CNC turning-milling center

DOOSAN Puma TT1800SY

Condition: excellent (used), Year of construction: 2010, turning length: 230 mm, turning diameter: 230 mm, spindle speed (max.): 5,000 rpm, spindle bore: 68 mm, spindle nose: A2-6, Doosan TT1800SY Isdpfx Aewzxcaofaotp

Condition: excellent (used), Year of construction: 2011, Turning and Milling Center Doosan Puma TT 1800 SY, Year 2012 Control: CNC Fanuc 18i-TB Number of simultaneous axes: 8 (C1, X1, Z1, Y / X2, Z2 / B & C2) Number of simultaneous axes according to export control: 4 (C1, X1, Z1, Y) Linear axes: 3 (X1, Z1, Y) Rotary axes: 1 (C1) Parallel axes: 4 (X2, Z2, B, C2) Technical Data: - X1 axis: 165 mm, X2 axis: 190 mm - Z1 axis: 700 mm, Z2 axis: 720 mm - Y axis: 100 (± 50) mm, B axis: 770 mm - Bar capacity: 65 mm - 2x Turrets – 12 + 12 tool stations Max. Turning Diameter: 230 mm Max. Working Length: 230 mm Spindle speed: 5,000 rpm Iodextxpbspfx Afastp Equipment: Standard, transformer, chip conveyor with coolant tank, 1 set of tool holders including driven tools, driven holders 2x axial and 2x radial holders, documentation Bar feeder LNS

Year of construction: 2014, condition: ready for operation (used), Control Unit Brand FANUC Model 31i-MODEL B Main Drive Spindle speed range 5000 Spindle motor power 18.5 / 22 kW Tool taper A2-6 Number of axis 9 Movement Iedpfexn U D Rsx Afaetp X-Axis Movement 165 mm Y-Axis Movement 100 mm Z-Axis Movement 770 mm Additional Equipment LNS bar interface the robot is not included Control Unit Brand FANUC Model 31i-MODEL B Main Drive Spindle speed range 5000 Spindle motor power 18.5 / 22 kW Tool taper A2-6 Number of axis 9 Movement X-Axis Movement 165 mm Y-Axis Movement 100 mm Z-Axis Movement 770 mm Additional Equipment LNS bar interface the robot is not included This 9-axis DOOSAN PUMA TT 1800 SY was manufactured in 2014, offering advanced capabilities for horizontal turning. Ideal for complex machining tasks, this machine ensures precision and efficiency. If you are looking to get high-quality turning capabilities, consider the DOOSAN PUMA TT 1800 SY machine we have for sale. Contact us for more information. Application Types Turning

Condition: used, Year of construction: 2007, turning diameter 300 mm turning length 600 mm control FANUC, 18i-TB turning diameter over bed slide 230 mm travel x1 165 mm Itsdpjxn Amtefx Afaop travel z1 700 mm travel x2 190 mm travel z2 720 mm travel -y axis +/- 50 mm main spindle bore 76 mm main spindle speed 5.000 U/min main spindle drive 22 kW max. torque on the spindle 208 Nm sub spindle bore 76 mm sub spindle speed 5.000 U/min sub spindle drive 22 kW max. torque on the spindle 208 Nm tool turret 2 x 12 Stat. number of driven tool stations 2 x 12 speed of driven tools 5.000 U/min max. torque 47 Nm work piece power 5,5 kW C-axis resolution 0,001 ° rapid traverse x + z axis 20 / 40 m/min rapid traverse y-axis 7,5 m/min total power requirement 68,4 kVA weight of the machine ca. 7,8 t Accessories: collet fixture on main spindle, hydr. 3-jaw chuck make KITAGAWA, BB 208, 210 mmø, on sub spindle, various tool holders for turret, bar loader make HYDRAFEED, model MULTIFEED MX-1B for bar dia. 3 - 80 mm and bar length up to 1650 mm, chip conveyor, coolant with belt filter device

Condition: excellent (used), Year of construction: 2012, Offered here is a Doosan Puma TT1800SY-GL CNC lathe including portal loader. The machine is in good condition and can be inspected under power in our warehouse. The scope of delivery includes various static tool holders and 4 driven tool holders. The machine will be loaded free onto truck by overhead crane. Make: Doosan Model: Puma TT 1800SY-GL Control: Fanuc 31i Year of manufacture: 2012 Technical Data: Turning diameter (lower and upper turret): 230 mm Turning diameter over bed: 230 mm Turning diameter over slide: 230 mm Recommended turning diameter: 210 mm Chuck size (both spindles): 210 mm/ 8 inch Spindle bore: 65 mm Travel: X1-Z1 (upper turret): 165x700 mm X2-Z2 (lower turret): 190x720 mm Y (upper turret): 100 mm A (sub spindle): 770 mm C-axis: 360° (0.001° increment) Feed rates: X1-X2-Z1-Z2: max. 20 m/min Y: 7.5 m/min A: max. 40 m/min Spindle speeds (both spindles): 6000 rpm Spindle power S1: 22/19.6 kW Spindle power S2: 22/18.5 kW Torque (both spindles): 208 Nm Number of tool stations: 24+24 (lower and upper turret) Iedpfexmkfhox Afastp Rotational speed of driven tools: max. 6,000 rpm Torque driven tools: 5.5/2.2 kW (7.4/3.0 kW) Power consumption: 64.86 kVA Dimensions: 3905x2250x2600 mm (machine only) + portal loader

Condition: good (used), Year of construction: 2008, Description Turning diameter: 300 mm Turning length: 600 mm Control: FANUC, 18i-TB + dialogue Turning diameter over bed slide: 230 mm Travel X1: 165 mm Travel Z1: 700 mm Travel X2: 190 mm Travel Z2: 720 mm Travel -Y axis: +/- 50 mm Main spindle bore: 76 mm Main spindle speed: 5,000 rpm Main spindle drive: 22 kW Max. spindle torque: 208 Nm Sub-spindle bore: 76 mm Sub-spindle speed: 5,000 rpm Sub-spindle drive: 22 kW Max. spindle torque (sub-spindle): 208 Nm Tool turret: 2 x 12 stations Number of driven tool stations: 2 x 12 Driven tool speed: 5,000 rpm Max. torque (driven tools): 47 Nm Workpiece power: 5.5 kW C-axis resolution: 0.001° Rapid traverse X + Z axis: 20 / 40 m/min Ijdpsw Av Szsfx Afajtp Rapid traverse Y axis: 7.5 m/min Total power requirement: 68.4 kVA Machine weight approx.: 7.8 t Machine dimensions (L x W x H): 3.91 x 2.07 x 2.08 m

Condition: like new (used), Year of construction: 2022, operating hours: 942 h, functionality: fully functional, turning length: 600 mm, turning diameter: 230 mm, spindle motor power: 22 W, spindle speed (min.): 50 rpm, spindle speed (max.): 5,000 rpm, spindle bore: 65 mm, travel distance X-axis: 165 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 700 mm, rapid traverse X-axis: 20 m/min, rapid traverse Z-axis: 40 m/min, rotational speed (max.): 5,000 rpm, rotational speed (min.): 50 rpm, bar passage: 65 mm, total height: 2,100 mm, total length: 5,000 mm, total width: 2,200 mm, overall weight: 8,800 kg, Equipment: documentation/manual, rotational speed infinitely variable, USED ​​8-axis CNC lathe "DN Solutions mod. PUMA TT1800SY" with motorized upper turret equipped with Y axis, motorized lower turret, opposing spindles and DN Solutions-Fanuc i-Plus iHMI CNC. Iedpfowuqp Eox Afajtp

Condition: like new (used), CUTTING DIAMETER: 230 MM TURNING LENGTH: 600 MM TAPER OF SPINDLE: ASA 6 STEP PANEL: 65 MM SPEED: 5000 RPM AXIS C: 0.001 DEGREE TAPER OF COUNTERSPINDLE: ASA 6 SPEED: 5000 RPM AXIS C: 0,001 DEGREE NR. TURRETS: 2 NR. STATIONS OF TOOL HOLDERS FOR TURRET: 12 NR. MOTORIZED TURRET: 12 CNC: FANUC 18 Itjdpeiux Agofx Afaop
