Used Servo Motor for sale (26,687)

Condition: used, Synchronous servo motor with holding brake and gear, Geared motor, electric motor, angular gear motor Engine: Manufacturer: LUST LTI DRIVES Type: LSK-190-4-30-560 T1,P,KK,1R Order no.: 716090 Art. No.: 0970.8015 Machine type: Permanently excited synchronous servo motor DC link voltage of the controller Uzk: 560 VDC Nominal power: 12,13 kw Nominal speed: 3000 rpm Nominal torque Mn: 38,6 Nm Standstill torque M0: 61.5 Nm Ijdef Dlzqopfx Ag Njih Rated current In: 26.6 A Standstill current I0 / I0max: 41 / 164 A Pole pairs: 3 shaft diameter: 32 mm Wavelength 50 mm - Shaft journal with keyway and keyway DIN 6885 / A10x8x50 - Option 1R Resolver 1 pole pair - Option KK Terminal box - Option T1 (DIN-PTC double basic insulation) - Power connection 8-pole junction box - Resolver connection 12-pole junction box Holding brake: Manufacturer: LUST LTI DRIVES Type: NFH10-H/BA Order no.: 717173 Art. No.: 228-00043 Nominal voltage: 24 VDC Rated current: 4.5 A Nominal power: 108 W Braking torque: 160 Nm Angular gearboxes WESTFALIA Systemtechnik Shaft journal output: Ø 60 mm with feather key Shaft journal Length: approx. 120 mm Gearbox output speed: max 450 rpm. Gearbox input speed: max 4500 rpm. Transmission ratio: 10:1 - Gearbox can be mounted on two flange surfaces - Mounting hole on gear unit 180 x 180 mm / 180 x 230 mm - Transmission with 3-fold sprocket outer diameter: 147 mm, number of teeth: 17 Overall dimensions L x W x H: 1020 x 250 x 350 mm total weight: 175 kg sound condition 2 pieces available, price per piece [...]

Condition: good (used), Permanent Magnet Motor, Permanent Magnet Motor, Electric Motor, n-Mot, Perm Magnet Motors, Servo Motor, Spindle Motor, Permanent Magnet Three-Phase Servo Motor, AC Spindle Motor -Manufacturer: Reliance Electric, servo motor -Type: H-4050-P-HOOAA -Power: 1.86 kW -Speed: 4000 rpm -Frequency: 0-200 Hz -Technical data: see photo type plate -Shaft: Ø 19 x 50 mm -Number: 4 motors available -Price: per piece -Dimensions: 315/120/H145 mm -Weight: 9.2 kg/piece Iodpjw Adq Ssfx Ag Neih

Condition: excellent (used), 3 phase brushless servo motor Manufacturer: SIEMENS Type: 1FT6105-1AC71-4AH1 Numbers: YF P7204929 01 YF R021977803 YF R122124201 Diameter clutch: 80 mm Speed normal: 2.000 rpm Speed max.: 3.000 rpm Hole spacing flange: Coupling: Rotex GS 38/45 KTR Manufacturer: Kupplungssystemtechnik Rheina Dimensions: 520 x 250 x 190 mm Weight: 43 kg Three motors are available. Motors are from a CNC BAZ Hurko EX20. Isdpfxef Umuao Ag Neih Price per piece, single sale possible.

Condition: ready for operation (used), Axle height: 80mm, power: 5.4kW, torque: 22.4Nm, speed: 2300rpm, moment of inertia: 98.3kg/cm², weight: approx. 50kg. Including integrated holding brake. Documentation available. On-site inspection is possible. Isdowf Nydopfx Ag Nsih

Condition: used, machine/vehicle number: n/a, Manufacturer: Fanuc Model: a22/3000 Motor Spec.A06B-0148-B675 Iiedpfx Asu Egv Ijg Nsh Technical Data Output 4 kw Volt 132V Amp ~ 20A Frequency 200 Hz Speed 3000 rpm

Condition: used, functionality: fully functional, KUKA AG Servo Motor, Rev07, 1FK7105 5AY81 1YY3 Z, 0000131491 Model: 1FK71055AY811YY3Z Type: 0000131491 Condition: Used Technical data: SIMOTICS 3 203V AC 15.5A 8.3kW General: Three-phase synchronous motor Frame size: S18 Rated speed: 3000 min⁻¹ / max. 5000 min⁻¹ Encoder type: KTY 84 Insulation class / Protection rating: IP65 Thermal class: F Iodjw Ex Nzjpfx Ag Njih Revision no.: 07 Standard: EN 60034 Removed from Kuka KR360 R2830

Condition: used, Linear unit, linear axis, gantry axis with servo drive, synchronous servo motor, electric slide, loading unit, linear guide with servo motor and pneumatic gripper REXROTH INDRAMAT Type: MKD0771B-061-KP1-KN Ident No. 247238 0001 Year of manufacture: 2000 Axis movement: 2400 mm Carriage length: approx. 500 mm Total length: 3520 mm - Pneumatic feed gripper (clamping gripper with 2 Festo compressed air cylinders) - Standard linear guide 65 x 25 mm - Steel base profile - Ball screw Ø 32 x 10 mm - pneumatic with position indicator - Permanent servo motor type: MKD071B-061-KP1-KN (Part no.: 261989, p. no. MKD071-50234, brake with 24 V DC) Iedpogi E Hajfx Ag Neih Overall dimensions L x W x H: 3520 x 400 x 580 mm Weight: 340 kg good condition possible drive controllers under stock no. 53628 and stock no. 53673

Condition: good (used), Servo motor, gear motor, electric motor, three-phase motor -Manufacturer. Lenze, servo motor with gearbox and encoder -Engine: Type MDSKS036-23 -Voltage: 345 V / 200 Hz -Power: 0.54 kW -Gearbox: Type GKR04-2 N SAR 2B i=8.178 -Shaft: Ø 25 x 60 mm -Encoder: Baumer BHK 06.24K500/K548 -Number: 1x gear motor available -Price: per piece -Dimensions: 440/260/H140 mm -Weight: 11.2 kg Isdpfxjwzi T Ne Ag Noih

Condition: new, Fanuc A06B-0266-B100 AC Servo Motor + A860-2000-T301 SN 8318 Pulse encoder, unused in opened original packaging, 100% functional, scope of delivery as per photos Iisdpfem Hq Aysx Ag Nsh

Condition: ready for operation (used), An unused Siemens servo motor is available. Axle height: 160mm, power: 31kW, torque: 257Nm, speed: 1150rpm, moment of inertia: 2586kg/cm², weight: approx. 300kg. Including integrated holding brake. Documentation available. On-site inspection is possible. Isdpfxjwf Nxmj Ag Noih

Condition: used, functionality: fully functional, KUKA AG Servomotor, Rev06, 1FK7083 5AF81 1YY3 Z, 0000131493 Model: 1FK70835AF811YY3Z Ijdpsw Ex Nhsfx Ag Neih Type: 0000131493 Condition: Used Technical Data: Simotics 3 133V AC 9.3A 3.1kW General Information: Three-phase synchronous motor Frame size: S16 Rated speed: 3000 min⁻¹ / max. 6000 min⁻¹ Encoder type: KTY 84 Insulation class / protection: IP65 Thermal class: F Rev. No.: 06 Standard: EN 60034 Removed from Kuka KR360 R2830

Condition: good (used), servo motor, electric motor, DC motor, stepper motor, stepping motor -Manufacturer: Isoflux, servo motor with encoder -Servo motor: Type 544,4,25,98/90 -Speed: max: 2500 rpm -Voltage: 96 V -Shaft: Ø 16 x 50 mm -Bolt circle: Ø 130 x 10 mm -Protection class: F -Encoder: Heidenhain ROD 426 1000 -Dimensions: 490/127/H150 mm -Weight: 14.9 kg Iisdpfx Ajww Twqsg Neh

Condition: new, Fanuc A06B-0266-B100 AC Servo Motor + A860-2000-T301 Pulse Decoder SN 9213, unused in opened original packaging, 100% functional, scope of delivery as per photos Iisdpfxjm Nx Nhe Ag Neh

Condition: used, functionality: fully functional, KUKA AG Servomotor, Rev07, 1FK7103 5AF81 1YY3 Z, 0000131492 Model: 1FK71035AF811YY3Z Type: 0000131492 Condition: Used Technical Data: SIMOTICS 3 156V AC 17A 6.9kW General Information: Three-phase synchronous motor Frame size: S17 Rated speed: 3000 min⁻¹ / max. 5000 min⁻¹ Iisdsw Ex Iqepfx Ag Nsh Encoder type: KTY 84 Insulation class / protection rating: IP65 Thermal class: F Revision number: 07 Standard: EN 60034 Removed from Kuka KR360 R2830

Condition: good (used), servo motor, electric motor, DC motor, stepper motor, stepping motor -Manufacturer: Isoflux, servo motor type 544,4,25,96/13 -Speed: max: 2500 rpm -Voltage: 96 V Iiodpfx Agjwwqi Ro Nsh -Shaft: Ø 16 x 50 mm -Bolt circle: Ø 130 x 10 mm -Protection class: F -Dimensions: 500/128/H150 mm -Weight: 16 kg

Condition: new, Fanuc A06B-0315-B001 AC servo motor, serial no. according to photo, unused in opened original packaging, 100% functional, scope of delivery according to photos Isdpfxji D H Aze Ag Neih

Condition: good (used), Permanent Magnet Motor, Permanent Magnet Motor, Electric Motor, n-Mot, Perm Magnet Motors, Servo Motor, Spindle Motor, Permanent Magnet Three-Phase Servo Motor, AC Spindle Motor -Manufacturer: Baumüller, servo motor with brake -Type: DSCG 045 S65U40-5 UL -Power: 1.2 kW -Speed: 4000 rpm -Technical data: see photo type plate -Shaft: Ø 14 x 30 mm -Number: 2 motors available Iijdpfx Ajwvqiueg Neh -Price: per piece -Dimensions: 255/93/H140 mm -Weight: 5.3 kg/piece

Condition: ready for operation (used), Fanuc A06B-0317-B002#7000 AC servo motor , serial no. according to photo , hole spacing of mounting holes: 142 x 142 mm, Ø drive shaft: 35 mm ,used, encoder cover damaged, otherwise normal signs of wear, 100% functional Ijdsi D H Dfopfx Ag Nsih

Condition: good (used), Permanent Magnet Motor, Permanent Magnet Motor, Electric Motor, n-Mot, Perm Magnet Motors, Servo Motor, Spindle Motor, Permanent Magnet Three-Phase Servo Motor, AC Spindle Motor -Manufacturer: Baumüller, servo motor with brake -Type: DSCG 045 A65U40-5 UL -Power: 0.46 kW -Speed: 4000 rpm -Technical data: see photo type plate -Shaft: Ø 14 x 30 mm -Number: 3 motors available -Price: per piece Iijdpowvqdrofx Ag Neh -Dimensions: 215/94/H135 mm -Weight: 3.6 kg/piece

Condition: ready for operation (used), Fanuc A06B-0502-B067#7000 AC Servo Motor, Ø drive shaft: 35mm, hole spacing of the mounting holes: 142x142mm, used, 100% functional Iedpji D H E Sefx Ag Njih

Condition: good (used), Year of construction: 2011, Permanent Magnet Motor, Permanent Magnet Motor, Electric Motor, n-Mot, Perm Magnet Motors, Servo Motor, Spindle Motor, Permanent Magnet Three-Phase Servo Motor, AC Spindle Motor -Manufacturer: Fanuc, AC Spindle Motor -Type: A06B-0269-B100 -Power: 5.5 kW -Speed: 3000 rpm -Technical data: see photo type plate Iedpfx Agowvfgzo Nsih -Shaft: Ø 35 x 75 mm -Dimensions: 320/175/280 mm -Weight: 23 kg

Condition: ready for operation (used), Fanuc A06B-0533-B551 AC servo motor , serial no. according to photo , hole spacing of mounting holes: 54 x 54 mm, Ø drive shaft: 9 mm ,used, mounting flange damaged (see photo), otherwise normal signs of wear, 100% functional, scope of delivery according to photos Iiedpfji D H Iqox Ag Nsh

Condition: good (used), Year of construction: 2011, Permanent Magnet Motor, Permanent Magnet Motor, Electric Motor, n-Mot, Perm Magnet Motors, Servo Motor, Spindle Motor, Permanent Magnet Three-Phase Servo Motor, AC Spindle Motor -Manufacturer: Fanuc, AC Spindle Motor -Type: A06B-0269-B400 -Power: 5.5 kW -Speed: 3000 rpm -Technical data: see photo type plate -Shaft: Ø 35 x 75 mm -Dimensions: 360/175/280 mm -Weight: 30 kg Isdpfewvfgnox Ag Noih

Condition: ready for operation (used), Fanuc A06B-2273-B100 AC- Servo Motor SN:C169V1F91 , used, small traces of use, 100% functional, scope of delivery according to photos Isdpfx Asi D H R Njg Nsih

Condition: ready for operation (used), Fanuc A06B-2273-B100 AC- Servo Motor SN:C179V33B0 , used, small traces of use, 100% functional, scope of delivery according to photos Iisdpfx Agoi D H R Te Nsh
