Sheet metal folder

Schechtl MAX 200 / STD

Condition: new, Year of construction: 2026, Technical specifications: - max. Thickness of cut sheet 1.2mm, - max. Working width: 3000 mm - in the equipment there is a stop for adjusting the cutting depth and a frame for holding the plate. - the extension table makes it easy to carry large-format metal sheets on the table - measuring table with graduation - robust and compact steel construction - high-quality, durable steel knives - extremely stable and heavy construction of cast iron - ground and hardened plate shear knives - Back gauge system - CE mark - declaration of conformity Gsdpjda I Ihefx Aadein open design suitable for endless cuts large cast work table engine power 2,2 kW oil HL 46 pressure force 4t working pressure 120-150 bar has hydraulic compensators from the cutter bar up Dimensions: Length: 3500 mm Width: 750 mm Height: 1150 mm Weight: approx. 1000 kg

Condition: new, Fastech 3-roll round bending machine FRS 2050 x 140 Technical specifications: Special equipment included in the price: hardened rolls motorized back roll adjustment motorized bottom roll adjustment 2 x digital display sheet width 2050 mm sheet thickness 4,5 mm max. sheet thickness 4,0 mm bending roll length 2050 mm roll diameter 140 mm smallest bending diameter 210 mm weight 1530 kg Godpfxohzq D Hj Aadsin dimension L-W-H 3240 x 900 x 1200 mm Motor:2,2 KW Equipment: upper and lower roller electr. driven upper roller can be swung out conical bending device asymmetric roller arrangement self-braking main motor sep. control and operation panel safety line values apply to St-37 / 240 N/mm² CE mark

Year of construction: 1984, condition: used, gr. grinding Ø: 40 mm small grinding Ø: 5 mm weight: 0,9 t Giodpfocq Rv Uex Aadsn 2 grinding wheels with flange 8 collets 1 coolant tank mechanical feed with fixed stop The cardan shaft for the workpiece drive is worn out

Condition: used, Year of construction: 1991, sheet width 2050 mm Gsdpfx Aajw U U Ukjdein plate thickness 3.5 mm distance between columns 2100 mm stroke of upper beam 250 mm adjustment UW 80.0 mm work height max. 920 mm total power requirement 6.0 kW weight 2910 kg range L-W-H 3185 x 875 x 1450 mm Features: - Robust electric-driven folding machine - With dynamic, powerful drive motors - Manual/automatic operation selectable - Control panel, right front - Bending angle preselection via electric potentiometer - Manual lower beam adjustment - 1x used upper tool rail - 2x used lower tool rails - 1x freely movable double foot switch - Original operating instructions

Condition: refurbished (used), Year of construction: 1988, - Refurbished in 2022 - Heidenhain TNC320 CNC control - CNC or manual control possible - Movable vertical milling head with extendable spindle - Counter bearing for long milling arbors - Hydraulic tool clamping - Automatic gearshift - Automatic clamping in the X, Y, and Z axes - Automatic central lubrication - Coolant system - Direct position measurement - Collision protection coupling in the Y and Z axes - Built in 1988 - Including tool holders, drilling/milling tools, and tool carriage Specifications Working area: - X-axis (longitudinal): 485 mm - Y-axis (transverse): 385 mm - Z-axis (vertical): 380 mm - Quill stroke (vertical): 80 mm - Vertical milling head manually movable on spindle block: 150 mm Main drive: - Pole-changing Three-phase brake motor: Manual gearbox with forward/reverse rotation - Power: 3.7 / 4.4 kW - Work spindle speeds: 63 - 3150 rpm (18 steps) - Step increment: 1.25 - Tool holder: SK40 (M16) - Tool clamping: Disc spring package - Tool release: Hydraulic Feed drive: - X-axis: 1 DC motor - Y & Z-axis: 1 DC motor - Ball screws: all axes Gijdpfswhk Ubsx Aaden - Feed rate: 2 - 3000 mm/min (programmable) - Rapid traverse X/Y/Z-axis: 3000 mm/min Table slide: - Number of T-slots: 4 - T-slot width: 14H7 mm - T-slot spacing: 63 mm - Permissible load: approx. 600 kg Installation: - Space requirement (including safety area): approx. 2300 x 2500 mm - Machine weight including vertical milling head and angle table: approx. 1830 kg - Operating voltage: 400 V - Total connected load: 12.5 kVA - Floor load: 3000 kg/m²

Condition: used, 7 pieces Bending tools for bending machine Gisdpjb D Ry Rofx Aadjn Length 3000 mm

Condition: used, sheet width 3100 mm plate thickness 2.00 mm thickness at "Niro-steel" 1.25 mm no. of strokes max. 36 Hub/min cutting angle 0.9 Grad table height 800 mm table width 430 mm distance between columns 3200 mm back stop - adjustable 5.0 - 750 mm Control konv. engine output 3.0 kW weight of the machine ca. 1950 kg range L-W-H 3730 x 2070 x 1400 mm Original price approx. 45.000 euros (!!) Special price on request Features: - Robust / motorized swing-cut guillotine shears - Machine with manual material/backgauge * Travel range 5.0 – 750 mm stop depth * Analog position display * Manual adjustment from the front - Break-proof, torsion-free steel welded construction - Compact and clear machine design - 1x hold-down beam * Hold-down opens before the knife beam moves up * No kinking of very sensitive sheets - Manual cutting gap adjustment - Integrated sheet metal holding system for thin sheet metal cuts - Sheet metal/cut material removal at the front (operator side) - 1x side stop with mm scale Giedpfexcyw Eox Aadsn - 3x table extensions - 1x freely movable foot switch - Operating instructions (PDF

Year of construction: 2001, condition: ready for operation (used), A Schechtl swing bending machine for sheet metal processing is available. Working length: 2040mm, opening height: 140mm, bending capacity: 3mm, bending speed: 50°/s, back gauge: 750mm. Machine dimensions X/Y/Z: approx. 3000mm/750mm/1250mm, weight: approx. 2750kg. On-site inspection is possible. Gijdpfox Hz Ntjx Aadjn

Condition: used, functionality: fully functional, Year of construction: 2003, FLEXIbend RAS 73.30 - General technical data in mm: Bending length: 3200 mm Maximum sheet thickness (400 N/mm²): 3.0 mm Maximum upper beam stroke: 300 mm Backgauge system (U gauge): 10-1550 mm Optional extension: (-3050) Machine dimensions (largest possible option): 4360 x 5220 mm Basic machine weight: 4400 kg - Machine-specific data: Motorized operation; 400V, 50/60 Hz, 3-phase Year of manufacture: 2003 Condition: Refurbished – very good used condition Complete tool set, with specific max. sheet thickness 2-person operation from the front Second foot switch for operation from the rear (incl. light barrier for working from behind) 15" CNC color graphic touchscreen control panel Touch&More CNC rear gauge and support system (10-1550) Backgauge system (standard): 10-1550 mm - Sample images Gjdpfx Aox Hx Slsadsin -

Condition: good (used), functionality: fully functional, Year of construction: 1990, This high-performance swing bending machine RAS 67.30 with single-program control comes from first ownership. Gjdpexmi Hdofx Aadoin Bending capacity: 3200 x 2.5 mm Drive power: 3 kW Machine weight: 3800 kg Includes pre-selection of bending angle via rotary potentiometer, second footswitch for two-person operation, continuous 45° upper bending bar, segmented/split and raised upper bending bar H = 100 mm Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel / Germany
