Used Pendulum Grinding Machine for sale (65,938)

Condition: excellent (used), PERFECT PFG-70150AHRD Surface Grinding Machine Year 2014 Table size 700 x 1500 mm Maximum longitudinal travel 1650 mm Maximum cross travel 760 mm Maximum distance table surface to spindle centre 600 mm Table speed 5 – 25 m/min Magnetic chuck size 700 x 1500 mm Spindle speed 1450 rpm Spindle motor 7.5 kW (10 HP) Grinding wheel size 355 x 40 x 127 mm Floor space required 4810 x 2550 mm Weight 7800 kg Lsdpfxezuxt Aj Aazert Supplied with: Automatic Downfeed System, 1500 x 700 mm Electromagnetic Chuck, Demagnetising Unit, 2 Axis Digital Readout, Remote Handwheel, Spindle Motor Speed Inverter Control, Automatic Paper Strip Filter & Magnetic Separator, Machine Pads & Levelling Bolts, Low Voltage Work Light. For sale with Jet Machinery Ltd Jet Machinery Stock No: #27039 Machine Serial Number: 1485022 Cost: £49,950.00 + VAT Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: used, Tschudin HTG310 Universal Cylindrical Grinder Centre height: 100mm Distance between centres: 340mm (13.4") Lrsdpfezrt Ipjx Aazot Maximum grinding diameter: 200mm Maximum grinding length: 340mm Hydraulic table traverse Table swivel: ±11° Wheelhead swivel: ±5° Workhead swivel: 360° Infinitely variable workhead spindle speed: 50–500 RPM Automatic plunge and traverse grinding cycles Automatic infeed with adjustable spark-out timer Rapid wheelhead advance and retract Hydrodynamic wheelhead bearings for exceptional accuracy Grinding wheel size: 350 x 50 x 127mm (14" x 2" x 5") Fitted With Hydraulic table drive Universal workhead Tailstock Coolant system Wheel guard Machine lighting

Condition: used, Model: CW Serial No: 26520 Capacities: Maximum Swing Over Bed: 430mm Maximum Distance Between Centres: 2500mm Wheel Dimensions: 660x 75mm Work Head Speeds: (3) 20 – 160rpmrpm Wheel Head Speeds: 735rpm Table Swivels: Electrics: 415v, 3ph, 50 Cycles Motors Wheel Head: 20 HP 975rpm Work Head: 3HP 1120rpm Complete With: 2 No 2 Point Open Steadies Complete Tailstock Mounted Wheel Dressing Attachment Coolant Lrsdpfx Aaeyx Hx Dezet Approximate Dimensions: 6,750 x 2000 x 1800mm Approximate Weight: 9,000kg

Condition: used, JONES AND SHIPMAN EIT 1076 PRODUCTION CYLINDRICAL GRINDING MACHINE MADE IN ENGLAND CAPACITY: 250 x 700.0mm DROP DOWN INTERNAL SPINDLE VARIABLE SPEED HEAD METRIC DIALS UNIVERSAL BED PAPER FILTRATION SYSTEM Lrodpfx Aaezw U Twszot AUTO CYCLE

Condition: refurbished (used), Year of construction: 1989, functionality: fully functional, rotary table diameter: 1,500 mm, grinding height: 457 mm, total height: 3,124 mm, total width: 3,150 mm, total length: 4,165 mm, overall weight: 15,000 kg, grinding wheel diameter: 863 mm, grinding spindle speed: 450 rpm, power: 45 kW (61.18 HP), table diameter: 1,500 mm, LUMSDEN Model 93ML Vertical Rotary Surface Grinder. Refurbished with new bearings in table and spindle, reconditioned main motor, new rectifyer, lubrication system, new control panel. Serial Number: to be advised New 1980's originally Country of Origin: UK Segmental wheel dia 34" Segments per set 16" Table dia and grinding capacity 60" Magnetic table dia (Humphreys) 60" Max height wheel to Magnetic table 18" Minimum height of wheel to table 4.1/2" Spindle speed 450 rpm. Table speeds 16 and 5.1/2 rpm. Automatic feeds 10 rates .004-.040 ins/min. Power elevation 25 ins/min. Spindle motor 60 Hp / 960 rpm 45 kW Ledpfx Aswugh Deazsrt Table motor 6/2.1/2 HP /1440/480rpm. Feed motor 1/4 Hp / 1440 rpm. Elevation motor 1 Hp / 720 rpm. Coolant pump motor 1 Hp / 1440 rpm. Overall height of machine 10'3". Floor space 13'8" x 10'4". Approx net weight 15 tons.

Condition: ready for operation (used), functionality: fully functional, grinding length 500 mm grinding width 200 mm workpiece height 250 mm Lodpfx Asz Aynweazsrt table surface 600 x 200 mm grinding wheel dimensions 225 x 20 x 51 mm grinding spindle drive 1.5 kW table feed 1 - 20 m/min total power requirement 2.6 kW machine weight approx. 2 t machine dimensions approx. 2.6 x 1.6 x 1.8 m

Condition: ready for operation (used), functionality: fully functional, Grinding length: 600 mm Grinding width: 250 mm Workpiece height: 450 mm Electromagnetic clamping table: 600 x 250 mm Grinding wheel diameter: 300 x 50 x 76.2 mm Spindle speed - stepless: 800 - 4200 rpm Total power requirement: 4 kW Machine weight: approx. 2.9 t Lrodpfjz Ayrvjx Aazot

Condition: used, Year of construction: 2004, CNC Surface Grinding Machine CNC control Siemens Sinumerik with handwheel, GRIPS 32 control software spindle drive motor type MS501/5 machine weight approx. 2300 kg, total weight approx. 3500 kg electrical supply 400V, 3-phase, 50Hz, rated current 29A, connected load 20kVA, supply fuses 50A Table clamping surface (standard): approx. 500 x 250 mm, other sizes available upon request Grindable workpiece area incl. 25 mm wheel width: approx. 600 x 300 mm Grindable workpiece area with VJCE cover incl. 25 mm wheel width: approx. 600 x 290 mm Distance from table top to upper limit switch (Y) at 250 mm wheel diameter: approx. 366 mm Max. permissible table load incl. magnetic plate: approx. 130 kg Height above floor: approx. 1085 mm Main spindle drive speed range: 800-4200 rpm, other options available upon request Main drive power: 10 kW at max. rpm, option 5 kW at max. rpm Cutting speed: 35 m/s, other options available upon request Grinding wheel diameter: 300 mm, option 250 mm Lrjdpfxjzwfmho Aazot Grinding wheel width: 25/30 mm, option 50 mm Grinding wheel bore: 76.2 mm, option 50.8/51 mm available upon request Radial wheel wear allowance: approx. 45 mm X-axis pendulum grinding speed (hydraulic, infinitely variable): 1000-24000 mm/min X-axis creep-feed grinding speed (AC servo motor): 5-1000 mm/min X-axis travel between limit switches: approx. 660 mm X-axis usable pendulum stroke: approx. 630 mm Y-axis travel speed: 0.1-2000 mm/min Y-axis travel between limit switches: approx. 360 mm Y-axis measuring system resolution: 0.0002 mm Z-axis travel speed: 0.1-2000 mm/min Z-axis travel between limit switches: approx. 280/275 mm Z-axis travel between limit switches with JC/JCE cover: approx. 270/265 mm Z-axis measuring system resolution: 0.0002 mm Installation length: approx. 3400 mm Installation width: approx. 2700 mm Installation depth (without control pendant): approx. 2440 mm Machine weight without full enclosure and control cabinet: approx. 3000 kg Machine weight with full enclosure and control cabinet: approx. 3700 kg Supply voltage: 400V AC -5% to +10%, 50 Hz, option 60 Hz Control voltage: 230V AC / 24V DC Connected load at 5 kW / 10 kW grinding power: 13.5 / 20 kVA Fuse protection: 35 A Data Cooling Unit (Erba/Schüler): equipment no. 85056334 Data Cooling Unit (Hyfra Pedia TRK 20-EF): equipment no. 85056333, year 2004 Data Filter Unit (Airtech MFE 20-SP): serial no. 393196, year 06/2004, rated voltage 230/400V, rated current 3.0A

Condition: used, Year of construction: 2001, functionality: fully functional, OKAMOTO ACC 64 DX Surface Grinding Machine Year: 2001 TBC Servo Automatic Downfeed Ledpfezv Ef Uox Aazjrt 600 x 400.0mm WALKER HAGOU MAGNET Electromagnetic chuck Paper coolant filtration system

Condition: ready for operation (used), functionality: fully functional, total width: 355 mm, total length: 381 mm, total height: 1,270 mm, grinding wheel diameter: 203 mm, Dormer Automatic Drill Grinder Lrodjzlg Szopfx Aazot Model: 108

Condition: ready for operation (used), functionality: fully functional, Brierley Universal Automatic Drill Grinder Lsdpezlhlpsfx Aazert Model: ZB 32 Capacity: 2.5-32mm With Cams

Condition: good (used), Year of construction: 1981, Surface grinding machine, manufacturer ELB, type: SWBE 010 ND, year of manufacture 1981. Electromagnetic chuck: 1000 mm x 500 mm Grinding area: Length 1000 mm, width 550 mm, height 400 mm Grinding wheel: 500 mm x 50 mm Truing device Paper band filter Wet grinding system Electrical diagrams Lrsdpfx Aoz Dv Exoazot Space requirements: 4,000 mm x 3,000 mm, height 2,600 mm, weight approx. 3,500 kg.

Condition: excellent (used), Year of construction: 1999, functionality: fully functional, grinding length: 1,500 mm, grinding width: 300 mm, Disc grinding machine with magnetic clamping plate, 1500mm x 300mm. The grinding machine was in operation until we dismantled it. The company was dissolved due to the owner's retirement. Lrjdpfxjz Dumns Aazst The senior manager was always very satisfied with this grinding machine and even bought the same model again! Includes coolant system. Loading onto a truck is possible with a crane or forklift and is free of charge.

Condition: new, functionality: fully functional, Topking X-25 CNC Cylindrical Grinding Machine Topking “The X-25 CNC cylindrical grinding machine is the perfect answer for UK manufacturers facing space constraints,” explains Simon Rood. “Unlike traditional T-type base designs, the X-Series utilises a revolutionary cross-slide structure. This design allows the X-25 to reduce floor space requirements by over 30% while significantly enhancing stability. It is a superior choice when space is limited, making it ideal for busy production environments where every square metre counts.” Machine overview INTRODUCTION Compact CNC cylindrical grinding machine with an impressive capacity. The X series CNC cylindrical grinding machine integrates advanced design and innovative features, offering efficient, precise, and flexible machining solutions. This grinder can meet various processing needs and ensure high-quality results for small or large components. The X-axis and Z-axis of the X-series CNC cylindrical grinding machine adopt a cross-slide design, effectively reducing the footprint and axial travel, thereby saving production space. The high-rigidity machine body and the heavy-duty spindle and tailstock significantly increase the component load capacity. The high rigidity machine body ensures stability during grinding, providing high-quality machining results. The operating system is equipped with a high-performance CNC control system and a built-in graphical user interface (GUI), making setup easy and enabling users to operate with ease. The grinding applications are extensive, offering customers the most suitable machining solutions. Lrsdpsubbqijfx Aazot Specification Swing (Max) 270mm Distance between centres 200mm Grinding Diameter (Max) 250mm Weight between centres (Max) 5kg CNC Control System FANUC or Mitsubishi CNC Controls

Condition: used, Year of construction: 2002, Technical details: Lrodpfx Aajz Dvidszot grinding length: 1500 mm grinding width: 700 mm workpiece height: 580 mm table load capacity: 2380 kp table speed -stepless-: 5 - 35 m/min grinding wheel dia. x width: 500 x 100 x 203 mm grinding wheel motor: 18 kW speeds:: infinitely variable (elektronically) total power requirement: 35 kW weight of the machine ca.: 12 t dimensions of the machine ca.: 5,3 x 2,9 x 3,8 (3,18) m surface grinding machine, paper-filter, DRO 3 axis, automatic infeed, el.handwheel, full cabin *

Condition: excellent (used), Year of construction: 2017, CNC cylindrical / roll grinding machine KRAFT / Praise TT60-40L-C2-H, used – Ø 600 x 4,000 mm, Siemens Traveling-table CNC grinder for rolls and heavy shafts up to 4,000 mm between centres and 3 t between centres. Built 2016/2017 by Praise Machinery, Taiwan, and hardly used since. Located in Einbeck (Germany), available at short notice. Inspection by appointment. Technical data (manufacturer's spec sheet): - Swing over bed: 600 mm - Distance between centres: 4,000 mm - Centre height: 320 mm - Max. workpiece weight: 3,000 kg between centres, 6,000 kg on steady rests - Control: Siemens Sinumerik CNC, Siemens drives - Grinding wheel: 760 x 100 x 304.8 mm, 45 m/s, wheel motor 22.5 kW, stepless spindle speed - X-axis travel 315 mm, 0.0005 mm/pulse; Z-axis travel 4,400 mm, 10–6,000 mm/min - Workhead speed 8–80 rpm, 11.25 kW - Tailstock quill stroke 100 mm, MT 6 - Accuracy: roundness and cylindricity 0.002–0.005 mm, Ra ≤ 0.3 µm - Hydrostatic/hydrodynamic lubrication of wheelhead and carriage - Connected load approx. 45 kW, 400 V / 50 Hz - Footprint approx. 13,000 x 2,900 x 1,800 mm, weight approx. 14.7 t Equipment: - Swivel workhead 0–90° - Electromechanical tailstock quill with foot pedal - Crowning device (type C2) - Grinding wheel guard sensor - 4-jaw chuck Lrsdpoz Ebl Tjfx Aazet - 2 two-point steady rests (neck Ø 100–300 mm) - Dresser, wheel flange with puller, dial gauge, magnetic base - Coolant system with magnetic and paper band filter - Full enclosure with sliding doors, telescopic covers - Electrical cabinet with air conditioner - CE documentation, operating manual Dismantling, transport and re-installation can be arranged. Price on request.

Condition: excellent (used), Year of construction: 2005, functionality: fully functional, grinding length: 1,000 mm, grinding width: 600 mm, Perfect PFG60100AHR surface grinder Lredpfx Ajzbrpfsazjt year of manufacture: 2005 magnetic table: 1000 x 600 mm max. grinding area: 1000 x 600 mm variable magnetic force automatic feed coolant/filter tank 5 grinding wheels and various grinding stones documentation machine is powered on for inspection

Condition: ready for operation (used), Year of construction: 2001, DELTA LB 300 - Cup grinding machine - Grinding area max. 330x140mm - Speed range max. 2840 rpm - Max. distance table - grinding wheel 280mm - Distance grinding spindle / column approx. 300mm - Cup wheel dimensions 200x80x78mm Ledpfx Aoz Dix Sjazort - Drive power approx. 3 kW - Coolant system - Machine housing - Grinding wheel guard - Machine feet - Documentation Dimensions: L x W x H 0.7 x 1 x 1.8 meters / Weight 500 kg Errors and omissions excepted.

Condition: used, JONES SHIPMAN 1307 EIT CYLINDRICAL GRINDING MACHINE MAKE JONES AND SHIPMAN, MADE IN ENGLAND MODEL 1307 EIT CENTRE HEIGHT 185.0 mm MAX DIAMETER 370.0 mm MAX GRINDING LENGTH 1016.0 mm MAX GRINDING WHEEL 350.0 mm x 40.0 mm GRINDING SPEED 40 – 320 RPM TABLE ROTATION 16 DEGREE TO – 12 DEGREE MAX INTENAL SPINDLE SPEED 24,000 RPM Lrjdoy Hi Epspfx Aazjt PLUS VARIABLE SPEED WORK HEAD INTERNAL SPINDLE. DOUBLE SWIVEL WHEEL HEAD. METRIC DIALS RANGE OF MAGNETIC CHUCKS PENDANT CONTROL HYDRAULIC PACK PAPER FILTRATION SYSTEM REBUILT BY ANDMAR EXTENSIVE RAGE OF TOOLING AND ACCESSORIES HYDRAULIC PACK

Condition: excellent (used), functionality: fully functional, total height: 1,760 mm, total length: 1,100 mm, total width: 800 mm, type of input current: three-phase, grinding wheel diameter: 125 mm, overall weight: 520 kg, input voltage: 400 V, spindle nose: ISO 40, Tool grinding machine DECKEL S11 TECHNICAL CHARACTERISTICS: Grinding wheel diameter: 125 [mm] Workpiece spindle nose: ISO 40 Paper filtration unit: No Supply voltage: 400 [V] Total power required: 2 [kVA] Dimensions: 1100 x 800 x 1760 Weight: 520 [Kg] EQUIPMENT INCLUDED: x1 universal index head - Part N°: 255X0X x10 dividing inserts for universal index head x1 tailstock with transverse adjustment - Part N°: 2621000 x1 tailstock with vertical adjustment - Part N°: 2624000 x1 swivel bracket assembly - Part N°: 2626000 x1 universal wheel dresser - Part N°: 2628000 x1 universal setting gauge - Part N°: 2570000 x1 spiral and relief grinding attachment - Part N°: 2580000 x1 relief grinding slide - Part N°: 2673000 x1 machine vice - Part N°: 2635000 x1 opto-electronic measuring unit with miscroscope - Part N°: 2650012 x2 digital readouts RSF-Elektronik x1 radius grinding attachment - Part N°: 2601X00 x1 LED lamp x3 feet pads Machine visible under power in our premises by appointment. Price on request, loading on truck included. Possibility of shipping Worldwide. The information on this page has been obtained by the best of our ability. Therefore, its accuracy can not be guaranteed. Lrodpfozz Hk Nox Aazst Machine for sharpening tools, milling cutters, taps, and drills. Similar to brands such as Blohm, Elb, Ewag, Favretto, Fenix, Ger, Jones & Shipman, Jung, Karstens, NUMAFFUT, Okamoto, Okuma, Saacke, SMP, Studer, Vollmer, Walter. Also see cylindrical or surface grinders, lathes, machining centers, and milling machines.

Condition: used, Year of construction: 2015, machine/vehicle number: MB536013A, functionality: fully functional, power: 28 kW (38.07 HP), input voltage: 400 V, input current: 54 A, input frequency: 50 Hz, overall weight: 2,800 kg, We are offering this used COSTA MD5CC 1350 belt grinding machine, manufactured in 2015. Model: MD5CC 1350 Serial number: MB536013A Voltage: 400 V Lrsdpfx Aezlcipjazst Frequency: 50 Hz Power: 28 kW Current: 54 A Year of manufacture: 2015 Total weight: 2800 kg If you have any questions or require further information, please do not hesitate to contact us.

Condition: excellent (used), functionality: fully functional, machine/vehicle number: 1761-1700, 457 x 152mm capacity. Equipped with magnetic chuck, power rise and fall to wheel head, table guard, coolant system, and dust extraction. SPECIFICATION Jones & Shipman Model 540P Working Surface of table 457 x 152mm Longitudinal traverse of table, hand and hydraulic 483mm Total cross traverse of table, hand and hydraulic 168mm Floor to table height 1035mm Table traverse speed range per min 1.5 – 18m Cross feed range per stroke at each reversal 0.178 – 1.78mm Micrometer cross feed graduated in Vertical feed adjustment in increments of 0.002mm Vertical movement of wheelhead (max) 280mm Wheel spindle center to table (min) 50mm Size of grinding wheel 180 x 13 x 31.75mm bore Speed of wheel 2880rpm Wheelhead motor 1.5kW Hydraulic pump motor 0.55kW Machine in Imperial execution MACHINE EQUIPPED WITH Magnetic chuck Power rise and fall to wheel head Table guard Wheel guard Coolant System Dust extraction Lrsdpfxjnxi Uue Aazet

Condition: used, Year of construction: 2003, Surface and Profile Grinding Machine table clamping surface approx. 600 x 250 mm grindable workpiece area (including 25 mm wheel width) approx. 600 x 300 mm max. permissible table load including magnetic plate approx. 130 kg height above floor approx. 1085 mm main spindle drive speed range 800-4200 rpm drive power 10 kW cutting speed 35 m/s grinding wheel diameter 300 mm, width 25/30 mm, bore 76.2 mm X-axis pendulum grinding travel speed (hydraulic, infinitely variable) 1000-24000 mm/min X-axis creep-feed grinding travel speed (AC servo motor) 5-1000 mm/min Ledpfx Aaozwfzlezert usable pendulum stroke 630 mm machine weight approx. 3400 kg, total weight approx. 3800 kg electrical supply 400V, 3-phase, 50Hz, rated current 30A, connected load 16kVA, supply fuses 35A

Condition: excellent (used), functionality: fully functional, Two Christen 2 - 32 drill bit grinding machines, sold as a package. Also available individually. Versatile grinding options up to diameter 32. In very good condition, not repainted. Ljdpfx Aoz Dbcpoazort Can be inspected while powered on. Free loading at D - 88433 Schemmerhofen.

Condition: ready for operation (used), functionality: fully functional, Vertical cup grinding machine DELTA LF 350 -Largest grinding surface approx. 155x360mm -Standard magnetic plate / Eclipse 350x150mm -Max. distance table / disc approx. 280mm -Distance grinding spindle / column approx. 315mm -Spindle speed 2840 rpm -Cup grinding wheel dimensions 200x80x78mm Lsdozz Sxlopfx Aazsrt -Drive power 3 kW -Coolant system -Machine enclosure -Grinding wheel guard -Documentation Dimensions: L x W x H 0.7 x 1 x 1.8 meters / Weight approx. 550 kg Errors and omissions excepted.
