Drilling depth stop Digital position display DRO 5 Drilling/tapping function Solid and large-sized cross table, precisely surface-finished with T-slots and adjustable wedge strips Solid machine base made of cast iron with chip collection groove Single-stage, high-quality industrial electric motor Large speed range of 60 - 2,760 rpm through 2 continuously adjustable speeds Dimensions and weights Length approx. 1600 mm Width/Depth approx. 930 mm Height approx. 2110 mm Weight approx. 495 kg Drilling/Milling performance Arbor size max. 63 mm Shell mill size max. 26 mm Drilling capacity steel (S235JR) 24 mm Continuous drilling capacity steel (S235JR) 20 mm Electrical data Connection voltage 230 V Mains frequency 50 Hz Electrical connection Total connected load 1.5 kW Milling table, horizontal Length 800 mm Width 240 mm Distance Vertical spindle - Milling table max. 420 mm T-slot size 14 mm Number of T-slots 3 T-slot spacing 80 mm Standards and approvals Standard DIN EN 55011 EMC class C2 Travel X-axis manual 560 mm Y-axis manual 195 mm Z-axis manual 350 mm X-axis automatic 480 mm Vertical spindle Overhang 258 mm Spindle mount MK 4 Speed range 60 – 2760 rpm Number of speed ranges 2 Speed control Steuerung der Drehzahlregelung electronic Draw bar M 16 Swivel range milling head Z - X plane ± 45 ° Quill diameter 75 mm Quill stroke 120 mm Location: In stock at 54634 Bitburg - available immediately -

Condition: good (used), Year of construction: 1982, bore capacity in steel (diameter) 35.0 / 40.0 mm throat 300 mm bore stroke 180 mm turning speeds 65 - 1750 U/min table-size 515 x 400 mm column diameter 155 mm spindle taper MT 4 MK engine output 0.9 / 1.3 kW weight 450 kg range L-W-H 800 x 650 x 1850 mm Features: - Heavy-duty column drill press - Drive: "VARIO" V-belt * Stepless speed adjustment - Manual spindle feed - Reversible motor - Clockwise rotation of the drill spindle - Adjustable fixed depth stop - Machine table with 2 T-slots * Height-adjustable via hand crank - Machine light - Emergency stop button on the front - User manual (PDF) Hsdpsz S N D Ssfx Andenu

Condition: good (used), Used horizontal boring mill/drilling machine by Cornac Hnodpsz Iarqsfx Andou Type BS 65 Spindle diameter 65 mm Table dimensions approx. 600 x 1000 mm X / Y / Z = 1000 / 800 / 650 mm

Condition: good (used), Year of construction: 1985, bore capacity in steel (diameter) 35.0 / 40.0 mm throat 315 mm bore stroke 180 mm turning speeds 130 - 3500 U/min table-size 615 x 470 mm column diameter 155 mm feed 0.1 / 0.2 / 0.3 mm/U spindle taper MT 4 MK engine output 2.0 / 2.4 kW Hnsdoz S N Drepfx Andeu weight 450 kg range L-W-H 800 x 650 x 2100 mm Features: - Heavy-duty column drill press - With extended column (200 mm) - Drive: "VARIO" V-belt * Continuously variable speed control - automatic spindle feed (0.1/0.2/0.3 mm/rev) * with electromagnetic engagement - pole-changing motor - clockwise rotation of the drill spindle - adjustable fixed drill depth stop - Machine table with 2 T-slots * Height-adjustable via hand crank - Machined base plate - Coolant system in the machine base - Machine light - Emergency stop button on the front - Operating instructions (PDF)

Condition: used, Year of construction: 1990, Archdale Radial Drill. Spindle speeds 475-2000. Box table Power Rise and Fall DC Injection Spindle Break Hodoz Hfdvspfx Andenu Speeds 4-2000 rpm 8 Hp.

Condition: good (used), Year of construction: 2000, Donau Danuflex 145 Donau Danuflex 145 high-speed radial drilling machine, year of manufacture 2000, in SUPER condition CE compliant!! Technical data: Year of manufacture: 2000 Drilling and threading capabilities Drilling capacity in steel: approx. 42 to 45 mm Threading: up to M36 Tool holder / spindle: MK 4 Spindle speed: 15 to 2,800 rpm (infinitely variable) [1, 2, 3] Travel distances & work area Outrigger travel: 1,050 mm Drilling radius: min. 540 mm / max. 1,590 mm Quill stroke: approx. 200 to 220 mm Column stroke (W-axis): approx. 450 mm Column diameter: 195 mm Table & dimensions Work table: typically approx. 1,200 x 750 mm with 5 T-slots Work table height: approx. 905 mm (ergonomic design for standing operation) Feed: automatic / stepless quill feed with electromagnetic feed clutch Equipment (standard): Threading device, hydraulic clamping for outrigger and lifting column, central lubrication and machine light Accessories and equipment: Several work tables Hnsdpfx Anoz Rwpyedju About the machine: Offered is a Donau Danuflex 145 high-speed radial drilling machine. This high-speed radial drilling machine is in very good original condition. It comes from a company where it was only used for training purposes. It has a very easy-to-use control system. Up to 3 fixed machining stations ensure maximum flexibility in the machining of workpieces, both large and small, as well as very long parts. Swivel tables allow the machining of angled bores. Large travel distances and workpiece heights up to 1500 mm are ensured. Effortless, simultaneous positioning to a drilling position in 3 axes. A self-centering spindle head positions itself precisely in centering bores. Concentric countersinking is achieved by self-centering countersinks in the bore. The guides are regularly lubricated by the central lubrication system. The Donau has been mechanically and electrically tested by us. Take the opportunity to inspect and try out the Donau on site under power. You can find more drilling machines from well-known manufacturers on our website.

Condition: new, Year of construction: 2026, Heavy-duty design for the entire machine High running smoothness thanks to a new spindle design Industrial motor Separate emergency stop switch Drill depth stop LED machine light integrated into the drill head Precisely machined, stable drill table with diagonally arranged T-slots and an all-around coolant channel Drill table can be tilted ± 45° and rotated 360° V-belt cover with safety switch Precision spindle bore Machine control and safety electronics in 24 V DC Guaranteed concentricity accuracy ≤ 0.02 mm measured in the drill spindle Thick-walled steel column for high force absorption and stability Massive, generously sized base plate with T-slots Dimensions and weights Column diameter 92 mm Length approx. 945 mm Width/Depth approx. 485 mm Height approx. 2040 mm Weight approx. 162 kg Drilling capacity Drilling capacity in steel (S235JR) 30 mm Continuous drilling capacity in steel (S235JR) 25 mm Drill table Working surface length 355 mm Working surface width 355 mm Type of T-slots diagonal T-slot size 14 mm Number of T-slots 2 Rotation 360° Tilt 45° Distance spindle - drill table max. 784 mm Speed range Speed range 120 – 1810 min⁻¹ Number of speed ranges 9 Electrical data Connection voltage 400 V Hnodog Uaiuopfx Andeu Mains frequency 50 Hz Machine base Distance spindle - machine base max. 1470 mm Working surface length 230 mm Working surface width 300 mm T-slot size 16 mm Number of T-slots 2 Spindle Quill stroke 125 mm Spindle mount MK 4 Overhang 270 mm Location: In stock at warehouse 54634 Bitburg - immediately available -

Condition: good (used), Csepel RF50/1250 Radial Drilling Machine Robust and reliable radial drilling machine from the reputable manufacturer “Csepel”, model RF50/1250. Hnodpjzninwofx Andou This machine is characterized by its solid construction and is ideal for workshops, metalworking shops, or demanding DIY enthusiasts. Technical specifications (according to the nameplate): Manufacturer: Csepel (Budapest) Type: RF50 / 1250 Power supply: 3~ (three-phase / 380 V) Frequency: 50 Hz Control voltage: 220 V Operating current: 10 A Required fuse rating: 16 A, slow-blow You can find more new and used items in our shop! International shipping costs available upon request!

Condition: excellent (used), functionality: fully functional, type of input current: three-phase, year of last overhaul: 2024, Well-maintained drilling machine for sale due to expansion; it was also overhauled in 2024 and has been in our inventory since 2024. Hjdpfx Aezhby Sendsnu

Condition: ready for operation (used), functionality: fully functional, Outrigger drilling machine UCIMU RP 1580 MP -Outrigger arm approx. 2000mm Hnsdpfx Aoz S Nb Dondeu -Speed range (gearbox) 30 - 1200 rpm -Automatic feed -Drilling table 1300x650x700mm -Morse taper MK 5 -Electrical safety device -Coolant system -Work light -Quick-change tool holder & adapter mounts Dimensions: L x W x H 2.5 x 1 x 2.85 meters / Weight 4500 kg Errors and omissions excepted.

Condition: good (used), Friedrich Deckel FP 2 LB Tool Milling Machine The accessories are not included in the scope of delivery but can be purchased in another auction at this link. Lot of Milling Tools The universal milling machine Deckel FP 2 LB is characterized by its extremely stable base and is designed as a floor-standing machine. This means that the machine retains its precision even when machining heavy workpieces weighing up to 1000 kg. Another feature is the 45-degree inclined bed. After removing the universal table, this design allows for direct clamping and machining of V-engine blocks with a 90-degree cylinder angle, such as American V8 engines. Furthermore, the long travel of 800 mm is advantageous in this application. Technical data: Deckel Universal Milling Machine FP 2 LB Digital display: 3-axis digital display Heidenhain Travel X-axis: 800 mm Travel Y-axis: 300 mm Travel Z-axis: 400 mm Tool holder: SK 40 clamping thread S 20 x 2 Milling head type: Vertical milling head Speed range: 40 - 2000 rpm Number of steps: 18 Table type: universal swivel/tilt table (± 45° / ± 15°) Table clamping surface: 1000 x 520 mm T-slot size: 16 mm Vise 160 mm Connected load: 9.5 kVA Weight: approx. 1900 kg Dimensions: approx. 1570 x 1675 x 1850 You can find more new and used items in our shop! Hnedpfegyw S Tox Andsu International shipping costs available upon request!

Condition: used, Donau DR52 Drilling capacity in steel (diameter) 52 mm Arm length 1140 mm Workpiece height max. 830 mm Drilling capacity in cast iron 60 mm Taper MK 5 Hnodpfx Aez D U Tzsndeu Table size 1100 x 620 mm Drilling spindle stroke 225 mm Spindle speed range 28 - 1400 rpm Feed rate 0.1 - 0.5 mm/rev Total power consumption 10.0 kW Machine weight approx. 3.5 t Machine dimensions approx. 2.4 x 1.3 x 2.61 m

Condition: good (used), Alzmetall AC 32 Turret Double-Head Drilling Machine An extremely robust and rare double-head drilling machine based on two Alzmetall AC 32 drilling head units. This machine is a high-quality industrial design intended for highly efficient series or multi-stage machining. Instead of simple spindles, this machine is equipped with two separate tool turrets. This enables fully automatic machining cycles (e.g., centering, drilling, countersinking, threading) without the need for manual tool changes. Technical data & equipment (per head / overall machine): Manufacturer of drilling head units: Alzmetall (Germany) Model: AC 32 (Electronically controlled with digital display) Drilling capacity: max. 32 mm in steel Threading capacity: max. M 24 / M 30 Hnjdpfx Aoznic Uondeu Tool changer: 2 x pivoting turrets with multiple stations Machine table: Solid, ground cast iron table with T-slots for flexible setup Safety: Complete enclosure of the working area (protective cabin) with viewing windows for optimal chip and splash protection Additional functions: Integrated coolant system, compressed air blow-off gun, central counterweight system for easy vertical adjustment of the entire beam More items – new and used – can be found in our shop! International shipping costs on request!

Condition: good (used), Used column drill press VSF 40 NAK Capacity: 40mm Equipped with a cross table (operation of the coolant pump is unknown) Hjdoz H U Nbjpfx Andonu

Condition: used, Year of construction: 2005, Second-hand machine Year of manufacture: 2005 Features and technical specifications: - Motor: 400 V, 50 Hz, 3-phase, 1.5 kW - Pneumatic single-head drilling machine with 23 spindles - Aluminium ruler with 4 stops (2 profiles on the right/left, 1500 mm each) - with quick-action chuck Hnsdpfxszk N S Uo Andsu - 2 patented, accident-proof pressure clamping cylinders - Connection for extraction system in accordance with EC standards - Aluminium drilling beam, spindle centre distance 32 mm - Work table made of MDF and cast iron - Patented spiral system for fine adjustment of the drilling depth - Pneumatic drilling head oscillation with Lockable in any position between 0° and 90° - Fold-down side stops with fine adjustment via counters with decimal display - Drilling height adjustment via dial gauges with decimal display - Back stop, travel up to 300 mm - Fixed stops 37 mm for fitting pot-type band drills - Complies with EC standards - Max. drilling width 704 mm - Max. drilling depth 65 mm - Max. workpiece width 960 mm - Max. workpiece length 3000 mm - Max. workpiece thickness 60 mm Availability: at short notice Storage location: 63934 Röllbach

Condition: good (used), power: 1.1 kW (1.50 HP), overall weight: 200 kg, Prebomat, drilling head for fitting operations, with 7 spindles, in very good condition. Hnodpfjz N T Uijx Andeu

Condition: used, Second-hand machine Second-hand Ganner Compact 30 row drilling machine Features and technical specifications: 2 drilling beams, each with 15 spindles Pitch 32 mm Drilling unit position adjustment 0–650 mm Distance between rows of drill holes: at least 190 mm Spindle speed 2800 rpm Motor power 2 x 0.75 kW Maximum workpiece clamping height: 70 mm Hodpezk Nwdjfx Andjnu Working height 850 mm Compressed air connection 6 bar Availability: by arrangement Location: Solingen
