Used Worm Gear for sale (11,967)

Condition: repair required (used), Warehouse clearance 2 gear hobbing machines for sale as parts donors. Price: 600.00 / for both Ltsdox E Uz Tepfx Ah Uea

Condition: excellent (used), Gear motor, electric motor, electric gear motor, stainless steel motor, stainless steel gear motor, stainless steel bevel gear motor Gearmotor: SEW-Eurodrive type SA87R57DRN80M4 -Speed: 17 rpm Ltedpow A Abijfx Ah Uea -Power: 0.75 kW -Hollow shaft: Ø 60 x 250 mm -Protection class: IP54 -Dimensions: 840/310/H370 mm -Weight: 128 kg

Condition: used, Year of construction: 2001, Technical details: Ljdpfx Asxxl Sgjh Ueta max. wheel diameter: 50 mm gear width: 20 mm max. module: 4 mm min. module: 0,1 mm total power requirement: 12,5 kW weight of the machine ca.: 4000 kg dimensions of the machine ca.: 2,2 x 2,5 x 2,3 m workpiece length - max.: 300 mm

Condition: good (used), Year 2003 Processing machine for machining splines and sprockets on crankshafts or shaft-like components Liebherr PC-NC control system for disk cutting wheels in the range 180-300mm for hobbing Vertical machining with straight shaping head and synchronization Clamping in chuck in the machine bed and tailstock as counterholder Integrated ring loader between machining and loading position Automatic loading hatch from above with loader interface The machine is currently still in series production and can be inspected under power Front screen of the monitor defective, display undamaged after visual inspection Fuse for controls and drives included - free location Availability after consultation, warranty excluded Year of Production:2003 Shaping machine for producing splines and sprockets onto crankshafts and Control Liebherr PC-NC For shaping tooling in range of 180-300mm for Hobbing Vertical machining with straight cutting head and Synchronization Clamping in Jaw on the machine bed and tailstock as counterpart integrated Ring-load between Machining and loading position automatic Gantry door for overhead loading and corresponding interface Ltedpfx Ahst Utdps Usa Machines are actually in serial production and can be inspected upon request front glass of Monitor damaged, screen itslef seems unharmed on first glance safeguarding of control and drives included - free location availability on agreement, no warranty possible

Condition: ready for operation (used), functionality: fully functional, Used gear grinding machine Niles ZSTZ 630i. The machine is fully functional; a video can be provided upon request. Ltodsxzfugjpfx Ah Uoa

Condition: excellent (used), Gear motor Flender MBH 125CC-B 27.7/1 Helical bevel geared motor 11 kW at 1400 1/min. 230/400 V, 50 Hz, IP 55 were operated with frequency converters Ltjdek E Htcopfx Ah Uea Suitable frequency inverters Walther Flender ZZ0103069.34003 Sinus Penta available Altogether 15 geared motors and 12 pieces frequency inverters available !!! Very good condition, directly from production!!!

Condition: good (used), Year of construction: 1998, spindle diameter 90 mm control Siemens SINUMERIK 840 C voltage 400 V stroke position adjustment 100 mm table hole 150 mm no. of strokes 100-1200 Hub/min weight of the machine ca. 8,0 t Key data Normal module: 6 mm Max. workpiece pitch circle diameter: 250 mm Max. tooth width (straight teeth): 60 mm Helix angle adjustment: 45° to +0.5° Axis angle: 0° to 90° Center distance workpiece/jigging spindle: –80 mm to +320 mm Stroke position, stroke length Max. stroke position range (depending on stroke length): 0 mm to 80 mm Stroke position adjustment range: 0 mm to 80 mm Ltsdpfexyadtsx Ah Uea Stroke drive Stroke rates infinitely variable Standard: 100 to 1200 DH/min Motor for stroke drive: 9 kW Maximum cutting speed: 150 m/min Feeds Rotation axes (tool C1, workpiece C2 axis): Feed stepless relative to 100 mm pitch circle diameter: 1.0 to 9420 mm/min Radial axis (column slide X1 axis): Feed continuously variable: 1.0 to 9420 mm/min, rapid traverse corresponds to maximum feed rates Connected load / weight Total connected load: 26 kVA Total weight (standard version): approx. 9,000 kg

Condition: good (used), Gear motor, electric motor, electric gear motor -Speed: 33 rpm -Power: 1.1 kW -Design: B3 -Diameter shaft: 40 mm -Protection rating: IP 54 -Height shaft axis: 155 mm -Long distance between holes: 115mm -Hole spacing across: 200 mm -Number: 1x motors available -Price per piece -Dimensions: 580/270/H260 mm Lodpfoci N Hhox Ah Usta -Weight: 49kg

Year of construction: 2015, condition: ready for operation (used), A high-performance planetary gear production line EMAG including automation and peripheral equipment is available. 1) Raw parts storage (stacker) EMAG. 2) Vertical single-spindle turning center EMAG VLC100, max. workpiece diameter: 100mm, max. workpiece height: 150mm, max. chuck diameter: 160mm, max. swing diameter: 210mm, travel X/Z: 650mm/375mm, speed: 6000rpm, rapid traverse X/Z: 60m/min/30m/min, tool stations: 12, tool holder: VDI30, control: Siemens 840D sl. 3) Vertical single-spindle turning center EMAG VLC100, max. workpiece diameter: 100mm, max. workpiece height: 150mm, max. chuck diameter: 160mm, max. swing diameter: 210mm, travel X/Z: 650mm/375mm, speed: 6000rpm, rapid traverse X/Z: 60m/min/30m/min, tool stations: 12, tool holder: VDI30, control: Siemens 840D sl. 4) Vertical hobbing machine EMAG VLC200H, max. workpiece diameter: 200mm, max. module: 4, travel X/Y/Z: 790mm/120mm/400mm, swivel range: +/-35°, control: Siemens 840D sl. 5) Vertical chamfering/deburring machine EMAG VLC100C, max. workpiece diameter: 100mm, max. workpiece height: 150mm, travel X/Z: 900mm/375mm, control: Siemens 840D sl. 6) Internal automation EMAG TrackMotion with 2x TransLift carriages. Type: transfer automation, purpose: part feeding/intermediate station transport/part removal, control: HT8. 7) O-belt automation for each EMAG machining machine with pallet and belt buffer, max. pallets: 24pieces/machine. 8) Marking press Markator for part marking. 9) Part handling unit EKF Automation in gantry design. 10) Basket stacking cell EKF Automation for the finished parts storage, number of stacks: 3. Documentation available. An on-site inspection is possible. Ljdpfxox Dm D Ij Ah Usta

Year of construction: 2015, condition: excellent (used), Polygon and surface machining, gear and spline shaft machining, gear tooth pointing, shift stop machining, chamfering and deburring, SCUDDING See document Ltjdsxupg Tjpfx Ah Usa

Condition: excellent (used), Year of construction: 2004, functionality: fully functional, CNC Gear Hobbing Machine Horizontal . no tailstock, just for chuck parts . max. gear diameter: 90 mm . max gear width (b): 50 mm . max module: 3 Lsdpfxoqaf U To Ah Usta

Condition: good (used), Year of construction: 2008, functionality: fully functional, total width: 1,700 mm, total length: 1,765 mm, travel distance X-axis: 500 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 400 mm, compressed air connection: 4 bar, Wenzel Smart Gear - gear and 3D coordinate measuring machine The machine is in very good condition and fully functional. It has been regularly serviced and well looked after. Machine data: • Machine dimensions L=1765mm W=1700mm H=2232mm • Max. rotary table workpiece diameter = 5 to 270mm • Measuring accuracy gear testing in accordance with VDI/VDE2612/2613 Group II • Max. rotary table load = 20 daN • Travel paths X= 500mm Y=450mm Z=400mm • Scanning probe - Renishaw SP600M • 7x SP600 change plate for probe included • Module measuring range 0.4 - 10mm • Active air damping of the machine • Year of manufacture 2008 • Accessories such as driver, reference ball etc. as shown • Jaw chuck D=80mm with inside and outside jaws • 24 inch monitor, mouse, keyboard The following software modules are included: Gear cutting software: • TMain - program management • TStylus – Probe management • TCali – Probe calibration • TAmo – Calculated axis position determination • TGear – Spur gear measuring program • TGear – Head and root circle option Ledjvvudkopfx Ah Ujta • TWorm – Worm measuring program 3D software • Metrosoft CM 3.8

Condition: ready for operation (used), Worm conveyor Saxlund Brand: Saxlund A-A Length: 4500 mm, ∅ 400 mm, Driving: 15 kW gear unit. On stock: 2 pieces Lodpot Izhvsfx Ah Usta

Condition: good (used), Servo motor, geared motor, electric motor Ljdpfx Ahshyutuj Usta -Manufacturer motor: Siemens type 1FK7042-5AF71-1SGO -Voltage: 267 V -Torque: 3.0 / 2.6 Nm -Speed: 9000/3000 rpm -Manufacturer gearbox: alpha type LP 090-M02-30 -111-001 -Translation:: 1:30 -Shaft: Ø 22 x 35 mm -Construction: B14 -Dimensions: 345/95/H143 mm -Weight: 10.1 kg

Condition: ready for operation (used), Year of construction: 1963, functionality: fully functional, wheel diameter: 900 mm, workpiece diameter (max.): 150 mm, overall weight: 8,200 kg, rotational speed (max.): 80 rpm, workpiece length (max.): 750 mm, TECHNICAL DETAILS Max. wheel diameter: 900 mm Max. module: 10 Ltsdsxvr Enjpfx Ah Uja Max. cutter diameter: 190 mm Max. cutter length: 320 mm Cutter speeds (stepless): 13–80 rpm Max. workpiece length: 750 mm Max. workpiece diameter: 150 mm MACHINE DETAILS Machine weight approx.: 8,200 kg Note: The arbor for the counter-support is missing.

Condition: used, Year of construction: 2012, max. wheel diameter 300 mm gear width 320 mm max. module 10 min. module 0,5 ical angle 45 ° frequency 50 Hz voltage 400 V Ltjdpfx Aovxwtgoh Uea main fuse 125 A x-axis 270 mm y-axis 250 mm z-axis 320 mm A - axis +/- 45 ° B - axis 360 ° C-axis 360 ° total power requirement 89 kW weight of the machine ca. 23,5 t dimensions of the machine ca. 11,2 x 5,5 x 2,9 m automated Oil slinger station EWAB workpiece storage Hoffmann coolant filter system HSF 100 SE/K Minimax fire extinguishing system W+W air filter system Promot Automation "Cellmaster" (3 cells) year 2019

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, machine/vehicle number: 27506, Complete overhaul in 2009 CNC gear hobbing machine Pfauter PE 150 Serial number: 27 506 Year of manufacture: 1991 – complete overhaul in 2009 Ltsdpfjxtpg Rjx Ah Uja CNC control: SINUMERIK 840 D

Condition: good (used), Year of construction: 2008, Gear grinding machines Reishauer RZ303 Ljdpfx Ahexz E S Ej Ueta

Condition: excellent (used), Year of construction: 2006, operating hours: 53,244 h, functionality: fully functional, Technical Data – Gleason Phoenix II 600HC (CNC Hypoid Gear Cutting Machine) Working Area Max. workpiece diameter: Ø 600 mm Max. tooth depth: 24.6 mm Max. gear width: 110 mm Number of teeth: 1–300 Cutterhead size face milling (FM): 18" diameter Cutterhead size hobbing (FH): 210 mm radius Max. cutter spindle speed: 600 min⁻¹ Work Spindle Front taper diameter: Ø 203 mm Taper bore diameter: Ø 181 mm Bore depth: 884 mm Max. work spindle speed: 600 min⁻¹ Dimensions and Weight Footprint L × W × H: 4.4 × 3.5 × 3.5 m (incl. peripherals) Machine weight: 26,000 kg Ljdpfxjxwzu Is Ah Uota Connection Data Total connected load: 139 kVA Main fuse: 200 A Operating voltage: 400 V Mains frequency: 50 Hz Control voltage: 24 V DC

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, machine/vehicle number: 73866, workpiece weight (max.): 60 kg, rotational speed (max.): 2,300 rpm, overall weight: 5,000 kg, TECHNICAL DETAILS Module, max.: 7 Grinding worm diameter: 280–350 mm Grinding worm width: 84–104 mm Grinding worm speed (grinding): 1,100–2,300 rpm Grinding worm speed (profiling): 50–95 rpm Number of teeth, min.: 6 Number of teeth, max.: 600 Ltodpfoxvrzisx Ah Uja Maximum permissible outside diameter: 360 mm Maximum workpiece weight: 60 kg Maximum grinding stroke: 175 mm Workpiece speed (grinding): max. 250 rpm MACHINE DETAILS Machine weight approx.: 5 t Electrical Data Mains connection: 3 × 400 V 50 Hz Machine voltage: 3 × 400 V 50 Hz Control voltage: 1 × 230 V 50 Hz / 1 × 24 V DC Contactor voltage: 1 × 24 V DC Solenoid valve voltage: 1 × 24 V DC

Condition: used, Year of construction: 2002, crown gear diamter max. 500 mm distance crown gear spindle - front pinion spindle 150 - 350 mm distance pinion spindle - front crown gear spindle 120 - 340 mm control GE FANUC Series 160i-M 70 mm pinion turning speeds max. 0 - 3.000 mm crown gear turning speeds max. 0 - 2.600 U/min inner taper pinion spindle Ø 99,2 mm inner tape crown gear spindle Ø 99,2 mm rated current 30 A weight of the machine ca. 6,40 t dimensions of the machine ca. 2,40 x 2,20 x 2,10 m Ljdjvxwpuspfx Ah Ueta Own lapping system included Was also operated at a lapping center

Condition: used, Year of construction: 2005, Reishauer RZ150 gear grinding machine Ltsdpfx Aoxz E Sreh Uea

Condition: used, Year of construction: 1999, Technical details: max. wheel diameter: 5 - 260 mm Lodjqvcnnopfx Ah Ueta gear width: 400 mm max. module: 15 min. module: 0,5 gear hobbing diameter - internal: 30 mm max. helix angle: > 85 ° Aussenverz. max. helix angle: > 45° Innenverz. Testing Range vertical: 400 mm dist. between centers: 5 - 600 mm table diameter: 260 mm max. table load: 100 kg speeds: 30 1/min total power requirement: 1,6 kVA weight of the machine ca.: 900 kg dimensions of the machine ca.: 200 x 1300 x 2150 mm CNC Gear Tester in good condition, out of OEM Test Lab. For measuring of spur and helical toothing, additional of rotationally symetric parts as true running, coaxiality, axial runout, etc. with tool changer ( 4 nos.) *

Condition: used, Year of construction: 2008, ratio of transmission 10:1 min. number of teeth 3 max. number of teeth 200 range of tooth size 20 mm tooth width max. 58 mm spindle speeds (infinitely variable) 6000 U/min work piece spindle speed 1200 U/min diameter of tools max. 230 mm diameter of tools min 69,85 mm x-axis 325 mm y-axis 350 mm z-axis 470 mm b-axis + 90,1 / - 1 ° work piece table - Ø 212,71 mm Control SIN 840 D SIEMENS total power requirement 75 kW weight of the machine ca. 10.000 Kg dimensions of the machine ca. 6,10 x 4,40 x 3,30 m Internal probe Renishaw LP2 (axis X2;Y2) Hoffmann coolant filter system HSF 100SE/K (built in 2008) Tank capacity 2500L VT oil mist filter system Ltodpfsvxwmtox Ah Uoa

Condition: ready for operation (used), Year of construction: 2018, functionality: fully functional, spindle speed (max.): 3,000 rpm, travel distance X-axis: 90 mm, travel distance Y-axis: 80 mm, travel distance Z-axis: 400 mm, spindle bore: 40 mm, TECHNICAL DETAILS Travel Distance X-Axis: 90 mm Travel Distance Y-Axis: 80 mm Travel Distance Z-Axis: 400 mm Ltedsxvrarjpfx Ah Uea Maximum Permissible Head Circle Diameter: 140 mm Milling Arbor Diameter: 22 mm Maximum Gear Cutting Length: 160 mm Angles Maximum Swivel Angle of Milling Head +A Direction: 45° Maximum Swivel Angle of Milling Head -A Direction: 118° Workpiece Spindle Outer Diameter: 105 mm Bore: 40 mm Rapid Traverse X-Axis: 7,500 mm/min Y-Axis: 5,000 mm/min Z-Axis: 15,000 mm/min Rotational Speeds Tool: 50 to 4,000 rpm Workpiece Spindle max.: 3,000 rpm MACHINE DETAILS Operating Hours: 29,790 h Cycle Time: 6,654 h Electrical Connection Mains Connection: 400 V (AC) Supply Voltage: 400 V (AC) Control Voltage: 24 V (DC) Frequency: 50 Hz Connected Load: 13 kVA Cable Cross-Section: 16 mm² Fuse Rating: 63 A Dimensions & Weight Space Requirement: 5.25 x 4.06 x 2.94 m Machine Weight: 8 t EQUIPMENT Industrial Filter IFS EC1500 Sediment Separator Knoll KF200/640 Integrated Chip Conveyor with Magnetic Separator Machine Automation for Loading and Unloading Workpieces Robot Automation Güdel KTB-31/62, Year Built: 2018 with Station for Part Remover
