Jet drum sanding machine

Studer S30

Condition: refurbished (used), Year of construction: 2005, functionality: fully functional, machine/vehicle number: 019.3790, Machine undergoing repair/overhaul = estimated delivery time approximately 8-10 weeks. Technical data + accessories, see separate PDF. Iedszbqzaopfx Afmsig

Condition: refurbished (used), Year of construction: 2004, functionality: fully functional, machine/vehicle number: 027.0149, CNC internal and external cylindrical grinding machine S33 CNC – undergoing refurbishment. Delivery time: approximately 14 weeks. Iijdpfx Aszcuwbefmeg Technical data and accessories as per the attached PDF. Photo = sample photo only.

Condition: refurbished (used), machine/vehicle number: 3439.39, Universal cylindrical grinding machine for external and internal cylindrical grinding. Iiodpfxexxy A Te Afmog • Distance between centers: 650 mm • Height between centers: 175 mm • Completely overhauled (refurbished) – The machine was completely disassembled and rebuilt component by component. Guide rails were reconditioned, bearings were replaced, new control cabinet and new electrical installation, complete new paint job, and geometrical readjustment for maximum precision. • Equipped with a digital measuring system (Fagor). • Machine condition comparable to a new machine, ready for immediate use. • Extensive accessories included in the scope of delivery, as shown in the photos. • Demonstration under power and test run possible at any time. Availability: Available for immediate delivery!

Condition: used, Year of construction: 2004, grinding diameter 250 mm grinding length 650 mm Iisdpfxjywntyo Afmog centre height 125 mm Maschine wird mit Wartung und neuer Geometrie verkauft Betriebsstunden bisher 12260 Reitstock mit Feinverstellung Schleifspindelstock schwenkbar mit 5° Hirtverzahnung Papierbandfilter Marposs Messeinrichtung Innenschleifeinrichtung

Condition: like new (used), Centerless grinding machine ESTARTA 301 CNC Iijdpfexfqzmjx Afmeg

Condition: refurbished (used), Year of construction: 2025, operating hours: 50 h, machine/vehicle number: 3018-04, Country of manufacture: Switzerland Voltage: 380/50/3 Net weight: 3100 kg Overall dimensions: 230x155x170 cm Installed power: 13 kVA Customs tariff position: 8460.2920 TECHNICAL SPECIFICATIONS MAIN DIMENSIONS Distance between centers: 650 mm Grinding capacity SpW+bs: -80 Stroke: 700 LONGITUDINAL SLIDE Max stroke: SpW+50 mm Minimum automatic feed: 1.5 mm Speed: 50-5500 mm/min Reversal delay: 0-6 sec Maximum table swivel: 12°/10°/8.5°/6° Pneumatic relief for table and workhead CROSS SLIDE Max stroke: 300 mm Rapid traverse: 60 mm Plunge grinding depth in diameter: 3.4 mm Feed 1: 0.012-6 mm/min Feed 2: 0.012-1.2 mm/min Feed per pulse: 0.001-0.05 mm GRINDING WHEEL HEADSTOCK Left-side wheel, external grinding: 400x80x127 mm Drive power: 5.5 kW Peripheral speed: 35 m/s RPM: 1670/2110 min-1 Ijdpfx Ajw T Sd Tjfmeig Internal grinding device for belt-driven spindles, including drive unit: 1.5 kW WORKHEAD Swivel range: 0-90° Continuously variable RPM: 30-1000 min-1 Internal taper: Morse 5 Collets: W-25 Drive power: 0.55 kW Maximum workpiece weight between centers: 130 kg Grinding load between centers: 100 Nm TAILSTOCK Internal taper: Morse 3 Quill stroke: 35 mm Fine adjustment for cylindricity correction: ± 40 μm TECHNICAL CHARACTERISTICS: GUARANTEED WORKING ACCURACY Straightness of the generator over 630 mm: 0.003 mm Roundness during chuck grinding: 0.0003 mm CONNECTION VALUES Maximum absorbed power: 13 kVA Maximum permitted voltage fluctuation: -15%/+10% Maximum permitted frequency variation: ± 3% Required compressed air pressure: 5 bar Unless otherwise stated or in case of error or omission, these technical details are provided without engagement.

Condition: refurbished (used), Year of construction: 2025, Studer S30 Maximum distance between centers: 125 mm Distance between centers: 650 mm Workpiece weight: 80 kg Additional optional features: - Completely new control cabinet with basic PLC and panel - Conversion to ball screw drive incl. PLC Pro (cycle-controlled) - "Workpiece memory" PLC Pro for 10/15/30/50 workpieces - Glass scale in X and Z axes - Swivelable internal grinding device - Motor spindle for internal grinding device - Frequency converter for external grinding spindle - Frequency converter for internal grinding spindle Isdpfx Afed Hdxwjmjig - In-process grinding sensor - Guard for external grinding spindle - Safety door - manually operated - Grinding wheel flange - LED spotlight with flexible arm - Matching coolant system

Condition: used, Year of construction: 2022, operating hours: 372 h, fuel type: diesel, motor manufacturer: 4045HP551-SV, Field of application: Construction Empty weight: 2.960 kg Iedowgvq Eepfx Afmjig Generator capacity: 110 kVA Dimensions of cargo space: 3640 x 1200 x 2295 cm Frequency: 50 Voltage: 230 Water tank volume: 1100 l Please contact Sales Department for more information Over 80 years experience in maintenance. Expert that jointly reflects on the ideal solution for your situation. 1,000 hours or one-year guarantee: optimal reliability. Available 24/7. Quickservice. We can always supply a replacement generator. Wide range of stock that can be supplied immediately.

Condition: used, Surface grinder Center height 125 mm Distance between centers 650 mm Grinding wheel diameter 250 mm Grinding disc diameter 400 mm Total power requirement 8 kW Weight approx. 2500 kg Iiodpjgfqn Njfx Afmsg This is a machine from Machines4you.

Condition: ready for operation (used), functionality: fully functional, The Studer S30-12 CNC is a precision cylindrical external grinding machine from Fritz Studer AG. Brand: Studer Type: S30-12CNC Serial number: 1248.74 Dimensions: L3250mm Dimensions: W2000mm Dimensions: H1950mm Isdezn Nqrspfx Afmoig Wheel speed: 30 m/s

Condition: used, Year of construction: 2008, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, torque: 46 Nm, controller manufacturer: HEIDENHAIN, controller model: 530, spindle nose: HSK A 63, number of slots in tool magazine: 170, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, CNC Heidenhain iTNC 530 WORKING AREA Longitudinal travel X: 800 mm Transversal travel Y: 600 mm Vertical travel Z: 500 mm B axis: +30° / -100° C axis: n x 360° WORK TABLE Table dimensions: 320 x 320 mm Maximum workpiece weight: 120 kg SPINDLE Spindle taper: HSK A63 Maximum spindle speed: 24.000 rpm Motor power 40% ED: 22 kW Maximum torque 40% ED: 46 Nm AUTOMATION Tool magazine capacity: 170 tools Erowa pallet changer: 7 positions MACHINE EQUIPPED WITH • High-pressure coolant through spindle • Probe • Laser tool presetting • Chip conveyor • Oil mist cooling system • Rotoclear • ITC Intelligent Thermal Control • ITC-5X 5 Axis Intelligent Thermal Control Iodpey Tam Rjfx Afmsig • APS Advanced Process System • Remote electronic handwheel • Instruction manuals and CE declaration

Condition: ready for operation (used), Year of construction: 1998, functionality: fully functional, machine/vehicle number: LEAN PRO, FANUC 16 T FULLY FUNCTIONAL RANGE OF ACCESSORIES Iiodpjzfx D Nsfx Afmsg FILTRATION SYSTEM MIST EXTRACTOR MACHINE MANUALS

Condition: good (used), Studer S30-12 cylindrical grinding machine TECHNICAL DATA Main dimensions Center height: 125 mm Center width: 400 / 700 / 1025 mm Largest longitudinal slide path: 400 / 700 / 1000 mm Longitudinal slide Table speed: 50 - 5000 mm/min Reversing delay: 0-6 s Smallest automatic travel: 1.5 mm Max. stroke: 400 / 700 / 1020 mm Max. Table inclination: 12 / 30 / 78° Cross slide Swivel range: +- 45° Iodsvca Izjpfx Afmoig Quick adjustment: 40 mm Feed path with handwheel: 20 mm Largest plunge depth: 1.7 mm Sanding headstock Grinding wheel diameter x width x bore: 450 x 80 x 203 mm Speed: 1340 / 1500 1625 / 1800 / 2000 / 2200 rpm Coarse adjustment: 210 mm Workpiece headstock Swivel range: 0 - 90 Speed range: 30 - 675 rpm Mounting cone: Morse 5 Collets: W25 Tailstock Mounting cone: Morse 3 Adjustment travel of the center: 30 mm Total power requirement: 5 / 8.25 kW No liability is assumed for the correctness, completeness and up-to-dateness of the information.

Condition: excellent (used), KELLENBERGER PRECISION UNIVERSAL CYLINDRICAL GRINDING MACHINE TYPE: 600 U YEAR OF MANUFACTURE: 2003 PARTIAL OVERHAUL: 2026 (Technical data see attached documents) Center height: 175 mm (without height adjustment) Grinding length: 600 mm Equipment: - Standard accessories - Internal grinding device for D: 80 mm max. incl. coolant supply through the workpiece spindle - Grinding wheel equipment left for D: 400 x 50 x 127 mm (standard) - Grinding wheel equipment right for D: 300 x 40 x 127 - Grinding wheel flange for wheels D: 400 x 50 x 127 mm (left) and D: 300 x 40 x 127 (right), balancing weights outside (3 pieces left, 2 pieces right) - Variable spindle drive with Danfoss frequency converter - Balancing device for dynamic balancing, type ELASO MANOBALANCE 750/EB 2000 - RENAUD internal grinding spindle type REN 828 (grease-lubricated with compressed air lock) - Various internal grinding mandrels for REN 828 – 1235, 1645, 2060, 2575 (4 pieces) - Various chucks HJNZ 28 for HJN 828 with 2 collets D: 3 mm and D: 6 mm - Tailstock standard MK 5 with adapter flange DIN 55027 size 5” Bore D: 38.2 mm (standard) - Sine bar on the tailstock - Tailstock with manual retraction for quill travel - Micrometer adjustment on the tailstock - Pneumatic relief of the tailstock - FORKARDT planetary three-jaw chuck D: 200 mm - REISHAUER wedge-bar three-jaw chuck D: 160 mm - Permanent magnet chuck D: 200 mm - Collet chuck for Schaublin B32 - Set of 59 collets Schaublin B32, D: 1.0 – 30.0 mm, graduation 0.5 mm - Set of 8 workpiece supports incl. holder - Three-jaw steady rest, 175 mm, foldable, D: 3-120 mm - Swiveling dressing tool for dressing during external, surface or internal grinding - Side and angled dressing tool for side and angled dressing of the grinding wheels - Dial indicator stop for table swiveling with dial indicator 1/100 mm - Dial indicator stop for table longitudinal movement with dial indicator 1/100 mm - Dressing stop for internal grinding - HEIDENHAIN Digital length measuring system for the X and Z axes Isdpfx Aozhma Defmsig - STREULI paper band filter SPB 3, 90 l/min at 0.26 bar, tank volume 240 l - WALDMANN machine lamp - Set of vibration-damping pads - Three-color paint finish (light gray RAL 7035/blue RAL 5012/dark gray RAL 7016) - New acceptance test report according to KELLENBERGER standard - CE conformity - Documentation Condition: very good, machine geometrically and mechanically overhauled (see geometry report)
