Used Turncraft Lathe for sale (5,463)

Condition: used, greates pass round over bed 480 mm swing diameter over bed slide 300 mm turning length 1500 mm centre height 240 mm centre distance 1500 mm spindle bore 42 mm spindle turning speed range 14 - 1400 U/min total power requirement 4 kW weight of the machine ca. 2,4 t Dodstqqx Aopfx Aggewb dimensions of machine L x W x H 3,00 x 1,05 x 1,40 m Accessories: 3-jaw chuck 250 mmø, MULTIFIX-head, running center

Condition: excellent (used), Year of construction: 2011, machine/vehicle number: 6V0146, MACHINE SPECIFICATION Height of centres 170mm Swing over bed 350mm Swing over cross slide 196mm Swing in gap 535mm Width in front of faceplate 165mm Bed length between centres 650mm Spindle speeds (infinitely variable) 15-3250rpm Spindle nose mounting (Camlock) D1-4 Spindle bore 42mm Spindle motor 7.5kW Width over bedways 318mm Travel of cross slide 250mm Travel of top slide 100mm Travel of tailstock barrel 145mm Taper in tailstock barrel No. 4 MT Machine in Metric execution   MACHINE EQUIPPED WITH Acu-Rite 2 axis DRO System 3 Jaw chucks Quick change toolpost and 2-off toolholders Chuck guard Saddle mounted chip guard Coolant system Lighting Rear splashguard Dwedpowmm S Tsfx Aggeb NB Machine ex display Dyson apprentice training facility, in excellent condition

Condition: used, Automatic lathe Dodpfx Agjyllr Iogswb Manufacturer: STROHM Model: M125

Condition: used, Year of construction: 2011, turning length 1500 mm control SINUMERIK 828D centre height 270 mm greates pass round over bed 540 mm swing diameter over slide rest 310 mm bed width 350 mm Djdjxyaf Rspfx Aggewb max. workpiece weight 1500 kg spindle bore 85 mm turning speeds 27 - 2250 U/min main drive DC 11 kW MACHINE EQUIPMENT: - AME chip conveyor - Lynette - Heavy grey cast iron bed for optimum damping and reduced tool wear - Inductively hardened and parallel synchronised bed guides - Counter guides completely Turcite-coated and hand-scraped - Hardened and ground ball screws - Thermosymmetrical headstock - Main drive 11 kW - Infinitely variable speed range 27-2250 rpm with 3-stage gearbox

Condition: used, Year of construction: 1953, turning length / mm turning diameter over plate // mm faceplate diameter / mm Plane disc diameter: approx. 3600mm Centre height above plate: approx. 1500mm Turning diameter over plate: 2600mm Turning diameter in the pit: 3600mm Turning diameter over bed: 1300mm Turning length: approx. 2400mm Max. Workpiece weight: 22000kg Max. Torque on the faceplate: 5000 mkg Faceplate gear rim pitch circle diameter: 1900mm Main spindle bore: 120mm Speed range normal: 0.71-35.5 rpm Dwodpfxsua Iw Te Aggjb increased: 1-50 rpm increased: 1.4-71 rpm Total power: 38kW Total weight: approx. 42.5 tonnes

Condition: used, Year of construction: 2000, faceplate diameter 3200 mm swing diameter 3500 mm turning height 2200 mm range L-W-H 7730 x 6240 x 6700 mm control Typ 840 D sl voltage 3 x 400 V frequency 50 Hz turning speeds 0,8 - 40 U/min max. turning diameter 3500 mm total power requirement 51 kW weight of the machine ca. 86 t Technical specifications Machine type: CNC vertical lathe Manufacturer: Rafamet Year of manufacture: 1973 conventional General overhaul with control retrofit 2010 Control upgrade 2016 Control: Siemens 840 D Sl Condition: very good faceplate Turning diameter of the faceplate 3,200 mm Number of rotation stages of the face plate 3 (infinitely variable) Speed ??ranges of the faceplate 0.8 - 40 rpm Level I 0.8 – 3 rpm Level II 0.8 - 11 rpm Level III 0.8 – 40 rpm processing of workpieces Max. turning diameter 3,500 mm Max. turning height of the workpieces above the faceplate 2,200 mm Dwedpfsuddcgox Aggob vertical supports Smallest axis distance between the vertical supports 470 mm Largest ram travel of the left vertical support 985 mm Largest ram travel of the right vertical support 985 mm Axis Feeds - Infinitely variable feed Max.: X1.2 3m/min max.: z1.2 2.5 m/min Plunger cannot be pivoted Support — crossbar Rapid feed of the cross beam 600 mm/min Larger distance of the cross beam to the faceplate 2,300 mm load sizes +Permissible turning force when turning workpieces with a turning diameter of 2,000 mm and a turning speed of 20 m/min. 8,000kg +Largest chip cross-section for workpieces made of steel Fz = 50 kg/mm² at a turning speed of 20 m/min for all supports 45 mm² +Largest chip cross-section for workpieces made of steel Fz = 50 kg/mm² at a rotation speed of 20 m/min for a vertical support with max. plunger length 985 mm 2.5 mm² +Largest chip cross-section for cast iron workpieces HB = 160 kg/mm² at a turning speed of 20 m/min for all supports 120 mm² +Largest chip cross-section for cast iron workpieces HB = 160 kg/mm² at a rotation speed of 20 m/min for a vertical support with max. plunger length 985 mm 22.5 mm² +Largest permitted workpiece weight at 0.8 - 3.15 rpm 17,500 kg +Largest permitted workpiece weight at 4 - 40 rpm 7,500 kg electric motors Main drive motor power and revolutions 51 kW Power of the feed motors of: - Vertical support beam (2 pieces) 16 Nm (gear 1:10) - Tappet (2 pieces) 16 Nm (gear 1:12) Power and revolutions of the drive motor of the hydraulic pumps (2 pieces) 3kW - 1,500 rpm Power and revolutions of the clamp hydraulic motor of the vertical support beam 1.5 kW - 1,500 rpm Power and rotation for crossbar adjustment 15 kW - 1500 rpm 3.5 Information on the compressed air supply and other consumables Compressed air connection: 6 bar free of oil and water 3.6 Energy Consumption Conditions Voltage: 3 x 400V Control Voltage: 24V Frequency: 50Hz Fusing: 315 A Main dimensions and weight of the machine Length 7,730mm Width 6,240mm Height: 6,700mm Weight: 85,750 kg Tool: Capto 60 recording Not powered front panel Turning diameter of the front plate 3,200 mm Clamping disc diameter 3,400 mm Number of rotation levels of the front panel 3 (continuously adjustable) Front panel speed ranges 0.8 - 40 rpm Level I 0.8 - 3 rpm Level II 0.8 - 11 rpm Level III 0.8 - 40 rpm processing of workpieces Max. turning diameter 3,500 mm Max. turning height of the workpieces above ...

Condition: used, Year of construction: 2001, Technical data: Okuma Space Turn LB 300 MY Year of manufacture: 2001 Control: OSP U 100 L Max. Turning length: 340 mm Chuck diameter: 10 inch X-axis: 280 mm Y-axis: 120 mm Dwsdpfxequcnbj Aggeb Z-axis: 500 mm C-axis: 360°(0.0001°) Spindle: 4500 rpm Spindle clearance: 62 mm Weight: 6000 kg Accessories: -Driven tools -Chip conveyor -Transformer -Manuals

Condition: new, functionality: fully functional, EUROPA eturn VS390. The workhorse of any workshop or toolroom, a 390mm swing over the bed and choices of 760, 1000 or 1250mm between centres. Newall DRO and Bison Chucks are standard across the Europa Lathe Range. Machine Specification EUROPA eturn VS390 Swing over bed 390mm Centre height 190mm Swing over cross slide 240mm Swing in gap 610mm Spindle Nose D1-6 (Camlock) Spindle Bore 54mm The EUROPA eturn VS390 Series is a gap bed centre lathe with a 390mm swing over the bed, 610mm in the gap and is available in three distance between centres. 750mm (30”), 1000mm (40”) and 1250mm (50”). Colchester Triumph sized machine. Dwedpfx Agenzhtwjgjb EEMT: Europa Energy Management Technology: The machine switches to a ‘sleep mode’ once a preset time limit has passed of inactivity. One press of a safety button and the machine is ready for operation. Reducing energy overheads. BISON: Bison 250mm dia 3 jaw scroll & 4 independent Jaw chucks with hard jaws are supplied as standard equipment. Manufactured in Europe, BISON chucks are manufactured to DIN55029, ISO702/11 standards for accuracy. NEWALL: A NEWALL NMS300 Digital Readout is professionally fitted and located on the saddle for operator ease of operation in mind. It makes so much sense, to install the DRO close to where the operator has his turning tool. The DRO travels with the machine. ELECTRONIC Variable Spindle Speed: Each model features a Schneider inverter controlling the spindle for exact turning requirements allowing you to select the correct turning speed for the job in hand. No hidden costs! Machine ready for turning: A Quick Change Toolpost complete with a set of toolholders ensures the EUROPA eturn VS lathe is supplied ‘ready for operation.’ DIN8605: An industry recognised quality standard, the entire range of EUROPA eturn VS lathes are built to the demanding toolroom standards of DIN8605

Year of construction: 1980, condition: used, turning diameter over bed 655 mm turning diameter over slide rest 390 mm turning length 1250 mm spindle bore 82 mm spindle turning speed range 9-1120 U/min feeds 0,049-3 mm/U total power requirement 12 kW Djdpjlc Uk Iofx Aggewb weight of the machine ca. 5,2 t required space 3,5 x 1,9 x 1,7 m m

Condition: excellent (used), Year of construction: 2013, Working area Chuck diameter 160 mm Weight max. 86* kg Swing diameter 200 mm X-travel (working stroke) 380 mm Z-travel 660 mm Loading time (depending on clamping device) 1 – 2 sec. Main spindle 2 number Spindle flange according to DIN 55026 5 size Spindle bearing – Ø front 80 mm Maximum speed 6000 rpm. Main drive, see description 2 number Feed drive Rapid traverse speed, X 60 m/min. Rapid traverse speed, Z 60 m/min. Feed force in X/Z 3.75 / 7.5 kN Ball screw diameter in X / Z 32 / 40 mm Disc turret, see description Electronic equipment in accordance with VDE 0113 Operating voltage 400 V Control voltage direct current 24 V -alternating current 230 V Frequency 50 Hz Connection value Connection power without Lt 36 kW Connection power with Lt 39 kW Rated current 64 A Supply line fuse 80 A Dimensions and weight Depth 2800 mm Depth including chip conveyor 4350 mm Width 1200 mm Width with automation 1600 mm Dwodpovz S Siofx Aggsb Height 2500 (2800) mm Weight approx. 7000 kg

Condition: used, CITIZEN CINCOM R 04 VI is a CNC automatic lathe / Swiss-type lathe designed for high precision, accuracy and reliability. It features 6 axes and 2 spindles, max. turning diameter 4 mm, max. turning length 40 mm, internal spindle diameter 9 mm, max. threading diameter 3 M. Main specs: up to 20000 t/min, spindle power 0.5/0.75 kW; tool-holder count 3 with 15 stations; turning tools 5, drilling tools 4, transverse tools 2; tool shank 8 mm; counter-operation 4 tools. Voltage 50 Hz 3x400 V; machine weight ≈850 kg; dimensions L1485×W560×H1410 mm. Accessories: LNS TRYTON 107 Hybrid bar feeder, parts catcher, coolant system, lamp. Ensures tight tolerances; suited to watchmaking, medical, automotive, aerospace and precision components. Djdpfjzv I D Hjx Aggswb

Condition: used, Year of construction: 2001, CNC long-turn lathe Dwsdpfx Aezwk Htjggob Manufacturer: CITIZEN Type: M32 Year of manufacture: 2001 with: Mitsubishi Meldas control system Synchronous spindle Powered tools Backworking capability Turret C-axis High-pressure pump Oil mist extraction system Fire extinguishing system Bar loader magazine IEMCA BOSS 432 R/37

Condition: used, Swiss-type cnc lathe TRAUB TNL 12K Dedpfx Agjzxigusgewb

Condition: used, Swiss-type cnc lathe TRAUB TNL 12K Dsdpfx Aszxigzoggewb

Condition: used, Swiss-type cnc lathe TRAUB TNL 12K Dedpfxezxig Us Aggewb

Condition: used, Swiss-type cnc lathe TRAUB TNL 12K Dwodpfx Agszxihljgsb

Condition: used, Swiss-type cnc lathe TRAUB TNL 12/7 Dwjdszxii Aopfx Aggjb

Condition: used, Swiss-type cnc lathe TSUGAMI B0206 E-III Dodpfezxik Tox Aggowb

Condition: used, Year of construction: 2008, chucking diameter 200/250/315 mm bar material dia. 65/90 mm spindle bore 79/100 mm control Siemens 840D powerline weight of the machine ca. 6 t dimensions of the machine ca. 4350x2460x2080 m Working area Circulation dia. above bed slide way cover: 680mm Circulation dia. above cross guide cover: 565 mm Facing traverse: 324 mm Longitudinal path: 600 mm Main spindle Spindle nose dia: 170 h5 / 220 h5 mm Bar dia. Max: 65 / 90 mm Spindle nose dia. in front bearing: 120 / 150 mm Spindle boring: 79 / 110 mm Chuck dia: 200 / 250 / 315 mm Drive rating S1 100% duty cycle: 25 / 33 kW Rotational speed range: 5000 / 4000 r.p.m Max. torque S1 100% duty cycle: 270 / 375 Nm Salient rotational speed: 900 / 850 r.p.m C axis (main spindle) Rotational speed: 250 r.p.m Stopping torque: 200 Nm Division accuracy: 0,025 deg. Compound slide X/Z/Y Facing traverse X: 260 / 1852 mm Longitudinal path Z: 635 / 6202 mm Ball spindle Z (dxh): 40x15 mm Vertical path Y: ±40 mm Ball spindle Y (dxh): 40x5 mm Rapid traverse speed X/Y/Z: 60/15/45 m/min Feed force X/Y/Z: 3,5/7/7 kN Tool holder Number of tool stations: 12 Tool mounting cylinder shaft (DIN 69880): 40 mm Tool disk, axial tool holder pitch circle dia: 370 mm Number of driven tools: 12 Drive rating max. 100% duty cycle: 4,9 kW Torque 100% duty cycle: 10,5 Nm Rotational speed range: 4500 r.p.m Tailstock Tailstock traverse path: 580 mm Tailstock force: 8 kN Tailstock mounting: MT 5 Rapid traverse speed Z2: 6 m/min Part accuracy for positioning: =/< 10 mm Hydraulic Contents: 40 l Pump capacity: 2,2 kW Max. pressure: 80 bar Pressure for clamping unit, tailstock: 10-60 bar Coolant unit Contents: 210 l Pump capacity: 1,7 kW Feed rate at 6 bar: 20 l/min Electrical energy requirement Connected rating: 50 kVA Operating voltage: 400 V Frequency: 50 Hz Fuses (slow blow/VDE 0100) perm: 80 A Voltage fluctuations at 400 V: 6% - 10% Machine dimensions Dwsdpfx Agoya Iirjgeb Dimensions (LxWxH) with chip conveyor: 4350/2460/2080 mm Weight without chip conveyor/chip bath: ca. 6.000 kg Workplace based constant noise pressure level: - (DIN 45635 part 1-04.85 (ISO 3740-1980), measured as a chip removing cycle as per DIN 45635 part 1601-07.78): 77 db (A) - in idle running as per DIN 45635 part 1601-07.78: 78 db (A)

Condition: used, Year of construction: 1996, turning diameter 600 mm turning length 850 mm swing diameter over bed slide 434 mm Control Siemens Sinumerik 840D total power requirement 54 kW weight of the machine ca. 10 t dimensions of the machine ca. 6000x2800 mm Spindle speed (max): approx. 0–4500 rpm Spindle speed (max): approx. 0–4500 rpm Spindle bore: approx. 65 mm Spindle taper: mostly DIN 55026 A6 / ISO taper Dwodpjzrzxiefx Aggob X-axis travel: approx. 220 mm Z-axis travel: approx. 950 mm Feed rate: approx. 25 m/min Tools & equipment Tool turret: usually 2 turrets with ~12 tool positions Powered tools: possible depending on equipment Tailstock: optional, often NC-controlled (SK30)

Condition: good (used), turning diameter over bed 520 mm turning diameter over slide rest 320 mm turning length 1000 mm turning speeds 21 - 1500 U/min spindle bore 52 mm transmission ratio 18 Dwedpfozyy E Djx Aggjb total power requirement 5,5 kW weight of the machine ca. 1500 kg dimensions of the machine ca. 2200 x 1100 x 1400 mm

Condition: used, Year of construction: 2000, Technical details: turning diameter: 1600 mm turning length: 3000 mm centre height: 800 mm turning diameter over bed: 1600 mm turning diameter over bed slide: 1400 mm turning dia. over face-slide: 1200 mm max. workpiece weight between centers: 20 to speeds: 5,6 -800 1/min transmission ratio: 3 spindle bore: 112 mm turret (x-stations): 8 / VDI 60 travel -x axis: 850 mm travel -z axis: 3020 mm rapid power traverse in X-and Z direction: 6 / 10 m/min power maindrive: 46 kW weight of the machine ca.: 22 to. dimensions of the machine ca.: 7,2 x 4 (3,11) x 2,7 m tech-in lathe, flatbed, tailstock, 8-pos. BARUFFALDI turret with 4 live tools, power 9kW, 4-pos. BARUFFALDI square-headed turret horizontal, C-axis, 3-jaw hydr. chuck SMW Autoblock KNCS 800/165, dia. 800mm, quick adjustment, power cylinder with 2 pressure clamping system, chipconveyor, coolant device, Dsdshutpvopfx Aggowb accessories *

Condition: used, Year of construction: 1992, gebraucht 1992 010190 prompt, Zwischenverkauf v 17900 € 1 320 mm 650 mm 160 mm 40 mm 192 mm 205 mm 5 5 MK 16 48 - 2500 1/min 24 0.02 - 0.63 mm/U 0.006 - 0.2 mm/U 0.25 - 8 mm 0.2 - 4 150 mm 100 mm 40 mm 3 MK 85 mm 2,4 / 3 kW 1582 mm 715 mm 1245 mm 680 kg Heidenhain 3-axis digital readout NEWRöhm 3-jaw chuck, 160 mm diameter, with internal and external jaws Quick-change tool post with one rectangular insert and one round insert Quick-release collet chuck with various collets from 1 to 27 mm Live centre Drill chuck Chuck guard Lead and feed screw guard Motor brake Coolant system Mounting feet Dwsdpfxoyycwxo Aggsb Operating instructions in German BUYING USED MACHINERY IS A MATTER OF TRUST - OUR TRANSPARENCY PROMISE We offer you maximum security and complete transparency. • HONEST INSIGHTS: Detailed photos and functional videos of the current condition • LIVE ON-SITE CHECK: Live testing is possible at our facility • DIGITAL DEMONSTRATION: Individual live demonstration via video call • RISK-FREE PURCHASE: 14-day return policy Details:

Condition: good (used), functionality: fully functional, Characteristics: Distance between centers: 4500 mm Dsdevy Adgspfx Aggowb Turning diameter: max. 750 mm Spindl bore diameter: 105 mm Control: Heidenhain Including 2 x chuck diameter 500 mm and 315 mm Including 2 x steady rest

Condition: ready for operation (used), Colchester Master 3250 Lead-/Feed-Screw Lathe | Lathe | Turning Machine Swing over bed: 350 mm Dwjdpfjy Nknkex Aggeb Swing over cross slide: approx. 196 mm Center height: 170 mm Spindle bore: 42 mm Spindle speed: approx. 20–3250 rpm Distance between centers: 1250 mm Main motor: 7.5 kW (10 HP) Thread cutting: - Metric pitch 0.2 – 14 mm (51) - Inch thread T.P.I. 2–56 (56) - Module threads, pitch 0.2 – 3.5 (20) - Diametral pitch (D.P.) 8–56 (20) You are welcome to arrange a viewing appointment. We can also organize cost-effective shipping for you! You will receive a proper invoice. For international customers, we can also provide a net invoice. A valid VAT ID number is required. Subject to prior sale. Visit our shop and check out our other listings. Brand names and trademarks mentioned are property of their respective owners and are used for identification and description purposes only. Deviations in technical data and errors in article description may occur and are subject to change.
