Gildemeister CTX 310

Gildemeister CTX 310

Condition: excellent (used), Year of construction: 2006, operating hours: 8,513 h, functionality: fully functional, machine/vehicle number: 8042942323C, We are offering this refurbished Gildemeister CTX 310 V4 CNC SIEMENS 840 D SHOPTURN CNC turning and milling center, year of manufacture 2006. Serviced and prepared for transport Extensive tool accessories included, such as tool cabinets and measuring devices Year of manufacture: 2006 Weight: 3950 kg Maximum spindle speed: 6000 rpm Connected load: 26 kVA Max. connection current: 35 A Current: 38 A Mains voltage: 400 V Frequency: 50/60 Hz Control voltage: 230 V Gsdpfxjyvfq Ss Ag Hebk Control power consumption: 150 W Internal voltage: 24 V If you have any questions or need more information, please feel free to send us a message or call us.

Condition: new, Precision control and lathe Make: OPTiturn Model: TH 4210 Item No.: 3462050 Gbodpfxsdbgxcj Ag Hjk Condition: new machine Tip height: 210 mm Top width: 1,000 mm equipped as standard with: -Machine base -Quad steel holder -Light machine -Reducing bushing MK 6 / MK 4 -2 fixed centres MK 4 -Fixed bezel, 15-105 mm -Bezel running with 10-65 mm -Chuck guard, electrically protected -Coolant system -Change gears set -Oil -Control tool -Manual

Condition: used, CNC Lathe DMG MORI SEIKI - GILDEMEISTER Type CTX 310 ecoline Machine No. 8044001846E Year of manufacture: 2013 CNC Control: SIEMENS Sinumerik 840D sl Swing diameter over bedway cover: 330 mm Swing diameter over cross-slide cover: 260 mm Centre height max.: 190 mm Centre distance max.: 580 mm Turning diameter max.: 200 mm Longitudinal slide travel (Z-axis) max.: 450 mm Cross-slide travel (X-axis) max.: 160 mm Spindle bore through draw tube: 51 mm Spindle bore through front bearing: 100 mm Spindle speed max.: 5,000 rpm Feed rate X and Z: mm/min. Rapid traverse X-axis: 30 m/min. Rapid traverse Z-axis: 30 m/min. Feed force X and Z: 4,500 Nm Tool turret: 12 stations Driven tool stations: 6 stations Tool holder cylindrical VDI 30 mm Spindle drive motor power at 100% duty cycle: max. 11 kW Spindle drive motor power at 40% duty cycle: max. 16.5 kW Power supply: 400 Volt, 50 Hz, 21 kVA - CNC control SIEMENS Sinumerik 840D sl, system software NCU V04.04+SP02+HF02 - Controlled C4-axis chuck position and C1-axis for tool turret - 3-jaw chuck AUTOGRIP Ø 210 mm with 1 set of hard jaws and 15 sets of soft jaws - AUTOGRIP hydraulic hollow clamping device - Clamping force adjustment for regulating clamping pressure - Tool turret SAUTER, type 0.5.901.020 with 12 stations (6 driven) - 20 tool holders VDI 30 - Tailstock MK 4 - Indirect measurement system via rotary encoder - Chip conveyor with integrated coolant system - Workpiece residual life display and piece counter as large display on machine enclosure - Control cabinet cooling unit - 9,716 total operating hours (main switch on), of which 3,322 spindle hours as per counter Gsdpeyk Hrgofx Ag Hsbk - Operating instructions and manuals Machine footprint with chip conveyor (L x W x H): 4,500 x 2,600 x 2,050 mm Base machine space requirement (L x W x H): 2,900 x 2,150 x 2,050 mm (3,200 kg) Chip conveyor space requirement (L x W x H): 3,350 x 850 x 1,650 mm (500 kg) Weight: approx. 4 tons Very good condition

Condition: used, Year of construction: 2004, functionality: fully functional, machine/vehicle number: 8038938456C, turning length: 450 mm, turning diameter over cross slide: 505 mm, turning diameter: 202 mm, spindle motor power: 10,000 W, spindle speed (max.): 6,000 rpm, spindle bore: 51 mm, Gildemeister CTX 310 Heidenhain Turn+ Gbodpfx Ajwk E Uzeg Hek The machine its full functional, but have some miner isue.

Condition: used, Year of construction: 2018, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 510 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, nominal power (apparent): 9 kVA, torque: 82 Nm, controller manufacturer: Siemens, table width: 560 mm, table length: 900 mm, table load: 600 kg, rotational speed (max.): 12,000 rpm, overall weight: 5,200 kg, number of spindles: 1, number of slots in tool magazine: 60, mount diameter: 40 mm, Equipment: chip conveyor, documentation/manual, Vertical machining center DMG MORI SLIMline Multi-Touch Control Gjdpfsw Ei E Hex Ag Hsbk Table size: 900 x 560 mm Table load capacity: 600 kg Direct path measuring system X, Y, Z SK 40 spindle taper 20 bar internal coolant supply 60-position tool changer Chip conveyor Renishaw probing kit for SIEMENS control

Year of construction: 2009, condition: ready for operation (used), Turning diameter: 200mm, passage diameter: 330mm, passage diameter over cross slide: 260mm, travel X/Z: 160mm/460mm, feed X/Z: 24m/min, speed: 5000rpm, spindle clearance: 51mm, spindle power: 16.5kW/11kW, torque: 1665.5Nm/112Nm, tailstock: 400mm, tool positions: 12. Machine dimensions X/Y/Z: approx. 4200mm/1700mm/2300mm, weight: approx. 3500kg, control: Siemens Sinumerik 810D. Including chip conveyor. Documentation available. On-site inspection is possible. Gbsdpjv Dkb Iefx Ag Hok

Year of construction: 2009, condition: ready for operation (used), A CNC universal turning and milling machine DMG Mori is available. Travel X/Z: 160mm/450mm, turning diameter over bed/face slide: 330mm/260mm, distance between centers: 450mm, chuck diameter: 210mm, speed: 5000rpm, spindle power: 16.5kW/11kW, tool positions: 12, rapid traverse: 30m/min. Machine dimensions X/Y/Z: approx. 3200mm/2000mm/1800mm, weight: approx. 3500kg, operating hours: 18127h. Dokumentation vorhanden. On-site inspection is possible. Gbjdjygmcqopfx Ag Hek

Condition: good (used), Year of construction: 2003, In good technical condition and in working order. Year of construction 2003. X-axis 350 mm. Y-axis 250 mm. Gedpfx Aou Tq Hweg Hjbk Z-axis 256 mm. Workpiece length: 750 mm. Workpiece width: 550 mm. Workpiece height: 250 mm. Machine dimensions: L 1670 mm x W 2040 mm, H 2305 mm. Machine weight approx. 2600 kg.

Condition: used, Year of construction: 2003, turning diameter 210 mm turning length 580 mm control 840 D Siemens centre height 190 mm turning diameter over bed 330 mm turning dia. over face-slide 260 mm turning speed range - main spindle max. 4.000 min/-1 power capacity - main spindel 10 / 7,5 kW max. Torque 115 / 86 Nm spindle bore 68,5 mm max. usable bar diameter 51 mm C - Axis 0,001 ° travel -x axis 185 mm travel -z axis 455 mm number of toolpositions 12 pos. tool taper VDI 30 Driven Tool Stations: 6 pos. tailstock adjustment 400 mm intake pressure max. 4.000 N rapid traverse X: 20 / Z: 30 m/min Feed force ( X / Y / Z ) 4,5 kN total power requirement 21 kW weight of the machine ca. 3,2 t dimensions of the machine ca. 8,0 x 2,2 x 2,0 m CNC Turning- and Milling Center GILDEMEISTER - CTX 310 V3 - incl. bar loading magazine IRCO Breuning - incl. 2x collet chucks Gbedpfotqmmujx Ag Hsk - incl. 2x jaw chuck including various clamping jaws - various VDI30 rotary holders - various reducing tubes - approx. 20x collets 173E - Pressure sleeve for collets 185E (for bars up to Ø50) - 11x collets 185E

Condition: good (used), Year of construction: 2002, functionality: fully functional, turning diameter over cross slide: 260 mm, turning diameter: 200 mm, spindle bore: 68 mm, overall weight: 3,200 kg, TECHNICAL DETAILS Turning diameter: 200 mm Turning diameter over cross slide: 260 mm Spindle bore: 68 mm Control: Siemens with ShopTurn MACHINE DETAILS Total weight: 3,200 kg Godpfxswbu E Dj Ag Hobk EQUIPMENT - Driven tools (2 axial, 2 radial) - Schunk 201 chuck - Collet chuck including various collets - Various rotary plates

Condition: like new (used), Year of construction: 2005, functionality: fully functional, turning length: 450 mm, spindle speed (min.): 25 rpm, spindle speed (max.): 6,000 rpm, travel distance X-axis: 213 mm, travel distance Z-axis: 450 mm, rapid traverse X-axis: 24 m/min, rapid traverse Z-axis: 30 m/min, bar passage: 65 mm, Siemens 840 D CNC Working area Max. swing diameter on bed 505 mm Swing diameter on X-slide 375 mm Chuck diameter 210 mm Bar capacity 65 mm Transverse travel (X) 213 mm Longitudinal travel (Z) 450 mm Feed rates X/Z-axis rapid traverse 24/30 m/min Main spindle Spindle nose (flat flange) 140 h 5 mm Internal diameter of front bearing 100 mm Spindle motor power (40/100% DC) 16/12 kW Torque (40/100% DC) 153/115 Nm Spindle speed 25 - 6.000 rpm Tool turret Number of tool stations 12 Of which motorized 12 Shank diameter (according to DIN 69880) 30 mm Motor power (40% DC) 9 kW Maximum torque (40% DC) 20 Nm Gbodow Adhwjpfx Ag Hsk Maximum speed 4.500 min-1 Tailstock Tailstock stroke, automatic 450 mm Center point attachment 4 CM Tailstock thrust, max 400 daN Machine equipment: • Chip conveyor • Provision for fume extractor • 2 axial motorized modules • 4 radial motorized modules • Fixed tool holders

Condition: excellent (used), Year of construction: 2003, functionality: fully functional, I have for sale a renowned brand CNC LATHE GILDEMEISTER CTX 310 V3 with driven tools, C axis. _ Type: CNC Lathe Manufacturer: GILDEMEISTER Model: CTX 310 V3 Control: HEIDENHAIN 4290 + TURN PLUS Overlay Country of manufacture: Germany Year of manufacture 1999 _ Machine parameters: - head: 12 - tools for VDI 30 holders (Every second socket driven) - max. rpm 6300/min. - max. turning length in the Z axis: 455 mm - max. turning diameter in the X axis: 200 mm - C axis - driven tools - holder on the main spindle: Fi-200mm - max. shaft diameter Fi-51 mm - finished part collector - cooling system - chip conveyor - spindle drive power: 11 KW - DTR - machine weight: 3.2 tons _ WHY IS IT WORTH BUYING MACHINES in PPM? - we have our own service _ stationary and mobile Gbedjvmy Icspfx Ag Hek - we have already sold over 700 DMG machines - possibility of starting the machine at the customer's - operator training and delivery of the machine to the customer included in the price - all our machines have undergone a professional technical inspection - 100% ready to work - purchase of the machine is possible through the installment system and leasing.
