Vertical machining centerDOOSAN
DNM 500
Machine data
- Machine type:
- Vertical machining center
- Manufacturer:
- DOOSAN
- Model:
- DNM 500
- Year of construction:
- 2012
- Condition:
- excellent (used)
- Functionality:
- fully functional
Price & Location
- Location:
- Rineanna, Windsor Hill, Glounthaune, T45 DP71 Cork, Ireland
Technical details
- Travel distance X-axis:
- 1,020 mm
- Travel distance Y-axis:
- 540 mm
- Travel distance Z-axis:
- 510 mm
- Feed length X-axis:
- 1,020 mm
- Feed length Y-axis:
- 540 mm
- Feed length Z-axis:
- 510 mm
- Nominal power (apparent):
- 33 kVA
- Controller manufacturer:
- Fanuc
- Controller model:
- i Series
- Workpiece weight (max.):
- 800 kg
- Total height:
- 2,700 mm
- Total length:
- 3,750 mm
- Total width:
- 2,285 mm
- Table width:
- 540 mm
- Table length:
- 1,200 mm
- Table load:
- 800 kg
- Overall weight:
- 6,500 kg
- Spindle speed (max.):
- 12,000 rpm
- Coolant supply:
- 20 bar
- Spindle motor power:
- 15,000 W
- Spindle nose:
- BT40
- Number of spindles:
- 1
- Number of slots in tool magazine:
- 30
- Input voltage:
- 400 V
- Type of input current:
- three-phase
- Equipment:
- chip conveyor, documentation/manual, rotational speed infinitely variable
Details about the offer
- Listing ID:
- A21109567
- Reference number:
- 969690
- Update:
- 28.01.2026
Description
Fanuc i-Series Control | 12,000 RPM | BT40 | Spindle Rebuilt 2024
2012 Doosan DNM 500 Vertical Machining Centre with Fanuc i-Series control. 12,000 RPM BT40 spindle (rebuilt 2024), 1200×540 mm table, 30-tool ATC, 20 bar TSC & data server. Available now.
Manufacturer: Doosan
Model: DNM 500
Machine Type: 3 Axis Machining Centre
Nwodpfxjyfh H Us Afhob
Control: Fanuc i Series Control
Year: 2012
Condition: Very Good - spindle rebuilt in 2024
We are pleased to offer this 2012 Doosan DNM 500 Vertical Machining Centre, a robust and highly accurate CNC milling machine designed for precision engineering, subcontract machining, and production environments.
Equipped with a Fanuc i-Series CNC control and a 12,000 RPM BT40 spindle, this machine delivers excellent cutting performance across a wide range of materials. The spindle was professionally rebuilt in 2024, ensuring reliability, accuracy, and long-term service life.
Key Specifications
Manufacturer: Doosan
Model: DNM 500
Year: 2012
Control: Fanuc i-Series CNC
Axis Travels
X Axis: 1020 mm
Y Axis: 540 mm
Z Axis: 510 mm
Table
Table Size: 1200 × 540 mm
Maximum Table Load: 800 kg
Spindle
Spindle Speed: 12,000 RPM
Spindle Taper: BT40
Spindle Motor Power: 15 kW
Spindle Condition: Rebuilt in 2024
Toolchanger
Automatic Tool Changer: 30 Tool Stations
Machine Dimensions & Weight
Overall Length: 3750 mm
Overall Width: 2284 mm
Overall Height: 2703 mm
Machine Weight: 6,500 kg
Features & Equipment
Fanuc i-Series CNC control
30-station Automatic Tool Changer (ATC)
20 bar Through-Spindle Coolant (TSC)
Data server / networking capability
Fully enclosed, rigid Doosan construction
Ideal footprint for busy workshops
Please Note
No swarf bin included
No tool holders included
No vices included
Ideal Applications
Precision CNC milling
Subcontract machining
Automotive, aerospace & general engineering
Small to medium batch production
The Doosan DNM 500 is renowned for its rigidity, accuracy, and reliability, making it a proven and popular choice for machine shops seeking dependable CNC performance.
Notes: *Specifications are given in good faith but not guaranteed*
