Plasma cutting machine

ESAB Suprarex SXE-P 3500

Condition: good (used), Year of construction: 2002, table width 2000 mm table length 2 x 3000 mm burner heads 2 (3) Control Version 5T gangway length 9000 mm sheet thickness max. 100 mm output 2 KVA Technical details: CNC portal flame cutting machine Manufacturer: ESAB Type: Suprarex SXE-P 3500 Year of manufacture: 2002 CNC control: Vision T5 (installed in 2014) Working area: 2 cutting tables, each L=3m, W=2m Gantry track width: 3.5m Track length: 9 m Max. sheet thickness that can be cut (autogenous): 100 mm 2 oxyfuel torches 1 plasma torch with ESAB ESP 200 power source Iielhcdovwgndswueb Extraction/filter system: Kappa Separator KS2/3 flame cutting table + Mykron Fine dust filter

Year of construction: 1999, Condition: ready for operation (used), Track height: 500mm, track length: 14,000mm, cutting length: 12,000mm, cutting width: 3000mm, cutting thickness: 150mm, table height: 700mm, connected load: 2kVA, length: 2250mm, height: 1900mm, width: 5270mm, weight: 2.5t. The machine is not functional, but mechanically in order. The computer still runs under Windows XP and needs a new program. With documentation, without accessories. On-site inspection is possible. Iielhcouui Ecjdwuob

Condition: good (used), Functionality: fully functional, ESAB autogenous cutter with extraction device for sale. Iijlhcou Ul Rtjdwusb

Year of construction: 2002, Condition: used, Serial number: 2020xxxx Please contact ATS Norway AS for more information Please provide reference number upon request: 20126 Specifications: Model Year: 2002 230V 4 amp settings: 60, 100, 150, and 200 Cuts all types of steel Plate size: up to 2500x6000 mm Recently replaced drive motors Ielowdvgzjhcdwueib Description:This is an Esab UXE-P 3500 with both plasma and gas burner on the same carriage. You can choose between 4 amp settings depending on the thickness of the steel to be cut: 60 amp, 100 amp, 150 amp, and 200 amp. It can cut all types of steel, including aluminum, stainless/acid-resistant, Hardox, and regular mild steel from 2 mm to 30 mm. With the gas burner, you can cut thicknesses up to 150 mm.Plasma and gas burner can also be operated simultaneously. The machine can handle plate sizes up to 2500x6000 mm.It has been regularly serviced, and the drive motors have recently been replaced.

Condition: ready for operation (used), Year of construction: 2020, Control Unit Brand ESAB Model VISION T5 CNC Ijlhceuznbksdwujib Additional Equipment Cutting with Bevel and V and Y Bevels X-axis with a guide length of 11,000 mm and dual motorization 1 synchronized axis spindle for tube cutting1 synchronized axis spindle for tube cutting 3 tube support carriages manually positioned via trapezoidal screw 1 carriage for the ESAB iSeries300 plasma generator with a maximum power of 300A 1 VBA WRIST bevel cutting unit Plasma torch collision protection system Torch height control with arc voltage and touch sensor for bevel cuts 1 safety system made with photocells 1 ESAB PIPE CUTTING programming software This plasma cutting machine was manufactured in 2020. It features a robust ESAB iSeries300 plasma generator with a 300A output and a VBA WRIST bevel cutting unit capable of intricate bevel and tilt cuts. The ESAB VISION T5 CNC enhances usability with its 18.5" touch screen. Ideal for handling tube lengths up to 8000 mm and diameters from 100 mm to 750 mm. Consider the opportunity to buy this ESAB SUPRAREX 3100 plasma cutting machine. Contact us for more information. Application Types Cutting

Year of construction: 2007, Condition: ready for operation (used), A complete CNC gantry plasma cutting machine ESAB is available. Travel X/Y: 12000mm/4000mm, max. workpiece dimensions X/Y: 12000mm/3000mm, max. material thickness steel: 150mm, total system dimensions X/Y/Z: approx. 15000mm/5200mm/1500mm. System components: Cooling unit Kjellberg KWE 360, gas box Kjellberg PGV 3 and plasma connection Kjellberg PBA-360. The system has fire damage. Documentation available. On-site inspection is possible. Iiolhov Dkcfscdwuob

Condition: ready for operation (used), Year of construction: 2003, Main Drive Number of axis 2 Table Outer length 3.3 m Outer width 12 m Additional Equipment Donaldson filter unit with sufficient capacity This ESAB SXE-P2 4000 plasma cutting machine was manufactured in 2003. It features an upgraded ESAB T5 touchscreen control and a robust Esab M3 Gen1 200A plasma system, capable of cutting up to 35mm in carbon steel and 25mm in stainless steel. Includes a large 3.3x12 meter table and a comprehensive Donaldson filter unit. Ideal for high-quality cutting tasks. Contact us for more information about this machine. Iolhcjvnikisdwuoib Application Types Cutting
