Vertical Turret Lathe - Single Column

SCHIESS-FRORIEP 32 DE 250

Condition: good (used), Year of construction: 1984, max. wheel diameter 250 mm gear width 275 mm max. module 6 weight of the machine ca. 5,5 t The gear hobbing machine ZFWZ 250 is suitable for the economical production of all hob-processable cylindrical gear types, such a: - spur and helical gear, wormgears and worms, splined shafts, keyed shafts, serrated profiles, chain wheels and ratchet wheels,as well as conical and crowned spur and helical gears. Fgsdsv T Nqaepfx Aanei Interchangeable wheels and milling accessories Technical data: - Workpiece diameter (max): 250 mm - Module (max): 6 mm - Axial feed travel (max): 275 mm - Tangential feed travel (max): 100 mm - Tooth helix angle (max): 45 degrees - Milling cutter diameter (max): 145 mm - Milling cutter length (max): 170 mm - Table clamping surface (min): 195 mm - Table clamping surface (max): 470 mm Power Milling cutter speeds - Stepped in 2 ranges: 56 ... 250 rpm - (Standard version): 90 ... 400 rpm - Infinitely variable in 2 ranges: 63 ... 180 rpm - (special version DC motor): 140 ... 400 rpm Weights - Machine net: approx. 5000 kg - Electrical cabinet: approx. 800 kg - Hydraulic unit + coolant tank + chip transport: approx. 700 kg Overall dimensions (with oil mist filter) - Length: Standard version: 3950 mm DC drive: 3450 mm (or 3350 mm according to table) - Width: 3300 mm - Height: Machine: 1980 mm Machine with DC drive: 2150 mm Electrical cabinet: 2200 mm

Condition: used, Technical details: balancing body max.: 7000 kg balancing body diameter w/o machining unit: 1870 mm balancing body diameter with machining unit: 1870 mnm distance between bearing centers: min. 200 mm rotation weight: 7000 kg Rotor-Ø: 1870 mm Bearing journal Ø: 40 - 180mm mm control: CAB 690 Fgsdpozuyd Nofx Aanei voltage: 380 V /50Hz V/Hz Rotor weight: 40–7,000 kg Machine overload capacity with symmetrical loading: up to 9,000 kg, i.e. max. 4,500 kg per bearing pedestal 1 × machine bed, divisible: 3.85 m + 2.0 m *

Condition: refurbished (used), ECCENTRIC PRESS SGP TYPE : PEZZ 500/1700/1000 Fsdpfx Aashqqnzjnogi PRESSURE : 500t DOWN TABLE DIMENSIONS: 1700x1000mm LENGTH OF STROKE: 20-153mm DISTANCE BETWEEN RAM -TABLE: Min 700mm , Max 800mm WEIGHT: 40.000 kgr MADE IN AUSTRIA

Condition: good (used), Year of construction: 2001, functionality: fully functional, Horizontal Boring Mill UNION T110 Year of manufacture: 2001 Travel axes: X: 1500 mm Y: 1250 mm (total vertical adjustment) 0 mm - lowest position of the spindle center to the table surface Z: 1000 mm W: 550 mm (quill movement) B: 360° infinitely variable Fodpfxoy Rpm Uj Aanogi Spindle diameter: 110 mm Transmission steps: 2 Max. spindle speed: 4000 rpm Rapid traverse: 15 m/min Spindle taper: SK 50 Clamping table surface: 1000 x 1250 mm T-slot width: 22 mm Height of clamping surface above floor: 1050 mm Max. table load: 6 t Total weight (complete): approx. 13.5 t Control system: Heidenhain TNC 426 Electronic handwheel Various tool holders can be purchased additionally.

Condition: used, Year of construction: 1980, turning diameter over bed 1930 mm turning diameter over slide rest 1520 mm turning length 5000 mm turning speeds 0,5-250 U/min spindle bore 105 mm workpiece weight 35 t steady 400-700 mm steady 700-1200 mm steady 1000-1600 mm control Siemens total power requirement 106 kW The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, Fedjyutp Hepfx Aansgi please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Year of construction: 1985, condition: reconditioned (used), Technical Details : Fgodpsh In Thefx Aansi Wire Dimeter range- 4-12mm Gscxckebw Run out table - 4m Speed -80' m/min. Reconstruction- 2022

Condition: good (used), Year of construction: 2017, turning height: 1,600 mm, workpiece weight (max.): 16,000 kg, Videos of the machine in operation can be provided upon request. Max. turning diameter: 3200 mm Table diameter: 2800 mm Max. turning height: 1600 mm Max. workpiece weight: 16,000 kg Fgedpfx Aoyrflzsansi Table speed range: 70 rpm Number of table speed ranges: constant Vertical movement in the Z-axis (ram stroke): 1100 mm Horizontal slide travel in the X-axis: 1720 mm Working feed rate range: 2 - 2000 mm/min Rapid traverse in the X/Z axis: 7 m/min Crossrail traverse: 360 mm/min Main motor power: 55 kW Installed power: 69 kW Dimensions: 5500 x 6540 x 4900 mm Weight: 43,000 kg

Condition: good (used), Year of construction: 2007, Manufacturer: Volz BMT Year of manufacture: 2007 Control: conventional with digital readout (DRO) Fjdpfx Aaex Uw S Hsnjgi Country of origin: Taiwan Swing diameter: 660 mm Max. turning length: 2000 mm Spindle bore: 85 mm Spindle mount: D1-8 Spindle motor: 7.5 kW Spindle speed: 17–1200 rpm with steady rest with digital readout (DRO) with thread cutting function

Condition: reconditioned (used), Year of construction: 2008, operating hours: 13,600 h, functionality: fully functional, machine/vehicle number: 106, Machine partially overhauled by Willemin with new geometry and a new secondary spindle (6,000 rpm). New ball screws on X-Y-Z axes. Alignment and calibration. Ready for production. 5 axes – Fanuc 31i A5 – HSK40E – max 30,000 rpm – Year 2008. Country of manufacture: Switzerland Voltage: 3x400V / 60Hz; 50 A; 35 kVA Dimensions: 270x200x260 cm Net machine weight: 2,500 kg TECHNICAL SPECIFICATIONS WILLEMIN MACODEL 508 MT Control: Fanuc 31i A5 X axis: 450 mm Y axis: 200 mm Z axis: 425 mm Fodew T Tlropfx Aanjgi B axis: -45° to +100° U axis: 300 mm Tool magazine: 48 PickUp stations Main spindle A: max Ø42 mm, max 6,000 rpm Main spindle C: max Ø42 mm, max 3,000 rpm Milling motor spindle: HSK40E, max 30,000 rpm All technical details are given without obligation and subject to errors or omissions.

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, travel distance X-axis: 730 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 425 mm, rapid traverse X-axis: 60 m/min, rapid traverse Y-axis: 60 m/min, rapid traverse Z-axis: 60 m/min, torque: 90 Nm, controller manufacturer: Siemens, controller model: 840D PL, overall weight: 10,000 kg, spindle speed (max.): 12,000 rpm, coolant supply: 25 bar, number of spindles: 1, number of slots in tool magazine: 20, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, We are Chiron experts. The machine is currently being partially overhauled and is in very good condition. If a probe or another option is needed, we can gladly provide it for an additional charge. FZ15W with 4th and 5th axis Machine dimensions: approx. 4200mm x 2400mm Fedpfswpcfujx Aanegi Travel range -X = 730mm -Y = 400mm -Z = 425mm Control: 840D Powerline Main spindle: -Speed: 12,000 rpm -Tool holder: SK40 -Torque: max. 90NM Tool changer -Tool places: 20 Workpiece changer -Peiseler table with Afrocontroller Chip conveyor Coolant system with internal and external cooling Hydraulic clamping device Complete documentation available Geometry tip-top HS runout 0.008mm QC20 measurement 12.6µm (Manufacturer's tolerance 18µm, new machine 23µm, used machine) The machine can be inspected under power.
