Bed type milling machine

Lagun GBM 32E

Year of construction: 1981, condition: good (used), machine/vehicle number: 3626, OFFER 21448 Technical data: - max. working width 2540 mm - max. cutting capacity St 40 4 mm - mot. cutting angle adjustment - cutting gap adjustment by scaled adjusting screws - number of hydraulic hold-downs 14 pcs. - motorized backgauge with positioning stop 10 - 1000 mm - Stroke rate depending on cutting angle and cutting length 23 per/min - hydraulic drive 400 V / 7,5 kW - table height 1030 mm - space requirement approx. W 2500 x H 1630 x D 2150 mm Dcjdpfehhc Ixsx Ab Ejb - weight approx. 3600 kg - with: - pneum. supported sheet metal support - front angle stop + support arms - Electronic cutting depth adjustment - cutting line illumination - E-foot switch

Condition: used, Year of construction: 2004, Technical details: faceplate diameter: 4770 mm swing diameter: 7000 mm turning height: 1000 mm slide stroke: 1000 mm workpiece weight max.: 100000 kg faceplate turning speed range: 2 - 20 U/min feed speeds: 1 - 10000 mm/min rapid traverse: 10 m/min ram head dimension: 250 x 250 mm main drive: 100 kW Dcedpfx Ajvb Hlweb Esb total power requirement: 200 kW with CNC SIEMENS 840 D 2 Vertical Supports with toolchanger 12 pockets C-axis and driven tooling SK 50 37 Kw 3000 rpm Chip conveyor and coolant attachment *

Condition: excellent (used), Year of construction: 2003, HMC 500 control unit Year of manufacture: 2003 Dcodpfxow Hxtvo Ab Esb incl. software ball end mill; face mill; drill; taper tools: woodworking tools; etc.

Condition: good (used), Year of construction: 2001, functionality: fully functional, machine/vehicle number: 155436, Positioning B-axis with minimum increment 0.001 degrees Bar Feeder Interface Automatic part pick-up Synchronized tapping for live tools Coolant through milling head 15 bar Dcedpfewb Epaox Ab Ejb Rear belt chip conveyor

Condition: like new (used), Year of construction: 1992, Retrofitted: 2023 Djdpfxsugbqye Ab Eocb Numerical control: SELCA 4045D Technical features Dimensions Table dimensions: 4500 x 1100 mmNumber of T slots: 8T slots dimensions: 22 mm Traverses of axis X axis traverse: 4000 mmY axis traverse: 1200 mmZ axis traverse: 1250 mm Milling head Head type: Universal manualTool clamping system: HydraulicTaper nose: ISO 50 (DIN 2080)  /  Pull stud: DIN 69872Speed range: 20 - 2000 rpmSpindle power: 22 kW Feedrates Feedrate: 2 - 5000 mm/minRapid feedrate (X / Y,Z): 15000   /   10000 mm/min Weight and dimensions Maximum weight on table: 8000 kgMachine weight approx.: 23500 kgMachine dimensions approx.: 11100 x 5392 x 3400 mm Accesories  Electronic handwheel: Joystick SELBOX S2External coolantGuarding Sales conditions Warranty: 6 months mechanical partsSale price (Ex Work): On request View all technical features

Condition: as good as new (ex-display), Year of construction: 2020, operating hours: 10 h, Compact precision small rotary table, suitable for single part or small series production in laser welding precision mechanics. A horizontal or vertical assembly is possible. Dsdpsb Nbpwjfx Ab Ejcb - Made in Germany - It is particularly suitable as a 4th axis on engraving and milling machines for engraving, lasering, drilling, grooving, slot milling, or for use on a tool or surface grinding machine. Precision worm gear with a reduction ratio of 50:1. The worm and worm wheel are manufactured in our company, the guarantee for the highest setting precision. The pair is four ball bearings and adjusted backlash free, but adjustable. The stable output spindle is provided with a face plate d=108 mm with inner taper MK 1 and through hole 10.5 optionally M12 internal thread. The electronic control as a handy module with foot switch in clockwise rotation with power supply and emergency stop included in the package.the speed can be adjusted according to the scale of 0-50 min-1. The speed change occurs promptly with the setting when the axis is rotating. The direction of rotation is determined by the foot switch. The right switch makes the axis rotate clockwise, the left switch counterclockwise. When the foot switch is pressed, the axis accelerates to the set speed, when the switch is released, the axis brakes again. Ideal for laser welding for Hermle, Trumpf, Haas, Maho, Deckel FP1, G1 or Gravograph. We can offer you

Condition: like new (used), Year of construction: 2016, travel distance X-axis: 1,575 mm, travel distance Y-axis: 660 mm, travel distance Z-axis: 635 mm, table width: 584 mm, table length: 1,524 mm, rotational speed (max.): 8,100 rpm, Machine in very good condition, can be tested in the workshop, sold for business closure. Dcodpfotd Eypsx Ab Ejb

Condition: good (used), CNC lathe with short bar loader and NC tailstock! Available immediately! Year of manufacture 2011 – first commissioning 2015; Low operating hours, Fanuc control with Manual Guide i; 250 mm chuck, 65 mm spindle bore, turning length approx. 750 mm; Box guideways in X and Z; Chip conveyor; Tool setter; LNS short bar loader; Parts catcher with belt; Various tool holders, fixed and driven; Fully equipped for turning; Dsdjx N S D Topfx Ab Eecb

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,700 mm, travel distance Z-axis: 1,500 mm, Heidenhain 530 Diagonal milling head with 2.5° x 2.5° indexing Spindle speed up to 6,000 rpm Tool holder SK50 Internal cooling with 36 bar Longitudinal chip conveyor + cross conveyor Djdpfx Abox I A Hvj Eocb

Condition: good (used), functionality: fully functional, Machine specifications: Swing over bed: 1300 mm Maximum turning length: 4000 mm Dcodpox H Ifzsfx Ab Eob Description: The machine is in good technical condition; test run is possible by prior arrangement. Machine weight: 15,800 kg Machine dimensions (L x W x H): 7,425 x 3,475 x 2,535 mm Connected load: 82 kVA Center height over bed: 650 mm Maximum workpiece weight between centers: 10,000 kg Maximum swing / machinable diameter over cross slide: 940 mm Maximum swing / machinable diameter over bed: 1300 mm Maximum turning length / distance between centers: 4000 mm Spindle bore diameter: 104 mm Spindle diameter at front bearing: 180 mm Spindle speed range (rpm): 1st gear 0-100, 2nd gear 0-200, 3rd gear 0-400, 4th gear 0-800 Rapid traverse of longitudinal slide – max. working feed: 8 m/min Rapid traverse of cross slide – max. working feed: 6 m/min Tailstock quill diameter: 180 mm Quill stroke: 300 mm Accessories: SAUTER turret 0.5.480.532, Universal chuck 800 mm, Faceplate 1200 mm, Steady rest – small 300 mm, Steady rest – large 500 mm, Chip conveyor with container.
