Used Drilling Machine Series for sale (66,328)

Condition: used, bore capacity in steel (diameter) 32 mm Nkjdpfxoyv I Une Abvsw Short spindle MK 3 bore depth 175 mm spindle throat 320 mm column diameter 130 mm distance spindle /table 140-790 mm feed 0,1 - 0,16 - 0,25 m/min number of spindle speeds 60-1600 weight of the machine ca. 450 kg

Condition: used, Year of construction: 1986, bore capacity in steel (diameter) 50 mm bore capacity in cast iron GG 20 70 mm arm length 2000 mm morse taper MK 5 Spindle Speed 28-1.250 U/min. Nkedpfeyv N Eujx Abvew spindle stroke 330 mm total power requirement 8 kW weight of the machine ca. 5.500 kg

Condition: used, Year of construction: 1996, bore capacity in steel (diameter) 60 mm arm length 1600 mm workpiece height max. ca. 1300 mm borehole diameter in Stahl 80 mm borehole diameter in Guss 100 mm threading in St 60 M55 mm spindle turning speed range 29-1.450 U/min Spindle Speed 12 Stück boring spindle 100 mm morse taper MK5 Njdeyv N Ehopfx Abvokw spindle stroke 350 mm total power requirement 7,5 kW weight of the machine ca. 4.600 kg dimensions of the machine ca. 2600x1100x3200 mm

Condition: used, Year of construction: 2018, 1 x CNC-CONTROLLED DRILLING, GLUING AND DOWEL INSERTING MACHINE GANNOMAT "INDEX 130 PRO" (with options as Index 180 Pro) 400V, 3Ph, 50Hz complete in standard design with: - Support with linear guide consisting of: 1 x single-spindle horizontal drilling unit, 1.1 kW motor, tool speed selectable via operator software (3000/5000/8000 rpm) 1 x blow-out, gluing and dowel inserting station in reinforced design for dowels Æ 8 mm, dowel length 30 mm - fully automatic, electronically controlled central lubrication - X-axis NC controlled, with working length 1300 mm, travel speed max. 78 m/min. - Z-axis, position via support table 5-40 mm programmable with NC-controlled Z-axis option - Dowel driving overhang of 7-20 mm, programmable with NC-controlled Y-axis option, drilling depth of 0-35 mm (with drill length GL 70 mm) is automatically set with driving overhang - Closed glue system with 6 bar glue pressure via glue nozzle, for glues with a viscosity of 150 to 350 mPas - Glue quantity continuously adjustable via operator software - GL/WATER selector switch for rinsing the glue system, 1 stainless steel container each for 5 kg glue and 5 l water - Control lamp for residual glue quantity display in the glue container - 1 side stop left, 1 side stop right and 1 center stop (all removable) - 4 start buttons for individual working with 1-4 workpieces - 4 pcs. Pneumatic inclined clamping cylinder 10° for workpiece thicknesses up to max. 80 mm, workpiece length (Y) min. 70 mm - 1 pc. suction funnel, connection Æ 80 mm - 1 pc. TCT control with: built-in industrial PC, incl. Soft PLC type Beckhoff TWINCAT, operating temperature range 0-50°C, TFT industrial display 15" resistive touchscreen, resolution 1024 x 768, CPU 2 GHz, 256 MB RAM, 2x network interface adapters, IDE hard disk, 4x USB rear, 1x USB front, operating system: WINDOWS 7 - programming via menu-driven user software, drilling distances freely programmable with ABSOLUTE, RELATIVE or GRID dimensioning, automatic workpiece mirroring and work step optimization, 4 work fields can be assigned with different programs, graphic workpiece display, parametric programming, 0-point shift, programmable work lists, error diagnosis with plain text OPTIONS: 1 electronic, optical glue monitoring system G.I.C. (Glue Insert Control) for 1 glue nozzle 4 vertical inclined clamping cylinders 10° with holder, additionally, (total 8 clamping cylinders) 1 surcharge for machine bed length 1800 mm with working length 1800 mm 1 surcharge for: 1 horizontal drilling unit, motor 1.5 kW, with multi-spindle drilling head with 3 individually controllable drilling spindles, pitch 32 mm arranged in X-axis, tool speed 3000 rpm. (The standard working length is not reduced) 1 Y-axis NC-controlled, with recirculating ball screw and dynamic traversing speed of 300 mm/sec. The dowel driving overhang 7-30 mm and the drill hole depth 0-42 mm can be programmed via software. (with drill length GL 77 mm) for vertical drilling unit drilling from TOP, Y-axis position 5-42 mm 1 surcharge Y-axis NC-controlled position 5-62 mm instead of 5-42 mm 1 surcharge for: 1 vertical drilling unit drilling from TOP, motor 1.5 kW, with multi-spindle drilling head with 3 individually accessible drilling spindles, 32 mm pitch arranged in X-axis, tool speed 3000 rpm. Y-axis position 5-42 mm, workpiece length (Y) min. 130 mm, (the standard working length is not reduced) 1 Z-axis NC-controlled, with K Nkodpsxwaz Hofx Abvsw

Condition: used, Year of construction: 2024, Dowel Hole Drilling Machine GANNOMAT "DB 21400V, 3Ph, 50Hz / 1.5 kW" complete in standard configuration, equipped with: Nkedpfx Abjxnlflsvsw - Fully automatic electronic control with pulse operation via foot pedal for clamp-drill-release sequence, including electrical skip operation. - Automatic return of the drilling unit after reaching the preset drilling depth. - Automatic drilling depth extension for end-face drilling. This saves the need to adjust the drilling depth when switching from flat-face to end-face drilling (+10 mm, e.g., with dowel length 35 mm, flat-face drilling depth 14 mm, end-face drilling depth 24 mm). - 1 drilling beam with 21 spindles, 32 mm pitch, 1.5 kW motor (drilling feed 0-70 mm). Includes 21 quick-change chucks (Ganner system) for easy drill bit changeover. - Easy pivoting of the drilling unit from 0° to 90°, assisted by gas cylinders. - 1 clamping beam movable on Y-axis with 3 pneumatic clamping cylinders, for workpieces up to max. 80 mm height. Ideal fence system consisting of: - 1 stop ruler, 1800 mm, for shelf drilling (aluminum profile 40x40 mm) with 3 drop-in stops. - Quick-change system, easily switchable from right to left stop for mirrored drilling of shelves in carcass construction; also suitable for line boring in system 32. - Side stops and position adjustments, as well as drilling height position, via mechanical digital counters on the support table. - Side stops can be easily folded away for fastest set-up change from carcass to frame or line drilling. - Clamping arms for the clamping beam enable line boring positions up to max. 300 mm. - Optimized three-stage tool system. Includes 1 set of dowel drill bits: - 5 carbide dowel bits, Ø 8x77 mm, right - 4 carbide dowel bits, Ø 8x77 mm, left Basic machine Dowel Hole Drilling Machine GANNOMAT "DB 21400V, 3Ph, 50Hz / 1.5 kW" complete in standard version, equipped with: - Fully automatic electronic control with pulse operation via foot pedal for clamp-drill-release, electrical skip operation. - Automatic return of the drilling unit after reaching the preset drilling depth. - Automatic extension of drilling depth for end drilling saves the need to adjust depth when switching from flat to end drilling (+10 mm, e.g. for dowel length 35 mm, flat-side depth 14 mm and end-side depth 24 mm). - 1 drilling beam with 21 spindles, 32 mm pitch, 1.5 kW motor (drilling feed 0-70 mm). Includes 21 quick-change chucks (Ganner system) for easy drill changeover. - Easy pivoting of the drilling unit from 0° to 90°, gas spring assisted. - 1 clamping beam, Y-axis adjustable, with 3 pneumatic clamps for workpieces up to max. 80 mm high. - Ideal stop system comprising: - 1 stop ruler, 1800 mm, for shelf drilling (aluminum profile 40x40 mm) with 3 drop-in stops, quick-change system, easily switched from right to left for mirrored shelf drilling in carcass constructions, also usable for line boring in system 32. - Side stops and adjustable positions, as well as drill height position, via mechanical digital counters on the support table. - Side stops can be folded away easily for shortest retool time from carcass to frame and line boring operations. - Clamping arms for the clamp beam suitable for line-boring positions up to max. 300 mm. - Three-stage optimized tool system. Extraction funnel, dust tested, Ø 120 mm 1 set for line boring in system.

Condition: like new (used), Year of construction: 2011, functionality: fully functional, operating hours: 987 h, Vertical Schraml Drilling Machine Top Drill 130 NC - Usable height: 1300 mm (open top) - Infeed and outfeed: 2900 mm Nkodpfx Abjyuiwaovsw - Glass thickness: 3-30 mm - Overall length: 6000 mm - Width: 2000 mm - Height: 2200 mm - Condition: As new - Year of manufacture: 2011

Condition: excellent (used), Control: Heidenhain TNC 124 Travel paths X/Y/Z: 500/250/160 mm Travel path W: 480 mm Clamping area (L x W): 885 x 320 mm Permissible table load: 250 kg Distance table – spindle nose: 0 – 605 mm Feed rate X/Y: 1 – 2000 mm/min Feed rate Z: 1 – 1200 mm/min Nedsyvrfdepfx Abvekw Tool quick-change system: SF 32 Stepless speed range: 9200 rpm Drive power: 5 kW Required space (W x D x H): 1850 x 2550 x 2400 mm

Condition: new, 40 mm M 24 M 30 spindle turning speed - stepless 160-2250 U/min MK 3 spindle stroke 120 mm throat 293 mm column diameter 115 mm 515x360 mm distance spindle /table min./max. 117/701 mm 2 x 14 x 224 mm feed 0,1 + 0,2 mm/U Machine height 1840 mm Nkedpfx Aeyvvq Dsbvew

Condition: used, Year of construction: 2022, 40 mm M 24 M 30 spindle turning speed - stepless 160-2.250 U/min Njdpfsyvvqwox Abvjkw MK 3 spindle stroke 120 mm throat 293 mm column diameter 115 mm 515x360 mm distance spindle /table min./max. 117/701 mm 2 x 14 x 224 mm feed 0,1 + 0,2 mm/U Machine height 1840 mm weight 285 kg

Condition: new, 40 mm M 24 M 30 spindle turning speed - stepless 160-2.250 U/min MK 3 spindle stroke 120 mm throat 293 mm column diameter 115 mm 515x360 mm Nodpeyvvp Tofx Abvskw distance spindle /table min./max. 117/701 mm 2 x 14 x 224 mm feed 0,1 + 0,2 mm/U Machine height 1840 mm weight 270 kg

Condition: new, bore capacity in steel St 60 32 mm bore capacity in cast iron GG 20 38 mm Drilling capacity in St 60 40 mm threading in St 60 M 24 threading in GG 20 M 30 Short spindle MK 3 spindle stroke 120 mm throat 293 mm column diameter 115 mm Nkjdpsyvvptofx Abvjw Machine table - usable table surface 515 x 360 mm T-Slots Amount - Width - Distance 2 x 14 x 224 mm Distance spindle-table min. 117 / 701 mm feed von Hand spindle turning speed - stepless 160 - 2250 U/min total power requirement 1,45/1,9 kW weight of the machine ca. 260 kg

Condition: new, bore capacity in steel St 60 25 mm Drilling capacity in St 60 30 mm threading in St 60 M 16 M 20 Short spindle MK 3 spindle stroke 140 mm throat 293 mm column diameter 115 mm Machine table - usable table surface 514x360 mm T-Slots Amount - Width - Distance 2x14x224 mm distance spindle - column min./max. 132/724 mm feed von Hand 0 stufenlos Spindle Speed 225-4300 U/min. engine 1,0/1,6 kW voltage 400 V Standard equipment: - 7" TFT LCD display with touch function: * Manual input of spindle speed set value * Actual speed display * Integrated drilling depth display with touch zero point transfer * Virtual drilling depth scale in the display * Machine status indicators and warnings on the display * Service information * Selectable operating language: DE/EN/FR/ES/IT/NL/RU - Thread cutting device, for thread cutting with stop, max. 6 threads/min (thread cutting capacity depending on spindle speed), thread depth adjustable via depth stop and on the TFT LCD display (4 tools) - Infinitely variable speed adjustment via adjustment lever - Spindle protection with electrical fuse - Three separate buttons for clockwise rotation - anticlockwise rotation - stop - Mushroom pushbutton (latching) for EMERGENCY STOP - Main switch, lockable - Clockwise and counter-clockwise rotation via contactor control - Control voltage 24 V, protection class IP 54 - Paint finish: DD textured paint signal white RAL 9003, PANTONE 4545c, black Item 20.5 Foot switch in addition to the thread cutting device, for switching the direction of spindle rotation in the process. direction of rotation during the process Item 25. Coolant unit B, consisting of: separate container (33 l), pump with motor protection switch, complete armature motor protection switch, complete fitting Item 37.5 Technology calculator in the display The technology calculator guides you through the cutting task Determination of the cutting data using the following parameters: - Manufacturing process Nedpfsyvvpgox Abvekw - Tool diameter - Cutting speed - Material table - Transfer function of the spindle speed as set value

Condition: new, bore capacity in steel St 60 30 mm bore capacity in cast iron GG 20 30 mm Drilling capacity in St 60 30 mm threading in St 60 M 16 threading in GG 20 M 20 Short spindle MK 3 spindle stroke 140 mm throat 293 mm column diameter 115 mm Machine table - usable table surface 514 x 360 mm Nsdpeyvvn Nofx Abvekw T-Slots Amount - Width - Distance 2 x 14 x 224 mm Distance spindle-table min. 132 / 724 mm feed von Hand spindle turning speed - stepless 100 - 1.800 U/min total power requirement 1,0/1,6 kW weight of the machine ca. 260 kg

Condition: new, 40 mm M 24 M 30 MK 3 Nkedpfx Ajyvvnvjbvow bore stroke 120 mm throat 293 mm column diameter 115 mm 514x360 mm 2 x 14 x 224 mm 117/701 mm feed 0,10 + 0,20 mm/U spindle turning speed range 160-2.250 UpM total power requirement 1,45/1,9 kW height of the machine 1840 mm weight of the machine ca. 285 kg Standard equipment: - Mushroom pushbutton (latching) for EMERGENCY STOP - Reversing switch for right-left rotation - Motor protection switch - Speed adjustment stepless - Speed display digital - Feed overload protection - Protection IP 54 - Connector (fully assembled, cable length 2 m) - Spindle protection with electrical protection

Condition: new, 40 mm threading in St 60 M24 threading in GG 20 M30 Short spindle MK 3 spindle turning speed - stepless 160 - 2250 U/min Center of spindle to wall or column 293 mm Nsdpfxjyvvm Sj Abvekw Column diameter 115 mm spindle stroke 120 mm Machine table - usable table surface 514 x 360 mm T-Slots Amount - Width - Distance 2 x 14 x 224 mm Distance spindle-table min. 117/701 mm feed 0,10 + 0,20 mm/U Motor output 1,45 / 1,9 kW height of the machine ca. 1840 mm weight of the machine ca. 285 kg

Condition: new, bore capacity in steel St 60 30 mm Nksdjyvvmxopfx Abvjw bore capacity in cast iron GG 20 30 mm Drilling capacity in St 60 30 mm threading in St 60 M 16 threading in GG 20 M 20 Short spindle MK 3 spindle stroke 140 mm throat 293 mm column diameter 115 mm Machine table - usable table surface 514 x 360 mm T-Slots Amount - Width - Distance 2 x 14 x 224 mm Distance spindle-table min. 132 / 724 mm feed von Hand spindle turning speed - stepless 225 - 4300 U/min total power requirement 1,0/1,6 kW weight of the machine ca. 260 kg

Condition: new, 40 mm threading in St 60 M24 threading in GG 20 M30 Short spindle MK 3 Center of spindle to wall or column 293 mm Nsdpsyvvmrjfx Abvekw spindle turning speed - stepless 160 - 2250 U/min Column diameter 115 mm spindle stroke 120 mm Machine table - usable table surface 514 x 360 mm T-Slots Amount - Width - Distance 2 x 14 x 224 mm Distance spindle-table min. 117/701 mm feed 0,10 + 0,20 mm/U Motor output 1,45 / 1,9 kW height of the machine ca. 1840 mm weight of the machine ca. 285 kg

Condition: excellent (used), functionality: fully functional, Grindable diameter from 2 to 40 mm. Smallest and largest point angle: 40 – 180°. Nedpfxjyuta Sj Abvekw For right- and left-cutting tools, 1-12 cutting edges. Suitable for sharpening twist drills, step drills, and taps. Accessories and an operating manual are included.

Condition: used, functionality: fully functional, spindle mount: MK 2, quill stroke: 120 mm, Gillardon column drilling machine, drill press in decent used condition Manufacturer: Maschinenfabrik Wilhelm Gillardon II Bretten i. Baden According to the information on the attached plate, the drilling machine is operated with a motor from VEM Elektromotorenwerke Thurm. Electric motor Three-phase asynchronous motor type KPER 80 K 4 VEM Motors Thurm GmbH D Zwickau 3 speed ranges via belt drive. Quill travel approx. 120 mm, drilling spindle with Morse taper 2. Weight approx. 150 kg / Approx. 1380 RPM MK2 drill column Nodpfx Aeh N Svlebvskw Power consumption 0.75 kW - Mains connection 380 Volt, 50 Hz. Price €390,-- net ex location, plus packaging costs All technical details subject to errors and omissions. Sale exclusively to countries within the EU.

Condition: refurbished (used), functionality: fully functional, spindle mount: MK 4, total height: 1,970 mm, throat depth: 345 mm, spindle speed (max.): 720 rpm, spindle speed (min.): 80 rpm, 1.) Alzmetall AB4/SV Nedpfx Ajunhtxobvekw Speed range: 80–720 rpm Feed rate: 0.09/0.16/0.28 mm/rev Spindle taper: MK4 Throat depth: approx. 345 mm Drive power: approx. 1.8 kW Column diameter: approx. Ø 160 mm Quill travel: approx. 180 mm Table clamping surface: approx. 730x560 mm with 14 mm T-slots Dimensions: 1000x500x1970 mm Weight: approx. 600 kg Price: 2,400 euros net plus VAT. 2.) Gillardon GB30 Speed range: 60–1600 rpm Spindle taper: MK3 Throat depth: approx. 320 mm Drive power: 1.1/1.6 kW Column diameter: approx. Ø 130 mm Quill travel: approx. 175 mm Table clamping surface: approx. Ø 500 mm with 14 mm T-slots Table swivel range: approx. + / – 90 degrees Dimensions: 1000x500x1970 mm Weight: approx. 400 kg

Condition: like new (used), Donau Donauflex 135 High-Speed Radial Drilling Machine Manufacturer: Donau Model: Donauflex 135 Nodpoyucahjfx Abvjkw Year of manufacture: 2020 Condition: Very good, used but like new Available immediately from stock.

Condition: used, machine/vehicle number: 12400, functionality: fully functional, power: 24 kW (32.63 HP), input voltage: 380 V, input current: 6 A, input frequency: 50 Hz, type of input current: three-phase, tool diameter: 25 mm, spindle mount: MK 4, drilling depth: 120 mm, height adjustment type: mechanical, actuation type: manual, rotational speed (max.): 1,000 rpm, rotational speed (min.): 63 rpm, total width: 590 mm, total length: 700 mm, total height: 2,050 mm, throat depth: 315 mm, table width: 590 mm, table length: 700 mm, overall weight: 1,000 kg, VEB BK 25 AI Column Drilling Machine – Robust Industrial Version For sale is a stable and durable column drilling machine, model BK 25 AI, manufactured by VEB Werkzeugmaschinenfabrik Saalfeld (GDR). This machine features a heavy-duty cast iron design, making it ideal for use in workshops, mechanical engineering, maintenance, or training facilities. Nksdpfxsyw Rpws Abvow The machine provides a drilling capacity of up to 25 mm in steel and is equipped with an MK4 spindle taper. It offers a total of 12 mechanical speed settings, ensuring high torque and optimal adjustment for various materials. The quill stroke is 120 mm, with a throat depth of 315 mm. The generous worktable (700 × 590 mm) with T-slots offers versatile clamping options. Both drill head and table are adjustable, allowing for flexible operation. Power is supplied by a 2.4 kW motor (380 V, 3-phase, 50 Hz). The spindle speeds range from 63 to 1000 rpm. Technical Highlights: • Drilling capacity in steel: 25 mm • Spindle taper: MK4 • Speed range: 63 – 1000 rpm • 12 mechanical speed settings • Quill stroke: 120 mm • Throat depth: 315 mm • Table size: 700 × 590 mm • Total weight: approx. 1000 kg • Connection: 380 V / 3-phase Equipment: • Height-adjustable worktable • Mechanical speed selection • Solid cast iron construction • Industrial-grade design • Made in Germany (GDR) The machine is in good used condition and ready for immediate operation. Inspection under power is possible.

Condition: used, Year of construction: 1994, functionality: fully functional, throat depth: 1,250 mm, Radial drilling machine Fab. Breda type. R 55-1250 Year of manufacture 1994 Technical details Make: BREDA Type: R 55-1250 Throat: 1250 mm Drilling capacity in steel: 55 mm Drilling capacity in cast iron: 70 mm Tapping capacity in steel: M 50 Tapping capacity in cast iron: M 65 Drill spindle mount: MT 5 Nkedpfsv Rpf Ssx Abvew Throat: 1250 mm Cross travel of headstock: 930 mm Minimum/largest distance from base plate: 5360 – 1375 mm Vertical travel of the boom: 705 mm Spindle stroke: 310 mm Number of spindle speeds: 12 Spindle speeds: 30 – 1200 rpm Number of feeds: 8 Feeds: 0.06 – 1.0 mm/rev Base plate 2070 x 910 mm Clamping area base plate 1325 x 910 mm Motor power 4.4 kW - 380 volts Dimensions (L x W x H) 2.1 x 1.0 x 2.5 m Weight 3 t Accessories Drilling table 750 x 600 x 550 mm Cooling Hydraulic clamping All information is subject to change. A demonstration is available at any time in our showroom.

Condition: used, Column Drilling Machine ALZMETALL Type AB 3 ESV Machine No. 15967 Year of manufacture 1977 Drilling capacity: 32 mm Spindle taper: MT 3 – short quill Distance spindle nose – table: 545 mm (short quill) Distance spindle adapter – table: 395 mm (MT adapter) Throat: 290 mm Quill stroke: 160 mm Table size: Ø 545 mm Njdoharwvepfx Abvokw Column diameter: 220 mm Spindle speed: 55 – 1450 rpm, stepless Motor power: 1 / 1.6 kW Supply voltage: 380 Volt, 50 Hz - Spindle speed via 2 gearbox stages, 2 motor speeds and stepless through variable-speed drive - Intermediate gear stage for high torque at low speeds - MT adapter from MT3 to MT4 - Automatic feed 0.1 – 0.2 – 0.3 mm/rev - Swiveling drill table - Table height adjustment via hand crank - Heavy machine base with machined workpiece support surface (not original Alzmetall) - Work area lighting Space required (L x W x H): 1150 x 650 x 2000 mm Weight: 850 kg Good condition

Condition: used, Universal Tool Milling Machine DECKEL Type FP 1 Machine No. 51265 Year of manufacture: approx. 1967 Travel paths X: 300 mm Y: 150 mm Z: 340 mm Table size 600 x 200 mm Spindle taper SK 40 - S20 x 2 Spindle speed 40–2000 rpm, 16 steps Motor power 1.0 and 1.6 kW, pole-changing Power supply 380 Volt, 50 Hz - Feed on X and Z axes - Spindle speed via 2 motor speeds and 8 gear steps - Quill movement at vertical milling head 60 mm - Swiveling, rotating, and tilting angle table - Coolant pump in machine base - Separate control cabinet Space requirements L x W x H 1100 x 1100 x 1600 mm Weight 690 kg In good condition Nkedpfsghtvasx Abvew
