Used Mechanical Lathe for sale (10,794)

Condition: used, turning diameter 250 mm turning length 610 mm control ARIX CNC spindle bore 54 mm tail stock MK4 turning speeds 20 - 6000 U/min Kjdpfx Agoxuv Uko Uslu weight of the machine ca. 3,5 t

Condition: ready for operation (used), Manufacturer: Ikegai - Japan Type: TNC 75 Year of manufacture: 1990 Control system: Fanuc 15-T Technical data: - Center height above bed: 750 mm - Center height above floor level: 1380 mm - Swing diameter above bed: 1500 mm - Swing diameter above tool slide: 1200 mm Klodpfx Aszdrm Isg Ueu - Max. distance between centers: 7000 mm - Bed (width x height): 1500 x 630 mm - Bed, full length: 10,200 mm - Spindle nose: JIS A2 No. 20 - Taper bore of the spindle: Ø 100, taper 1:10 - Diameter of front spindle bearing: 280 mm - Diameter of rear spindle bearing: 240 mm - Speed: 2.5 - 250 min⁻¹, infinitely variable, 2 ranges (H: 10 - 250, L: 2.5 - 60 min⁻¹) - Rapid traverse X-axis: 2000 mm/min - Rapid traverse Z-axis: 4000 mm/min - Rapid traverse tailstock: 2000 mm/min - Travel X-axis: 560 mm - Travel Z-axis: Distance between centers + 200 mm - Tailstock: integrated, rotating center with its own drive and radial force measuring device - Tailstock quill diameter: 260 mm - Taper bore tailstock: MK No. 7 - Tailstock quill travel: 350 mm Condition: Good, functional condition.

Condition: excellent (used), Year of construction: 2012, Colchester Student 2500 Gap Bed Centre Lathe (2012) Ex Research Machine Super Condition Swing over Bed 330mm Swing in Gap 480m Swing Over Cross Slide 210mm Distacne Between Centres 635mm Spindle Bore 40mm Spindle Nose D1-4 Spindle Speeds 40 – 2500rpm Spindle Power 2.2kW Supplied with: 3 Jaw Chuck with Forwards and Reverse Jaws Tool Holders as Picures QCTP Coolant Tool Box 5C Collet Chuck Chuck Keys 3 Phase 415V Electics Kodpfx Aoy U Rtwsg Uelu For sale with *Jet Machinery Ltd* Jet Machinery Stock No: #79230 Machine Serial Number: 308029 Cost: £7,950.00 + VAT Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: not inspected (used), Faceplate: 2500 mm Swinging diameter: 3200 mm Max. turning height under tool: 2500 mm Max. workpiece height under support: 2780 mm Max. workpiece weight: 25 tons Cross slide: 2000 mm Ram travel, vertical: 1600 mm Ram travel, horizontal: 1800 mm Ram cross-section: 250 x 300 mm Smallest distance between two rams: 1150 mm Faceplate drive: 71 kW Faceplate speed: 125 rpm Milling drive motor: 18 kW Klsdpfx Aozdk A Ujg Uou Milling drive speed: 1600 rpm Milling drive torque: 710 Nm

Condition: ready for operation (used), turning length 500 mm turning diameter over bed 297 mm turning diameter over slide rest 160 mm spindle bore 36.0 mm tool adaptor DIN 55022 Gr. 5 quill: 3 MK quill travel 90.0 mm turning speeds 30 - 3550 U/min motor speeds: 1410 / 2830 U/min total power requirement 3.3 kW voltage 380 V weight of the machine ca. 620 kg. range L-W-H 1420 x 700 x 1200 mm from a vocational school - in very good condition (!!) particularly suitable for medium-precision turned parts Features: - Robust lead/feed screw lathe - HEIDENHAIN 3-axis digital display “VRZ 773” - RÖHM three-jaw chuck Ø 160 mm Kljdpfx Agjxmakys Ueu - Foldable lathe chuck guard - Chuck key - MULTIFIX steel holder A, with 3x new inserts - Movable tailstock - Swiveling machine light - Control panel, front left - Automatic feeds for face and upper support - Machine base, with cabinet door (storage space) - Chip splash guard rear panel - Emergency stop button - Operating instructions

Condition: ready for operation (used), turning length 800 mm turning diameter over bed 330 mm turning diameter over slide rest 170 mm turning speed range 24 - 1900 U/min spindle bore 38.0 mm centre height 165 mm total power requirement 3.5 kW weight of the machine ca. 850 kg. dimensions of the machine ca. 1850 x 800 x 1700 mm from a vocational school - in good condition (!!) particularly suitable for medium-precision turned parts - in checked conditions - machinenvideo - ?v=GDoJ0Z7Dckw Features: - Robust lead/feed screw lathe Klodsxmaktjpfx Ag Usu - HEIDENHAIN 3-axis digital display “VRZ 770” - RÖHM three-jaw chuck Ø 160 mm - Foldable lathe chuck guard - Chuck key - TRIPAN steel holder with 3x inserts - Sliding tailstock - Swiveling machine light - Control panel, front left - Automatic feeds for face and upper support - Machine base, with cabinet door (storage space) - Chip splash guard rear panel - EMERGENCY stop button - Operating instructions

Condition: used, Year of construction: 2000, max swing diameter 700mm, X/Y 255/520mm, tailstock, 12-position tool turret, CNC SIEMENS SINUMERIK 840D, 400V 50Hz 45kW, weight 12t Kodpfx Agjym Sm Us Uelu

Condition: new, Year of construction: 2022, functionality: fully functional, HYUNDAI-WIA HD3100M FANUC 0IT PLUS CNC HIGH POWER TURNING CENTRE WITH HARDENED & GROUND BOX GUIDEWAYS, HIGH SPEED SERVO TURRET, C-AXIS & DRIVEN TOOLS & 12" STD CHUCK Swing Over the Bed Ø 750 MM Swing Over the Carriage Ø 500 MM Maximum Turning Diameter Ø 420 MM Maximum Turning Length 740 MM Bar Capacity - Main Ø 102 MM MAIN SPINDLE Chuck Size Ø 12” – 305 MM Spindle Bore Ø 115 MM Spindle Speed (Rpm) 2,800 RPM Motor (Max. / Cont.) 26.0 / 18.5 KW Torque (Max. / Cont.) 1,123 / 657 NM Spindle Type BELT [GEARLESS] Spindle Nose A2-11 C-Axis Indexing 360° (0.001°) Travel X 265 MM Travel Z 830 MM Rapid Speed X 24 M / MIN Rapid Speed Z 30 M / MIN Slide Type HARDENED & GROUND BOX GUIDEWAYS TURRET Number of Tools 12 Tool Size - OD 25 MM² Tool Size - ID Ø 40 MM Indexing Time 0.15 SEC / STEP LIVE TOOLS Motor (Max / Cont.) 5.5 / 3.7 KW Milling Tool Speed 5,000 RPM Torque (Max. / Cont.) 70.0 / 35.4 NM Collet Size ER32 - Ø 25 Type BMT65P QUILL TYPE TAILSTOCK [PROGRAMMABLE BUILT IN TAILSTOCK] Taper MT5 [MT4] Quill Diameter Ø 100 MM Quill Travel 120 MM Tailstock Travel 830 MM TANK CAPACITY Coolant Tank200 L Lubricating Tank 1.8 L POWER SUPPLY Electrical Power Supply Ksdpfx Ajx Thzvsg Uelu 27 [30 GEARLESS] KVA Voltage 415V / 50HZ / 3PH MACHINE Floor Space (L x W) 3,885 x 1,800 MM Height 1,850 MM Weight 6,050 KGS STANDARD FEATURES SPINDLE POSITIONING MAIN - 0.001 DEG INDEX (C1-AXIS) CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 12 INCH 3 JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" TOUCH SCREEN MONITOR FOR FANUC (SMART GUIDE i) HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) PART PROGRAM STORAGE - 2MB (1,000 REGISTERABLE PROGRAMS) SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) COOLANT TANK (SIDE TYPE) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR FULL SPLASH GUARDING SYSTEM STANDARD HYDRAULIC UNIT 35 BAR (30 LITRES) CALL LIGHT (1 COLOUR) TOOLBOX MAIN SPINDLE - 2,800 RPM, 26.0 / 18.5 KW, 1123 NM BELT DRIVEN TOOLING PACKAGE QUILL TYPE TAILSTOCK WITH STD LIVE CENTER 12 STATION BMT65P SERVO TURRET, LIVE TOOLS 5,000 RPM, 5.5 KW, 47.0 NM FACTORY FITTED MACHINE OPTIONS CHIP BUCKET STANDARD CHIP CONVEYOR SIDE HINGED HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD (RATED AT 60HZ SUPPLY) BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE 30 KVA TRANSFORMER AND CABLE QUICK TOOL SETTER - MANUAL PROGRAMMABLE TAILSTOCK IN LIEU OF STDMACHINE CONSTRUCTION & FEATURES 12” STANDARD CHUCK SIZE. 30° SLANT BED ONE PIECE HEAVY DUTY CAST IRON CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. HARDENED & GROUND BOX GUIDEWAYS FOR HEAVY DUTY CUTTING. 12 STATION HIGH SPEED RIGID SERVO DRIVEN TOOL TURRET – BMT65P. 2,800 RPM 26.0 / 18.5 [35.0 / 25.0 GEARLESS] KW HIGH POWER MAIN SPINDLE. 24 X 30 M/MIN RAPID TRAVERSE RATES – X & Z AXES. C-AXIS MAIN SPINDLE. ERGONOMIC DESIGN FOR EASY ACCESS TO CHUCK & TURRET.

Condition: new, Year of construction: 2023, functionality: fully functional, HYUNDAI-WIA HD2200 FANUC 0IT PLUS CNC LATHE MACHINE CONSTRUCTION & FEATURES ▪ 8” STANDARD CHUCK SIZE. ▪ 45° SLANT BED ONE PIECE HEAVY DUTY CAST IRON CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. ▪ HARDENED & GROUND BOX GUIDEWAYS FOR HEAVY DUTY CUTTING. ▪ 12 STATION HIGH SPEED RIGID SERVO TURRET. ▪ 4,500 RPM HIGH POWER MAIN SPINDLE. ▪ 24 X 30 M/MIN RAPID TRAVERSE RATES – X & Z AXES. ▪ ERGONOMIC DESIGN FOR EASY ACCESS TO CHUCK & TURRET. Swing Over the Bed Ø 550 MM Swing Over the Carriage Ø 390 MM Maximum Turning Diameter Ø 380 MM Maximum Turning Length 565 MM Bar Capacity Ø 65 MM MAIN SPINDLE Chuck Size Ø 8” – 203 MM 10” - [254] MM Spindle Bore Ø 76 MM Spindle Speed (rpm) 4,500 RPM Motor (Max/Cont.) 18.5 / 15.0 KW Torque (Max/Cont.) 206 / 125.3 NM Spindle Type BELT Spindle Nose A2-6 FEED Travel X 215 MM Travel Z 580 MM Rapid Speed X 24 M/MIN Rapid Speed Z 30 M/MIN Slide Type HARDENED & GROUND BOX GUIDEWAYS TURRET Number of Tools 12 Tool Size - OD 25 MM² Tool Size - ID Ø 40 MM Indexing Time 0.12 SEC / STEP TAILSTOCK Taper MT 4 Quill Diameter Ø 65 MM Quill Travel 80 MM Travel 513.7 MM TANK CAPACITY Coolant Tank 150 L Lubricating Tank 1.8 L POWER SUPPLY Electric Power Supply 23 KVA Thickness of Power Cable Over 16 MM² Voltage 415V / 50Hz / 3Ph MACHINE Floor Space (L x W) 2,925 x 1,650 MM Height 1,820 MM Weight 4,100 KGS INCLUDED MACHINE OPTIONS CONVEYOR SIDE HINGED WITH CHIP BOX COOLANT GUN HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD OIL SKIMMER BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE TRANSFORMER - 415V 3PH 50HZ QUICK TOOL SETTER - AUTO PROGRAMMABLE TAILSTOCK IN LIEU OF STD STANDARD FACTORY FITTED MACHINE OPTIONS CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 8 INCH 3 JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE CHUCK OPEN / CLOSE CONFIRMATION DEVICE MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" TOUCH SCREEN MONITOR FOR FANUC (SMART GUIDE i) HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR STANDARD COOLANT TANK 150 LITRES FULL SPLASH GUARDING SYSTEM Kedpox Tqppofx Ag Uelu STANDARD HYDRAULIC UNIT 35 BAR (15 LITRES) CALL LIGHT (1 COLOUR) MACHINE MANUALS & OPERATOR HANDBOOKS TOOLBOX STANDARD TOOLING PACKAGE QUILL TYPE TAILSTOCK - 4MT WITH STD LIVE CENTER

Condition: used, Year of construction: 1992, faceplate diameter 1200 mm turning diameter 1520 mm turning speeds . U/min max. workpiece weight -without tailstock 6000 kg max. workpiece weight between centres 25000 kg turning diameter in the pit 3200 mm Control Siemens Ksdpfx Ajzfwt Njg Ujlu turning length 1200 mm main drive 70 kW total power requirement 70 kW dimensions of the machine ca. 22x5x4 m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: new, Year of construction: 2022, functionality: fully functional, HYUNDAI-WIA HD3100L FANUC 0IT PLUS CNC LATHE MACHINE CONSTRUCTION & FEATURES 12” STANDARD CHUCK SIZE. 30° SLANT BED ONE PIECE HEAVY DUTY CAST IRON CONSTRUCTION FOR HIGH ACCURACY & RIGIDITY. HARDENED & GROUND BOX GUIDEWAYS FOR HEAVY DUTY CUTTING. 10 STATION HIGH SPEED RIGID SERVO TURRET. 2,800 RPM 26.0 /18.5 KW HIGH POWER MAIN SPINDLE. 24 X 30 M/MIN RAPID TRAVERSE RATES – X & Z AXES. ERGONOMIC DESIGN FOR EASY ACCESS TO CHUCK & TURRET. MACHINE CAPACITIES Swing Over the Bed Ø 750 MM Swing Over the Carriage Ø 500 MM Maximum Turning Diameter Ø 500 MM Maximum Turning Length 1,300 MM Bar Capacity Ø 102 MM MAIN SPINDLE Chuck Size Ø 12” – 305 MM Spindle Bore Ø 115 MM Spindle Speed (rpm) 2,800 RPM Motor (Max/Cont.) 26.0 / 18.5 KW Torque (Max/Cont.) 1,123 / 657 NM Spindle Nose A2-11 FEED Travel X 265 MM Travel Z 1,350 MM Rapid Speed X 24 M/MIN Rapid Speed Z 30 M/MIN Slide Type HARDENED & GROUND BOX GUIDEWAYS TURRET Number of Tools 10 Tool Size - OD 25 MM² Tool Size - ID Ø 50 MM Indexing Time 0.15 SEC / STEP TAILSTOCK Type QUILL TYPE TAILSTOCK [PROGRAMMABLE TAILSTOCK] Taper MT5 [MT4] Quill Diameter Ø 100 MM Quill Travel 120 MM TANK CAPACITY Coolant Tank 220 L Lubricating Tank 1.8 L POWER SUPPLY Electric Power Supply 27 KVA Thickness of Power Cable Over 16 MM² Voltage 415V / 50Hz / 3Ph MACHINE Floor Space (L x W)4,405 x 1,978 MM Height 1,850 MM Weight 7,200 KGS INCLUDED FACTORY FITTED MACHINE OPTIONS Klodpjx Tiggofx Ag Usu CONVEYOR SIDE HINGED WITH CHIP BOX SMART GUIDE-I (CONVERSATIONAL PROGRAMMING) COOLANT GUN HIGH PRESSURE COOLANT SYSTEM 20 BAR IN LIEU OF STD BARFEED INTERFACE - MAIN SPINDLE PARTS CATCHER - MAIN SPINDLE TRANSFORMER - 415V 3PH 50HZ QUICK TOOL SETTER - AUTO STEADY REST PREPARATION - PROGRAMMABLE CLAMPING & TRAVEL PROGRAMMABLE TAILSTOCK IN LIEU OF STD QUILL TYPE TAILSTOCK - MANUAL TYPE MT#5 100 MM DIA QUILL, 120 MM QUILL TRAV STANDARD FACTORY FITTED OPTIONS CHUCK CLAMP FOOT SWITCH MAIN SPINDLE 12 INCH 3 JAW HYDRAULIC CHUCK STD INC SET SOFT JAWS - MAIN SPINDLE STANDARD HYDRAULIC CHUCKING CYLINDER - HOLLOW 15" MONITOR FOR FANUC FOR STANDARD CNC SPECIFICATION - SEE MANUFACTURER'S BROCHURE HW ENERGY SAVING SYSTEM (HW-ESS) MACHINE GUIDANCE (HW-MCG) COOLANT TANK (SIDE TYPE) STANDARD COOLANT SYSTEM (NOZZLE) STANDARD COOLANT SYSTEM 0.5 BAR FULL SPLASH GUARDING SYSTEM STANDARD HYDRAULIC UNIT 35 BAR (30 LITRES) CALL LIGHT (1 COLOUR) TOOLBOX STANDARD TOOLING PACKAGE - SEE MANUFACTURER'S BROCHURE STANDARD LIVE CENTER

Condition: excellent (used), Year of construction: 2015, workpiece weight (max.): 20,000 kg, spindle motor power: 90,000 W, spindle speed (max.): 75 rpm, turning diameter: 4,000 mm, turning height: 1,900 mm, New 2015. Purchased 2022 for a project was cancelled before commissioning was completed and the machine has not been used in any production after commissioning. Very full documentation is available upon request Main specification details. Turning diameter 3600mm. Maximum turning height 1900mm. Maximum table load 20,000kgs. Table speeds are infinitely variable between 14rpm and 75rpm. Table drive motor 90KW AC. Table torque to 61168NM. Z axis thrust 36000NM. X and Z axes traverse rates 1-5000mm/min. Klsdpfx Aey Uxdkeg Ueu Ram is 320mm diameter Price, ex works UK Midlands £330,000 VTT-WB can quote transport installation and commissioning

Condition: refurbished (used), Year of construction: 1998, functionality: fully functional, feed length Z-axis: 1,000 mm, workpiece weight (max.): 15,000 kg, spindle motor power: 37,500 W, spindle speed (max.): 415 rpm, turning diameter: 2,100 mm, turning height: 1,300 mm, workpiece diameter (max.): 2,100 mm, year of last overhaul: 2026, As with all Millenniums this machine has the wonderful base structure and table drive design that makes all the production wishes possible – the highest accuracy and the highest chip removal When this machine is delivered to the customer it will have been fully serviced and refurbished to ensure those qualities are ready for you to use turning, pcd drilling, rotary contour milling, angle drilling, grinding – see it all on the Millennium films on the website Kljdpfxsy Uw Sgo Ag Usu Only the best machine tools are designed and built with this quality and strength

Condition: excellent (used), Year of construction: 2002, functionality: fully functional, travel distance Z-axis: 1,500 mm, chuck outer diameter: 1,800 mm, spindle speed (max.): 315 rpm, turning diameter: 2,000 mm, turning height: 2,450 mm, rotational speed (max.): 3,000 rpm, year of last overhaul: 2026, FOR SALE – 12 MONTHS GUARANTEE – CE MARKED A DORRIES-SCHARMANN VCE2000/180MC-FC CONTUMAT Vertical Turning, Centre for high accuracy heavy cut turning, high precision heavy PCD drilling and continuous rotary milling Delivered in 2002. Condition: Excellent - see INTRO page CNC specification – high level Siemens 840D Hydrostatic crossrail and ram guideways. Cutting and positioning feed rates up to 18m/min A 9-STATION MAGAZINE is for turning toolheads & machining heads. These heads are picked up by the ram during cycle The turning and milling heads are fed by a KELCH DOUBLE GRIPPER TOOL CHANGER, as seen on most machining centres Klodpfoy Uw Emox Ag Ueu The tool changer collects the turning tools (CAPTO C8) and live spindle tools (SK50) from a WERO magazine The magazine as supplied with this machine originally has the capacity to hold 60 Capto C8 tools and 76 SK50 tools The KELCH toolchanger can change the tools in both vertical and horizontal working positions. This means, for example, that various SK50 tools can be fed into a right angle milling head while it remains on the ram MACHINE SALE POSSIBILITIES The machine specification will be finalized by the purchaser and VTT-WB New guarding will be supplied to match the final specification GUIDE PRICES A – machine without the pallet system but with the full tool changing and tool storage system. New guarding. CE marking 12 months full warranty, including 96% uptime guarantee and 12 months Preventive Maintenance Tool storage capacity can be reduced within this price £525,000 B – machine without the pallet system and toolchanging and storage system replaced with 30 pocket disc type magazine New guarding. CE marking 12 months full warranty, including 96% uptime guarantee and 12 months Preventive Maintenance £540,000 C – machine to original specification including full pallet system and full tool change system New guarding. CE marking 12 months full warranty, including 96% uptime guarantee on machine but excluding pallet and toolchange system £650,000

Condition: refurbished (used), Year of construction: 1998, workpiece weight (max.): 15,000 kg, travel distance Z-axis: 1,000 mm, chuck outer diameter: 1,750 mm, spindle speed (max.): 400 rpm, turning diameter: 2,100 mm, turning height: 1,350 mm, rotational speed (max.): 3,000 rpm, feed force Z-axis: 50,000 N, year of last overhaul: 2026, The Millennium provides very high precision turning and versatile machining capability. Always precise, always powerful. Features of this machine:- – Involute chain drive for very high speeds, very low noise – a 36” diameter Timken cross roller bearing, the ultimate bearing – see last page – All steel 1750mm dia. 4 jaw chuck for high speeds. Maximum loading 15,000kgs. – A servo powered C axis control that provides backlash free C axis movement – high power and high accuracy – 200mm square forged steel ram - high accuracy heavy cutting when required and incorporating a 15KW ISO 50taper live spindle providing speeds 20 to 3000rpm for rotary contour milling, pcd drilling and angle milling and grinding with attachments (new heads can be provided to order). 1350mm maximum height under ram – Automatic pick up of turning tools, live tools and attachments from the 18 pocket tool magazine Klsdpey Uwxtjfx Ag Ueu – Raise and lower crossrail - high precision latching and clamping at 200mm pitches – flexibility without loss of accuracy Fanuc 18Ti. A very precise, powerful and versatile machine tool. Performs all functions shown in photo gallery 12 months guarantee

Condition: excellent (used), Year of construction: 2003, operating hours: 8,000 h, functionality: fully functional, feed length X-axis: 3,500 mm, feed length Y-axis: 2,800 mm, feed length Z-axis: 1,500 mm, workpiece weight (max.): 35,000 kg, spindle motor power: 120,000 W, spindle speed (max.): 4,000 rpm, turning diameter: 4,000 mm, total height: 3,100 mm, rotational speed (max.): 180 rpm, workpiece diameter (max.): 4,000 mm, Equipment: documentation/manual, A STARRAG DORRIES 2VC2800/280MC-FC-V CONTUMAT Kjdpfxey Uwg Rs Ag Uolu High-Production 4/5 AXIS Vertical Turning Centre with Siemens 840D cnc This is not a machining centre with a turning table but a real high power, heavy duty vertical turning machine with the high power turning table on a massive base with guideways to provide a Y axis This configuration enables the machine to turn a round component to its maximum diameter and machine a square component to a similar dimension – and many more possibilities in between If a DS CNC swivelling head would be purchased from DS this machine is ready for huge 5 axis work. For large precise and complex components in these industries this is the perfect ‘one stop’ machine Defence, Aero Engine, Nuclear, Turbines, Rail, Oil and Gas, Pumps, Gearboxes, Rockets etc. 12 month guarantee. PAYMENT PLAN AVAILABLE

Condition: good (used), Year of construction: 2006, Switch-on hours (date 18. May 2026): 28.970 h Technical details turning diameter 570 mm turning length 1000 mm control WEILER D3 swing diameter over slide rest 325 mm Swing in gap 600 mm length of gap 140 mm spindle bore 83 mm spindle diameter in front bearing 120 mm face stroke 340 mm longitudinal stroke 1100 mm workpiece weight max. 1200 kg Kledpezcmccsfx Ag Uju spindle turning speed - stepless 1 - 2500 rpm transmission ratio 2 rapid travel - longitudinal/face 10 / 5 m/min main drive motor (60/100 % ED) 20 / 17 kW tailstock quill diameter 80 mm tailstock quill stroke 200 mm tailstock quill taper MT 5 weight of the machine ca. 3,8 t dimensions of the machine ca. 2,95 x 1,90 x 1,82 m * Control WEILER D3 * Chip conveyor * 4-station toolholder PARAT with several inserts * 3-jaw chuck SCHUNK ROTA-S plus 315-92

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, turning diameter over cross slide: 455 mm, turning length: 1,000 mm, spindle bore: 107 mm, spindle speed (max.): 2,800 rpm, spindle speed (min.): 4 rpm, travel distance X-axis: 320 mm, travel distance Z-axis: 1,097 mm, rapid traverse X-axis: 24 m/min, rapid traverse Z-axis: 3 m/min, Equipment: documentation/manual, rotational speed infinitely variable, The machine is currently still in operation but will be decommissioned due to the operator’s retirement. Kodpezbik Tsfx Ag Uolu Available from week 30.

Condition: good (used), Year of construction: 2010, functionality: fully functional, Technical details turning diameter 475 mm turning length 830 mm Ksdpfx Ajzclhdeg Uslu control HEIDENHAIN MANUALplus 620 swing diameter over slide rest 260 mm centre distance 1000 mm spindle bore 70 mm spindle turning speed range 1 - 3000 U/min feeds - cross 0,001 - 1000 mm/U feeds - longitudinal 0,001 - 2000 mm/U rapid travel - longitudinal/face 10 / 5 m/min tailstock quill diameter 70 mm tailstock quill stroke 120 mm tailstock quill taper MT 5 main drive (40 % ED) 25 kW weight of the machine ca. 2,9 t Additional information * Control HEIDENHAIN MANUALplus 620 * DXF conversion software (processing of contours in DXF format from CAD drawings) * Ethernet and USB interfaces inside the control cabinet * Coolant system (frequency-controlled), 1–4 bar * Glass scale for direct position measurement on the X and Z axes * 4-position PARAT quick-change tool holder, size 2 * Roller guide for easier movement of the tailstock * 2 movable safety doors * Main motor fan control, temperature-controlled, for particularly quiet environments such as laboratory workshops and schools

Condition: good (used), Year of construction: 2006, CAZENEUVE OPTICA 360 CNC - NUM - 2006* *CNC training/production lathe – Very recent for an Optica – CE marked* *1. Identification* Kedpfszc Ul Ssx Ag Ujlu Make: CAZENEUVE S.A. - Pont-Évêque Model: OPTICA 360 Serial Number: 5055 Year: 2006 - CE Marking Control: NUM Distance between centers: 750 mm Spindle bore: Ø 54 mm *2. Why this 2006 model?* It is one of the last Optica 360 models produced. Therefore: 1. *NUM Control*: Reliable, parts and service are still provided by NUM. It is the standard in France. 2. *Year 2006*: Less wear, more modern electronics than models from the 90s. 3. *3 Cazeneuve modes*: Manual / Training / CNC. Ideal for a general mechanical workshop or vocational school. 4. *Robust*: Cast iron bed, 7.5 kW. You can switch from machining brass to pre-treated materials without any issues. *Condition*: Very clean for a 2006 machine. Original white/blue paint, no damage. Machine is on blocks, stored in a dry place. Can be seen powered on. *3. Technical Specifications* Characteristic | Value Ø over bed | 360 mm Ø over carriage | 200 mm Distance between centers | 750 mm Spindle bore | Ø 54 mm Spindle nose | A2-5 Spindle power | 7.5 kW Spindle speed | 50 to 3500 rpm Control | NUM 1020 / 1050 *Specify if you know which one* Weight | ~2300 kg *4. Included Equipment* - 3-jaw chuck Ø 200 - Rotating tailstock CM4 - Full splash guard with door safety interlock - Operator panel + NUM screen - Lighting - Cazeneuve technical documentation + NUM schematics - Basic tooling

Condition: excellent (used), Year of construction: 2022, control OSP P 300LA spindle turning speed range 5000 U/min turret (x-stations) 12 Kodezfql Ejpfx Ag Ujlu turning diameter over bed 580 mm turning diameter over slide rest 470 mm turning diameter 340 mm turning length 800 mm x-axis 260 mm z-axis 1.010 mm y-axis 120 mm spindle nose ASA 6" spindle bore 90 mm w-axis 895 mm total power requirement 22 kW weight of the machine ca. 6,8 t dimensions of the machine ca. LBH 3,5 x 2,1 x2,5 m • Turret: 12-position radial, motorized; turret motor 6,000 rpm, 7.1 kW • Pedals: Separate for spindle and tailstock • High-pressure coolant pump: 0.8 kW; 6 bar; 20 l/min • Tool presetter: Manual • Programming: IGF conversational programming incl. Chip Conveyor incl. Tools

Condition: used, turning diameter over bed max.: 4000 mm turning diameter over slide rest . mm turning length 7500 mm speed 0-750 u/min The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Kjdeyqt Hkopfx Ag Uelu Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 1998, swing diameter max. over bed cover 570 mm swing diameter over face slide 420 mm control Heidenhain CNC PILOT longitudinal stroke 635 mm face stroke 220 spindle bore 79 mm centre distance 1000 mm chucking diameter 250 mm Kledpfx Agezcfc Io Ueu tailstock taper MT 4 feed speed longitudal 0,025-24.000 mm/min. feed speed face 0,025-20.000 mm/min. power feed longitudinal 7.000 N Feed Force Face 3.500 N total power requirement 44 weight of the machine ca. 5,7 t dimensions of the machine ca. 7,5 x 4,0 x 1,7 m Accessories: - 3 clamping jaws - various tool holders

Condition: used, Year of construction: 1995, turning diameter 250 mm turning length 750 mm control Siemens type 840 c spindle passage 65 mm Tool changer 2 Ksdpfx Aszfqhyog Uelu live tooling 2x Revoler weight of the machine ca. 7 t Main and counter spindle 3-jaw chuck with numerous jaws Hainbuch collets Many tool holders Various driven tools Bar loader "Index MBL" Chip conveyor with coolant unit Complete set of spindle reducers etc. see photo The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 1965, faceplate diameter 1250 mm swing diameter 1450 mm turning height 1200 mm slide adjustment 800 mm side head - cross travel 600 mm Overhauled in 1996 Machine is cycle-controlled with Heidenhain Positip New control panel The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. Kedpoyqvriofx Ag Uolu About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team
