Used copy milling machines for sale (21)

Condition: used, Year of construction: 2017, machine/vehicle number: O3pl, functionality: fully functional, power: 0.75 kW (1.02 HP), input voltage: 230 V, input frequency: 60 Hz, type of input current: AC, rip fence adjustment: manual, actuation type: pneumatic, rotational speed (max.): 12,000 rpm, rotational speed (min.): 12,000 rpm, table width: 330 mm, table length: 2,400 mm, total length: 2,600 mm, total width: 800 mm, total height: 1,800 mm, overall weight: 540 kg, PEMAC 03PL 3-head copy milling machine – Year of manufacture 2017 – Ready for immediate use Very well-maintained PEMAC 03PL copy milling machine for aluminum profiles, manufactured in 2017. The machine has always been used in a commercial setting, has been well-maintained, and is in fully working condition. Inspection and test runs are possible. Specifications Year of manufacture: 2017 230V (1-phase) 3 milling heads Spindle speed: 12,000 rpm Working pressure: 6–7 bar Weight: approx. 540 kg Included 35 used and new milling cutters Video of the machine in operation available Bodezlar Ujpfx Aiwoww Optionally available: Tekna TK280 punching machine (2012) Compressor Asking price: €6,500. Serious offers will be considered.

Condition: used, Year of construction: 2004, machine/vehicle number: 2161, For sale is a Schüco LKF 2600 machine for processing aluminum and steel profiles, manufactured in 2004. The machine is particularly suitable for the efficient processing of long profile lengths. The 3-sided processing over a processing length of 2,600 mm allows complex milling patterns to be incorporated into door and frame profiles without having to remove the profile from the clamping device. The pneumatic profile clamping system with four adjustable clamping cylinders ensures secure fixation of the profiles during processing. The pneumatic 180° rotation allows the profile to be conveniently positioned for processing the opposite side. A special advantage of the machine is the pneumatic rotation of the clamped profile by 180°. This allows processing on multiple sides to be carried out comfortably and precisely. Technical data: • 3-sided processing with a processing length of 2600 mm. This allows the operator to mill the milling pattern, e.g., of a 5-point locking mechanism, into a door profile without having to remove the profile from its clamping device. • During processing, the speed of the milling cutter can be adjusted to the profile. • 1 vertical milling spindle • Pneumatic rotation of the profile by 180° • All intermediate angles can be adjusted via a clamping device • Pneumatic profile clamping with 4 adjustable horizontal clamping cylinders • The working head is lowered manually and pneumatically fixed at the working height • Copying templates along the entire length of the machine Bwjdpfx Aijz Spttewow

Condition: ready for operation (used), Year of construction: 1984, Deckel Copy Milling Machine Model KF 3 S Year of manufacture: 1984 Table surfaces: 600 x 555 / 620 x 750 mm Y-axis travel: 150 mm Z-axis stroke: 380 mm X-axis stroke: 150 mm Drive: 3 kW Roughing spindle Finishing spindle Locking arm Control lever with cable Tracing stylus holder Collets Weight: 2400 kg Bwjdpfe Aa Ilijx Aiwew Price: EUR 2,000—plus VAT, ex works

Condition: good (used), Year of construction: 2013, – 2 pneumatic clamps Bwedpey An U Iofx Aiwsw – 12,000 rpm – Mist lubrication system – Weight 180 kg – 230V

Condition: excellent (used), Year of construction: 2008, machine/vehicle number: 1780021272, functionality: fully functional, 3 spindle copy router elumatec KF 178/00 Top routing unit: Cutting range using stops or copy templates 340 x 100 mm Travel 110 mm Bottom routing unit: Cutting range using stops or copy templates 240 x 85 mm Travel at front 95 mm Travel at back 45 mm Spindle speed 12,000 rpm Clamping range for profiles 115 x 100 mm Power supply 230/400 V, 3~, 50 Hz Bwedpjzy Staefx Aiwjw Power output per motor 0.74 kW Compressed air supply 7 bar Air consumption per working cycle 12 l without spraying, 24 l with spraying Length 980 mm, depth 1,250 mm, height 1,610 mm, weight 360 kg The machine is in perfect working order We can ship the machine to your address (On demand)

Condition: used, Year of construction: 2010, machine/vehicle number: 1780021340, Order No. 26305 Three-spindle copy milling machine Technical data: - Operation via two-hand lever - Material clamping via pneumatic clamping cylinder - Workpiece width / clamping range B 115 x D 100 mm Bwodpfx Aszxc Swoiwjw - Milling area above, to stop / copy template B 340 x D 100 mm - Stroke above D 110 mm - Milling area below, to stop / copy template B 240 x 90 mm - Stroke below, front / rear 95 / 45 mm - Spindle speed 12000 rpm - Metering spray device - Air consumption per working cycle - Without spraying 12 liters - With spraying 24 liters - Left + right original material support - Drive 400 V / 0.75 kW - Space requirement approx. B 900 x H 1400 x D 1250 mm - Weight approx. 300 kg

Condition: good (used), Pantograph Milling / Engraving Machine Stock number: 3098 Manufacturer: Scripta Machine number: Type / Model: SR 300 Travel range x-y-z: mm Pattern table / working table: 600 x 400 // 600 x 250 mm Speed range: 700 to 18,000 rpm, stepless Transmission: 1 : 1.33 to 1 : 10 Bodpfsy H Hhbox Aiwjww Accessories/equipment: Font sets; others (see pictures) Power requirement: kW Condition: good Weight: 0.7 t

Condition: excellent (used), Year of construction: 1990, machine/vehicle number: 43655, functionality: fully functional, Horizontal cutting range using a stop 230 x 90 mm Horizontal cutting range using a copy template 230 x 90 mm Spindle speed 12,000 rpm Clamping range for profiles 180 x 130 mm Travel 110 mm Power supply 230/400 V, 3~, 50 Hz Power output 0.74 kW Compressed air supply 7 bar Air consumption per working cycle 12 l without spraying, 24 l with spraying Length 720 mm, depth 650 mm, height 1,440 mm, weight 120 kg Versatile for many applications in aluminium and PVC profile machining Precision routing with a minimum of effort and easy, two-lever operation Bwsdjzz Aqlopfx Aiwjw Copy routing at a ratio of 1:1 transfers the cutting pattern from a template to the profile Your own custom templates can be created (by copying the template to a blank) Copy routing using stops is also possible (only rectangular cutting patterns) Can be set up in only a few steps Pneumatic material clamping unit Manual tracer point with three levels for different cutter diameters Pulsed coolant system The machine is ready for operation, we can ship the machine to your address.

Condition: good (used), Copy Milling / Engraving Machine Stock number: 3065 Manufacturer: WMW Union Gera Machine number: 11020 Type / Model: FG 250x500-200 Travel distances x-y-z: 280 - 200 - 315 mm Template table / work table: 380 x 380 // 500 x 250 mm Speed range: 2,500 to 20,000 rpm Accessories / Equipment: Font set Bwodpfx Aieygcnpswow Power requirement: 0.25 kW Condition: Good Weight: 0.37 t Footprint: 600 x 500 mm Dimensions: 1,100 x 1,000 x 1,300 mm

Condition: excellent (used), Year of construction: 1991, functionality: fully functional, rotational speed (max.): 12,000 rpm, Technical specifications – Elumatec AS 70/44 1-spindle copy milling machine for aluminum and PVC profiles Feature Value Machine type 1-spindle copy milling machine Milling range with stop 230 × 90 mm Milling range with copy template 230 × 90 mm Clamping range for profiles 180 × 130 mm Milling stroke 110 mm Bwjdpfx Aiszgglkjwsw Mains connection 230/400 V, 3 ~, 50 Hz Motor power 0.74 kW Spindle speed 12,000 rpm Operating pressure 7 bar Air consumption 12 l/cycle without spray device, 24 l/cycle with spray device Dimensions (L × W × H) 720 × 650 × 1,440 mm Weight approx. 120 kg Equipment Versatile for processing aluminum and PVC profiles. Copy milling in a 1:1 ratio using templates or stops. Pneumatic material clamping. Manual feeler pin with three levels for different cutter diameters. Pulse spray device for tool cooling. Simple operation via two control levers. Quick setup and high machining accuracy.

Condition: new, – 2 pneumatic clamping devices – Mist lubrication system – Emergency stop Bwsdpfeyug Trex Aiwow – Air blow gun – Documentation – 400V

Condition: new, Year of construction: 2025, machine/vehicle number: SÇ 502 S Alüminyum Pvc 3'lü kol yeri delme su tahliye makinesi yüksek frekans motorlu, - Complies with CE standards. - Possibility of opening locking places, hinge slots, handle holes and water drainage channels of aluminum and PVC profiles. - Vertical axis operation of the copy head - Horizontal axis operation of the triple drilling system - Ability of the water drainage system to operate in angled position - Possibility to make universal template optional template - Possibility of triple drilling copy milling cutter or grooving system working as one - High frequency motor (18000 rpm) - Right conveyor system (1 meter) Bwodperamz Hsfx Aiwow

Condition: excellent (used), Year of construction: 1994, functionality: fully functional, ELUMATEC AS 170 – Single-spindle profiling machine Technical data Milling area, horizontal, against stop: 300 x 120 mm Milling area, horizontal, using template: 285 x 110 mm Milling spindle speed: 12,000 rpm Profile clamping range: 150 x 130 mm, adjustable up to 400 mm Stroke: 105 mm Electrical connection: 230/400 V, 3 ~, 50 Hz Power output: 0.74 kW Compressed air connection: 7 bar Air consumption per working cycle: 12 l without spray device 24 l with spray device Dimensions AS 170/00 Length: 780 mm Depth: 770 mm Height: 1,500 mm Weight: 200 kg Features Bwodpfxjza Iifj Aiwjw Large milling area despite compact design Profiling using side stops or templates (1:1) Pneumatic, two-stage tracing device for different cutter diameters Patented suspension of the tracing lever for precise milling Table height adjustment for profiles up to 400 mm high “Spindle Lock” for quick tool changes Pneumatic material clamping device Metering spray device

Condition: new, Year of construction: 2025, Equipment: CE marking, documentation/manual, - 2 pneumatic clamps - Cooling system - Material stop - Documentation Bsdpfx Aegg N Tajiwsww - 400V

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 2750x1800x2200 mm Bodpovz Epnjfx Aiwoww Weight 2500 kg Total power requirement 11 kw

Condition: new, Year of construction: 2025, machine/vehicle number: SÇ 542 Alüminyum Kopya Freze Makinası Yüksek Frekanslı, - Conforms to CE standards - Used for handle, lock, etc. processing of all profiles - It works comfortably with advanced technology motor support. - It has burr-free and comfortable processing speed - Water cooling system available - Pneumatic profile clamping system - High frequency motor (18000 rpm) Bwedpfora Nr Rjx Aiwsw OPTION - Right conveyor system (1 meter)

Condition: excellent (used), Year of construction: 1989, functionality: fully functional, Horizontal cutting range using a stop 230 x 90 mm Bsdpfsxz Sknox Aiwjww Horizontal cutting range using a copy template 230 x 90 mm Spindle speed 12,000 rpm Clamping range for profiles 180 x 130 mm Travel 110 mm Power supply 230/400 V, 3~, 50 Hz Power output 0.74 kW Compressed air supply 7 bar Air consumption per working cycle 12 l without spraying, 24 l with spraying Length 720 mm, depth 650 mm, height 1,440 mm, weight 120 kg Versatile for many applications in aluminium and PVC profile machining Precision routing with a minimum of effort and easy, two-lever operation Copy routing at a ratio of 1:1 transfers the cutting pattern from a template to the profile Your own custom templates can be created (by copying the template to a blank) Copy routing using stops is also possible (only rectangular cutting patterns) Can be set up in only a few steps Pneumatic material clamping unit Manual tracer point with three levels for different cutter diameters Pulsed coolant system Shipping on demand

Condition: excellent (used), Year of construction: 1994, functionality: fully functional, Deckel KF 3 S type Copy Milling Machine Very good condition Bwjdpfx Aisv E Rw Sowjw

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 1200x750x1150 mm Weight 50 kg Bodpfx Ajvz Hkyjiwsww Total power requirement 1,05 kw

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 1050x730x1380 mm Bwodpsvz Excsfx Aiwow Weight 350 kg Total power requirement 1 kw

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 800x650x450 mm Weight 40 kg Bodpsvz Ew Sefx Aiwsww Total power requirement 0,8 kw
