Dynamic Power Laser GmbH

Condition: new, Year of construction: 2024, warranty duration: 24 months, Equipment: cooling unit, Prices Pulsed laser cleaning machine Portable as a trolley 100 W 12.000,- € 200 W 18.500,- € 300 W 23.700,- € OPTION: GENERAL TERMS AND CONDITIONS Transportation costs: Air freight : 1200,-€ Delivery: 3 weeks working days after receipt of payment Payment : 100% before shipment List of laser cleaning parameters Parameter Function Value range Scan length (width) Change the pattern size 0-110 Scan speed (mm/s) Change the pattern scan speed from Galvo 3,000-12,000 Amplitude coefficient Changing the amplitude size 100-300 End optimization Optimize the end of a pattern 0-50 Calibration coefficient of the X-axis Increase the length of the pattern scan 0-100 Kljloqml H Sohcdw Hjr Y-axis calibration coefficient Increasing the width of the pattern scan 0-100 X-axis shift coefficient Change the pattern shift in the X direction 0-100 Y-axis shift coefficient Change the pattern shift in the Y direction 0-100 Line spacing Change the line spacing in a filled pattern 0.10-1.00 Laser power Setting the laser power 10%-100% Laser pulse width Set the laser pulse width 10-500 Laser frequency Set the laser frequency 55-500

Condition: new, Year of construction: 2024, laser power: 6,000 W, 1. Raycus 6000W laser source 2. raytools laser head 3. FHBS machine-welded bed 4. helical KH rail from Taiwan 5. Germany NEUGART gearbox 6. Yaskawa servo motor 7. PMI instructions 8. with shuttle table 9. safety cabinet 10.FScut 8000 software 11.integrated control cabinet 12.exhaust fan 13.HANLI water cooler 14.one-piece extrusion air drive Aluminum carrier 15. protective board of the machine bed Теchnical parameters Working area 3000×1500mm X-axis stroke 1525mm Kslon Up Ebohcdw Hjlr Y-axis stroke 3025mm Z-axis stroke 150mm Positioning accuracy ±0.03mm/m Repositioning Accuracy ±0.03mm Max cutting speed 220m/min Maximum acceleration 1.5G Maximum loading 1500KGS Voltage 380V ± 5 %; 50HZ; 3Phase Machine size 9550*3580*2550 Machine weight 6800KGS  Compact design  Easy maintenance  Quick installation  Economical

Condition: new, Year of construction: 2024, power: 20 kW (27.19 HP), We convert your machine from CO2 laser to fiber laser Kljlsnkaqljhcdw Hor

Condition: new, Year of construction: 2024, We convert laser cutting machines from CO2 to fiber laser Kslhcdwonkal Ds Hjlr

Year of construction: 2023, Condition: new, Laser source: Raycus 3 to 6kW Laser head: Raytools autofocus Structure: 2 horizontal chucks Loading: 6.5m unloading 2.5m Software: CAD CAM Tubest, Tube pro (Windows 10) Tube diameter: 15-230mm Tube profiles: round, rectangular, square Options: - 3 D swivel head - Automatic bundle loader - Table loader - Conveyor unloader - Weld seam detection - Raybox - Extraction system Kjlhcdwonkailo Hjlr

Year of construction: 2023, Condition: new, Laser source: 2/3/4kW Raycus Laser head: Raytools Autofocus Servo: DELTA/Matsushita/Yaskawa/Panasonic System: FSCUT 5000 A Klolomx R Ukjhcdw Hjr CAD - CAM: Tubest - Tube pro Tube length: 6000mm loading, 4000mm unloading Tube diameter: 15-230mm Maschinengröße: 13850x5100x2500mm

Year of construction: 2023, Condition: new, Laser head: Raytools Autofocus Kslhcdwsmx R Tme Hslr Laser source: 3kW Raycus Servo motor: Yaskawa System: FSCUT 5000 A CAD-CAM: Tubest, Tube Pro Tube length: loading 6000mm, unloading 3000mm Tube diameter: 15-230mm Maschinengröße: 12821x3726x2430mm

Condition: new, Year of construction: 2024, Laser source: 12 kW Raycus/IPG Laser head: Precitec Pro-Cutter 2.0 Control system: FSCUT 8000 Kljlhcdwji Ar Rus Hor Effective working area: 1520x3050 mm Max. Positioning speed: 120 m/min Max. Acceleration: 1,5 m/s² Positioning accuracy: 0,02 mm/m Repeatability: 0.03 mm/m Max. Table load: 1500 kg

Condition: new, Year of construction: 2025, Laser source: 3kW Raycus Laser head: Raytools autofocus Control system: FSCUT 5000 A Loading of tubes up to 6400 mm long, unloading up to 4000 mm Positioning accuracy: ±0.05/1000 mm Klslhcoi Arwlsdw Hsr Acceleration: 1 m/s² Speed: 120 rpm Max. Positioning speed: 100 m/min Max. Max. weight of a pipe: 250 kg Pipe diameter: 15-230 mm Total machine size: 12728 × 3400 × 2450 mm

Condition: new, Year of construction: 2024, Laser source: Raycus or Max: 4/6/8/12 kW Laser head: 3 D BOCI , Control system: FSCUT 5000 A Chuck: 20-450 mm Loading/unloading: 12000 mm X/Y axes Positioning accuracy: ±0.05/1000mm Repeat accuracy: ±0.03/1000mm Acceleration: 0.8g (m/s²) Rotation speed: 60 rpm Max. Positioning speed: 60 m/min Max. Max. weight of a tube: 1500kg 1.Raycus 6000W laser source 2.BEVEL laser head 3.welded frame DPL 4.Schneider electrical components 5.helical rack KH 6.techmech reducer 7.Yaskawa servomotor 8.SHAC guides 9.integrated power control 10.FScut 5000 software 11.integrated electrical cabinet 12.HANLI water chiller 13.cantilever gantry axis-X FHBS 14.automatic waste collection 15.crawler-type automatic workpiece collection Kslhcji Apfzodw Helr 16.automatic support system 17.loading frame 12000mm 18.unloading frame 12000mm
