Used Milling Arbor for sale (9,827)

Condition: good (used), Double-end tenoner, edge processing machine, scoring motor, cutting motor, electric motor, spindle motor, milling motor Rcsdpsb A Nmpsfx Ah Uek -Power: 1.5 kW at 18000 rpm at 300 Hz -Shaft mounting: Ø 20 mm -Number: 1x motor available -Weight: 10 kg

Condition: excellent (used), Year of construction: 2003, Deep Hole Drilling and Milling Machine TBFZ 1600 CNC Year of manufacture: 2003 X-AXIS TRAVEL: 1600 MM Y-AXIS TRAVEL: 1200 MM Rcodjxz Aygjpfx Ah Usk Z-AXIS TRAVEL: 500 MM W-AXIS TRAVEL: 1200 MM B-AXIS TRAVEL: 360° (Rotary table) * Table size (LxW): 1500x1500 mm * T-slots: 5x DIN 650-22 h12, 150 mm spacing * Tool clamping: hydraulic * Electrical connection: 400 V, 50 Hz * Compressed air connection: rated flow rate 7000 l/min, operating pressure: 6 bar * Botek driller optionally available * Feed drive: brushless AC servo motors * Feed rate: 0-20000 mm/min * Rapid traverse: X 20000 mm/min, Y+Z 20000 mm/min * Manual mode: 20000 mm/min * Setup operation: 0-2000 mm/min

Condition: used, Year of construction: 2015, turning diameter 250 mm turning length 600 mm control FANUC Series 31i-Model A travel -x axis 180 mm travel -y axis +/-45 mm - - - - - Main spindle - - - - - - - - - - - turning speeds 0 - 5.000 U/min bar capacity 65 mm --- Subspindle --- - - - - - - turning speeds 0 - 7.000 U/min bar capacity 42 mm Rsdpfx Ajx I Shpjh Uock --- upper turret 1 --- - - - - - - numbers of positions in the tool changer 12 tool taper BMT 45 Number of axles X1 / Y1 / Z1 St. Tools speed 8.000 U/min --- upper turret 2 --- - - - numbers of positions in the tool changer 12 tool taper BMT 45 Tools speed 8.000 U/min Number of axles X3 /Y3 / Z3 St. --- lower turret 3 --- - - - numbers of positions in the tool changer 12 tool taper BMT 45 Number of axles X2 / Z2 St. Tools speed 8.000 U/min CNC Turning- and Milling Center | SPINNER - TTS 65 Triplex equipped with a main spindle and a sub-spindle, each including a C-axis, three triplex turrets designed for driven tools, as well as a bar feeder (Top Automazioni X-Files-S Series 3000, SX version). The machine has only 3.500h processing time hours. The machine is in good condition and can be inspected under power. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: TTS65Triplex | TTS 65Triplex | TTS-65-Triplex | TTS-65 Triplex

Condition: ready for operation (used), Year of construction: 1982, feed length X-axis: 700 mm, feed length Y-axis: 490 mm, feed length Z-axis: 250 mm, Heidenhain Visue, 3 axes ISO 40 spindle Table 1100x305 mm Travels 700x490x250 mm 7.5 HP Rcodpfxsxxmpme Ah Ujk Weight 2100 kg

Condition: used, Year of construction: 2001, Technical details: turning diameter: 33 mm turning length: 330 mm control: 840 total power requirement: 20 kW weight of the machine ca.: 6 t dimensions of the machine ca.: 3850,2000,2100 m 17 axes 3 revolvers with the powered tools 1 gantry with the driven tools Main and counter spindle with C axes Barfeeder Machine On-time 58,133 hours Redpfxew D Hh Aj Ah Uock *

Condition: excellent (used), Year of construction: 2014, operating hours: 2,050 h, functionality: fully functional, CNC Turning and Milling Center Okuma Multus U4000 2SW 1500 Control: OSP-P 300S-H Year of manufacture: 2014 Spindle hours: 2,050 h Travels: X-axis: 695 mm Y-axis with stroke: +150 / -150 = 300 mm Z-axis: 1,600 mm B-axis: 240°, positioning in 0.001° increments C-axis: 360°, positioning in 0.001° increments W-axis: 1,524 mm Turning diameter: 650 mm Turning length: 1,500 mm Tool holder: HSK 63 Total number of tool stations: 40 Rsdpfxex I D Ubj Ah Uock Equipment: XA and YA axes with direct absolute measuring system (Okuma ABSO-Scale) In-process measuring with Renishaw probe for X/Z axis Measuring in Y-axis, including inclined-axis measurement mode Kitagawa B215A11 max. 2,800 rpm Kitagawa B210A8 max. 4,200 rpm Hollow clamping cylinder Kitagawa F 2596-H01 Ø96 mm One-Touch IGF Multi-function tool software Harmonic spindle speed oscillation Simultaneous 5-axis machining software package Chip conveyor Coolant tank with high-pressure pump 70 bar

Condition: used, functionality: fully functional, Good day, We are pleased to offer you, without obligation, a used universal/vertical milling machine, model SH 4 D, manufactured by Steinel. Manufacturer: Steinel Model: SH 4 D with vertical milling head FVK 3 Machine no.: 8160 Travel range X-Y-Z axis: X = 300 mm, Y = 150 mm, Z = 250 mm Table size: 740 x 200 mm Clamping surface: 620 x 130 mm Spindle speed: 32 – 1250 rpm Feed rates: 0.2 / 0.32 / 0.5 / 0.63 / 1 / 1.6 mm/min Quill stroke / drilling spindle stroke: 100 mm Main motor power: 1.5 kW Rodex Rcpijpfx Ah Usck Weight: approx. 800 kg Space required: approx. 1,100 x 1,300 x 1,600 mm Control: conventional Note: The above technical data is taken from the operating manual, manufacturer’s brochures or other sources for which we cannot guarantee the accuracy or completeness. Scope of supply: 1 used universal/vertical milling machine, Steinel, type SH 4 D Field of application and condition: The machine was occasionally used in a maintenance workshop for repair work and reproduction of spare parts for our own machine fleet. The machine is operational and can be inspected under power in our workshop. We would be pleased if this machine is of interest to you. Your service team Mertens & Frowein GmbH

Condition: excellent (used), Milling Machine MAHO MH 600 W * Max. travel in longitudinal X-axis: 600 mm * Max. travel in transverse Y-axis: 400 mm * Max. travel in vertical Z-axis: 400 mm * Clamping surface/table dimensions: 900 x 480 mm * Spindle power: 5.5 kW * Spindle taper (ISO): ISO 40 Rsdpfxow I T Rwj Ah Ueck * Speed range: 40 - 4000 rpm * Digital readout: Millplus CNC * Weight: 2900 kg

Condition: used, Year of construction: 2008, turning diameter 210 / 350 mm turning length 400 mm control Fanuc 0i-TC swing diameter 500 mm travel -x axis 195 mm travel -z axis 430 mm spindle speed: 3500 1/min spindle bore 75 mm bar diameter 51 mm C-Axis 0,001 ° turret head 12 Pos. taper in tailstock-quill MK 4 tailstock travel 100 mm diameter of quill 80 mm rapid traverse X-axis 30 m/min rapid traverse Z-axis 30 m/min drive capacity - spindle motor 11 / 15 kW voltage 400 V total power requirement 30 kVA weight of the machine ca. 4,2 t dimensions of the machine ca. 2,70 x 1,90 x 2,10 m chip conveyor 2,80 x 0,60 x 1,30 m Transformer 0,60 x 0,45 x 0,55 m - Serial-No.: M015356K2F - Machine ON: 14.494 h - control: FANUC Oi-TC - Machine with C-axis and turret for life tools (1x radial + 1x axial in the accessories) - Tool meeasuring arm - Parts collecting tray - Collet chuck - 3-jaw chuck Samchully Ø 250 mm - Open center clamping cylinder - Automatic sliding door Rodpfsttckmsx Ah Uock - chip conveyor

Condition: like new (used), Year of construction: 2002, functionality: fully functional, Equipment: documentation/manual, rotational speed infinitely variable, Dufour milling machine, type 250, with Acu-Rite digital readout. Complete – includes vise, tooling, and dividing head. In excellent, very clean condition. Rebuilt in 2002. Rjdpfjx Iv Dzjx Ah Usck

Condition: used, Year of construction: 1995, Technical details: Rcedpfx Ahew D Hhpo Ujk x-travel: 600 mm y-travel: 500 mm z-travel: 450 mm weight of the machine ca.: 3,5 t

Condition: good (used), Three-phase motor, electric motor, double-end tenoner, edge processing machine, scoring motor, chipper motor, spindle motor, milling motor -Power: 1.49 kW -Speed: 2800 rpm Rcodsb A Nnzepfx Ah Ujk -Shaft: Ø 15 x 25 mm -Design: B5 -Protection class: IP 54 Price: per piece Quantity: 3 pieces -Dimensions: 320/130/H155 mm -Weight: 13.7 kg/piece

Condition: excellent (used), Year of construction: 2011, CNC Turning-Milling Center MTCUT T20MC Year of manufacture: 2011 Driven tools available Accessories included Technical data: Working area • Max. swing diameter: Ø 470 mm (18.5”) • Max. machining diameter: Ø 280 mm (11.02”) • Max. machining length: 508 mm (20”) • Bed slide and inclination angle: 45° Bed • Max. longitudinal travel (Z-axis): 520 mm (20.47”) • Z-axis servo motor: 1.4 kW (1.8 HP) • Z-axis rapid traverse: 30 m/min (1181”/min) • Max. cross travel (X-axis): 176 mm (6.93”) • X-axis servo motor: 1.4 kW (1.8 HP) • X-axis rapid traverse: 30 m/min (1181”/min) Spindle • Main spindle bore / draw tube diameter: Ø 62 mm (Ø 2.44”) / Ø 52 mm (Ø 2.04”) • Spindle nose: ASA A2-6 • Taper angle of the bore in 8" spindle: 1/20 • AC main spindle motor: FANUC 7.5/11 kW (10 HP / 15 HP) • Speed (8" main spindle): Standard 4500 rpm Rcodextnhaopfx Ah Uek Tool turret • Type: Hydraulic clamping device • Boring bar diameter / position: Ø 32 mm • Turning tool cross-section / position: □ 20 mm × 20 mm / □ 25 mm × 25 mm Tailstock • Quill diameter: Ø 75 mm (2.95”) • Stroke: 425 mm (16.73”) • Quill type: Fixed • Quill taper: MT No. 4 • Quill travel: 100 mm (3.94”)

Condition: used, Year of construction: 2009, Technical details: rotor dia: 30-500 mm Redpfx Ahjv Hrp Eo Ueck hobbing length: 500-1000 mm total power requirement: 80 kW weight of the machine ca.: 15 t dimensions of the machine ca.: 3,6 x 2,5 x 3,0 m max. module: 8 Max. module Et milling = 12 Max. module hobbing = 12 Max. axial travel = 110 to 1100mm Max. cutter speed = 300rpm Max. cutter displacement tangential = -350 to -55mm Max. table speed = 100rpm Table drive: torque motor Filter system: chip conveyor is for magnetic materials, belt filter is for all suspended matter that floats in the oil Including milling mandrel *

Condition: good (used), Double-end tenoner, edge processing machine, scoring motor, cutting motor, electric motor, spindle motor, milling motor Rcedpfx Ahsb A Nnre Uek -1x motor: 0.3 kW 18000 rpm at 300 Hz -Voltage: 200 V -Hole diameter: 16 mm -Weight: 5 kg

Condition: excellent (used), Year of construction: 1999, CNC Lathe MAZAK SQT 200 MS Year of manufacture: 1999 Including indicated tools and sub-spindle Control: Mazatrol PC Fusion CNC 640T Technical specifications: Max. swing diameter: 525 mm Max. swing diameter over saddle: 350 mm Max. turning diameter: 300 mm Bar work up to max. diameter: 51 mm Main spindle: Speed range: 35 – 4,000 rpm Main drive power: 15 kW Max. torque: 350 Nm Spindle nose: A2 – 6 inch Spindle bore: 61 mm Spindle positioning C-axis: 0° - 360°/0.001° Second spindle: Speed range: 35 – 5,000 rpm Rcodjx Hgl Hjpfx Ah Ujk Drive power: 7.5 kW Max. torque: 57 Nm Indexing: 72 positions/5° Tool turret: Number of tool stations: 12 (freely configurable with stationary and driven tools) Turret indexing time – 1st station: approx. 0.2 s Driven tools: Drive power: 3.7 kW Max. torque: 35 Nm Speed range: 25 – 4,500 rpm Travel: Turret travel: X-axis: 190 mm Z-axis: 575 mm B-axis: 585 mm Rapid traverse: X-axis: 30 m/min Z-axis: 30 m/min B-axis: 18 m/min Feed range: X/Z-axis: 0 – 5,000 mm/min C-axis: 1 – 2,000°/min

Condition: used, Year of construction: 2003, Technical details: turning diameter: 270 mm weight of the machine ca.: 6,5 t max. swing diameter: 590 mm with automatic loading and unloading system, chip conveyor G300 with "spindle bore clamping capacity 90mm" in tailstock version Rodpfjx Dlhlex Ah Ujck The machine has no driven tools. The information in the circuit diagram refers to the rotary drive for indexing the turret, not to driven tools. *

Condition: good (used), Double-end tenoner, edge processing machine, scoring motor, cutting motor, electric motor, spindle motor, milling motor Rodpfxob A Nnqj Ah Uock -1x motor: 0.3 kW 17300 rpm at 300 Hz -Voltage: 165 V -Hole diameter: 20 mm -Weight: 4 kg

Condition: excellent (used), Hermle UWF 900 Year of manufacture (according to circuit diagram): 1992 Heidenhain 407 control Handwheel Network connection Spindle speed: 4,000 rpm Rcedpfoxf Ec Sox Ah Uek Technical data: X travel: 600 mm Y travel: 400 mm Z travel: 420 mm Tool holder: SK 40 Distance spindle/table: 127 - 567 mm Spindle diameter at front bearing: 55 mm Videos of the machine available!

Condition: used, Year of construction: 1983, Technical details: Rcodpswgdz Ejfx Ah Ujk x-travel: 560 mm y-travel: 500 mm z-travel: 450 mm

Condition: good (used), Double-end tenoner, edge processing machine, scoring motor, cutting motor, electric motor, spindle motor, milling motor Rodpfxeb A Nnpo Ah Usck -Motor: 0.40 kW 12000 rpm at 200 Hz -Motor: 0.55 kW 18000 rpm at 300 Hz -Receptacle: Collet -Weight: 4 kg

Condition: good (used), Double-end tenoner, edge processing machine, scoring motor, cutting motor, electric motor, spindle motor, milling motor Rcsdpsb A Nnasfx Ah Ujk -Motor: 0.3 kW 17300 rpm at 300 Hz -Voltage: 165 V -Hole diameter: 16 mm -Motors: some with right-hand or left-hand threads -Number: 9 motors available Price: per piece -Weight: 3 kg/piece

Condition: good (used), Double-end tenoner, edge processing machine, scoring motor, cutting motor, electric motor, spindle motor, milling motor -1x motor: 0.3 kW 18000 rpm at 300 Hz Rcjdpfx Ajb A Nm Ueh Uok -Voltage: 165 V -Hole diameter: 16 mm -Number: 12 motors available Price: per piece -Weight: 3 kg/piece

Condition: good (used), Double-end tenoner, edge processing machine, scoring motor, cutting motor, electric motor, spindle motor, milling motor Redob A Nn Aopfx Ah Uock -Motor: 1.5 kW 2820 rpm at 50 Hz -Motor: 2.2 kW 5800 rpm at 100 Hz -Voltage: 380 V -Shaft mounting: Ø 30 mm -Weight: 15 kg

Condition: good (used), Universal milling angle head, milling angle head Rcjdpfx Aeb A Hfcsh Uok -Receptacle: Collet -Recess inlet: Ø 160 mm -Bolt circle: 174 mm -Milling spindle: 45° -fully swiveling -Dimensions: 200/185/H320 mm -Weight: 20 kg
