Used High Performance Drills for sale (28,145)

Condition: good (used), Year of construction: 1999, functionality: fully functional, drilling capacity: 40 mm, quill stroke: 200 mm, quill diameter: 80 mm, • Worktable 1200 x 750 mm with 5 T-slots • Arm travel 1050 mm • Drill spindle Morse taper 4 • Infinitely variable speed control • Infinitely variable quill feed • Thread cutting device • 2 T-slots (18 mm) each, machine base rear and left • Machine lamp • Central lubrication • Table surface machined on all sides • Safety guard on drill • Coolant system Dimensions and Travel Tool holder MT 4 Column diameter mm 195 Table dimensions mm 1200 x 750 Number of T-slots 5 T-slot spacing mm 125 Quill stroke mm 220 Column stroke mm 450 Distance spindle nose to table min. mm 40 max. mm 710 Distance spindle nose to base plate min. mm 840 max. mm 1510 Drilling radius min. mm 540 max. mm 1590 Working table height mm 900 Machining Data Drilling capacity solid material St 60 Ø 45 mm GG 22 Ø 55 mm Thread cutting St 60 M 36 GG 22 M 45 Main Spindle Drive AC motor, frequency-controlled kW 5.5 at 100% duty cycle Speed range rpm 15 - 2800 Torque Nm max. 250 Constant from rpm 15 - 200 Feed Drives Feed, stepless mm/rev 0.02 - 0.7 Feed force N 12,000 Electrical Data Operating voltage / frequency V / Hz 400 / 50 Control voltage V 24 Total connected load kVA 9.3 Weight DANUFLEX 145 (without packaging) with 750 x 1200 mm table kg 2,600 Documentation Operating manual, incl. Gkodpfjynt Ucjx Aaneb Lubrication and hydraulic diagram Electrical schematic

Condition: excellent (used), Year of construction: 2020, Ref: 11146 . 2020 Horizon RD-4055 Rotary Die Cut System Efficient production with separator and card stacker for labour saving operation. Features: • Die cutting, waste separation and stacking in one pass for efficient production. • A wide range of applications can be processed such as business cards, greeting cards, labels and light packages. • Maximum 6,000 sheets can be processed. • 21-up round corner business card production can processed at 126,000 cards per hour. • Simple and easy operation without relying on a skilled operator. • Uniquely designed servo motor controlled ‘Repeat-cut’ feature allows multiple-up cuts from a single up die to minimize die cost. • Ruggedly constructed yet compact compared to normal die cutters. • Various delivery options are available to process a wide range of applications. • Die-cutting and Kiss cutting can be performed simultaneously by using a die which has two different blade heights, ideal for making stickers and labels. • Creasing can be achieved to avoid image cracking. Suitable for boxes, pocket folders and greeting cards which require additional folding processes after die cutting. • Repeat-cut enables the running of multiple up imposed applications with a smaller die to reduce die cost (Up to 8 repeats) Equipped with: TOUCH PANEL: Both setup and control can be done through the intuitive touch screen. After mounting the upper and lower die, the system can be set up by simply inputting sheet size and product size. The graphical illustrations on the screen are simple and easy to understand. FEED SECTION: Vacuum belt feeding enables superior feeding with easy setup and operation. An ultrasonic sensor is used for double feed detection on a wide range of substrates. The optional code reader BR-N4055 enables job separation for easy handling. TRANSPORT SECTION: Godpfx Aasz Aklmonjkb Sheets are registered by vacuum belt and position is firmly secured with gripper rollers for accurate and consistent register. Servo motor driven gripper rollers ensure the die cut position without effecting processing speed. The optional alignment detection sensor ADS-N4055 detects the alignment error for additional quality control. DIE CUTTING SECTION: Rigid magnetic upper roller and solid lower anvil cylinder ensure high quality die cutting. Uniquely designed die cutting section enables easy and quick die setting. Specification: Sheet Size (Before processing): Max. W400 x L550 mm or W15.740" x L21.650" Min. W200 x L275 mm or W7.875” x L10.830” Processed Material: Normal paper, Coated paper, Cardboard Material Thickness: 127.9 to 400 gsm Die Cutting: Max. 0.5 mm or 0.019” (In case of blade height: 0.8 mm or 0.031”) Max. 0.3 mm or 0.011” (In case of blade height: 0.6 mm or 0.023”) Creasing: Max. 0.4 mm or 0.015” (In case of blade height: 0.8 mm or 0.031”)

Condition: good (used), Year of construction: 1983, Stock number: 3005 Manufacturer: HKS Singen Year of manufacture: 1983 Machine number: 401044 Gedpfxewu Ilwe Aanjkb Model: HKS 40 Drilling capacity: 40 mm Spindle taper: MK 4 Speed range: 26 to 1,940 rpm Feed: 0.05 to 0.45 mm/rev Table: 1,520 x 740 mm Clamping surface: 1,370 x 610 mm Outreach min/max: 400 / 1,120 mm Stroke: 200 mm Swiveling range: 360° Vertical adjustment of arm: mm Horizontal adjustment of arm: 720 mm Accessories: Connection: 6.5 kW Footprint: 1,500 x 1,100 mm 2nd plate: 1,500 x 1,000 mm Dimensions: 1,800 x 1,600 x 2,700 mm Weight: 2.3 t

Condition: used, Year of construction: 1987, We are offering this used Donau DR 40-Z high-speed radial drilling machine, year of manufacture 1987. Gedpsy Dn E Nsfx Aanokb Manufacturer: Donau Model: DR 40-Z Serial number: 1146-3 If you have any questions or require further information, please feel free to send us a message. The machine is located in Osterode/Harz. Viewing can be arranged by appointment. This is a used machine, therefore we sell under exclusion of any warranty.

Condition: new, Year of construction: 2026, drilling capacity: 40 mm, throat depth: 1,220 mm, spindle speed (min.): 110 rpm, spindle speed (max.): 2,900 rpm, overall weight: 1,710 kg, spindle stroke: 200 mm, spindle mount: MK 4, Drilling capacity in St 60 40 mm Drilling capacity in GG 20 40 mm Thread cutting (St 60 / GG 20) M 27 / M 36 Tool holder short spindle MK 4 Projection center spindle / column min. - max. approx. 210 - 1220 mm Clamping surface machine table approx. 1200 x 510 mm T-slots in the machine table: Number x width 3 x 18 mm Distance drill spindle - table min. - max. approx. 375 - 675 mm Gkodpfotzkmbsx Aanob Distance drill spindle - base plate (= option) min. - max. approx. 1075 - 1375 mm Spindle stroke approx. 200 mm Feed rates approx. (4) 0.08 - 0.1 - 0.2 - 0.3 mm / U Speed range of the main spindle: infinitely variable 110 - 2900 rpm Dimensions (height x width x depth) approx. 2500 x 1200 x 1710 mm Net weight approx. 1710 kg Drive power spindle motor 400 V, 50 Hz approx. 2.2 / 4.0 kW

Condition: good (used), Year of construction: 1962, High speed radial drilling machine, radial drilling machine, drilling machine, boom drilling machine, high speed radial drilling machine -Clamping table: 400 x 1100 mm -Projection: 930 mm -Taper mount: MK4 -Engine power: 1.35/1.8 kW -Speed: 41-1700 rpm -Columns: Ø 200 mm Gkedpeirax Ujfx Aaneb -Spindle stroke: 125 mm -Thread cutting device: YES -Feed: 0.075 - 0.3 mm/rev -Dimensions: 1800/1235/H2240 mm -Weight: 1500kg

Condition: excellent (used), Year of construction: 1976, TOYOSK 0-R fixed spindle pitch high speed 12-spindle fine thread drilling machine Year of manufacture: 1976 Speed ​​(3 stages): 850 / 1200 / 1700 rpm Spindle diameter: 8mm Table feed: 65mm Table surface: 200x260mm Speed ​​change: Mechanical (stepped stages) Spindles: 12pcs For precision mechanical, small holes / threads. Godpfjwifgusx Aanokb Power: 0.75kW Application: Simultaneous preparation of multiple holes in precise, mass production tasks (e.g. automotive parts, sheet metal, castings)

Condition: used, Year of construction: 1991, spindle mount: MK 4, Work table 600mm x 1200mm Arm travel 600mm Tool holder MK 4 Drilling capacity 40mm in steel Thread cutting device Gksdpfx Asx N Ifteaneb Coolant system Documentation

Condition: new, Year of construction: 2023, Capacity Ø 15 - 100 mm sawing motor 11 kW saw speed 30-130 U / min hydraulic motor 2,2 kW Saw Feeding Servo 1,5 KW Siemens Material Feeding Motor 1,5 KW Siemens saw-blade dia. Ø360 x T2.6 x 2.25 x 40 mm Gedpfx Aeyk Ihvsanokb cutting range min. 3000 mm cutting range max. 7000 mm control Siemens hydraulic Rexroth Valve coolant Pulverisiertes Schneidöl required space 2900 x 7400 m weight of the machine ca. 4900 kg GERD WOLFF GLS-160 High-performance circular saw From 10 to 250 Millimeters round material, within seconds, they cut steal of all kinds with precision an ease. Equipped with a material feed system and components from Germany, we combine german with turkish mechanical engineering.

Condition: excellent (used), Year of construction: 1993, wire diameter range: 2,4 - 3,8 mm nail length: 50 - 90 mm output: 820 nails/min Gjdpfxsd Ez Ere Aanekb

Condition: ready for operation (used), Year of construction: 1994, quill travel distance: 170 mm, throat depth: 900 mm, power: 3 kW (4.08 HP), High-speed radial drilling machine Manufacturer: HKS, Type: HKS 34 MG Year of manufacture: 1994 Technical data Manufacturer: HKS Gedpozbr Ibefx Aanokb Type: 34MG Year of manufacture: 1994 Drill spindle mount: MK 4 Overhang: max. 900 mm Drilling capacity: 32/38 mm, see data sheet Drill spindle stroke: 170 mm Distance spindle – table: 300 / 750 mm Motor power: 3 kW Clamping area with T-slots: 1050 x 420 mm External dimensions W x D x H: 1400 x 2000 x 2450/2900 Weight approx.: approx. 2000 kg Equipment - Thread cutting device - Hydraulic column and arm clamping - Coolant system - Swivel table 510 x 310 mm All information without guarantee. A demonstration is possible at any time in our showroom.

Condition: ready for operation (used), Year of construction: 1984, functionality: fully functional, travel distance X-axis: 1,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,000 mm, spindle speed (max.): 3,000 rpm, controller model: DIXI CNC 4400, TECHNICAL DETAILS Travel range, X-axis: 1,000 mm Travel range, Y-axis: 1,000 mm Travel range, Z-axis: 1,000 mm Vertical movement with pallet changer (Y-axis): 880 mm Distance from spindle axis to top of table: 0 – 1,000 mm Distance from spindle axis to top of table with changer: 0 – 880 mm Table dimensions without changer: 840 x 1,000 mm Table dimensions with standard changer: 800 x 800 mm Max. table load: 2,000 kg Max. table load with pallet changer: 1,200 kg Table rotation: 360° continuous Rapid traverse: 1,500°/min T-slots: 7 equally spaced slots, width 18 H7 Tool interface: ISO 50 Spindle speeds: 8 – 3,000 rpm (in 3 ranges) Drive power: 11 kW Drive power in overload: 13.75 kW Max. torque: 200 kpm Working feed rates (X, Y, Z): 1 – 9,999 mm/min Rapid traverse (X, Y, Z): 9,999 mm/min Measuring system resolution: +/- 0.001 mm / 0.001° Gksdpfjzd Rizsx Aanjb Positioning accuracy: 0.001 mm / 0.001° Distance from table axis to spindle flange: 390 mm to 1,390 mm MACHINE DETAILS Control system: DIXI CNC 4400 Installed total power: 47 kW Compressed air requirement: 6 kg/cm² Dimensions & Weight Dimensions (L x W x H): 4,835 x 4,160 x 3,190 mm Machine weight: approx. 17 t Compressed air requirement: 6 kg/cm²

Condition: refurbished (used), Year of construction: 1997, functionality: fully functional, drilling capacity: 40 mm, quill stroke: 200 mm, quill diameter: 80 mm, Danumeric 440 overhauled and digitized 2024 Machine version - Work table 1800 x 600 mm with 4T-slots - Boom travel 1050 mm - SK 40 drilling spindle with tool clamping device - Infinitely variable speed programming - Infinitely variable quill feed via three-phase servo motor - 2 T-slots 18 mm on the machine base at the rear - 2 T-slots 18 mm on the left machine base frame - Thread cutting device - Central lubrication - Coolant device - Machine light - CE marking - Safety device - USB interface Dimensions and travels Tool holder SK 40 Column diameter mm 195 Table dimensions mm 1800 x 600 Number of T-slots 4 Distance between T-slots mm 125 Quill stroke (Z-axis) mm 200 Column stroke (W-axis) mm 410 Distance spindle bottom edge - min mm 70 Table top edge max. mm 680 Distance spindle bottom edge - min mm 970 Floor max. mm 1580 Drilling radius mm 540 - 1590 Worktable height mm 900 Cutting values Drilling capacity into solid St 60  40 GG 22  50 Thread cutting St 60 M 36 GG 22 M 42 Main spindle drive AC motor, frequency-controlled kW 5.5 at 100 % duty cycle. Speed range: min -1 15 - 2800 Torque Nm max. 250 constant from min -1 15 - 2000 Feed drives X-axis - AC - servo motor kW 0.25 Y-axis - AC - servo motor kW 0.25 Z-axis - AC - servo motor kW 4.50 W-axis - AC - servo motor kW 2.50 Rapid traverse speeds (X/Y/Z): m/min. 7.5 / 7.5 / 5 Rapid traverse speeds (W): m/min. 3 Feed rates stepless mm/min 5 - 2000 Accuracy Positioning accuracy X-, Y-axis to 1200 mm mm ± 0.075 Electrical data Operating voltage / frequency V / Hz 400 / 50 Godpfxou Dg D As Aanekb Control voltage V 24 Hydraulic unit for clamping kW 0.75 Total connected load kVA 13.0 Weight Danumeric 440 (without packaging) with table 1800 x 600 mm kg 2800 CNC control Axes: 4 (X, Y, Z, W), expandable Processor: 32-bit CPU Screen: TFT flat screen, backlit, easy to read from all sides legible from all sides, 215 x 160 mm Position information: Cartesian or polar, absolute or incremental measurements, Unit of measurement: mm or inch or in degrees Interpolation: 2 axes (X, Y) Technology database: tool management, tool suggestions according to machining type, material-dependent cutting data suggestions Tool management: max. 500 tools Subroutine technology: yes Machining cycles Standard software options: Programming in dialog, 38 zero offsets, rotation and mirroring, teach-in for X, Y, Z, restart in program with selection functions for targeted entry Zero point determination: Cycles for determining zero points by manually probing the workpiece for probing the workpiece for: - any clamped rectangular parts - any clamped round parts - Mediation of cast and flame-cut parts - Angular position detection for round parts by touching reference edges or surfaces Test graphic Graphic display of drilling patterns Data interfaces USB

Condition: new, round material Ø 100 - 230 mm square edge steel Ø 100 - 170 mm Saw Body 30 Grad Linear Schlitten sawing motor 22 kW hydraulic motor 5 kW total power requirement 34 kW Gkedeymf Tzjpfx Aansb Saw speed 30-120 rpm /min saw-blade dia. Ø630 x 3,4 x 2,8 mm control Siemens hydraulic Rexroth Valve coolant Pulverisiertes Schneidöl required space 7,5 x 2 x 1,2 m required space 3200 x 7600 mm GERD WOLFF GLS-230 High-performance circular saw Introducing the new generation of High-Performance Metal Circular Saws, seamlessly blending precision and efficiency with German quality. Our High-Performance Metal Circular Saw machines are setting the standard in metalworking thanks to their innovative technology, allowing for precise and effortless cutting of steel of any kind. From 10 millimeters to an impressive 250 millimeters in steel diameter, our machines cut with utmost accuracy within seconds. At the core of these machines are their automatic functionalities, coupled with an advanced ball screw spindle and an automatic material feeding system. This combination ensures not only maximum precision but also impressive speed. A Siemens motor and Siemens PLC screen guarantee reliable performance and easy control. Moreover, our High-Performance Metal Circular Saw machines feature a special system for quick and convenient blade changes. The hydraulic material tension provides secure fixation of the workpiece during the cutting process. Additionally, a programmable misting system is integrated to ensure optimal lubrication and cooling of the saw blade, extending the tool's lifespan. With our servo and driver technology, you have full control over your manufacturing processes, allowing you to optimize production and achieve the highest quality standards. Choose our High-Performance Metal Circular Saw machines and embrace the future of metalworking – precise, efficient, and reliable.

Condition: excellent (used), Year of construction: 1983, bore capacity in steel (diameter) 32 mm arm length 636 mm workpiece height max. 720 mm spindle turning speed range 38 - 2000 U/min threading 38 - 643 stroke 450 mm spindle stroke - max. 170 mm Gjdpfx Aajwvl Irjnskb total power requirement 6 kW weight of the machine ca. 1,9 t dimensions of the machine ca. 2,5 x 1,5 x 2,2 m Left / right rotation.

Condition: refurbished (used), Year of construction: 1998, workpiece weight (max.): 15,000 kg, travel distance Z-axis: 1,000 mm, chuck outer diameter: 1,750 mm, spindle speed (max.): 400 rpm, turning diameter: 2,100 mm, turning height: 1,350 mm, rotational speed (max.): 3,000 rpm, feed force Z-axis: 50,000 N, year of last overhaul: 2026, The Millennium provides very high precision turning and versatile machining capability. Always precise, always powerful. Features of this machine:- – Involute chain drive for very high speeds, very low noise – a 36” diameter Timken cross roller bearing, the ultimate bearing – see last page – All steel 1750mm dia. 4 jaw chuck for high speeds. Maximum loading 15,000kgs. Gkjdpfx Aoy Uwxteaneb – A servo powered C axis control that provides backlash free C axis movement – high power and high accuracy – 200mm square forged steel ram - high accuracy heavy cutting when required and incorporating a 15KW ISO 50taper live spindle providing speeds 20 to 3000rpm for rotary contour milling, pcd drilling and angle milling and grinding with attachments (new heads can be provided to order). 1350mm maximum height under ram – Automatic pick up of turning tools, live tools and attachments from the 18 pocket tool magazine – Raise and lower crossrail - high precision latching and clamping at 200mm pitches – flexibility without loss of accuracy Fanuc 18Ti. A very precise, powerful and versatile machine tool. Performs all functions shown in photo gallery 12 months guarantee

Condition: used, Axial high-performance fan, Axial fan AEG Wall-mounted fan for extraction or ventilation Type AG 80 NY6 No. 4268465 Airflow approx. 11,000 m³/h 6-blade fan Ø 600 mm Internal mounting frame Ø 645 mm External mounting frame Ø 900 mm Installation depth 190 mm Motor power 0.55 kW Power supply 400 Volt, 50 Hz - 6-bladed profiled impeller with bionic blade geometry Gkodpoxciw Iefx Aanjb - Fan blades made of aluminium - Fan housing made of metal with wall mounting ring (galvanized sheet metal) - Metal stand with protective guard, custom-built - Mobile Dimensions L x W / H: 1200 x 870 x 1520 mm Weight approx. 90 kg The high-performance fan is in very good condition.

Condition: new, - High-speed cut-off saw for solid materials / profiles up to 75mm - Automatic loading magazine for bars up to 6300mm in length and 3t in weight - Feed system via ball screw - Single stroke of 600mm - SIEMENS electronics / drive / control system - Good parts / initial cuts are sorted Gedpfx Aajggytqonskb - Optional conveyor system for cut parts - Robot integration possible - Includes dust extraction system

Year of construction: 2023, operating hours: 5 h, condition: as good as new (ex-display), functionality: fully functional, rotor diameter: 420 mm, rotor width: 800 mm, Genox GC800T Series - High Performance Granulator suitable for processing various materials including plastics, wood, rubber etc. 37kW Drive Motor with outboard rotor bearings, heavy duty precision machines rotor, and 580rpm operating speed as standard. 800mm wide x 420mm diameter cutting chamber with heavy duty, high inertia Cascade Rotor with 24 x rotor knives. Two rows of counter knives are mounted in the chamber. All knives are manufactured from Vacuum Heat Treated D2 Tool Steel. An electric assisted chamber opening with actuator with integrated safety interlocks and a setting jig is for pre-setting of knives off the machine are provided to enable quick, easy knife changes. Output size is controlled by replaceable screens mounted beneath the rotor shaft - sizes supplied as required (4mm-50mm). Gksdpfx Asz Akakjanjb We can provide infeed conveyors and product conveying systems as required to transfer product in to bulk storage bags if required. This machine is as new and in stock at our warehouse in the UK and has only been used previously for exhibition displays. Significant saving available over a newly built machine machine.

Condition: new, capacity Ø 10 - 75 mm sawing motor 11 kW hydraulic motor 3 kW Saw Feeding Servo 1,5 KW Siemens Gsdpeymf Ifefx Aanjkb Material Feeding Motor 1,5 KW Siemens Saw speed 70-160 rpm /min saw-blade dia. Ø285 x 2,0 x 1,7 x 32 mm cutting range min. 1000 mm cutting range max. 7000 mm control Siemens hydraulic Rexroth Valve coolant Pulverisiertes Schneidöl required space 2950x6800 m weight of the machine ca. 3500 kg GERD WOLFF GLS-75 High-performance circular saw From 10 to 75 Millimeters round material, within seconds, they cut steal of all kinds with precision an ease. Equipped with a material feed system and components from Germany, we combine German with turkish mechanical engineering.

Condition: new, capacity Ø 140 - 250 mm sawing motor 30 kW hydraulic motor 5,5 kW Saw Feeding Servo 3 KW Siemens Material Feeding Motor 3 KW Siemens Saw speed 30-80 rpm /min saw-blade dia. Ø750 x 3,8 x 3,2 x 80 mm Gksdpoymf Swofx Aansb cutting range min. 1000 mm cutting range max. 7000 mm control Siemens hydraulic Rexroth Valve coolant Pulverisiertes Schneidöl required space 3500 x 8000 mm Saw speed 30-80 rpm / U pro min weight of the machine ca. 9000 kg GERD WOLFF GLS-250 High-performance circular Saw From 10 to 250 Millimeters round material, within seconds, they cut steal ofall kinds with precision an ease. Equipped with a material feed system and components from Germany, we combine german with turkish mechanical engineering.

Condition: like new (used), Year of construction: 2020, operating hours: 516 h, functionality: fully functional, laser power: 120 W, type of cooling: air, table length: 813 mm, table width: 508 mm, working width: 813 mm, Trotec Speedy 360 120W CO2 Laser + Atmos Filter Low Hours – Practically New Laser Tube Up for sale is a professionally maintained Trotec Speedy 360 CO2 Laser Engraver and Cutter paired with a Trotec Atmos Filter system. This machine features the maximum 120W power configuration for incredible speed and deep cutting capability. It has been used and meticulously looked after in a clean, professional commercial environment. The Standout Detail: Low Usage As shown in the images, the actual laser source has barely been used: Laser Hours: Only 516 hours of active firing time. The 120W tube is practically brand new with a massive lifespan left ahead of it. Engraver Hours: 6,786 hours. This is just standby/idle time from the machine being left turned on during work shifts while prepping files or swapping materials. Key Features 120W CO2 Laser: Maximum power upgrade for fast cutting and crisp engraving. Large Work Area: 813 x 508 mm (32" x 20") bed. InPack-Technology™: Keeps dust and smoke away from the rails and optics for minimal maintenance. Trotec Atmos Filter: High-performance fume extraction for safe indoor operation. Gkjdezycf Hspfx Aaneb Pickup & Collection from our business. Please contact us directly for more details regarding: Additional photos or videos of the machine running. Any other technical questions.

Condition: ready for operation (used), Year of construction: 2021, operating hours: 15,000 h, functionality: fully functional, Equipment: documentation/manual, 2021 Star SR32 JII Type A (15,000 hours) 4m FMB Turbo 3-36, Hydrajet UB20 High Pressure Coolant, LNS Swarf Conveyor, FireTrace Suppression, JBS Guide Bush System, Fully inspected & serviced, 30 Day Warranty # Star SR-32JII CNC Sliding Head Lathe Machine Hours: Approx. 15,000 hours Maximum Machining Diameter: Ø32 mm standard / Ø34 mm optional Gedpfozuxfrsx Aanjkb CNC Control: Fanuc 32i-B ## Machine Configuration * Twin-spindle CNC sliding head lathe * Main spindle and sub-spindle * Main and sub-spindle full C-axis control * Gang-type tooling system * Cross-working driven tooling * Back-working tooling * X1, Y1, Z1, C1, X2, Z2 and C2 controlled axes * Type B configuration additionally incorporates Y2 control on the back-working unit ## Main Spindle * Maximum spindle speed: 8,000 rpm * Spindle motor: 7.5 kW continuous / 11 kW short-time rating * Maximum headstock stroke: 320 mm * Full C-axis contouring capability ## Sub-Spindle * Maximum spindle speed: 8,000 rpm * Spindle motor: 3.7 kW continuous / 5.5 kW short-time rating * Full C-axis contouring capability * Maximum chucking diameter: Ø32 mm / Ø34 mm optional ## Main Tooling * 6 × turning tool positions * Tool size: 16 mm square * 5-spindle sleeve holder * Maximum drilling capacity: Ø13 mm * Maximum tapping capacity: M12 × P1.75 ## Cross-Working / Driven Tooling Configuration options include: * 3 × ER20 cross-milling positions + 2 cartridge-type positions * Or 6 × ER16 cross-milling positions * Maximum milling capacity: Ø10 mm * Maximum driven tapping capacity: M8 × P1.25 * Cross-milling spindle speed: 6,000 rpm * Cartridge-type driven tooling speed: up to 8,000 rpm * Driven-tool motor: 2.2 kW continuous / 3.0 kW short-time rating ## Back-Working * Maximum chucking diameter: Ø32 mm / Ø34 mm optional * Maximum front ejection length: 125 mm * Maximum projecting component length: 45 mm * Back-working tool positions: * 6 positions – Type A * 8 positions – Type B * Stationary drilling capacity: Ø13 mm * Driven drilling capacity: Ø8 mm * Stationary tapping capacity: M10 × P1.5 * Driven tapping capacity: M6 × P1.0 * Maximum back-working driven-tool speed: 6,000 rpm ## Rapid Traverse * X1 / X2 / Y1 / Z1 / Z2: 35 m/min * Y2: 24 m/min on applicable Type B machines ## Ancillary Equipment Included * 4 metre FMB Turbo 3-36 Magazine Bar Feeder * Hydrajet UB20 High-Pressure Coolant System * LNS Swarf Conveyor * FireTrace Automatic Fire Suppression System * JBS Guide Bush System ## Machine Condition & Support * Approx. 15,000 operating hours * Fully inspected and serviced * Supplied ready for production * 30 Day Warranty * Warranty valid within the UK only ## General Specification * Coolant tank capacity: 255 litres * Approximate machine dimensions: 2,690 × 1,345 × 1,780 mm * Approximate machine weight: 4,100 kg * Power requirement: 8.8 kVA * Maximum sound pressure level: 77 dB

Condition: like new (used), 2024 Star SP-23 CNC Sliding Head Lathe – Low Hours, High Specification, Immediate Availability Swiss CNC Ltd are pleased to offer two exceptional 2024 Star SP-23 CNC Sliding Head Lathes, both presented in excellent condition with low operating hours. Designed for manufacturers demanding uncompromising precision, high productivity and long-term reliability, the SP-23 is one of the most capable 23mm sliding head machines available today. Each machine is fully equipped for immediate production and supplied with a comprehensive automation package including an FMB Turbo 3-38 magazine bar feeder, LNS MH500 swarf conveyor, Filtermist oil mist extraction and FireTrace automatic fire suppression system. Machine Specification The Star SP-23 features a highly capable 7-axis configuration, providing exceptional flexibility for complex component manufacture. Axis Configuration * Main Spindle (Headstock): Z1 / C1 * Main Working Platen: X1 / Y1 * Sub Spindle: X2 / Z2 / C2 Machining Capacity * Maximum machining diameter: Ø23mm * Headstock stroke: 205mm (50mm Non-Guide Bush mode) * Bar feeder capacity: 4,280mm The machine offers the flexibility to run both guide bush and non-guide bush applications, making it ideal for both long, slender components and shorter, more economical parts. Main Spindle Performance The main spindle delivers outstanding productivity with: * Maximum spindle speed: 10,000rpm * 3.7kW spindle motor Tooling configuration includes: * 8 turning tool positions (12mm square) * 5 drilling sleeve holders accepting Ø22mm sleeves (ER16) * 2 fixed + 5 modular driven tool stations * Driven tooling speed up to 8,000rpm The high-frequency driven spindles provide excellent performance for milling, drilling, cross drilling and tapping operations, reducing cycle times while maintaining exceptional surface finish and accuracy. Sub Spindle Capability The fully programmable sub spindle provides efficient back-working operations and complete part machining in a single cycle. * Maximum chucking diameter: Ø23mm * Maximum spindle speed: 10,000rpm * 2.2kW spindle motor Back-working tooling includes: * 4 back-working platen positions * ER20 drill sleeve capacity * 4 driven tool positions (ER16) * Driven tooling speed up to 8,000rpm This configuration allows complex second-operation machining without secondary handling, improving productivity and part accuracy. Included Equipment Each machine is supplied with: * FMB Turbo 3-38 Magazine Bar Feeder * LNS MH500 Swarf Conveyor * Filtermist Oil Mist Extraction * FireTrace Automatic Fire Suppression * High Frequency Driven Spindles Ideal Applications The Star SP-23 is perfectly suited to high-volume production across a wide range of industries including: * Medical * Aerospace * Automotive * Hydraulics * Electronics * Precision Engineering * Motorsport Available Now * 2 Machines Available * 2024 Model Year * Excellent Condition * Low Hours * Immediate delivery available Installation, commissioning, operator training and ongoing technical support are available through Swiss CNC Ltd. For further information, photographs or to arrange a viewing, please contact Swiss CNC Ltd. Gjdpfx Aaozqvhvsnjkb

Condition: excellent (used), Year of construction: 1999, functionality: fully functional, Workpiece & Performance Panel Formats: • Length 1,200–1,400 mm • Width 195 mm • Thickness 5–12 mm Line Performance (excerpt): • Multi-blade saw feed: 2–48 m/min • Pack assembly: max. 100 pieces/min • Packaging: up to 12 packs/min • Palletizing: up to 12 cycles/min Feeding & Cutting 1. BARGSTEDT TBP16/DG/30/22/S Gantry Feeder Vacuum gantry for feeding raw panels (fixed edge on the right) • Workpiece weight up to 100 kg • Capacity up to 5 cycles/min • Pallet return and light barrier safety system 2. BARGSTEDT TPP20/28/21/S Pallet Magazine Provision of empty pallets for feeding • Capacity approx. 12 pallets • Max. stack height 1,800 mm 3. BARGSTEDT TAR40/28/22 Décor Alignment Station Aligns panels for décor-oriented further processing 4. Multi-blade Circular Saw K34/G/2200 Longitudinal splitting with edge trimming • Feed speed 2–48 m/min • Cutting height up to 58 mm • Main motor 22 kW • 9 saw blades + 2 chippers 5. Brushing Unit (after longitudinal cut) Horsehair brush, working width 2,200 mm, with extraction 6. BARGSTEDT Cross-Cut Saw Station HPp11 Cross-cutting in throughfeed mode with pressure beam • Cutting width 2,200 mm • Pneumatic overhead pressure rollers Singulation & Transfer 7. BARGSTEDT TFV40/ZR/RL/22/13/02 Singulation Station Turner with compartments (2×8 compartments) for distributing multi-panel assemblies • Conveyor speed 10–50 m/min 8. BARGSTEDT Right-Angle Transfer (TW) 90° transfer with belt conveyors, feed up to 130 m/min For transfer to the profiling line Profile Processing (soundproofed) 9. HOMAG FR 20/08/10/S Longitudinal Profiling Double-sided format processing • 6 units per side • 6.6 kW per unit • Tool diameter up to 200 mm • Joint color application + drying 10. HOMAG FL 20/08/15/S Cross Profiling Double-sided end profiling • 6 units per side • identical performance structure • integrated edge sealing 11. Sonolit Soundproof Cabin Housing for both HOMAG profiling machines • Approx. 12,000 × 7,000 × 3,000 mm Post-processing 12. BARGSTEDT TTK44/21/14/02 Dry Turner Workpiece turning in throughfeed • up to 100 cycles/min 13. BARGSTEDT B017/R/19/12/2/S Brushing Unit Double-sided fine cleaning with extraction Packing 14. BARGSTEDT TVP40/L/14/02 Pack Assembly Station Automatic pack forming with 1st/2nd choice sorting • Panels 1,200–1,400 × 195 × 5–12 mm • Pack height up to 80 mm • Capacity 100 pieces/min 15. BARGSTEDT TVK40/R/14/02 Carton Station Folding and providing cartons prior to packaging • Up to 12 packs/min Gsdpeywxrasfx Aanskb 16. BARGSTEDT TVA40/07/02 Paper Feeder Automatic application of protective paper • up to 10 packs/min guaranteed 17. Labelling Station Automatic pack identification (format range according to packaging data) Packaging 18. LP Maskin LPFK-2PFL-400 Shrinking Unit Fully automatic film packaging with shrink tunnel • Connection load 36–40 kW • Capacity up to 12 packs/min • Film width up to 800 mm 19. BARGSTEDT Belt Conveyor TFB20/017/04 with Air Shower Cooling section after the shrink tunnel Palletizing 20. BARGSTEDT TSH80/EO/14/08 Crosswise Package Stacking Automatic stacking of packages onto pallets • Packages up to 1,400 × 195 × 58 mm • Capacity max. 12 cycles/min 21. BARGSTEDT TBS0/D/30/08/S Swing Arm Stacker Layer-by-layer palletizing with vacuum suction cups • up to 6 cycles/min • Package weight up to 50 kg 22. BARGSTEDT PP20/12/08 Pallet Magazine Automatic provision of empty pallets for final palletizing
