Used Table Milling Machine for sale (96,711)

Condition: good (used), Year of construction: 1996, Milling machine, universal milling machine, tool milling machine, drilling and milling machine Podpfxexvraxe Adiogw -Manufacturer: EMCO, milling machine with digital display and hydraulic clamping -Clamping table: 800 x 400 mm -Clamping table: rotatable/tiltable/swivelable -Travel range X/Y/Z: 600/400/400 mm -Spindle mount: SK40 with hydraulic clamping Accessories: incl. 9 tool holders (see photos) -Speeds: from 63 - 3150 rpm -Feed rate X/Y: 16-800 mm/min -Feed Z: 8-400 mm/min -Quick stroke: 100 mm -Rapid traverse X/Y: 2000 mm/min -Rapid traverse Z: 1000 mm/min -Coolant system: yes -Dimensions: 1740/1670/H1940 mm -Weight: 2200 kg

Condition: reconditioned (used), Year of construction: 2008, functionality: fully functional, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 1,000 mm, rapid traverse X-axis: 25,000 m/min, rapid traverse Y-axis: 25,000 m/min, year of last overhaul: 2025, RepairFIT by Dornhöfer The Difference. Including installation and commissioning! Technical details of the machine: Year of manufacture: 2008 Control: Heidenhain iTNC 530 Travel range: X-axis (mm) 2,500 Y-axis (mm) 1,250 Z-axis (mm) 1,000 Rotary table size: Length (mm) 1,000 Width (mm) 1,000 Spindle speed range: 15,000 rpm Feed rates: X, Y & Z axes (mm/min): 10 - 10,000 Max. rapid traverse speed X, Y & Z axes (mm/min): 25,000 Milling head: Automatic milling head, vertical Tool holder: HSK 63 A Main spindle drive power: 100% duty cycle KW25 - Chip conveyor - Cooling lubricant system - 3D thermal expansion compensation - Portable electronic handwheel Heidenhain HR 410 with 3m spiral cable - INA RUE 45 linear guideway system on all linear axes with central lubrication - Complete splash guard enclosure RepairFIT is our proven offering for a profitable entry into our product lines. The machines available in this line are procured by us following a rigorous selection process and subjected to a thorough inspection (deep dive check). After intensive cleaning, any obvious defects and faults identified are professionally repaired by our expert service team. Pgodpfx Adjv Rw Uujijw

Condition: good (used), - Pneumatic workpiece clamping devices - Pneumatic tool clamping device - Protective cover - 400V Pedexylxvepfx Adijgw

Condition: used, Universal Tool Milling Machine DECKEL Type FP 1 Machine No. 51265 Year of manufacture: approx. 1967 Travel paths X: 300 mm Y: 150 mm Z: 340 mm Table size 600 x 200 mm Spindle taper SK 40 - S20 x 2 Spindle speed 40–2000 rpm, 16 steps Motor power 1.0 and 1.6 kW, pole-changing Power supply 380 Volt, 50 Hz - Feed on X and Z axes - Spindle speed via 2 motor speeds and 8 gear steps - Quill movement at vertical milling head 60 mm - Swiveling, rotating, and tilting angle table - Coolant pump in machine base - Separate control cabinet Space requirements L x W x H 1100 x 1100 x 1600 mm Weight 690 kg Podjghtvajpfx Adiogw In good condition

Condition: excellent (used), Tool milling machine Manufacturer: Mikron Model: WF 3 DP Three-axis Heidenhain digital readout Tool holder: SK 40 Pgedpexvr Trjfx Adisw 24 spindle speeds: 30 – 2240 rpm Infinitely variable feeds, from 1 – 750 mm/min Table clamping surface: 450 x 800 mm X travel: 500 mm Y travel: 500 mm Z travel (vertical): 400 mm Hydraulic tool clamping Space requirements: Width: 1800 mm Depth: 1700 mm Height: 2000 mm (with pallet) Weight: 1800 kg

Condition: used, Year of construction: 2006, x-travel 560 mm y-travel 300 mm z-travel 420 mm table-size 1055 x 240 mm spindle taper ISO Sk 40 spindle turning speed range 40 - 1550 U/min total power requirement 5,5 kW weight of the machine ca. 1,3 t dimensions 1,6 x 1,5 x 1,85 m Universal milling machine Pgsdexfb Htspfx Adiow - Digital display - Chip guard - Coolant system - Machine light - Chip tray

Condition: used, x-travel 400 mm Podpoxv D Uzsfx Adisgw y-travel 400 mm z-travel 300 mm rapid traverse 1,2 m/min feed range 5 - 500 mm/min creep feed 1:100 tool taper ISO 40 stroke v60 h70 mm table - universal ca. 620 x 320 mm table vertical adjustable 350 mm weight of the machine ca. 1200 kg Machine was used in a public facility and is in good condition. Machine can be viewed under power by prior appointment

Condition: refurbished (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 1,200 mm, rapid traverse X-axis: 25 m/min, rapid traverse Y-axis: 25 m/min, rapid traverse Z-axis: 25 m/min, feed rate X-axis: 10 m/min, feed rate Y-axis: 10 m/min, feed rate Z-axis: 10 m/min, spindle speed (max.): 4,000 rpm, spindle speed (min.): 20 rpm, table width: 850 mm, table load: 5,000 kg, table length: 2,700 mm, overall weight: 15,500 kg, year of last overhaul: 2024, RefurbishmentPLUS by Dornhöfer The difference. Including installation and commissioning! MAIN TECHNICAL DATA Year of manufacture: 2007 Capacities / Travel: Longitudinal (X): 2,500 mm Vertical (Y): 1,250 mm Cross (Z): 1,200 mm Table size: Length: 2,700 mm Psdsun Nnqspfx Adiegw Width: 850 mm Number of T-slots on the table surface: 6 T-slot width: 22H12 mm Reference slot: 22H8 mm Distance between slots: 140 mm Max. table load: 5 t/m² Paint finish: RAL 5011 (steel blue) and RAL 7035 (light gray) Tool holder: ISO 50, DIN 69871 AD Pull stud: DIN 69872 form A Main drive: Drive power: 100% duty cycle KW24 Spindle speed range: Spindle speed: 20-4,000 rpm Torque: 479 Nm Feed rates: X, Y, and Z axes mm/min 10-10,000 Max. rapid traverse speed: X, Y, and Z axes mm/min 25,000 Weight: approx. 15,500 kg BASIC MACHINE EQUIPMENT: Heidenhain iTNC 530 HSCI Automatic milling head, diagonal H200 Chip conveyor Coolant system STANDARD EQUIPMENT: - Portable electronic handwheel HR 510 with 3m spiral cable - Hydraulic counterbalance acting directly on the vertical slide - 3D thermal expansion compensation for Heidenhain CNC contouring controls - Complete splash guard enclosure consisting of two front doors and one rear door for operating the machine from the front and rear. All doors are equipped with viewing windows. - Heidenhain AC drive motors in all axes with diagonal drive technology - INA RUE 45 linear guideway system in all axes with central lubrication - Ball screws (IT5) in all axes - Heidenhain direct linear measuring system in all axes - Telescopic covers for the X-axis guideways - Automatic cyclic lubrication for all axes and motion components - Work area lighting Refurbishment+ – what does that mean? The RefurbishmentPLUS line offers you a machine that has been uncompromisingly restored to its original technical and visual condition. All assemblies have been completely disassembled, repainted, and rebuilt with new, original spare parts. Cables, hydraulics, guides, spindles, rolling bearings – everything new!

Condition: used, Year of construction: 1999, x-travel 12000 mm y-travel 3600 mm z-travel 1500 mm spindle turning speed range 3000 U/min Control: Heidenhain iTNC430 Milling head 2 axes, indexed 2.5° Vertical (Y-axis): 3600 mm Transverse (Z-axis): 1500 mm Longitudinal (X-axis): 12,000 mm Guide rail length: 14,700 mm Guide rail width: 1400 mm Lowest milling position of the spindle nose measured from the floor (head horizontal): 855 mm Low column design 870 x 900 x 2,625 mm: 3,000 kg High stand design 870x900x3,025 mm: 3,500 kg Motor power: 37 kW Mounting: ISO 50/ DIN 69871-A Speeds: 11.7:231:3000 rpm Feed range: 2:2500 mm/min Rapid traverse X-axis: 12000 mm/min Z-Y axis: 15000 mm/min Feed motor power X-axis: 55 Nm Z-axis: 37 Nm Y-axis: 37 Nm Accuracy Positioning accuracy: 0.025 mm Repeatability: 0.015 mm Weight: approx. 42,000 kg Air supply to the machine: 300 L/min at 4.5 bar NOTE: The clamping plates and chip conveyors are not included in the scope of delivery. However, we can offer you both used and new clamping plates and chip conveyors on request. Pgsdsxwdygopfx Adiow

Year of construction: 2011, condition: ready for operation (used), Main Drive Number of axis 3 Spindle Speed 4000 RPM Spindle motor power 25 kW Movement X-Axis Movement 3000 mm Z-Axis Movement 900 mm Y-Axis Movement 865 mm Table Table load 10000 kg This 3-axis Auerbach FBE 3000 Bed Type Milling Machine was manufactured in 2011. It features a robust clamping surface of 3100 x 800 mm, capable of handling a maximum table load of 10,000 kg. The machine is equipped with a multi-position milling head KFM 1, a tool holder SK 50, and offers a spindle power of 25 kW with speeds up to 4000 rpm. If you are looking to get high-quality milling capabilities, consider the Auerbach FBE 3000 machine we have for sale. Contact us for more information. Application Types Pgsdpfjxyl Rlsx Adisw Milling

Condition: excellent (used), Year of construction: 1989, Philips CNC 432 control Travel paths X/Y/Z 600 x 400 x 450 mm Spindle speed 4,000 rpm Podpfxsxc N Iyj Adiegw 20-position tool magazine SK 40 4th axis Lehmann

Condition: new, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,300 mm, travel distance Z-axis: 1,500 mm, rapid traverse X-axis: 30,000 m/min, rapid traverse Y-axis: 30,000 m/min, rapid traverse Z-axis: 30,000 m/min, position of the milling head: Universal-Diagonal-Fräskopf, spindle speed (max.): 6,000 rpm, table width: 1,200 mm, table load: 6,000 kg, table length: 1,600 mm, torque: 1,178 Nm, power: 31 kW (42.15 HP), Equipment: rotational speed infinitely variable, BRAND NEW BED-TYPE MILLING MACHINE WITH ROTARY TABLE Control and Motors: HEIDENHAIN TNC 640 digital path control HEIDENHAIN package (motors, measuring systems, and handwheel) IKZ: Internal coolant supply – 36 bar Rotary Table: 1600 x 1200 mm – Dual-motor drive system Additional Equipment: ATC tool changer with double gripper, 40 positions Double hinged belt chip conveyor (longitudinal), one at the front and one at the rear Perimetric enclosure Pedeff Hz Hopfx Adiogw Accuracies: Positioning accuracy: ± 0.015 mm Repeatability: ± 0.008 mm Only inquiries from Germany will be answered.

Condition: ready for operation (used), Year of construction: 1986, Immediately available from location: Fully automatic milling machine Busch Type NF 8/32 Year of manufacture: 1986 Groove width up to 32 mm Podpjxzdkysfx Adiegw Machining length up to 6100 mm Automatic material feed Automatic infeed Drive 5.5 kW Accessories: support tables Tool holders, milling cutters Coolant system Digital readout Weight: 4 t Price: EUR 3,750.— plus VAT, ex location.

Condition: reconditioned (used), Year of construction: 2002, travel distance X-axis: 16,000 mm, travel distance Y-axis: 3,200 mm, travel distance Z-axis: 1,500 mm, rapid traverse X-axis: 15,000 m/min, rapid traverse Y-axis: 15,000 m/min, rapid traverse Z-axis: 15,000 m/min, spindle speed (max.): 4,000 rpm, spindle speed (min.): 20 rpm, 100% Retrofit by Dornhöfer The Difference. Including installation and commissioning! Year of manufacture: 2002 Control: Heidenhain TNC 640 / TNC 7 Travel: X-axis (mm) 16,000* (see below) Y-axis (mm) 3,200 Z-axis (mm) 1,500 Spindle speed range: 20–4,000 rpm Feed rates: X, Y & Z axes (mm/min): 2–12,000 Max. rapid traverse speed X, Y & Z axes (mm/min): 15,000 Milling head: Automatic milling head, orthogonal H10, 1° pitch Tool holder: ISO 50, DIN 69871 AD Main spindle drive power: 100% duty cycle KW37 - Automatic tool changer with 60 magazine positions - Coolant system with 20 bar & (IKZ) - Chip conveyor, floor ejection Pgedsv S Upfopfx Adiow - Ergonomic operator platform - Hazardous area protection - 3D thermal expansion compensation - INA linear guides *Adaptive X-axis length: We supply the machine bed in the length you require, up to a maximum of 16,000 mm. 100% RetroFIT – our core business! For us, it means offering a machine that can only be compared to a new product, but also offers you many other advantages: Latest CNC control technology with proven machine stability Significant CO₂ savings compared to a new machine Shorter delivery times Often savings on complex foundation costs Significantly lower investment costs All mechanical components (e.g., ball screws, guides, rolling bearings, etc.) have been renewed. Our designers designed the entire electrical peripherals (such as the most modern drive, control, and regulation technology) using the most efficient technologies. This was implemented using new cabling and a completely new control cabinet, as well as the latest Heidenhain control system with a wide range of innovative options. The completely new and innovative hydraulic concept meets the most modern requirements and achieves maximum efficiency. The machine's visual appearance is in no way inferior to a new machine thanks to its refurbishment: The entire machine was first disassembled down to every screw, sanded, primed, and then painted with a robust 2K EP paint. We equipped the machine with a safety concept that is individually tailored to the needs of the operator. We offer the highest level of safety, flexibility, and ergonomics. You receive a state-of-the-art machine combined with significant CO₂ savings.

Year of construction: 1999, condition: used, CNC Steuerung Heidenhain TNC 426 Kuehlmitteleinrichtung Spaenewanne CNC control Heidenhain TNC 426 Podpjdk Rwnefx Adisgw coolant device chip tank Technische Daten / technical details: X-Weg / X-travel 600 mm Y-Weg / Y-travel 525 mm Z-Weg / Z-travel 500 mm Spindeldrehzahlen / spindle speed 6300 UpM /rpm Werkzeugaufnahme / spindle taper SK40 Vorschubbereich X/Y/Z / feed range 10000 mm/min. Universaltisch / clamping area of universal table 750x530 mm Gewicht der Maschine ca. / weight 6500 kg

Year of construction: 1991, condition: ready for operation (used), Control Unit Brand HEIDENHAIN Model TNC 415 Pgedsxl Hyxjpfx Adisw This 3-axis Huron X 61 38 bed type milling machine was manufactured in 1991. It is equipped with a Heidenheim TNC 415 control system and offers substantial travel dimensions with an X-axis of 2400 mm, Y-axis of 1000 mm, and Z-axis of 1000 mm. The machine's transport dimensions are 3000 mm in breadth, 1400 mm in thickness, and 3000 mm in height. Consider the opportunity to buy this Huron X 61 38 machine we have for sale. Reach out for more information. Application Types Milling

Condition: new, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,300 mm, travel distance Z-axis: 1,500 mm, rapid traverse X-axis: 30,000 m/min, rapid traverse Y-axis: 30,000 m/min, rapid traverse Z-axis: 30,000 m/min, position of the milling head: Universal-Diagonal-Fräskopf, spindle speed (max.): 6,000 rpm, table width: 1,100 mm, table load: 10,000 kg, table length: 3,100 mm, torque: 1,178 Nm, power: 31 kW (42.15 HP), Equipment: rotational speed infinitely variable, FACTORY NEW BED MILLING MACHINE Control and Motors: Pgsdpfsh Ekrtox Adiow HEIDENHAIN TNC 640 digital path control HEIDENHAIN package (motors, measuring systems, and handwheel) IKZ: Internal coolant supply, 36 bar Additional Equipment: ATC tool changer with double gripper, 24 positions Double hinge belt chip conveyor (longitudinal), one front and one rear 4th axis preparation (rotary table) Perimetric enclosure Accuracies: Positioning accuracy: ± 0.015 mm Repeatability: ± 0.008 mm Only inquiries from Germany will be answered.

Condition: ready for operation (used), Year of construction: 2000, Immediately available ex CH toolmaking: Podpfx Adjxzdkaeiogw 5-axis milling machine Deckel Maho Type DMU 35 M Year of manufacture: 2000 CNC control: Heidenhain TNC 310 M Electronic handwheel Table: 400 x 280 mm Table load capacity up to 100 kg Travel X/Y/Z: 350/240/340 mm Stepless spindle speeds: 0 – 5000 rpm Taper: SK 40 Rapid traverse: 5 m/min Servo motors for X/Y/Z axis Swivel range: 360 degrees Table clamping: plus 105 / minus 150 degrees Weight: 2 t Tool holders, hydraulic vice Price: EUR 5,750 plus VAT, ex location

Condition: reconditioned (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 3,500 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 1,000 mm, feed rate X-axis: 25,000 m/min, feed rate Y-axis: 25,000 m/min, feed rate Z-axis: 25,000 m/min, spindle speed (max.): 3,000 rpm, spindle speed (min.): 20 rpm, table width: 850 mm, table length: 3,700 mm, overall weight: 18,500 kg, RepairFIT by Dornhöfer The Difference. Including installation & commissioning! Psdpfx Aoxgn Efediogw Year of manufacture: 2007 Travel / Stroke Capacities: Longitudinal (X): 3,500 mm Vertical (Y): 1,250 mm Cross (Z): 1,000 mm Table dimensions: Length: 3,700 mm Width: 850 mm T-slots: 5 x 22 H12 Reference slot: 1 x 22 H8 T-slot spacing: 140 mm Paintwork: RAL 5011 (steel blue) RAL 7035 (light grey) Tool holder: ISO 50, DIN 69871 AD Pull stud: DIN 69872 Form A Main drive: Drive power: 100% duty cycle 24 kW Spindle speed range: Spindle speed: 20-3,000 rpm Torque: 479 Nm Max. feed rate: X, Y, and Z axes 25,000 mm/min Mean acceleration: 2 m/s² Weight: approx. 18,500 kg HEIDENHAIN iTNC 530 HSCI Swiveling control pendant including Heidenhain iTNC 530 control (1 processor / 4 axes) with software options 1 and 2. Automatic Milling Head, Diagonal H4 Automatic indexing Soraluce “Diagonal” milling head, Type H4 / 2 planes with 2.5° x 2.5° indexing, 479 Nm, tool clamping force 18,000 N. Automatic tool changer: Automatic tool changer (random carousel) with 20 magazine positions: The automatic tool change is carried out in the vertical position of the tool spindle. Maximum tool diameter: 125 mm Maximum tool length: 250 mm Maximum tool weight: 15 kg Number of magazine positions: 20 Chip conveyor package: Three chip conveyors, two longitudinal screw conveyors and one cross hinge belt conveyor with integrated coolant tank, discharge height: 1,000 mm Coolant System 2: Coolant/lubricant system 2 with discharge via shower ring and internal coolant supply according to DIN 69871 Form AD, tank capacity 500 l + 150 l lift tank with pump, delivery rate 50 l/min, delivery pressure 5/8 bar. Increased delivery pressure of high-pressure pump from 15 bar. RepairFIT is our proven offer for a profitable entry into our product lines. The machines available in this line are sourced by us following a strict selection process and undergo a thorough inspection (deep-dive check). After intensive cleaning, all identified visible defects and faults are professionally repaired by our expert service team.

Condition: good (used), Year of construction: 2008, feed length X-axis: 400 mm, feed length Y-axis: 250 mm, feed length Z-axis: 400 mm, Heidenhain TNC 124 control quill electronical hand wheel coolant device Technische Daten: Längsweg (X-Achse) / X-travel longitudinal 400 mm Querweg (Y-Achse) / Y-travel cross 250 mm Senkrechtweg (Z-Achse) / Z-travel vertical 400 mm Tischaufspannfläche / table clamping area 600 x 320 mm Werkzeugaufnahme / spindle taper SK40 Drehzahlbereich / spindle speed range 30-6300 UpM Vorschub x,y,z / feed x,y,z 10,10,8 m/min. Podpfx Asrb A Tcedijgw Antriebsleistung gesamt / drice capacity 6,5 kW Gewicht ca. / weight ca. 1200 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: new, travel distance X-axis: 6,000 mm, travel distance Y-axis: 1,300 mm, travel distance Z-axis: 2,000 mm, position of the milling head: Universal-Diagonal-Fräskopf, rapid traverse X-axis: 30,000 m/min, rapid traverse Y-axis: 30,000 m/min, rapid traverse Z-axis: 30,000 m/min, spindle speed (max.): 6,000 rpm, pivoting range: 1 °, table length: 7,500 mm, table width: 1,100 mm, torque: 1,178 Nm, table load: 42,000 kg, coolant supply: 36 bar, spindle motor power: 53 W, Equipment: rotational speed infinitely variable, BRAND NEW FLOOR TYPE MILLING MACHINE Control and Motors: Two HEIDENHAIN TNC 640 digital CNC controls – one at the machine’s front, one at the rear in the cabin HEIDENHAIN package (motors, measuring systems and portable handwheel) Additional equipment: Tool changer with double gripper, 60 stations Pgsdsvrv Sujpfx Adiow Double hinge-belt chip conveyor (longitudinal), one in front and one at the rear Accuracies: Positioning accuracy: ±0.040 mm Repeatability: ±0.008 mm Only inquiries from Germany will be answered.

Condition: reconditioned (used), Year of construction: 2015, functionality: fully functional, travel distance X-axis: 10,000 mm, travel distance Y-axis: 3,000 mm, travel distance Z-axis: 1,500 mm, rapid traverse X-axis: 25,000 m/min, rapid traverse Y-axis: 25,000 m/min, rapid traverse Z-axis: 25,000 m/min, spindle speed (max.): 4,000 rpm, RepaitFIT+ by Dornhöfer The difference. Including installation and commissioning! MAIN TECHNICAL DATA Year of manufacture: 2015 Capacities / Travel: Longitudinal (X): 10,000 mm Vertical (Y): 3,000 mm Transverse (Z): 1,500 mm Paint finish: Graphite gray RAL 7024 / Agate gray RAL 7038 Tool holder: ISO 50, DIN 69871 AD Pull stud: DIN 69872 Form A Pjdsv R Hwrepfx Adiogw Taper: DIN 69871 Main drive: Motor / Make: Siemens Main spindle drive Tap: 1PH7 Maximum drive power: From 198 rpm 100% duty cycle KW41 Maximum torque: Constant up to 198 rpm 100% duty cycle 1920 Nm Speed control / Gearbox: 3-stage (oil-cooled) With automatic Switching Spindle speeds 4000 rpm: low range rpm 0 - 516 medium range rpm 460 - 1,288 high range rpm 1,200 - 4,000 Axis drives/axis feeds: Axis drive motors: Maximum rapid traverse: (X/Y/Z axis) 25,000 mm/min Maximum working feed: (X/Y/Z axis) 15,000 mm/min Maximum feed force: (X-axis) 35,000 N (Y/Z axis) 32,000 N Axis drive systems: X-axis (longitudinal) pinion/rack (Atlanta brand) Y-axis (vertical) ball screw (preloaded) Ø 63 x 20 Z-axis (transverse) Ball screw (preloaded) Ø 50 x 20 Weight: (without clamping table/plate area) approx. 49,500 kg Connection cable: approx. 60 kVA Innotrol HBG wireless handwheel Automatic tool changer with 60 magazine positions BIG Plus tool spindle Operator platform with height adjustment of 1800 mm and transverse adjustment of 800 mm Interface for adapter milling heads RepairFIT+ – what does it mean? With RepairFIT+, we offer you a profitable and safe entry into our product lines. Our machines undergo a rigorous selection process, undergo a comprehensive deep-dive inspection, and are thoroughly cleaned by our experts. All identified defects, both technical and cosmetic, are professionally repaired so that the machine is presented in perfect condition.

Condition: good (used), Year of construction: 2001, Heidenhain TNC 310 cnc control electronical hand wheel coolant device Technische Daten: Längsweg (X-Achse) / X-travel longitudinal 600 mm Querweg (Y-Achse) / Y-travel cross 400 mm Senkrechtweg (Z-Achse) / Z-travel vertical 400 mm Werkzeugaufnahme / spindle taper SK 40 Pgedpfjit Tr Tox Adijw Drehzahlbereich / spindle speed range 60-5000 UpM Vorschub / feed 0-2000 mm/min. Eilgang längs + quer / rapid feed x/y 5 m/min. Eilgang senkrecht / rapid feed z 4 m/min. Antriebsleistung gesamt / drice capacity 7 kW Gewicht ca. / weight ca. 2000 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: new, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 800 mm, feed rate X-axis: 30,000 m/min, feed rate Y-axis: 30,000 m/min, feed rate Z-axis: 30,000 m/min, table length: 1,900 mm, table width: 1,100 mm, spindle speed (max.): 6,000 rpm, table load: 4,000 kg, position of the milling head: Vertikal, torque: 1,356 Nm, spindle nose: SK 50 - DIN 69871A, Equipment: rotational speed infinitely variable, BRAND NEW GANTRY MILLING MACHINE Control and Motors: HEIDENHAIN TNC 640 Digital Path Control HEIDENHAIN Package (motors, measuring systems, electronic handwheel) Spindle Performance: Maximum spindle motor power: 30 kW ICS: Internal coolant supply, 70 bar Additional Equipment: Tool changer with double gripper, 60 positions Pgodpfsq Ixc Tjx Adisw Dual worm conveyor (longitudinal) Hinged belt swarf conveyor (transversal) Preparation for 4th axis (rotary table) Full enclosure, closed at the top Accuracies: Positioning accuracy: ± 0.025 mm Repeatability: ± 0.020 mm Only inquiries from Germany will be answered.

Condition: good (used), Year of construction: 1997, functionality: fully functional, feed length X-axis: 450 mm, feed length Y-axis: 300 mm, feed length Z-axis: 350 mm, 3-axes digital read out horizontal and vertical milling spindle quill Technische Daten / technical details: Längsweg X / X-travel longitudinal 450 mm Querweg Y / Y-travel cross 300 mm Senkrechtweg Z / Z-travel vertical 350 mm Tischgröße / table size 800x400 mm Spindelaufnahme / spindle taper SK40 Drehzahlbereich / spindle speed 50-2500 UpM /rpm Vorschubbereich / feed range 8-400 mm/min. Antriebsleistung / power capacity 3,2 kW Pjdpfx Aewyit Hedisgw Gewicht der Maschine / weight 1500 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.
