5-axis vertical machining

Matsuura 650 MC VG660

Condition: good (used), Year of construction: 2000, functionality: fully functional, Model Year: 2000 Hedpfx Ajx T Dipebdji Width: 700 Length: 400 Height: 500 Number of Axes: 5 Holder: BBT40 Spindle Speed (RPM): 20,000 Machinable Materials: Steel, Aluminum, Titanium, Graphite, Copper, Invar, Composite, Delrin, PEEK

Condition: good (used), Year of construction: 2008, HAAS VF-5D / 40 MACHINING CENTER TRAVELS : X : 1,270 mm Y : 660 mm Z : 635 mm DISTANCE BETWEEN PLANE – TABLE AND SPINDLE NOSE : 178 – 813 mm TABLE : DIMENSIONS : 1,321 x 584 mm LOAD CAPACITY : 1,815 mm NUMBER AND SIZE X PITCH OF T-SLOTTS : 7.14 X 80 mm SPINDLE : ROTATIONAL SPEED : 8,000 RPM SPEED RANGES : 2 SPINDLE NOSE : ISO 40 Hsdpsvf Nw Dsfx Abdoi HIGH PRESSURE / INTERNAL COOLANT FEEDS : RAPID SPEED : 18,000 mm / min. WORKING SPEED : 12,700 mm / min. JOG : 0 – 1,260 mm / min. TOOL MAGAZINE : 24 POSITIONS POWER : 15 KW WEIGHT : KG. 7,000 YEAR OF FIRST INSTALLATION : 2008

Condition: ready for operation (used), Year of construction: 2022, operating hours: 8,574 h, General Data Hsdpfex D Izbex Abdoi Machine weight 9200 kg Control Unit Brand SIEMENS Main Drive Spindle speed range 5000 Number of axis 5 Movement X-Axis Movement 750 mm Y-Axis Movement 200 mm Z-Axis Movement 1100 mm Workpiece Workpiece drm 400 mm This 5-axis DMG MORI CLX 450 TC was manufactured in 2022, featuring a max. X-axis stroke of 750 mm, Y-axis stroke of 200 mm, and Z-axis stroke of 1,100 mm. It handles a max. workpiece diameter of 400 mm and length of 1,100 mm, with a bar capacity of 65 mm. Spindle speeds reach up to 5000 rpm. Weighs 9200 kg. If you are looking to get high quality turning capabilities consider the DMG MORI CLX 450 TC machine we have for tact us for more information. Application Types Turning

Condition: excellent (used), Year of construction: 2000, TECHNICAL DETAILS Travel X / Y / Z: 1,250 / 880 / 800 mm Control: Heidenhain Spindle speed: 10,000 rpm B-axis: automatic Number of tool changer stations: 60 Tool holder: SK-50 Number of pallets: 2 pcs Pallet dimensions: 1,000 x 800 mm MACHINE DETAILS Operating time: 59,112 h Spindle hours: 21,619 h Machine transport dimensions: 5.5 x 3.0 x 3.1 m; 14.3 t EQUIPMENT - electronic handwheel Hedpfsxdncljx Abdoi - MillPlus 3D contouring control - Central spindle air blast - Measuring probe - Rinse gun - Documentation - Chip conveyor (hinged belt) - Coolant system - Oil mist extraction

Condition: good (used), Year of construction: 2014, functionality: fully functional, travel distance X-axis: 1,520 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 420 mm, spindle speed (max.): 12,000 rpm, CNC control Sinumerik 840D NC-swivel-rotary table (B-axis and C-axis) automatic tool changer for 30 tools coolant device chip conveyor Technische Daten / technical details: X-Weg / X-travel 1520 mm Y-Weg / Y-travel 520 mm Z-Weg / Z-travel 420 mm Hodpox S Htzsfx Abdoi B-Achse Schwenktisch / B-axis swivel table -90 - +110 ° C-Achse Rundtisch / C-axis rotary table 360 ° NC-Schwenk-Rundtischdurchmesser / NC swivel-rotary table diameter 500 mm Starrtischaufspannfläche / fixed table clamping area 920 x 540 mm Spindelaufnahme / spindle taper SK40 Drehzahl Spindel / spindle speed 12000 Upm /rpm Eilgang / rapid feed 32 m/min Antriebsleistung Spindel / drive capacity spindle 25 kW Gewicht der Maschine ca. / weight 10500 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: good (used), Year of construction: 2016, operating hours: 22,500 h, functionality: fully functional, machine/vehicle number: 20160606, travel distance X-axis: 2,050 mm, travel distance Y-axis: 1,150 mm, travel distance Z-axis: 700 mm, controller manufacturer: Heidenhain, controller model: 530, workpiece weight (max.): 5,000 kg, table width: 1,000 mm, table length: 2,000 mm, spindle speed (max.): 12,000 rpm, operating hours of spindle: 10 h, coolant supply: 20 bar, distance table center to spindle nose: 900 mm, number of slots in tool magazine: 60, Equipment: chip conveyor, rotational speed infinitely variable, PosMill 2050: Currently undergoing a complete overhaul New spindle, spindle motor, rotary union, fan €35,000 net, documentation available Machine available immediately Hedpfx Absyabrmodji Travel paths: 2050 x 1150 x 700/900 mm Table size: 2200 x 1000 mm Spindle: 12,000 rpm Heidenhain glass scales on all axes Heidenhain 530 Tool changer: 60 positions / HSK 63 Coolant through spindle 20 bar, belt filtration system Blum laser tool measurement 3D probe Renishaw Electronic handwheel Active electrical cabinet cooler Air through the spindle via M-function Air at the spindle via M-function Lang clamping plates can be taken over at extra cost

Condition: used, Year of construction: 2010, functionality: fully functional, HAAS VF6 5 AXIS WHEEL MACHINE CNC MACHINE £45K PLUS VAT This machine is set up for the five axis machining of automotive wheels. Extra Z height machine to allow full use of 5 axis 2010 machine. 10k spindle Hedpfx Abox U Earjdei side mount tool changer High speed machining enabled Networking enabled. we can set up the machine if required.

Condition: like new (used), Year of construction: 2023, operating hours: 3,290 h, functionality: fully functional, machine/vehicle number: 10002197, Hartford LG 1570 — Specifications • Machine type: CNC machining center (vertical machining center) • Make: Hartford • Model: LG 1570 • Year: 2023 • Serial No.: 10002197 • Control: Heidenhain Hodpfjyap Agex Abdji Axes • 3-axis Table • Table size: 1,600 x 700 mm Travels • X-axis: 1,500 mm • Y-axis: 700 mm • Z-axis: 650 mm Spindle / tool interface • Tool taper: SK40 • Spindle speed: up to 12,000 rpm • Spindle motor: 11 kW Tool changer • 40-position automatic tool changer Workpiece capacity • Max. workpiece weight: 1,000 kg Features / equipment • Coolant system • Cyclone filter extraction unit • Chip separator and chip conveyor Hours (read) • Total hours: 3,290 h • Cutting/milling time: 2,145 h Weight • 9,227 kg Overall dimensions • 4,750 x 3,400 x 3,300 mm (as provided; originally stated in cm) Condition / note • A decoder is defective and still needs to be replaced

Condition: used, Year of construction: 2007, functionality: fully functional, MATSUURA MAM72-25 5 AXIS PALLET CHANGE MACHINING CENTER G -TECH 30i CONTROL 15 K SPINDLE RENISHAW SPINDLE PROBE SUPLIED WITH 4 PALLETS LANG VICES AND ZEROPIONT BASES . 3 JAW CHUCK AND COLLETS 15 BT40 TOOLS Hjdpfx Asx U D U Ijbdsi

Condition: used, Year of construction: 2014, travel distance X-axis: 1,350 mm, travel distance Y-axis: 640 mm, travel distance Z-axis: 640 mm, rapid traverse X-axis: 32 m/min, rapid traverse Y-axis: 32 m/min, rapid traverse Z-axis: 25 m/min, controller manufacturer: FANUC, controller model: 0-iMD, workpiece weight (max.): 2,300 kg, table width: 1,500 mm, table length: 600 mm, spindle motor power: 27 W, VERTICAL MACHINING CENTER "AKIRA SEIKI" MOD. V 5.5 XP Complete with standard equipment and: - Chip conveyor - Remote electronic handwheel - Tool presetting device Hsdpfxox U S N To Abdoi - Random tool magazine with 28 positions
