Used Vdf Due Lathe for sale (5,487)

Condition: used, Year of construction: 2003, Mazak Integrex E-410H Multi-Tasking Lathe with Mazatrol 640M Pro Control, Serial No. 164385 (2003). Country of Origin: Japan Please note: Toolholders/Tooling photographed in the toolchanger will not be supplied with this machine. Any available tooling will be a specifically described. Iodpfx Asx T Df Deddsht Please Note: This lot is located in Birmingham, UK. A charge of £4,500 for dismantling and loading onto suitable transport will be automatically added to your invoice should you be successful in purchasing this item. Blocking and securing will be at the cost of the purchaser. All/Any tooling is being offered as specifically described.

Condition: good (used), Year of construction: 1996, Victor Vturn-20 CNC turning centre, 10 station tool holder, Fanuc Series 0-T CNC, swarf conveyor, fitted air bench, with Hydrafeed Multifeed MLI bar feeder, serial no. 2766 (1996) Ihsdpfx Adeyahz Isdet

Condition: like new (used), Year of construction: 1999, functionality: fully functional, MORI SEIKI SL-600B/2000 CNC LATHE Category: CNC Turning Centers Reference No.: 400212 Capacity: Ø900 X 2000 MM Year of Construction: 1999 Technical Specification: CNC Control : Fanuc 18iT WORKING CAPACITY Max Turning Diameter : 900 mm Max Turning Length : 2000 mm Swing over bed : 994 mm Distance Between Centers : 2300 mm Swing over cross slide : 733 mm Travels (X) : 485 mm (440 + 45) mm Travels (Z) : 2150 mm TURRET Turret : 12 Station Square tool shank size : 32 mm Ihodsx Nv Shjpfx Addot Boring bar shank diameter : 65 mm TAILSTOCK Tailstock : MT5 Tailstock Quill Travel : 150 mm Tailstock Quill Dia : 150 mm SPINDLE Max Rotation Speed : 1500 RPM Main Spindle Nose : JIS A2-15 Main Spindle Bore : 185 mm Spindle Type : 3 Step Gearbox Spindle bearing inner diameter : 260 mm MACHINE DIMENSIONS Weight : 16T Additional Details: All Specifications are found online, and subject to verification by buyer.

Condition: good (used), Year of construction: 2007, functionality: fully functional, turning diameter over cross slide: 330 mm, spindle bore: 52 mm, turning diameter: 330 mm, turning diameter over bed slide: 160 mm, turning diameter over top slide: 160 mm, center width: 1,000 mm, turning length: 1,000 mm, total length: 1,800 mm, total width: 650 mm, total height: 1,400 mm, spindle speed (max.): 2,000 rpm, spindle speed (min.): 70 rpm, Distance between centres: 1.000 mm Swing: 330 mm over bed / 160 mm over cross slide Spindle bore: 52 mm Spindle speed: 70 - 2.000 rpm Featured with: - 1x fixed steady, 1x moving steady Ihodpfsyac Enjx Addet - Gearwheels-set - Flat chuck - Chuck protection hatch - Cooling unit Country of origin: The Netherlands Machine LxWxH: 1.800 x 650 x 1.400 mm Machine weight: 750 kg

Condition: excellent (used), Year of construction: 2024, operating hours: 314 h, functionality: fully functional, machine/vehicle number: LL393806057, total length: 8,470 mm, total width: 3,050 mm, total height: 2,370 mm, overall weight: 20,500 kg, Axe & Status Tuscan LL550 X 6000 5-Bedway Heavy Duty Lathe With Fanuc Series 0i-TF Plus CNC Control Running Time 314 Hours. Swing Over Bed Ø950mm. Centre Height Approx 575mm. Distance Between Centres Approx 6,000mm. Carriage Type Box (2 Box Way), Carriage Width Approx 955mm, Cross Slide Width Approx 450mm, Bed Width 990mm. Axis Travel 'X'=480mm, 'Z'=6,000mm. Feed Rate 'X'=0-3,000mm/min, 'Z'=0-3,000mm/min. (2) 'FCG-32C' Ø800mm x Ø320mm Through Bore 4-Jaw Manual Chucks (Front & Back of Spindle). (2) SMW Autoblok 'K4 ZSW' Programmable Steadies, Range Ø52mm - 280mm. Headstock Spindle Nose A2-20. Spindle Bore Ø305mm. Spindle 'X' Axis Servo Motor 3kW, 'Z' Axis Servo Motor 7kW. Spindle Speeds 7-400rpm (Motor 30/37kW), Morse Taper 6. V12-200 Hydraulic 12 Station Turret, 32mm Tool Size, Ø50mm Boring Bar Holder Dimension. Motorised Tailstock Body Movement, Quill Ø165mm, Quill Travel 250mm, MT 6. S/No LL393806057 (2024). Ijdpfxox Ivzmj Addjht Electrical Specification AC220V/50Hz, 3 Phase. Automatic Doors & Full Cover Guard, Motorised Fondex Front & Rear Chip Conveyors, Auto Lubrication & 15-Bar Coolant System, Air Conditioned Electric Cabinet, Halogen Work Lights, Unimag DS-2030-30 Disc Type Oil Skimmer, Yong Teng E04-AL60 kVA Transformer, Plus: (2) Steel Cabinets: (1) 500mm x 500mm x 800mm With 6 Drawers & (1) 1,000mm x 700mm x 1,000mm With 6 Drawers, Full Range Of Machine Manuals, Ø800mm 4-Jaw Manual Chuck (Already Described In Original Detail) With Backing Plate & Spare Jaws, (11) Assorted C6 Capto Adaptors Including Boring Bar Holders, Tool Blocks & Facing Tool Holder,; Boring Bar Attachment (To Hold up to 150mm). Overall Dimensions Approx 8,470mm x 3,050mm x 2,370mm High; Weight Approx 20,500kg.

Condition: used, Year of construction: 2007, turning length 1500 mm control FAGOR 8055i/A TC centre height 230 mm greates pass round over bed 475 mm swing diameter over slide rest 240 mm bed width 355 mm max. workpiece weight 1500 kg spindle bore 65 mm Ihodpfxov Hhv Uj Addjt spindle turning speed range 100-4500 U/min weight of the machine ca. 3,15 t required space 3,51 x 1,80 x 2,02 m

Condition: used, Year of construction: 2002, Mazak Integrex E-650H Multi-Tasking Lathe with Mazatrol PC-Fusion 640M Pro Control, 3000mm B/C, SMW-Autoblock KS-MSW 135-460mm Hydraulic Steady, Boring Bar Attachment, 120 ATC, Swarf Conveyor. S/No. 159927 (2002) Country of Origin: Japan Please note: Toolholders/Tooling photographed in the toolchanger will not be supplied with this machine. Any available tooling will be a specifically described. Ijdpfx Asx T Dfwoddeht Please Note: This lot is located in Birmingham, UK. A charge of £4,500 for dismantling and loading onto suitable transport will be automatically added to your invoice should you be successful in purchasing this item. Blocking and securing will be at the cost of the purchaser. All/Any tooling is being offered as specifically described.

Condition: new, Year of construction: 2025, turning diameter over bed 290 mm turning diameter / mm turning length / mm swing diameter over bed slide / mm Number of sanding units / st. sanding width / mm Sanding height max. / mm total power requirement / kW weight of the machine ca. 310 kg required space 1400 x 700 x 1030 mm The following features and characteristics make the G2930 combination lathe unique and competitive in the market: 1. V-shaped guides provide higher stability and are firmly anchored. 2. The gearbox is fixed for maximum stability and offers comprehensive feed and threading functions. 3. Advanced tapered roller bearings support the D1-4 spindle with high precision. 4. Automatic vertical feed enables maximum threading capabilities. 5. The cross slide is equipped with ‘T’-shaped slots. 6. The slideways are effectively controlled by adjustable gibs. 7. Advanced gearbox design with maximum functionality. 8. Maximum working area thanks to the lowered bed section. 9. The spindle with carriage mounting is controlled by a lever arm. 10. Two lead screws are integrated. 11. User-friendly interface for forward/reverse with zero tolerance. 12. Versatile tailstock that can be offset for turning tapers. 13. Equipped with an emergency stop button, load switch, process control, etc. TECHNICAL SPECIFICATIONS - Max. swing over bed: 290 mm - Max. swing over cross slide: 165 mm - Distance between centers: 750 mm - Spindle taper: MT5 - Spindle bore: 38 mm - Max. travel of tailstock: 80 mm - Tailstock taper: MT3 Ihsdpoxb Eidsfx Addot - Large carriage travel: 560 mm - Middle carriage travel: 140 mm - Small carriage travel: 80 mm - Transverse feed: 0.017~0.25 mm/r, 15 steps - Longitudinal feed: 0.07-1.0 mm/r, 15 steps - Metric thread: 0.2-3.5 mm, 18 steps - Inch thread: 8-56 T.P.I, 21 steps - Spindle speed range/steps: 50~1800 RPM, infinitely variable - Motor power: 1.5 kW Other dimensions and weight: - Overall dimensions: 1400 x 700 x 1030 mm - Package size: 1450 x 750 x 970 mm - Net weight: 290 kg - Gross weight: 310 kg

Condition: used, Year of construction: 1996, Harrison Alpha 550 CNC Straight Bed Lathe Approx Ø550mm Swing Over Bed. Distance Between Centres Approx 2,000mm. Turning Speeds 15-1,800 RPM. Ø90mm Spindle Bore. (1) Ø300mm - 3 Jaw Chuck. (1) T3 Dickson Quick Change Toolpost. Manual Tailstock, 5 Morse Taper. (1) YP-150 Coolant Pump (1998). S/No. A50029. Ijdpfx Asx H S Uysddeht Note: Only Plastic Materials Have Been Cut On This Machine. This Lot Includes (3) Assorted Toolholder Blocks. Dimensions Of Machine Approx 3,100mm x 1,550mm x 1,700mm High. Power Input 415 Volt, 3-Phase, 11kW.

Condition: used, Year of construction: 1998, turning length 3500 mm swing diameter 1000 mm Iodpfxsv Hhv Io Addjht centre height 500 mm turning diameter over slide 600 mm weight of the machine ca. ca. 8,5 t including 2 lynettes and 900mm faceplate

Condition: used, turning diameter over slide rest 800 mm Control Siemens 802D Isdpfx Aev H Etdeddjht swing diameter 2000 mm centre height 1000 mm

Condition: used, Year of construction: 1982, turning diameter over bed 500 mm Isdsqy Rp Ujpfx Addoht turning length 1500 mm centre height 250 mm spindle passage 70 mm swing diameter over face slide 285 mm turning speeds 11,2 - 2240 U/min

Condition: used, Year of construction: 1953, turning length / mm turning diameter over plate // mm faceplate diameter / mm Ihjdpsua Iw Tjfx Addet Plane disc diameter: approx. 3600mm Centre height above plate: approx. 1500mm Turning diameter over plate: 2600mm Turning diameter in the pit: 3600mm Turning diameter over bed: 1300mm Turning length: approx. 2400mm Max. Workpiece weight: 22000kg Max. Torque on the faceplate: 5000 mkg Faceplate gear rim pitch circle diameter: 1900mm Main spindle bore: 120mm Speed range normal: 0.71-35.5 rpm increased: 1-50 rpm increased: 1.4-71 rpm Total power: 38kW Total weight: approx. 42.5 tonnes

Condition: new, Year of construction: 2025, functionality: fully functional, turning diameter: 290 mm, turning length: 750 mm, total length: 1,400 mm, total width: 700 mm, total height: 1,030 mm, rotational speed (max.): 1,800 rpm, spindle mount: MK 3, The following features and characteristics make the G2930 combination lathe unique and competitive in the market: 1. V-shaped guideways provide superior stability and are securely anchored. 2. The gearbox is fixed for maximum stability and offers comprehensive feed and thread cutting functions. 3. State-of-the-art tapered roller bearings support the D1-4 spindle with the highest precision. 4. Automatic vertical feed enables maximum threading capabilities. 5. The cross-slide is equipped with T-slots. 6. Guideways are effectively controlled by adjustable gibs. 7. Advanced gearbox design with maximum functionality. 8. Maximum working area due to the lowered bed section. 9. Carriage-mounted spindle is operated by a lever arm. 10. Two feed screws are integrated. 11. User-friendly forward/reverse interface with zero backlash. 12. Versatile tailstock that can be offset for taper turning. 13. Emergency stop button, load switch, process control, etc., are installed. TECHNICAL DATA Max. turning diameter over bed: 290 mm Max. turning diameter over cross slide: 165 mm Distance between centers: 750 mm Spindle taper: MT5 Spindle bore: 38 mm Max. tailstock travel: 80 mm Tailstock taper: MT3 Longitudinal carriage travel: 560 mm Cross-slide travel: 140 mm Compound slide travel: 80 mm Cross feed: 0.017~0.25 mm/rev, 15 steps Longitudinal feed: 0.07-1.0 mm/rev, 15 steps Metric thread: 0.2-3.5 mm, 18 steps Imperial thread: 8-56 TPI, 21 steps Spindle speed range/steps: 50~1800 RPM, stepless Ihjdpfx Adoxb Up Tjdst Motor power: 1.5 kW Further dimensions and weight: Overall dimensions: 1400 x 700 x 1030 mm Packing size: 1450 x 750 x 970 mm Net weight: 290 kg Gross weight: 310 kg

Condition: used, Year of construction: 1988, turning diameter over bed 2000 mm turning diameter over slide rest / mm turning length / mm - Type 1 K 671 320 F3 - Year of manufacture 1988 (first commissioned in 1998) - Turning length 10,000 mm - Turning diameter over bed 2,000 mm (modified) - Faceplate diameter 1,950 mm - Faceplate clamping range 400 - 1,350 mm Isdpfexn Tz Iex Addoht - Speeds 1.00 - 140 rpm - Torque 125,000 Nm - Main cutting force 130 kN max. - Automatic swiveling tailstock - Max. workpiece weight 70 tonnes - Max. workpiece weight with steady rest 100 tonnes - Drive power 100 kW - Number of bed ways 4 - Dimensions 22,000 x 6,200 x 2,900 mm - CNC control SIEMENS 840D (2010 for €220,000.00) - Support feed X-Z 0.3 - 4,000 mm/min. - Support rapid traverse X-Z 4,000 mm/min. - Inner cone dimensions 140 x 1:7 - The machine complies with CE guidelines - Includes 2 steady rests, 1 roller block, 4 jaws, boring device - Condition: very good condition

Condition: used, Year of construction: 1980, turning diameter 7000 mm faceplate diameter 3500 mm workpiece height 3000 mm 160 mm 1998 Control Siemens 840 C max. table load 60000 kg electr. connected load 400 V Serial number 11 33 0051 total power requirement 71 kW weight of the machine ca. / t required space 13 x 6 m The SCHIESS-FRORIEP 40 DV is a vertical lathe built in 1980. The machine was modernized and improved in 1998. Among other things, a driven tool system (C-axis) was installed. In addition, the control system was modernized to SIEMENS 840 C. Iedpfx Adouddlzedjht The large open-sided vertical boring mills with travelling column - type DV - are particularly suited to situations where likely workpieces frequently change in diameter but where maximum workpiece dimensions are rare. Decisions in favour of this type of machine are generally due to minimum floor space requirement, universal adaptability and economical advantages. The modern design of these machines is characterized by rigid all-steel construction optimized by computer - SCHIESS can claim to have done much valuable pioneering work in this area of heavy-duty machine tool building.

Condition: used, Year of construction: 2000, faceplate diameter 3200 mm swing diameter 3500 mm turning height 2200 mm range L-W-H 7730 x 6240 x 6700 mm control Typ 840 D sl voltage 3 x 400 V frequency 50 Hz turning speeds 0,8 - 40 U/min max. turning diameter 3500 mm total power requirement 51 kW weight of the machine ca. 86 t Technical specifications Machine type: CNC vertical lathe Manufacturer: Rafamet Year of manufacture: 1973 conventional General overhaul with control retrofit 2010 Control upgrade 2016 Control: Siemens 840 D Sl Condition: very good faceplate Turning diameter of the faceplate 3,200 mm Number of rotation stages of the face plate 3 (infinitely variable) Speed ??ranges of the faceplate 0.8 - 40 rpm Level I 0.8 – 3 rpm Level II 0.8 - 11 rpm Level III 0.8 – 40 rpm processing of workpieces Max. turning diameter 3,500 mm Max. turning height of the workpieces above the faceplate 2,200 mm vertical supports Smallest axis distance between the vertical supports 470 mm Largest ram travel of the left vertical support 985 mm Largest ram travel of the right vertical support 985 mm Axis Feeds - Infinitely variable feed Max.: X1.2 3m/min max.: z1.2 2.5 m/min Plunger cannot be pivoted Support — crossbar Rapid feed of the cross beam 600 mm/min Larger distance of the cross beam to the faceplate 2,300 mm load sizes +Permissible turning force when turning workpieces with a turning diameter of 2,000 mm and a turning speed of 20 m/min. 8,000kg +Largest chip cross-section for workpieces made of steel Fz = 50 kg/mm² at a turning speed of 20 m/min for all supports 45 mm² +Largest chip cross-section for workpieces made of steel Fz = 50 kg/mm² at a rotation speed of 20 m/min for a vertical support with max. plunger length 985 mm 2.5 mm² +Largest chip cross-section for cast iron workpieces HB = 160 kg/mm² at a turning speed of 20 m/min for all supports 120 mm² +Largest chip cross-section for cast iron workpieces HB = 160 kg/mm² at a rotation speed of 20 m/min for a vertical support with max. plunger length 985 mm 22.5 mm² +Largest permitted workpiece weight at 0.8 - 3.15 rpm 17,500 kg +Largest permitted workpiece weight at 4 - 40 rpm 7,500 kg electric motors Main drive motor power and revolutions 51 kW Power of the feed motors of: - Vertical support beam (2 pieces) 16 Nm (gear 1:10) - Tappet (2 pieces) 16 Nm (gear 1:12) Power and revolutions of the drive motor of the hydraulic pumps (2 pieces) 3kW - 1,500 rpm Power and revolutions of the clamp hydraulic motor of the vertical support beam 1.5 kW - 1,500 rpm Power and rotation for crossbar adjustment 15 kW - 1500 rpm 3.5 Information on the compressed air supply and other consumables Compressed air connection: 6 bar free of oil and water 3.6 Energy Consumption Conditions Voltage: 3 x 400V Control Voltage: 24V Frequency: 50Hz Fusing: 315 A Main dimensions and weight of the machine Length 7,730mm Width 6,240mm Height: 6,700mm Weight: 85,750 kg Tool: Capto 60 recording Not powered front panel Iedpfouddcgox Addsht Turning diameter of the front plate 3,200 mm Clamping disc diameter 3,400 mm Number of rotation levels of the front panel 3 (continuously adjustable) Front panel speed ranges 0.8 - 40 rpm Level I 0.8 - 3 rpm Level II 0.8 - 11 rpm Level III 0.8 - 40 rpm processing of workpieces Max. turning diameter 3,500 mm Max. turning height of the workpieces above ...

Condition: used, Year of construction: 1962, faceplate diameter 2250 mm swing diameter 4500 mm turning height 2000 mm turning diameter 3150 mm workpiece weight max. 25000 kg total power requirement 55 kW Ijdpfx Adouc Aldodjht weight of the machine ca. ca. 32 t required space / m

Condition: used, turning diameter over bed / mm turning diameter over slide rest / mm turning length / mm Ihjdowgi Tmopfx Addjt

Condition: used, Year of construction: 1989, control / centre distance // mm greates pass round over bed / mm Control: TRAUB System TX-8 Isdpjud Inmjfx Addsht Spindle clearance (max. bars ®) mm 42 Chuck © mm 200 Turning diameter mm 180 Turning length mm 450 max. circulation ® mm 450 Rotation ® via sorting device mm 350 Rotation ® crosswise tailstock mm 180 Rotation ® over steady rest body mm 240 Longitudinal slide travel mm 490 Slide path flat mm 160 Spindle head DEN 55.026 = 26 - Spindle ® in front bearing mm 85 Power: 41 kW

Condition: used, turning diameter over bed / mm turning diameter over slide rest / mm turning length / mm total power requirement / kW weight of the machine ca. / t required space / m Conventional lathe with copying attachment and extensive accessories Turning diameter over cross slide: 240 mm Spindle bore: 52 mm Turning diameter: 360 mm Center height: 180 mm Turning length: Isdpfev Rgzwsx Addjht 1,000 mm Overall length: 2,200 mm Overall width: 750 mm Overall height: 1,400 mm Maximum spindle speed: 1,750 rpm Min. spindle speed: 60 rpm Total weight: 1,800 kg All technical specifications are subject to change without notice. Deviations may occur depending on the year of manufacture, model, or condition of the machine. We assume no liability for the accuracy or completeness of this information.

Condition: used, Year of construction: 2011, turning length 1500 mm control SINUMERIK 828D centre height 270 mm greates pass round over bed 540 mm swing diameter over slide rest 310 mm bed width 350 mm Ihodpfx Aoxyaf Rsddet max. workpiece weight 1500 kg spindle bore 85 mm turning speeds 27 - 2250 U/min main drive DC 11 kW MACHINE EQUIPMENT: - AME chip conveyor - Lynette - Heavy grey cast iron bed for optimum damping and reduced tool wear - Inductively hardened and parallel synchronised bed guides - Counter guides completely Turcite-coated and hand-scraped - Hardened and ground ball screws - Thermosymmetrical headstock - Main drive 11 kW - Infinitely variable speed range 27-2250 rpm with 3-stage gearbox

Year of construction: 1961, condition: used, centre height 235 mm turning diameter 470 mm turning speeds 2700 U/min turning length 1500 mm Ihsdpsl Ab Htofx Addot inkl. Zubehör (siehe Bilder)

Year of construction: 1980, condition: used, turning diameter over bed 655 mm turning diameter over slide rest 390 mm turning length 1250 mm spindle bore 82 mm spindle turning speed range 9-1120 U/min feeds 0,049-3 mm/U Ihsdpfjlc Uk Ijx Addst total power requirement 12 kW weight of the machine ca. 5,2 t required space 3,5 x 1,9 x 1,7 m m

Year of construction: 2001, condition: used, turning diameter 420 mm turning length 1200 mm control Fanuc bore diameter 60 mm Ihodpfx Adjh N D Unodot
