WEINIG / DIMTER Opticut S90

WEINIG / DIMTER Opticut S90

Condition: excellent (used), Year of construction: 2005, Weinig Dimter OptiCut S 90 optimizer with 2 ejectors Dsdpfsi Apgmsx Ag Rokk – after technical review – German production – year of manufacture 2005 TECHNICAL PARAMETERS: max. length of cut material 4500 mm max. width 360mm max. height 160mm automatic length measurement optimization in 4 quality classes total power 13 kW blade motor power 7. 5 kW pneumatic side and top pressure disc diameter max. 500mm OptiCom Assist control receiving conveyor 5600 mm two ejectors total length 13 m component marking printer cutting accuracy +/- 0.5 mm transport dimensions (length / width / height) 600 / 240 / 190 cm weight ~ 1800 kg

Condition: new, Year of construction: 2026, CORMAK C2141 ATC PREMIUM (2100 x 4200 mm) is a dynamic and precise milling plotter based on components from global manufacturers, suitable for the toughest tasks, which works great in industrial production. Constant quality control and components used in the machine construction guarantee high quality processing of materials such as: wood, wood-like boards, MDF, OSB, PVC, HPL, plywood, plexiglass, dibond, carbon, alucobond. 1. Work table Sectioning table with four independent vacuum sections, made of rigid and durable HPL boards, Each section has holes to which negative pressure from the vacuum pump is supplied through a system of pipes, The main holes in the vacuum table have plugs that allow you to attach different formats of materials, 2. HQD spindle Brushless spindle from a renowned high-class manufacturer with a power of 9 kW , powered by an inverter, with overload protection. Milling electrospindle equipped with an innovative AIR cooling system . Adapted to automatic tool changing, which shortens machining time due to the lack of downtime associated with manual cutter change. 3.Drive Energy-saving high-end drives Leadshine servo drives with 1500W power and high holding torque (Double on the Y axis) controlled by the NK-105 G3 digital controller , they ensure excellent quality machining while maintaining high working speeds in individual directions. Brushless servo motors driving the X and Y axes transmit power via high-quality planetary gears. The Z axis, where positioning precision is crucial, is driven by a reinforced ball screw. The movement of the gate along the X and Y axes is carried out by means of HIWIN guide rails and helical gear wheels, which guarantee many years of trouble-free operation and are made of high-quality hardened and tempered steel. 4. Construction The construction of the sliding gate is made of cast iron, which achieves incredible rigidity and absorbs vibrations generated during processing very well. 5. 8-tool magazine + tool measurement sensor The machine is equipped with an 8-position linear tool magazine, a set of ISO30 cones and ER32 collets The set includes holders: ISO30 and sleeves for mounting tools in the following dimensions: 1/2" - 6 pcs.; 1/8" - 2 pcs.; 3-4mm - 2 pcs.; 5-6mm - 4 pcs.; 7-8mm - 2 pcs.; 9-10mm - 2 pcs. 6. Vacuum pump and suction foot (optional) 4 independent vacuum sections. The pneumatically operated extraction foot is located at the spindle and allows for the connection of any chip extraction system, maintaining the cleanliness of the processing, safety and at the same time maintaining the precision of the work. Dksdpfx Aevupu Ujg Rsk 7. Software, INDUSTRIAL CONTROL : Control NK-105 G3 The machine supports the latest version of CAD/CAM software. OPTIONALLY The latest UCanCAM V12 software Technical parameters Working Field 2100x4200mm Z-axis 300mm Design Arm - cast iron / table - welded steel Drives 1500W Leadshine servo drives Table T-shaped / hybrid Spindle power 9kW Spindle Air cooled HQD (oil mist optional) Spindle revolutions from 6000 to 24000 rpm Power supply 400 V, compressed air min. 8 bar Re-positioning accuracy 0.01mm Linear bearings trapezoidal rails, Hiwin trolleys Material fixing vacuum, hybrid Vacuum pump vacuum 2x7.5 kW (option) Software UCanCAM V12 (option) Dimensions 5070x2870x1900mm Weight 3350 kg

Condition: new, Step By Step Wet Painting Systems Elboy Industrial Solutions designs and manufactures full range of paint shops for your product. With ELBOY, you can navigate through your facility with virtual reality in the design phase, enabling you to make the desired changes in the design phase and not to encounter the surprise results. It provides designing and manufacturing services for your application by paying special attention to environmental pollution and work safety issues for the processes of Sandblasting, Putty, Washing, Undercoat and Finishing Coat for all sizes of products. Step by Step are systems with overhead conveyor or floor conveyors which can be designed for all sizes of product. Dkjdpfody Dw Ajx Ag Rek Booths of Sandblasting, Chemical Washing, Pre-coat, Drying, Putty , Top Coat and Baking can be integrated into the system. In order to respectively carry out the processes determined by the system step by step, the automatic doors are opened at the end of the time period and the product automatically proceeds to the next process line. These fully automated systems are controlled via a 15” touch screen and provide various reporting methods such as main computer monitoring, product reporting and score reporting upon the demand and provide remote control. These are the paint shops where your product is designed and manufactured by our engineers in line with your capacity, use area and other demands. Maximum efficiency is aimed to be provided with minimum staff and the least space usage at electrostatic powder coating or wet paint, sandblasting, varnishing, coating, washing and similar system requirements.

Condition: excellent (used), Year of construction: 2002, Manufacturer - OMES Capacity - 1400 pallets/shift Dkjdswwiv Ajpfx Ag Rsk Year - 2002 Line currently dismantled

Condition: used, cutting width max. 310 mm Cutting height max. 125 mm Saw blade diameter 500 mm Motor output 5,5 kW SALVAMAC LEGEND 500 – The semi-automatic under-table cross-cut saw ----- ----- Maximum cutting area: 220x125/ 260x100/ 285x80/ 310x50 mm. When sawing stacked boards h max. 100 mm. The structure is made entirely of thick-walled and reinforced throughout painted steel. Solid floor mounting system with flanged steel feet for the mounting hole. Bimanual safety cutting control in ergonomic position. Engine power of the saw motor 5.5 kW. Adjustable cutting speed via a pneumatic controller. Maximum system for weight balance and longevity. Shock absorbing system. Independent pneumatic adjustment options to adapt to different Types of processing. Durable and easily replaceable saw blade adjustment bar. HM circular saw blade, diameter 500 mm, Z=108. Pneumatic upper workpiece clamping press with electro-pneumatic control. Presser movement system using innovative ball bearings with double dust protection and automatic lubrication system. CE-compliant electrical system. The CE models must come with it as standard At least 1 meter long support plates/roller tables must be provided at the inlet and outlet. Technical data: ----- Saw cross section max. mm. 220x125, 260x100, 285x80, 310x50 Dodov Uq Tlspfx Ag Rekk Saw blade motor power: 5.5 kW Saw blade diameter: 500 mm Saw blade type: HM Z=108 Saw blade rotation speed: 2800 rpm Air consumption per cycle: 5 Nl Intake port: 1 x 120 mm / 1 x 100 mm Air pressure: 6 - 8 bar Voltage: V 400/50 Hz, 3 phase Worktop height: 900 mm +- 20 mm Color: Ral 7035 Machine additionally equipped with: ----- 2 m infeed table (right of the saw) with unpowered rollers: Painted steel frame with galvanized wheels. load capacity 230 kg, Diameter 60 mm, distance 250 mm, width 320 mm. The space between the roles is enclosed in painted steel. Including lateral guidance. 2 m outfeed table (left of the saw) with unpowered rollers: Painted steel frame with galvanized wheels. Load capacity 230 kg, diameter 60 mm, distance 250 mm, width 320 mm. The space between the rollers is of enclosed in painted steel. Includes side guide, stop guide and millimeter scale. 2 pieces of strong pneumatic stops with a width of 200 mm ----- Total price ex works: on request! ----- Image and video not original, show identical model Further options such as longer inlet/outlet, stop systems on request! (technical data according to the manufacturer without guarantee!)

Year of construction: 2016, condition: excellent (used), functionality: fully functional, X-axis positioning speed HS version: 50 m/min Dodsygr H Iopfx Ag Rskk Electronic control of intermediate angles Max. internal inclination: 45° Max. external inclination: 15° Electronic CNC feed axis for the saw blade Usable cutting length, depending on model: 5 m Saw blade diameter: 550 mm Conveyor belt for step-by-step or automatic cutting Windows XPE operating system 10.4” color graphic TFT display – 800x600 (SVGA) Touch screen functionality

Year of construction: 2011, condition: used, functionality: fully functional, Finger jointing line for cross sections up to 200 cm² (80/240 mm or 100/200 mm), with the following. components: 1. HOWIAL tilt unstacking - SH/4t - 1,75x1,75x6,00m - 4t - short. Length 2,50 m, semi-automatic separation of the package. For tilting the wood pile up to 45°. Electric motor drive. stack dim. max. 1,75 x 1,75 x 6,00 m max. stacking load 4 t shortest wood length 2,5 m 2. HOWIAL - VE 1 lamella separator for crosscut saw. With pneum. controlled tongues, on which the material is marked for defects, deposited on the roller conveyor below. 3. HOWIAL - evaluation roller conveyor RO-1 digital wood moisture measuring, control and recording system for autom. recording and control of wood moisture in cycle measuring method according to electric resistance principle. 4. gann DMT-8 dig. Wood moisture measuring, control and recording system for automatic detection and control of wood moisture in the cycle measuring method according to the electrical resistance principle. Plant in large switchboard complete with ink jet printer. 5. HOWIAL - crosscut saw AS-30 B pneum. Under table crosscut, with 2 autom. feed units, autom. crosscut. Special photocell control for detection of fluorescent line markings. Automatic waste disposal possible. Saw motor power 7,5 kW saw blade diameter 700 mm feed drive approx. 2 x 1,5 kW Air pressure 8 bar feed speed max. approx. 60 m/min. 6. HOWIAL - conveyor belt cut off waste, with studded belt and guide plates belt width 350 mm belt 2000 mm long belt speed 0,4 m/sec. 7. HOWIAL - double roller conveyor RO-2 6,00 m long incl. transversal transport, drive by round belt, all rollers driven. Cross transport chain conveyor. Ejection ± moisture right Transport speed adjustable 100 m/min. length approx. 6,00 m Width of rollers approx. 400 mm Diameter 112 mm 8. compact finger jointing machine Cook Bolinder The technical data are original from Cook Bolinder: wood width from 75 to 245 mm Timber thickness from 20 to 105 mm Input lengths from 1m to 6 m Cross sections from 30 cm² to 200 cm² Pressing force 5 - 22 to Spindle diameter 50 mm tine profile 15/15 spindle speed approx. 6000 upm Total electrical connected load approx. 62 kW Machine weight approx. 9 to. Gluing OEST comb system for PU Modern Telemechanique SPS control. 9. HOWIAL - Roller conveyor with destacking system Driven roller conveyor with autom. ejector and hydr. driven destacking arms. Technical data: H: 920 mm Dkjdpoi Ezx Djfx Ag Rjk L: approx. 12.000 mm 10. safety fences incl. circuit breaker 11. finger joint testing machine BSPLT-100 Testing machine for finger joint bending test according to DIN 1052-1/A1 and EN 385 Support distances freely adjustable, attached dimension scale, autom. calculation of support distances in the software. Fully automatic test procedure by mouse click on PC (not included). Alternatively, the test procedure can be started by key operation on the front panel. Connection of any commercially available PC or laptop (Win 2000/XP) via the supplied RS232 serial cable. Fully automatic measured value logging as well as automatic logging in MS-Excel with graphical display. Representation max. wood width: 300 mm max. wood thickness: 140 mm max. compression force: < 100 kN max. support length: 2100 mm Measuring accuracy WITHOUT DISMANTLING

Condition: used, For sale: BRENTA industrial log bandsaw with Progress log carriage Heavy-duty BRENTA industrial log bandsaw (bandsaw / frame) including Progress log carriage, from a professional sawmill. Technical data - log bandsaw Manufacturer: Ateliers de Construction Louis Brenta SPRL (Belgium) Model: ETYELEC Machine serial number: 406341 Motor power: 60 HP (approx. 44 kW) Dsdex Ndphopfx Ag Rjkk Speed: 340 RPM Bandwheel diameter: Ø 1,400 mm Condition Bandwheels and frame overhauled and ground approx. 1 year ago New bearings on the bandwheels Runs smoothly Progress log carriage Heavy-duty industrial design Mechanical roller conveyor with chain drive

Condition: used, mileage: 962,877 km, lifting height: 20,000 mm, Year of construction: 2007, operating hours: 1 h, Drivetrain Drive: Wheel Weights Empty weight: 25.460 kg Dodjxwim Eopfx Ag Rskk Functional Lifting capacity: 14.800 kg Identification Serial number: 970090 / 5127349 Other information Front tyres / undercarriage remaining: 80 Rear tyres remaining : 80 Tyre brand: Goodyear Carrier engine: - Upper engine: - Counterweight: 0 Transport dimensions (LxWxH): 0x0x0 Additional information Please contact PFEIFER GROUP for more information

Condition: used, Präzision Kapp- und Gehrungssäge  / Precision Miter Saw OMGA T55 300 Baujahr / Year ca. 2009 mit Absaugung / with suction Sägeblattdurchmesser / Saw blade Diameter 300mm Dedpfxoxvh E Re Ag Rjkk Schnittbreite / Cutting width max. 90° 135 mm Schnittbreite / Cutting width max. auf 45° 90 mm Schnitthöhe / Cutting high  max. 98 mm Festpunkte bei / Fixed Points on a 45°- 30° - 22°30' - 15° - 10° rechts und links Sehr guter Zustand / Very good condition Verstellbare Präzisionskapp- und Gehrungssäge mit Drehtisch, selbstzentrierender Blockierung in den Hauptwinkeln 45°, 30°, 22°30’, 15°, 10° und 0° rechts und links, manueller Blockierung der Zwischenwinkel, Winkelablesung von Gradskala. Online-Video-Inspection by WhatsApp - MS Zoom - Telegram On Stock Emskirchen/Nürnberg - Available Immediately - Can be test
