Used Geared for sale (6,711)

Condition: used, Year of construction: 2000, Technical details: max. wheel diameter: 275 mm gear width: 55 mm max. module: 6,5 min. module: 1,5 Face Hobbing-Continious Process Continuous process: The workpiece and tool (usually Spiron) rotate at the same time, and all teeth are created in one operation at the same time. Knife head has several knife groups (not arranged in a circle) Parallel tooth Conical tooth tip surface Single Item procedure: The workpiece is stationary and the tool (usually Arcon) rotates and cuts a tooth by immersing the tool. Once a tooth is cut, the tool moves out of the tooth again, the workpiece divides by one tooth width and the next tooth is cut until all teeth are finished. Knife head has arranged all knives in a circular path. Conical tooth height Parallel tooth head surface C28 can do both, wheel + pinion. However, a C28 must be “prepared” for the individual part procedure. I.e. direct measuring system + part gear brake, workpiece axis + license file for the production of individual parts. Bdjdpfev N Hilex Al Isb *

Condition: good (used), Geared motor, electric motor, electric geared motor -Manufacturer: Ametek, geared motor -Transmission: with toothed belt pulley -Speed: rpm Bdedjy Ecryjpfx Al Iob -Engine: Ametek 18323 6330620005 -Voltage: 220/240V -Dimensions: 125/85/H160 mm -Weight: 1.7 kg

Condition: used, Year of construction: 2018, Used angle head for Holz Her CNC machining centers Year of manufacture: 2018 HSK 63 F holder with torque support with 2 horizontal tool spindles suitable for holding a CLAMEX grooving cutter and a saw blade Bedewkbcnjpfx Al Isdb Technical data: max. drive speed: 8,000 rpm max. output speed: 12,000 rpm Permissible operating temperature: 85°C Unit swivels 360° around drive axis Sound level: 80 dB(A) Weight: 3.257 kg Availability: short-term Storage location: Hochheim

Condition: good (used), Mechatronic drive system, gearbox, spur gear gearbox, bevel gearbox, worm gearbox, Movegear Bdjdpfx Alsy D I Hyo Iob -Gearbox: Angle gearbox -Translation: 31 : 1 -Shaft: Ø 20 x 50 mm / Ø 30 x 25 mm -Dimensions: 280/270/H210 mm -Weight: 24.5 kg

Condition: good (used), Flat geared motor, geared motor, electric motor, electric geared motor, flat geared motor, flat geared motor -Manufacturer: Nord, flat geared motor -Type: SK 2080A-80 L/4 i= 10.27 -Speed: 135 rpm -Engine: Type SK 80 L/4 -Power: 0.75 kW -Hollow shaft: Ø 30 x 100 mm -Protection class: IP54 Bdedpfx Aey D Hupjl Iob -Dimensions: 340/310/H215 mm -Weight: 22.7 kg

Condition: good (used), Flat geared motor, geared motor, electric motor, electric geared motor, flat geared motor, flat geared motor -Manufacturer: Nord, flat geared motor -Type: SK 2080A-80 L/4 i= 10.27 -Speed: 136 rpm -Engine: Type SK 80 L/4 -Power: 0.75 kW Bodpfst E D Exox Al Iodb -Hollow shaft: Ø 30 x 100 mm -Protection class: IP54 -Dimensions: 320/290/H205 mm -Weight: 20 kg

Condition: used, Year of construction: 1997, Technical details: Bdodpfx Alex Aq Egj Isb max. module: 7 weight of the machine ca.: 5 t worm grinding diameter: 280-350 mm width of grinding worm: 84-104 mm min. number of teeth: 6 max. number of teeth: 600 max. top circle diameter: 360 mm max. workpiece weight: 60 kg without filter *

Condition: good (used), max. wheel diameter 145 mm gear width 110 mm max. module 2 min. module 0,3 turning speeds 112 - 1000 U/min min. number of teeth 6 Bdsdpfxey Ivdho Al Ieb clamping length max. 150 mm total power requirement 3,5 kW weight of the machine ca. 1,3 t dimensions of the machine ca. 1,3 x 0,8 x 1,4 m

Condition: used, Year of construction: 1963, Technical details: Bdjdpfx Alsvkpu Ho Isb max. wheel diameter: 900 mm max. module: 10 weight of the machine ca.: 8200 kos. hob dia. - max.: 190 mm cutter length max.: 320 mm milling spindle speeds (infinitely variable): 13-80 U/min workpiece length - max.: 750 mm max. workpiece diameter: 150 mm Counter holder milling mandrel is missing *

Condition: used, Year of construction: 2007, max. wheel diameter 400 mm workpiece dia. 36-300/400 mm axis distance 135-290 mm spindle turning speed - stepless 3000 1/min dist. between centers 100-550 mm Control Siemens 840D weight of the machine ca. 4000 kg dimensions of the machine ca. 2000x3055x2788 mm Bodpfx Ajy D T Susl Isdb Test method: - Single flank rolling test - Double flank rolling test - Structure-borne noise test - Heli testing in two-flank contact. Features: - Use of up to 6 test slides - Highest testing accuracy and repeatability - Machine table with workpiece drive - Swiveling pneumatic unit - Spray oil lubrication (type: Vogel) - Oil mist extraction (type: Elbaron)

Condition: used, Year of construction: 2008, control Siemens 840D Bdsdowzypnepfx Al Iob

Condition: good (used), Year of construction: 1981, max. wheel diameter 650 mm gear width 450 mm max. module 10 milling head speed 32-256 U/min electrics - voltage/frequency 380/50 V/Hz table load 1,8 t max. milling cutter diameter 192 mm cutter length max. 250 mm milling tool taper SK 40 weight of the machine ca. 11,5 t Bsdpfxoy H Nz De Al Iedb dimensions of the machine ca. 3,4x1,9x2,3 m

Condition: good (used), max. wheel diameter 630 mm gear width 375 mm max. module 10 clamping table 550 mm table hole 125 mm milling spindle speeds infinitely variable 62 - 390 U/min taper MORSE 5 axial-feeds 0,40 - 6,80 mm/U radial feeds 0,10 - 1,76 mm/U dist. cutter spindle - workpiece spindle 50 - 425 mm no. of teeth min. 8 milling cutter dia. x width 192 / 215 mm shifting 200 mm Bodpfx Ajua It Uel Iodb main drive motor 7,5 kW total power requirement 21 kVa weight of the machine ca. 8,2 t Equipment of the machine: - Universal milling head with tangential displacement - Pressure reducing valve for counterholder - Magnetic chip transport - Year of construction approx. 1976

Condition: used, Year of construction: 1998, workpiece diameter with ratio 1:10 300 mm workpiece diameter with ratio 1:1 212 mm max. number of teeth 200 min. number of teeth 6 x-travel 300 mm X - Axis speed 0,1-5.000 mm/sec. y-travel 400 mm Y - Axis speed 0,1-5.000 mm/sec. Bdjdpfx Ajul El Tsl Ieb A - axis -170 / +170 ° control Siemens Sinumerik 840 C total power requirement 38 kW weight of the machine ca. 10 t dimensions of the machine ca. 4,20 x 2,20 x 2,10 m incl. suction

Condition: used, max. wheel diameter 180 mm gear width 45 mm max. module 4 min. module 0,5 stroke length max. 0 - 52 mm spindle taper innen MK 4 table diameter 160 mm table bore diameter 75 mm no. of strokes 355 - 630 Hub/min feed range 0,008 - 0,4 mm/Hub Bedpfxstycg Ss Al Iodb dimensions of the machine ca. 2,30 x 1,50 x 2,36 m power capacity 6 kW weight of the machine ca. 2.500 kg With rack and pinion unit Change gear set Year of construction: Approx. 1981

Condition: used, max. wheel diameter 0-200 mm max. module 25 min. module 0,5 Bjdpfxetuxa Uj Al Iedb

Condition: good (used), Year of construction: 1978, max. pitch circle 152 mm Number of teeth 8-50 St. Bedpfxexq Hgco Al Isdb weight 7500 kg Technical data – Min./max. foot cone angle: 15° / 55° – Pitch circle diameter: 152 mm – Max. tooth height with 21° finished broach head: 10.7 mm – Max. tooth width at tooth root with 21°: 28 mm – Broach head diameter: 200 mm – Number of teeth range: 8–50 – Max. broach head diameter: .21" Workpiece spindle – Diameter of the tapered bore at the wide end: 99.219 mm – Clamping length at 304.8 mm: 15.478 mm – Taper depth: 15.875 mm – Diameter of the entire spindle bore: 22.225 mm Maximum tooth height: 14.8 mm Maximum tooth width at the root: 28 mm Maximum root angle: 55° Minimum root angle: 15° Milling head speed: 32.6-49.7 m/min Feed speeds (seconds per tooth): 2-3.1 Index range: 8-50 mm Diameter of taper bore at large end: 99 mm Taper per foot: 15.4 mm Depth of taper: 15.8 mm Countersink behind the taper: 57.2 x 77.9 mm Diameter of the bore through the spindle: 22.3 mm Power of the main drive motor: 10 HP Rotation of the main drive motor (60 Hz/50 Hz): 1800/1500 rpm Rotation of the hydraulic motor (60 Hz/50 Hz): 1800/1500 rpm Rotation of the coolant pump (60 Hz/50 Hz): 3600/3000 rpm Rotation of the chip screw motor (60 Hz/50 Hz): 1800/1500 rpm Footprint (L x W): 320 x 221 cm Total weight of the 726 REVACYCLE machine: approx. 9 t

Condition: good (used), Year of construction: 1984, max. wheel diameter 250 mm gear width 275 mm max. module 6 weight of the machine ca. 5,5 t The gear hobbing machine ZFWZ 250 is suitable for the economical production of all hob-processable cylindrical gear types, such a: - spur and helical gear, wormgears and worms, splined shafts, keyed shafts, serrated profiles, chain wheels and ratchet wheels,as well as conical and crowned spur and helical gears. Interchangeable wheels and milling accessories Technical data: - Workpiece diameter (max): 250 mm - Module (max): 6 mm - Axial feed travel (max): 275 mm - Tangential feed travel (max): 100 mm - Tooth helix angle (max): 45 degrees - Milling cutter diameter (max): 145 mm - Milling cutter length (max): 170 mm - Table clamping surface (min): 195 mm - Table clamping surface (max): 470 mm Power Milling cutter speeds - Stepped in 2 ranges: 56 ... 250 rpm - (Standard version): 90 ... 400 rpm - Infinitely variable in 2 ranges: 63 ... 180 rpm - (special version DC motor): 140 ... 400 rpm Weights - Machine net: approx. 5000 kg - Electrical cabinet: approx. 800 kg - Hydraulic unit + coolant tank + chip transport: approx. 700 kg Overall dimensions (with oil mist filter) - Length: Standard version: 3950 mm DC drive: 3450 mm (or 3350 mm according to table) - Width: 3300 mm - Height: Machine: 1980 mm Machine with DC drive: 2150 mm Bedpfx Asv T Nqaol Isdb Electrical cabinet: 2200 mm

Condition: used, Year of construction: 1989, max. wheel diameter 400 mm gear width 275 mm max. module 6 Overall size 300x310x245 cm weight of the machine ca. 5,0 t Specifications: - Maximum wheel diameter: 400 mm - Min. module: 1 - Max. module: 6 - Table diameter: 370 mm - Maximum wheel diameter: with counter support: 340 mm / without counter strut: 400 mm - Max. axial offset: 275 mm - Max. tangential adjustment: 100 mm - Max. tooth helix angle: 45 degrees - Max. cutter diameter: 145 mm - Max. hob length: 170 mm Performance - Cutter speed: 50-200 rpm Bdodou A I Elepfx Al Iob - Axial feed continuously adjustable: 0.2-10 mm/rev - Tangential feed continuously adjustable: 0.1-5 mm/rev - Radial for spur gears: 0.1-4 mm/rev - Radial for worm gears: 0.025-1 mm/rev - Rapid traverse axial: 500 mm/min - Rapid traverse tangential: 250 mm/min - Radial for spur gears: 400 mm/rev - Radial for worm gears: 100 mm/rev - Motor power: 7.4 kW Gewicht - Machine 5000 kg - Electrical cabinet approx. 800 kg - Hydraulic unit, coolant tank, chip conveyor approx. 700 kg Dimensions - Length with chain drive (normal) 2950 mm with DC drive 3350 mm - Width: 3100 mm - Height Machine: 1980 mm Electrical cabinet approx.: 2200 mm Machine with DC drive approx.: 2150 mm

Condition: excellent (used), Gear Hobbing Machine LORENZ E16 Suitable for: - Spur gears - Helical gears - Worm gears with radial feed - Worm gears with tangential feed - Internal gear rings Max. workpiece diameter: 1,600 mm Max. workpiece diameter with tailstock: 1,100 mm Max. gear width: 660 mm Max. module with hob cutter: 16 mm Max. module with disc-type cutter: 18 mm Max. module with finger cutter: 25 mm Max. distance table center – cutter center: 950 mm Min. distance table center – cutter center: 50 mm Max. vertical traverse: 740 mm Table diameter: 1,250 mm Table bore diameter: 250 mm Bore depth: 400 mm Mandrel table diameter: 90 mm Electrically overhauled and equipped with SIEMENS SIMATIC OP7. Manuals available. Bdodpfxsy Hqnrj Al Ijb 1. Including change gears 2. Including milling arbors 3. Including finger milling head 4. Including tangential milling head

Condition: new, functionality: fully functional, machine/vehicle number: FDU1407/2210069 014, power: 0.75 kW (1.02 HP), rotational speed (min.): 1,440 rpm, input frequency: 50 Hz, type of input current: three-phase, protection type (IP code): IP55, Siemens gear motor as good as new. It is versatile and can be used well in industry due to its robust construction. Dust and water resistant. Insulation class F; maximum operating temperature for the windings is 155 °C The motor is equipped with a thermistor (TP-PTC). Bodpfx Aljuqch Aj Iodb The electric motor is a compact and reliable drive motor with an output of 0.75 kW at 230/400 V and a current of 3.11/1.79 A. The motor is designed for continuous operation (S1) and operates at a rated speed of 1440 rpm at 50 Hz. With a rated torque of 106 and an IP55 protection class, it offers protection against dust and water jets, making it ideal for industrial applications.

Condition: new, machine/vehicle number: FDU1509/2272220 001, power: 0.55 kW (0.75 HP), rotational speed (min.): 1,440 rpm, input frequency: 50 Hz, type of input current: three-phase, overall weight: 15 kg, torque: 106 Nm, protection type (IP code): IP55, Siemens gearbox as good as new. Bodpfx Alouqaz Tj Iedb It is versatile and can be used well in industry due to its robust construction. Dust and water resistant. Insulation class F; maximum operating temperature for the windings is 155 °C The motor is equipped with a thermistor (TP-PTC) The electric motor is a compact and reliable drive motor with an output of 0.55 kW at 230/400 V and a current of 1.37/2.38 A. The motor is suitable for continuous operation (continuous operation). The motor is designed for continuous operation (S1) and operates at a rated speed of 1440 rpm at 50 Hz. With a rated torque of 106 and an IP55 protection class, it offers protection against dust and water jets, making it ideal for industrial applications. The motor uses 0.15 liters of oil and weighs 15 kg, making it a compact and easy to install solution. Other technical features include a power factor of 0.76 and an efficiency at load of 0.63 kW.

Condition: new, functionality: fully functional, machine/vehicle number: FDU1510/2278843 001, power: 5.5 kW (7.48 HP), rotational speed (min.): 1,455 rpm, type of input current: DC, overall weight: 222 kg, torque: 80 Nm, protection type (IP code): IP55, The Siemens FDU1419/2278843 001 electric motor is an efficient drive motor with an output of 5.5 kW, ideal for use in industrial environments. It works with an operating voltage of 400V and a speed of 1465 rpm (at 50 Hz). With its IP55 protection class, it is dust-tight and protected against water jets. The motor is designed for continuous operation (S1) and offers high reliability under demanding conditions Bdjdeup Uc Ajpfx Al Ieb

Condition: new, functionality: fully functional, machine/vehicle number: 01.3206969317.0003.00, power: 2.2 kW (2.99 HP), rotational speed (max.): 1,400 rpm, input frequency: 50 Hz, type of input current: AC, overall weight: 89 kg, torque: 1,700 Nm, protection type (IP code): IP54, Voltage: 230/400 V (three-phase current) Bdjdpfx Aleu Datqj Iob Brake voltage: 400 V AC Insulation class: B This bevel geared motor is a powerful drive solution that is ideal for demanding industrial applications. With its robust design and high efficiency, this motor offers reliable performance at variable speeds. The integrated bevel gearbox ensures a compact design and enables optimum power transmission. It is particularly suitable for conveyor technology, mechanical engineering and other industrial applications where precision and durability are required.

Condition: new, functionality: fully functional, machine/vehicle number: FDU1407/2210069 001, power: 0.75 kW (1.02 HP), rotational speed (min.): 1,440 rpm, input frequency: 50 Hz, type of input current: three-phase, overall weight: 16 kg, torque: 45 Nm, protection type (IP code): IP55, Siemens gear motor as good as new. It is versatile and can be used well in industry due to its robust construction. Bsdpfx Alourli Es Iodb Dust and water resistant. Insulation class F; maximum operating temperature for the windings is 155 °C The motor is equipped with a thermistor (TP-PTC). The electric motor is a compact and reliable drive motor with an output of 0.75 kW at 230/400 V and a current of 3.11/1.79 A. The motor is designed for continuous operation (S1) and operates at a rated speed of 1440 rpm at 50 Hz. With a rated torque of 106 and an IP55 protection class, it offers protection against dust and water jets, making it ideal for industrial applications.
