Deep drilling machine

Imsa MF 1600 S

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, drilling depth: 1,600 mm, feed length X-axis: 3,000 mm, feed length Y-axis: 2,100 mm, feed length Z-axis: 1,500 mm, overall weight: 50,000 kg, feed rate X-axis: 10,000 m/min, feed rate Y-axis: 10,000 m/min, feed rate Z-axis: 10,000 m/min, spindle speed (max.): 4,500 rpm, drill diameter: 40 mm, table length: 2,100 mm, table width: 1,900 mm, CNC Heidenhain iTNC 640 AXES OF MOVEMENT Maximum drilling depth in a single operation (V axis): mm 1,600 Table travel, horizontal movement (X axis): mm 3,000 Vertical movement (Y axis): mm 2,100 Lodpoywnr Nsfx Aa Iehg Column approach movement (milling) (Z axis): mm 1,500 Drilling slide tilting (resolution 0.001°) (A axis): +30° / -15° Table rotation (resolution 0.001°) (B axis): 360° Max axis feed rate: mm/min 10,000 DEEP HOLE DRILLING AND MILLING SPINDLE – ISO 50 Solid drilling capacity: mm 5 – 25 Maximum drilling diameter: mm 40 Adjustable spindle speed: rpm 1 – 4,500 Spindle power S1: kW 17 Spindle torque: Nm 324 Standard drilling tool holder: mm Ø 25 x 70 Maximum internal spindle pressure: bar 120 Taper type: ISO 50 DIN 69871/A Coolant system: Yes ROTARY TABLE Rotary table dimensions: mm 1,900 x 2,100 Table rotation (resolution 0.001°) (B axis): 360° Table load capacity in rotation: kg 20,000 T-slots: mm 22 OIL SYSTEM Hydraulic pump motor power: kW 4 – 7.5 Self-regulated oil pressure: bar 15 – 120 Self-regulated oil flow rate: l/min 5 – 80 Oil tank capacity: L 800 – 1,000 Cooled oil temperature: 25 – 32 °C Filtration grade: micron 16 MACHINE DIMENSIONS AND WEIGHT Width x Length x Height: mm 7,000 x 7,900 x4,700h Machine weight: kg 50,000 DRILLING CAPABILITIES WITH GUN DRILLS Maximum depth: mm 1,600 Maximum rotation speed: rpm 4,500 Minimum drilling diameter: mm 6 Maximum drilling diameter: mm 40 THREADING HEAD “IMSASISTEM” WORKING FEATURES Max rotation speed: rpm 4,500 Maximum threading on C40 steel: M36 Machine equipped with: • Remote electronic handwheel Heidenhain • ISO 50 tool changer magazine with 40 positions • Fume extraction system 4,000 m³/hour • Through-spindle air/oil system • M24 threads on table side • Various tools and equipment • Tool rack with assorted gun drills • User and maintenance manual and CE declaration of conformity

Condition: good (used), Year of construction: 2005, Horizontal machining center Machine type: Mori Seiki NH 8000 DCG Control: Fanuc 18 imb + Mapps 2 Year of construction: 2005 TECHNICAL DATA: Travels: X-axis: 1,400 mm Y-axis: 1,200 mm Z-axis: 1,200 mm B-axis: 0.001° Rapid traverse: (X/Y/Z): 50 m/min. Speed range: 10,000 1/min. Drive power: 30 / 25 kW Tool holder: BT 50 Tool changer Tool places: 140 Pallet system Number of pallets: 2 Pallet size: 800 x 800 mm Lhodpfsv Nhylsx Aa Ijg Machine weight: 32,000 kg Space requirement (LxWxH): 9.200 x 4.900 x 3.920 m Equipment features: Internal cooling (IKZ): bar Chip conveyor High pressure pumps

Year of construction: 2013, condition: used, cutting diameter 420 mm saw band length 41 x 5600 mm cutting width 1,3 mm Control Simatic S7 Touch band speed 17 - 110 m/min sawing motor 7,5 kW diameter of round bars 420 x 3000 mm diameter of round bars 300 x 6000 mm total power requirement 30 kW weight of the machine ca. 18,5 t dimensions of the machine ca. 12,5 x 5,0 x 2,5 m CNC sawing machine with band saw JAESPA Compact 4S and round steel magazine and discharge gripper for sawing round bars from 50 - 420 mm and 6 pockets with a max. bar weight per pocket of 3400 kg. Cut-off lengths 20 - 1000 mm. As good Ledpfxsd Izmas Aa Ijhg as new condition, approx. 1,000 working hours.

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, workpiece weight (max.): 1,000 kg, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 310 mm, wire diameter (max.): 0.3 mm, workpiece height (max.): 310 mm, workpiece width (max.): 820 mm, workpiece length (max.): 1,050 mm, feed rate X-axis: 600 m/min, feed rate Y-axis: 1,000 m/min, table load: 1,000 kg, Equipment: compressor, fridge, FANUC Robocut α-C600iB Lodpsyhb D Eofx Aa Ijhg

Condition: ready for operation (used), Year of construction: 2012, controller manufacturer: SIEMENS, controller model: 840 D, number of axes: 4, This 4-axis Mazak VTC 800/30SR was manufactured in 2012. It features a high-pressure coolant system at 15 bar, a 48-tool magazine, and dual auto tool length measurement units. Equipped with Siemens software, a Visiport, and an RMP60 probe, it's ideal for precise vertical machining tasks. If you are looking to get high-quality milling capabilities, consider the Mazak VTC 800/30SR machine we have for sale. Contact us for more information. • High-pressure coolant (15 bar) • Auto tool length measurement x 2 units • Visiport • 19" screen • Siemens software P • Signal tower • Additional work light Lhsdpfx Ajx D I A Sja Isg • RMP60 probe • Bracket for NCRT for vertical use • Table centre partition • 48-tool magazine Additional equipment • Consep 2000 (chip conveyor/coolant system) for 15 bar, left-hand discharge

Condition: used, Year of construction: 1983, Technical details: Pressure: 160 t Ledpfxeu Nfvus Aa Iehg throat: 360 mm max. ram stroke: 500 mm distance table/ram: 800 mm clamping plate on table: 1250x630x100 mm passage opening in table: 4x Ø 62mm mm ram speed - forward: 200 mm/s ram speed - reverse: 125 mm/S ram surface area: 450 x 850 mm mortise hole in ram: Ø 49 mm height over floor: 810 mm total power requirement: 17 kW weight of the machine ca.: 7200 kg dimension machine xH: 2,1 x 1,4 x 3,4 m manual counter *

Condition: excellent (used), Year of construction: 2011, Control system MXS 850 IV Data: Max Swing over bed 755 mm Max swing over support 740 mm Max Turning diam. 366 mm Turning length 785 mm Movements X 260 mm Y 100 +-50 mm Z 795 mm Rapid transport X/Y/Z 30/20/50 m/min Spindle power 26/22 kW Spindle speed 4,000 rpm Bar Capacity 80 mm Chuck diameter 250 mm Spindle nose JIS A2-8 Spindle indexing 0.001° Sub Spindle power 11/7,5 kW Sub Spindle speed 6,000 rpm Sub Bar cap. 80 mm Sub spindle Chuck diameter 150 mm Sub Spindle nose JIS A2-5 Ledjyilzhepfx Aa Ijhg Sub Spindle indexing 0.001° Number of tools in turret/driven 12/12 pcs. Power driven tools 5.5 kW Spindle speed driven tools 6,000 rpm Machine weight 6,200 kg Machine dimensions LxWxH 4.34 x 2.00 x 2.120 m Equipment: Chip conveyor, 3-jaw chuck Kitagawa BB-210 in main Spindle and a Kitagawa B 206 in Sub Spindle, Part catcher, Various tool holders, Parts catcher, Interface for Bar-Feed, Synchronised threading, The machine has 17800 work hours.

Condition: excellent (used), Year of construction: 2008, operating hours: 82,500 h, functionality: fully functional, travel distance X-axis: 5,000 mm, travel distance Y-axis: 3,000 mm, travel distance Z-axis: 1,750 mm, feed rate X-axis: 65 m/min, feed rate Y-axis: 65 m/min, feed rate Z-axis: 65 m/min, spindle speed (max.): 20,000 rpm, rapid traverse X-axis: 65 m/min, rapid traverse Y-axis: 65 m/min, rapid traverse Z-axis: 65 m/min, torque: 63 Nm, overall weight: 90,000 kg, Equipment: rotational speed infinitely variable, First commissioning: 2008 Control system: Heidenhain iTNC 530 incl. HR420 handwheel Lsdpfx Ajxl R Hvja Ishg X-axis: approx. 5,000 mm Y-axis: approx. 3,000 mm Z-axis: approx. 1,750 mm A-axis: -120 / +95° C-axis: ±360° Maximum workpiece dimensions 3,800 mm (X-direction) 1,800 mm (Y-direction) 1,150 mm (Z-direction) 5-axis machining is possible in a single setup with a 300 mm long tool (A-axis at 90° swivel). Machine operating hours: approx. 82,500 h Total spindle hours: approx. 36,500 h Clamping table No machine table is included in the delivery. However, we are happy to offer a customer-specific solution at extra cost. 2-axis fork-type milling head 5 Spindle power: 20 kW Spindle speed: max. 20,000 rpm Torque: max. 63 Nm Tool holder: HSK 63A Tool release: hydraulic Holding torque (clamped) A & C axis: 2,000 Nm Drives, linear axes Feed rate X, Y, and Z axis: up to 65 m/min Axis acceleration X, Y, and Z: up to 5 m/s² Connection data Voltage: 400 V Frequency: 50 Hz Power requirement: 130 kW Dimensions, weight Space required machine without peripherals: approx. 7,500 x 8,500 x 6,600 mm Total weight: approx. 90,000 kg Colour Enclosure, portal, control cabinet: RAL 7035 light grey Milling head and applications: RAL 5002 aquamarine blue Additional equipment - Minimum quantity lubrication - 50-fold tool changer - Work area enclosure Optionally available at extra cost: - Renishaw RMP60 probe - BLUM LaserControl NT mini Condition of the machine Fully functional, in very good condition. Can be inspected under power until April 2026.

Condition: good (used), Year of construction: 2014, center height: 180 mm, center width: 600 mm, grinding diameter: 260 mm, Sinumerik 840D sl cnc control tail stock measuring device diamant roll portal loading device Technische Daten / technical details: Spitzenweite / center to center 600 mm Spitzenhöhe / center height 180 mm max. Schleifdurchmesser / max. grinding diameter 260 mm Schleifscheibenmaß / grinding wheel dimension 600x80x304,8 mm Reitstock / tail stock MK4 Lodpfx Aevygwwsa Iehg Antriebsleistung Schleifspindel / drive capacity grinding wheel 12 kW Gewicht der Maschine / weight 7500 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: excellent (used), 5-axis Year of production: 2018 Lhedpsun Rqgjfx Aa Ijg Machine working area dimensions for the X and Y axes: X 2100 mm Y 3100 mm Head stroke in the Z axis: 1250 mm Machine travel speed X, Y. Z: X: 80 m/min Y: 80 m/min Z: 12 m/min Vacuum table BECKER pump HITECO spindle in the HSK 63F standard Price of a new machine: approx. 135.000 €
