Used milling machines - univ.conv. 400-499mm X-axis travel for sale (77)

Condition: excellent (used), Year of construction: 1987, functionality: fully functional, Universal Milling Machine Deckel FP4M with 3-Axis Heidenhain Digital Readout, Special Paint Finish in Light Grey, CE Compliant!!! Technical Specifications: - Year of manufacture: 1987 Machine no.: 2203-2790 - Rigid angle table (freshly planed) - Spindle speed: 50–2500 rpm - Feed rate: 8–630 mm/min - Drive power: 3.7 / 4.4 kW - Spindle brake - Rapid traverse: 1300 mm/min Lhjdpfx Aexctyaonxol - Travel X/Y/Z: 500/400/400 mm - Vertical milling head on column adjustable by 150 mm - Vertical and horizontal quill – SK40 - Vertical quill extendable by 90 mm - Drawbar thread: M16 - Weight approx. 1500 kg Accessories & Features: - 3-axis Heidenhain digital readout - Coolant system - Chip tray - Central lubrication system About the machine: For sale is a Deckel FP4M universal milling machine, CE compliant and in very good condition. The machine has been partially overhauled, displays minimal backlash on the handwheels, and all lead screws move smoothly and evenly. Even at maximum speeds, the milling machine runs quietly. Rapid traverse is available on all axes; all bellows are new. The rigid angle table has been freshly planed. This is a reliable and user-friendly machine. An oil change has been performed. Mechanically and electrically tested. The Heidenhain digital readout makes operation easier and even more precise. Take advantage of the opportunity to inspect and test the machine under power on site.

Condition: reconditioned (used), Year of construction: 2011, Universal tool milling machine Make: KUNZMANN Model: WF 400 MC Year of manufacture: 2011 - partially overhauled, newly painted, Lhodpfx Aevdrx Uenxol RAL7035 light gray / RAL3027 raspberry red RAL7016 anthracite gray Mach. no.: 410016 with guarantee geometric acceptance with test report Accessories: - HEIDENHAIN TNC 320 contouring control - HEIDENHAIN HR 410 electronic handwheel - attachment kit for TS 220 probe head with taper on the control panel and spindle lock - fixed table 650 x 375 (T-slot: 14 mm) - vertical milling head SK 40 with hydraulic tightening system DIN 69872 - central lubrication, electric - coolant system - splash guard cabin, travelling, electrically secured - rope left window of the spike protection cabin removable, electrically secured - control panel on the substructure - operating instructions used as seen The machine corresponds technically to the standard of the year of manufacture.

Condition: new, 3-axis digital display Fagor 40i Innova, Spindle speed: 65 - 2600 rpm Taper: ISO 40 Working area: 420 x 220 x 380 mm Table: 840 x 390 mm Motor: 2.2 kW Lhjdpfxoxtu D Ij Anxjl Clamping surface of work table: 840 x 390 mm Rapid traverse in all 3 axes: 1000 mm/min T-slots: 5 Width x spacing: 14 x 63 mm Max. table load: 200 kg Longitudinal travel: approx. 420 mm Cross travel: approx. 220 mm Vertical travel: 380 mm Infinitely variable feed (X, Y axes): 0 - 600 mm/min Infinitely variable feed (Z axis): 0 - 600 mm/min Horizontal spindle speed range: 65 - 2600 Spindle centreline distance from column guideways: 90 - 310 mm Vertical spindle speed range: 65 - 2600 Spindle swivelling: +/- 90° Quill travel: approx. 100 mm Tool clamping: manual Spindle motor: 2 kW Vertical table: 950 x 250 mm Distance vertical milling spindle to milling table: 90 - 310 mm Distance horizontal milling spindle to milling table: 100 - 480 mm

Condition: used, Year of construction: 1972, Milling machine used Make:Kunzmann Model: UF6N year of construction: 1972 Technical data: Table longitudinal travel automatic: 440 mm Table longitudinal travel by hand: 450 mm Transverse table travel 200 mm Table vertical travel horizontal/ vertical 465/500 mm Table size 860x240 mm Table swivels 45° on both sides Distance table/spindle 430 mm Spindle holder ISA 30 Quill stroke 60 mm Tiltability of the spindle head +/- 90 18 spindle speeds horizontal 32-1342 rpm 18 spindle speeds vertical 72-2888 rpm Lsdpfx Aoudb N Djnxjhl 6 automatic feeds lengthwise 13.12-164 mm/min 6 automatic cross feeds 26.24-328 mm/min. Spindle drive 1.8/2.6 kW with inclinable vertical milling head/clamping vice/ Counter holder/collet chuck with collets Weight approx. 850 kg Dimensions approx. 1400x1900x1800 mm

Condition: repair required (used), Machine number: 1464 Type / Model: FUW 250/IV Travel ranges x-y-z: 400 - 220 - 400 mm Table: 630 x 350 mm Table clamping area: 700 x 300 mm Speed range: 45 to 2,240 rpm Spindle connection: SK 40 Lhsdod Hl Stjpfx Anxol Feed rate range, longitudinal: 6.3 to 1,250 mm/min Feed rate range, transverse: 6.3 to 1,250 mm/min Power consumption: 7.4 kW Accessories / Equipment: Vertical head Condition: 2 controllers defective Note: Machine repair EUR 2,000 Weight: 1.45 t Dimensions: 1,500 x 1,600 x 1,800 mm

Condition: good (used), Year of construction: 1985, machine/vehicle number: 1076-85, Offer 24303 Technical data: - Table size approx. 630 x 340 mm - Working range of the axes - X (longitudinal) approx. 400 mm - Y (transverse) approx. 220 mm - Z (vertical) approx. 400 mm - max. distance milling spindle - table surface 400 mm - Tool holder SK 40 - Work spindle speeds adjustable in 16 steps 45 - 2240 rpm Ljdpst Dxwgofx Anxohl - Mot table feeds X ; Y ; Z 6.3 - 1250 mm/min - Drive 400 V / 8.5 kW - Space requirement approx. W 1450 x H 1900 x D 1450 mm - Weight approx. 1600 kg - with: - 3 axes digital readout HEIDENHAIN - Vertical milling head tiltable - Horizontal spindle counter holder - Machine vice

Condition: good (used), Year of construction: 1986, 3 units in stock Universal milling machine Manufacturer: KUNZMANN, Type: UF 6 / 3, Year of manufacture: 1986, with Heidenhain digital display Lsdpfjich Dvjx Anxjhl Spindle mount: ISO 40, horizontal and vertical Spindle speeds: 50 - 2150 rpm Feed rates, stepless: 0-1000 mm/min, stepped X / Y and Z 0-250 mm/min Rapid traverse: 2000 mm/min X / Y and Z 500 mm/min Table surface: 860 mm x 265 mm, swivel range: +45 to -45 degrees Machine documentation available. Good condition, ready for demonstration. Price per unit: €4,850 net, ex works, free on board (FOB) at warehouse.

Condition: good (used), Hispano Suiza Geneve milling machine offered. X-travel: 410 mm Y-travel: 200 mm Z-travel: 400 mm Speed: 67- 3000 RPM Spindle: ISO 40 Bed: 430x225 mm Head adjustable Dimensions: 130x130x140 cm LxWxH Ljdpfx Aef Srhgjnxshl For more information call us or send an e-mail.

Condition: excellent (used), Year of construction: 1999, x-travel 400 mm y-travel 320 mm z-travel 400 mm Lhsdpfx Anount Ihjxol Control HEIDENHAIN TNC 410 spindle turning speed - stepless 0 - 4000 U/min quill stroke 60 mm tool taper SK 40 table surface area 650 x 350 mm total power requirement 6,5 kW weight of the machine ca. 1,8 t dimensions of the machine ca. 2,5 x 1,8 x 2,0 m Electric handwheel HR 410 Probe MP 11, automatic tool measurement TT 120 Cabin, tool holders,...

Condition: used, Year of construction: 1981, Technical details: x-travel: 400 mm y-travel: 420 mm z-travel: 380 mm table surface area: 710 x 400 mm max. table load: 120 kg range of revolution per miute: 45 - 2240 / 18 step U/min feed continuous: 6,3 - 600 / 2 steples mm/min quill stroke vertical: 100 mm quill stroke: horizontal: 100 mm spindle taper: vertical/horizontal: SK 40/SK40 spindle head swivable left - right: 90 ° distance table/horizontal spindle: min./max.: 200 / 325 mm distance table/vertical head: min./max.: 150 / 730 mm total power requirement: 5,5 kW weight of the machine ca.: 1,95 kg machine dimensions LxWxH: 1,7 x 1,4 x 1,9 m dimensions electric cabinet: 850x500x1500 mm The milling machine is equipped with a 3-measuring path display. incl. machine feet and operating instructions Lhsdpfeu Nc Hksx Anxel *

Condition: good (used), Year of construction: 2004, Universalfräsmaschine mit Streckensteuerung HEIDENHAIN TNC 124 mech. Handräder drehbarer Kipptisch +- 45°, hydr. Werkzeugspannung, Halbkabine Lodoigm Tcspfx Anxehl Kühlmittelbehälter Handbuch Technische Details: x-Weg 600 mm y-Weg 400 mm z-Weg 400 mm Spindeldrehanzahl 63 - 3.150 1/min Vorschub stufenlos 12-3000 / 6-1500 (Z) mm/min Pinolenhub 100 mm Kopf schwenkbar +/- 90° Spindelaufnahme ISO SK 40 Aufspannfläche 630 x 400 mm Gesamtleistungsbedarf 8 kW Maschinengewicht ca. 2,2 t Raumbedarf ca. 2 x 1,9 x 1,95

Condition: reconditioned (used), Year of construction: 2002, Universal tool milling machine Make: KUNZMANN Model: WF 4/3 Year of manufacture: 2002 - partially overhauled, newly painted, RAL7035 light gray / RAL3027 raspberry red RAL7016 anthracite gray Mach. no.: 344025 with guarantee geometric acceptance with test report Accessories: - HEIDENHAIN TNC 124 path control - HEIDENHAIN HR 410 electronic handwheel - HEIDENHAIN KT 130 electronic 3D touch probe system for recording the workpiece position for determining workpiece reference points for measuring a finished part incl. Weldon chuck SK40/Ø 16 mm - universal table 650 x 395 mm (T-slot: 14 mm) can be swiveled around 3 axes can be rotated 360° (as 4th axis digital displayed in the control) pivotable +/- 30° Lhjdpom Nbwtofx Anxol tilting range towards the machine 45° tilting range away from the machine 15° centering hole Ø 32 mm table load 150 kg - vertical milling head SK 40 with hydraulic tightening system DIN 69872 - central lubrication, electric - coolant system - splash guard cabin, travelling, electrically secured - operating instructions used as seen The machine is technically corresponding to the state of the year it was built.

Condition: reconditioned (used), Universal Tool Milling Machine Make: harich (DECKEL) Model: B (FP 2) Aktiv Refurbished with CE certification Geometric inspection with test protocol with warranty Accessories: - 3-axis digital readout Heidenhain Positip 8016 - Fixed table or universal table - Vertical milling head SK 40 - Centralized manual lubrication - Coolant system - Operating manual CE and safety equipment: - New machine electrics with control cabinet - Electronically monitored cover on the vertical milling head Lhodsx A T Evopfx Anxjl - Chuck guard with electrical interlock - Drive motor with brake function - Control panel with emergency stop, enable, start and stop buttons, potentiometer for feed rate adjustment - New documentation for machine and control cabinet - CE declaration of conformity

Condition: good (used), Travel X / Y / Z: 475 / 330 / 280 mm Table size W x D: 650 x 250 mm Quill stroke: 60 mm Spindle speed: 63 - 2800 rpm / 12 steps Mounting cone: ISO 30 / DIN 2080, ISO 40 / DIN 2080 Weight: approx. 950 kg Machine size W x D x H: approx. 1100 x 1400 x 1600 mm Spindle bore: 17.8 mm (24.8 mm) Lodpfx Aod Dgdyenxehl Movement range: Longitudinal travel. table: 330 mm Table: 330 mm* 1 handwheel rotation: 5 mm Vertical travel: Console: 475 mm* 1 handwheel rotation: 2 mm Transverse travel: Milling spindle carrier head: 400 mm 1 handwheel rotation: 5 mm *These two directions of movement are provided with automatic feed and can be controlled by programs. Shortest cycle time 15 seconds, or 4 program sequences per minute. Reading accuracy at the scale drums: 0.02 mm Main motor: Milling head 2 speeds Engine: 1.1/1.5 kW, 1500/3000 rpm Automatic feeds: Rapid speed motor: 0.55 kW, 1000 rpm Rapid traverse lengthwise: 2500 mm/min Rapid traverse vertical: 1000 mm/min Working feed motor: 0.2 kW max. Control range in longitudinal direction 4 - 500 mm/min Control range in vertical direction: 1.6 - 200 mm/min Coolant device: Engine: 0.15 kW, 3000 rpm Coolant pump capacity: 20 l/min Coolant tank capacity: 30 l

Condition: used, Year of construction: 1995, - Heidenhain position display - Infinitely variable feed in all axes - rapid traverse in all axes - Hydraulic tightening system - Rigid angular table - electric central lubrication - coolant system - workplace lighting - machine feet - year of construction 1995 Specifications Milling table: - Clamping surface: 650 x 350 mm - Clamping grooves: 5 - Slot width: 14 H7 - Groove spacing: 63 mm - Max. load: 250 kg Working range: - X-axis: 400 mm - Y-axis: 320 mm - Z-axis: 400 mm Max. Max. distances: - Top edge of table to horizontal spindle center: 140 - 540 mm - Max. table top edge to vertical head bottom edge: 430 mm Milling spindle: - Tool holder: SK40 - Vertical/horizontal speeds: 40 - 2550 rpm - Gear stages: 2 - Vertical quill stroke: 60 mm - Vertical head can be swiveled on both sides: 90 ° Feed rates: - Feed lengthwise & crosswise: 0 - 1000 mm/min - Rapid traverse lengthwise & crosswise: 4000 mm/min - Vertical feed: 0 - 1000 mm/min - Rapid traverse vertical: 3000 mm/min General data: - Drive power: 3 kW / 1410 rpm Lhsdevhfqrepfx Anxel - Dimensions WxHxD: approx. 1600 x 1850 x 1350 mm - Weight: approx. 1300 kg

Condition: reconditioned (used), Year of construction: 1999, Universal tool milling machine Make: KUNZMANN Model: WF 4/3 Year of manufacture: 1999 - partially overhauled, newly painted, RAL7035 light gray / RAL3027 raspberry red Lhodpfxjub R R Ss Anxol RAL7016 anthracite gray Mach. no.: 343006 with guarantee geometric acceptance with test report Accessories: - HEIDENHAIN TNC 124 path control - HEIDENHAIN HR 330 electronic handwheel - Fixed table 640 x 350 (T-slot: 14 mm) - Vertical milling head SK 40 with hydraulic tightening system ISO 7388 - Central lubrication, electric - Coolant system - Splash guard cabin, electrically secured - Control panel on the base - Operating instructions Used as seen The machine is technically corresponding to the state of the year of manufacture.

Condition: excellent (used), MIKRON WF 3 DP Universal Milling Machine TECHNICAL DATA Tilting Table Clamping surface: 450 x 800 mm Number of T-slots: 9 T-slot spacing: 45 mm Weight: 144 kg Machine dimensions: 1475 x 1770 x 2000 mm Weight: 1800 kg Connection power: 8.7 kW Milling Spindle Drive Spindle speed: 21 steps Speed range: 25 – 2500 /min Step jump: 1.258 Spindle motor power: 3.3 / 4.0 kW Tool holder: ISO 40 / M16 Arbor movement, vertical: 110 mm Feed Drive Feeds in all 3 axes: Infinitely adjustable Feed range: 1 – 2000 mm/min Rapid traverse in all feed directions: 3000 mm/min Torque at the motor Longitudinal + transverse: 4 Nm Vertical: 8 Nm Lhodpfx Aolnfggenxsl Travel Longitudinal travel of the clamping table (X-axis): Automatic: 400 mm Transverse travel of the clamping table (Y-axis): Automatic: 400 mm Vertical travel of the clamping table (Z-axis): Automatic: 385 mm We cannot guarantee the accuracy, completeness and up-to-dateness of the information provided.

Condition: used, Model milling machine, milling machine, universal milling machine, tool milling machine, drilling and milling machine Lhsdpfsd Dt R Hsx Anxsl -Milling machine head: pivoting/rotating -Feed: in X and Y no feed because no motors are installed (gears are available, see pictures) -Clamping table: 280 x 1300 mm -Travel: X/Y/Z 450/300/325 mm -Spindle mount: SK40 -quill stroke -quill feed: 0.04-0.16 mm/rev -Speeds from: 60 to 3000 rpm -Dimensions: 1700/1530/H2200 mm -Weight: 1362 kg

Condition: used, Year of construction: 1965, x-travel 1000 mm y-travel 600 mm total power requirement 2,5 kW Lhodpjwqrw Nsfx Anxjl

Condition: excellent (used), x-travel 450 mm y-travel 175 mm z-travel 400 mm spindle turning speed range 60 - 2800 U/min tool taper ISO SK-30 weight of the machine ca. 1 t dimensions of the machine ca. 1,1 x 1 x 1,5 m Lodpfx Ajvwgn Donxohl Die Fräsmaschine ist in einem sehr gutem gepflegtem Zustand

Condition: reconditioned (used), Universal Tool Milling Machine Brand: harich (DECKEL) Model: B (FP 2) stepless Refurbished with CE Geometric acceptance with inspection protocol With warranty Accessories: - 3-axis digital readout FAGOR Innova 30i-M - Fixed table or universal table - Vertical milling head SK 40 - Centralized lubrication, manually operated - Coolant system - Operating manual CE and Safety Equipment: - New machine electrics with control cabinet - Electronically monitored cover on vertical milling head - Chuck guard with electrical interlock - Drive motor with brake function - Control panel with emergency stop, release, start, and stop buttons, potentiometer for feed rate adjustment Lhedevfdatepfx Anxel - New documentation for machine and control cabinet - CE declaration of conformity

Condition: excellent (used), Year of construction: 1986, Dear Sir or Madam, We hereby offer you well-maintained milling machines of the Deckel FP4M type. The machine will undergo a thorough technical inspection in our workshop and will therefore be fully functional. We look forward to receiving your inquiry! Delivery time: upon request Machine no.: xxxx-xxxx Year of manufacture: xxxx Table design: fixed Ledpfx Anjlrw Tijxjhl Spindle speed: 50 - 2500 rpm Feed rate: 8 - 630 mm/min Rapid traverse: 1300 mm/min Drive power: 3.7 kW / 4.4 kW Rapid traverse: 1300 mm/min Travel distances X/Y/Z: 500/400/400 mm Tool holder: SK40 Drawbar system: M16 Vertical quill stroke: 90 mm Weight: approx. 1.6 t Further equipment and accessories: upon request Our service promise to you: - We are a certified master workshop in the field of mechanical engineering - All machines are thoroughly checked - All lubricants and, if applicable, worn parts are replaced beforehand - Upon request, we can completely or partially overhaul the machine of your choice - You can freely choose the paint color of the machine - Upon request, you can order additional accessories such as tools, etc., directly - Upon request, we can install additional accessories such as safety devices, etc. - We will gladly take care of the shipping and/or installation.

Year of construction: 1968, condition: used, Cover milling machine FP1 with 3 axis digital display 380V Machine no. 37729 120-1900 rpm Travel X-axis:300 mm Travel Y-axis:150 mm Z-axis travel:340 mm Tool holder: MK 4 with tightening thread S 20 x 2 Milling head type:Vertical milling head Table type:Fixed table Table clamping surface:600 x 210 mm T-slot size:12 mm X-axis feed:290 mm Y-axis feed:150 mm Z-axis feed:330 mm Weight:700 kg Cover milling machine FP1 ID: M100000409 Lhodepmrpxopfx Anxsl

Condition: reconditioned (used), Year of construction: 2008, Universal tool milling machine Manufacturer: KUNZMANN Model: WF 4/3 Year of manufacture: 2008 - partially overhauled, newly painted, RAL 7035 light gray / RAL 3027 raspberry red Machine no.: 344349 Warranty: 6 months Geometric acceptance with test report Accessories: - HEIDENHAIN TNC 124 linear control system - HEIDENHAIN HR 410 electronic handwheel Ledjhikrrjpfx Anxshl - Fixed table 650 x 350 (T-slot: 14 mm) - Vertical milling head SK 40 with hydraulic clamping system DIN 69872 - Central lubrication, electric - Coolant system - Chip tray - Operating manual - used, as is -

Condition: reconditioned (used), Universal milling machine Manufacturer: Harich (DECKEL) Model: B (FP 2) Overhauled and CE-certified Geometric inspection with test report Includes warranty Accessories: Lhsdpfx Ajdvdczenxol - 3-axis digital display FAGOR Innova 30i-M - Fixed table or universal table - Vertical milling head SK 40 - Coolant system - Operating manual CE and safety features: - New machine electrical system with control cabinet - Electronically monitored safety cover on the vertical milling head - Tool holder guard with electrical interlock - Drive motor with braking function - Control panel with emergency stop, release, start, and stop buttons - New documentation for the machine and control cabinet - CE declaration of conformity
