Mitsubishi MV2400 S

Mitsubishi MV2400 S

Condition: excellent (used), Year of construction: 2022, functionality: fully functional, machine/vehicle number: 02DC2563, workpiece weight (max.): 1,500 kg, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 310 mm, Mitsubishi MV 2400S Year of manufacture: 2022 Travel (X/Y/Z): 600 x 400 x 310 mm Travel (U / V): 150 / 150 (+/-75) mm Taper angle (workpiece height): 15 / 260 or 30 / 110 °/mm Maximum workpiece weight: 1,500 kg Maximum workpiece dimensions: 1,050 x 820 x 305 mm Table dimensions: 840 x 560 mm Hardened 3-sided table Usable wire diameters: 0.10 - 0.30 mm Wire spool capacity: 10 kg Machine dimensions: 2,687 x 3,030 x 2,150 mm Machine weight: 3,500 kg The machine is currently still in operation and will be available from April 2026. Cgsdpfx Aaoyqwmhe Nop We are happy to offer on-site commissioning of the machine upon request.

Condition: excellent (used), Year of construction: 2005, machine/vehicle number: 1, grinding length: 1,000 mm, grinding width: 600 mm, Geibel & Hotz FS 1050 SD horizontal surface grinder Grinding area 1000 x 600 mm Fine pole pitch of the magnetic plate Many flanges and discs Large paper belt filter Adjustable feet Blade and circuit diagram Balancing scale Machine was in use a maximum of 2 days a week - Not a standard machine Pricing: ex-works - unpacked - uninsured Cgodpjv U Dfuefx Aa Njp Delivery time: immediately - subject to prior sale Errors excepted - technical data is non-binding

Condition: ready for operation (used), Year of construction: 2015, operating hours: 64,348 h, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 310 mm, controller manufacturer: MITSUBISHI, number of axes: 3, This 3-axis Mitsubishi MV 2400S wire EDM machine was manufactured in 2015. It features an X-axis travel of 600 mm, Y-axis travel of 400 mm, and Z-axis travel of 310 mm. The machine can accommodate workpieces up to 1,050 mm in length and 820 mm in width, with a maximum weight of 1,500 kg. If you are looking to get high-quality wire EDM capabilities, consider the Mitsubishi MV 2400S machine we have for sale. Contact us for further details. • Maximum workpiece length: 1,050 mm • Maximum workpiece width: 820 mm • Maximum workpiece height: 305 mm Codpsylm Scjfx Aa Nogp • Maximum workpiece weight: 1,500 kg • Tank length: 1,050 mm • Tank width: 820 mm • Tank height: 305 mm • Automatic wire threading: Yes Additional equipment • Wire feeder with enlarged 25 kg spool

Condition: good (used), Year of construction: 2021, Wire EDM machine MITSUBISHI MV2400S II, no. 51DC2501, year of manufacture 2021, weight 3,500 kg, with various auxiliary units, work area 600 x 400 x 310 mm Cgsdpsyl Uu Ejfx Aa Nep

Condition: used, Year of construction: 1979, max. wheel diameter 1000 mm gear width 180 mm max. module 7 min. module 0,5 min. ram stroke 16 mm max. ram stroke 180 mm table hole 160 mm total power requirement 4 kW weight of the machine ca. 5,2 t Cgjdpfjyb S H Djx Aa Njp

Condition: used, Year of construction: 2014, operating hours: 45,000 h, Travel: X 600 / Y 400 / Z 310; Water bath machine; Automatic wire threading; Chiller. Cgjdpfoyftr Ajx Aa Nop

Year of construction: 2015, condition: ready for operation (used), General Data Measurements width 3030 mm Measurements depth 2687 mm Measurements height 2150 mm Machine weight 3500 kg Main Drive Number of axis 5 Movement Cgsdpfxex D Rqfo Aa Nep X-Axis Movement 600 mm Y-Axis Movement 400 mm Z-Axis Movement 310 mm V-Axis Movement 150 mm U-Axis Movement 150 mm Workpiece Workpiece weight 1500 kg Additional Equipment Cooling/Temperature Control: Cooling system with temperature regulation Generator: Transistor pulse generator Output Current: 50 A Generator Size: 600 x 650 x 1765 mm Generator Size: 600 x 650 x 1765 mm This 5-axis Mitsubishi MV2400S wire EDM machine was manufactured in 2015. It features X, Y, Z movements of 600 x 400 x 310 mm and U, V axes at 150 x 150 mm, supporting a maximum workpiece weight of 1,500 kg. Equipped with an advanced Mitsubishi M700 controller with 3D CAD/CAM capabilities, it ensures precise machining. Consider the opportunity to buy this Mitsubishi MV2400S wire EDM machine. Contact us for more information about this machine. Application Types EDM

Condition: used, Specifications Manufacturer LORENZ Model LS 630 Condition Used Stock Number DCL1722 Module 12 Max diameter 630 mm Working stroke 220 mm Center distance worktable / cutter spindle 450 mm Machine weight 10.000 kg Spindle diameter 110 mm Csdpfx Aaewr Dx Uo Nsgp Table diameter 730 mm distance between table and spindle 580 mm Ø table hole 450 mm Description Equipped with : Change gears Manuals

Condition: ready for operation (used), Year of construction: 2015, functionality: fully functional, machine/vehicle number: 55DM2758, TECHNICAL DETAILS Travel paths X / Y / Z: 600 / 400 / 300 mm Cutting capability: H/W 30°/45° (30/45° instead of 15° for 0.25 mm wire) Control unit: MITSUBISHI M700 Control software: MITSUBISHI ELECTRIC “ADVANCE Plus” Replacement of X and Y linear scales: November 2022 MACHINE DETAILS Total weight: 3,500 kg Overall length: 2,687 mm Overall width: 3,030 mm Overall height: 2,150 mm Input voltage: 400 V Input current: 50 A Type of current: Three-phase Input frequency: 50 Hz Cgjdpfjwr Aclox Aa Nep EQUIPMENT - ODS optical drive system - Direct drive motors for the X and Y axes - Linear scales on the X and Y axes - Intelligent automatic wire feeding system (wire diameter 0.1–0.3 mm) - Wire straightening unit - Automatic wire cutter (for thicker wires) - Automatic hole detection - 3D CAD/CAM control - 5 controlled axes + preparation for additional axes - PFC precision machining (Precise Finish Circuit) - LLS longevity system - 10 kg wire spool holder (reel) - U-shaped, hardened, segmented receiving table - Compressor dielectric (water cooling) - Preparation for remote communication (mcAnywhere) - CE version - Clear display of main functions on the screen - Programming with ESPERADVANCE interactive dialog system - Control unit prepared for receipt of 3D files - Graphical inspection: 3D, front view, side view, top view - Handheld control device - Ethernet TCP-IP and 2 USB connection options - Preparation for remote communication (mcAnywhere)

Condition: ready for operation (used), functionality: fully functional, Manufacturer: LORENZ Model: S8/630 Wheel diameter: 630 mm Wheel width: 180 mm Max. module: 8 Serial number: 12371 Power (kW): 10 Dimensions (L×W×H mm): 3000 × 2500 × 3500 Weight (kg): 5500 Max. workpiece diameter (mm): 630 Max. module: 8 Current condition: fully functional Cgedexakzpepfx Aa Njp
