Mazak QUICK TURN COMPACT 200 MSY L
Mazak QUICK TURN COMPACT 200 MSY L

Name: Mazak QUICK TURN COMPACT 200 MSY L
Brand: Mazak
Availability: InStock

Year of construction

2018

Condition

Used

Location

Slovenia

Mazak QUICK TURN COMPACT 200 MSY L Mazak QUICK TURN COMPACT 200 MSY L

Machine data

Machine type:: Mazak QUICK TURN COMPACT 200 MSY L

Manufacturer:: Mazak

Model:: QUICK TURN COMPACT 200 MSY L

Year of construction:: 2018

Condition:: ready for operation (used)

Price & Location

Location:: , Slovenia

Call

Technical details

Spindle speed (max.):: 5,000 rpm

Travel distance X-axis:: 234 mm

Travel distance Y-axis:: 100 mm

Travel distance Z-axis:: 625 mm

Controller manufacturer:: MAZATROL

Controller model:: Mazatrol SmoothG CNC

Workpiece diameter (max.):: 695 mm

Details about the offer

Listing ID:: A21264572

Reference number:: SI-TUR-MAZ-2018-00001

Update:: 19.06.2026

Description

This 4-axis Mazak QUICK TURN COMPACT 200 MSY L was manufactured in 2018. It features a maximum swing of 695 mm and a machining diameter of 380 mm. Equipped with a Mazatrol SmoothG CNC control system, it ensures precision and efficiency. The main spindle supports up to 5000 rpm, while the second spindle reaches 6000 rpm. A great opportunity to buy this Mazak QUICK TURN COMPACT 200 MSY L lathe. Contact us for further details.

Machine Benefits

Technical Machine Benefits
1. Capacity:- Maximum Swing: 695 mm- Maximum Machining Diameter: 380 mm- Maximum Bar Work Capacity: 65 mm2. Spindle:- Main Spindle Chuck Size: 8 inches- Main Spindle Maximum Speed: 5000 rpm- Second Spindle Chuck Size: 6 inches- Second Spindle Maximum Speed: 6000 rpm3. Turret:- Number of Tools: 12- Maximum Speed: 5000 rpm4. Axes Travel:- X Axis: 234 mm- Y Axis: 100 mm- Z Axis: 625 mm- W Axis: 585 mm5. Control System:- Mazatrol SmoothG CNCInstalled Options : EIA / ISO programming Spiral machining EIA 3D compensation Rotation function Geometric functions Scaling External data I/O Shape compensation Thread cutting cycle Sub C-axis control Inverse time feed Polar coordinate input G54.1 additional work offsets Synchronous mill tapping Variable 600 macro sets Cylinder & polar coordinate interpolation EIA helical tap cycle EIA pattern cycle Seamless corner control Variable acceleration control Rapid overlap Lead error compensationMachine Hours : Power on time: 12,929 h Auto operation time: 17,565 h Auto cutting time: 15,375 hEquipment included: Turrets: 2 × revolver head – one on each side of the machine Driven tools: 1 × driven tool on the Z axis 1 × driven tool on the X axis Tool holders: Fixed holders for drilling Fixed holders for external turning

Dusdpfxeyk Tg Re Anyjw
Extra Information
Full equipped version with C axis / Y axis / Subspindle / Long bedMachine still under power
