Condition: excellent (used), Year of construction: 2013, with PC control E555 Maximum cutting length: 6000m Weight: approx. 2200kg Total power: 13.6kW Left head is fixed, right head is mobile. Both saw heads are universally pivoting and tilting. Lrelhcov Syduscqlsi Minimum cutting length at 90°: 375mm Minimum cutting length at 45° tilt: 375mm Inward tilt angle up to 22.5° via control, accurate to 0.1° Inward tilt angle: pneumatically controlled 90/-45° Intermediate angle: manual with turret stop and digital display Saw blade diameter: 550mm Saw blade speed: 2800 rpm.

Condition: excellent (used), Year of construction: 2014, Semi-automatic band saw with miter adjustment on both sides • Fast miter adjustment from 90° to 30°, continuously adjustable to 0.5° accuracy according to the scale. The miter pivot point is the intersection point between the saw blade and the material feed system, thus ensuring no change in the length. • End stops at 30° + 45° left • Quick material clamping: The material is clamped parallel at 90° at any angle of the saw frame. • Machine stand with chip collection tray • Saw blade drive with limit switch and automatic frame lifting to the top of the material. • Precise carbide-tipped saw blade roller guide. • Miter range continuously adjustable from 30° to 150°. • Coolant system supplied as standard (including electric preparation for minimum quantity spray system). Additional equipment DG-HS: Hydraulic raising/lowering of the saw frame. Semi-automatic sawing process. Lslhcev Rbtnjcqlori Hydraulic material clamping/short-stroke cylinder. Rapid traverse lowering to the top of the material. Cutting range: 30° left Ø 130 or 120x120 45° left Ø 200 or 180x180 90° Ø 260 or 300x260 45° right Ø 200 or 180x180 30° right Ø 130 or 120x120 Remnant length 25mm Smallest diameter 5mm Motor 1.0 / 1.5 kW Saw blade 3350x27x0.9mm Cutting speed 28/56 m/min

Condition: good (used), Year of construction: 2016, Robust electro-hydraulic CNC swing cut shears including CYBELEC CNC touch screen control including motorized cutting gap adjustment Equipment: - some functions of the CNC control: - back stop pre-selection - X axis - motorized cutting gap adjustment - number of pieces - cutting length limitation - material pre-selection, including sheet thickness - cutting line lighting (cutting on scribe mark) - motorized back stop, travel = 5.0 - 1,000 mm (X axis) on ball screws - including selectable retraction function ("swing-away function") - 1x side stop, with T-slot and mm scale - 2x front support arms, with T-slot and mm scale - ball rollers in the front support table - hinged finger guard, with safety switch - cutting line lighting with silhouette - BOSCH/HOERBIGER hydraulic system - SIEMENS electrical system - Light curtain behind the machine (safety device) - Freely movable foot switch - CE mark/declaration of conformity Technical specifications Sheet width: 3100 mm Sheet thickness: 6.0 mm Sheet thickness for stainless steel: 4.0 mm Lrjlsv Ikp Tohccqlji Holders: 14 pieces Stroke rate: 20 strokes/min Cutting angle: 1.2 ° Weight: 5500 kg Dimensions L-W-H: 4000 x 2410 x 1610 mm

Condition: good (used), Year of construction: 2013, Profile machining center Axis travel X-axis: 7430 mm Y-axis: 1320 mm Z-axis: 500 mm A-axis: +/-90° Working areas X-axis: 7460 mm Y-axis: 650 mm Z-axis: 250 mm 8 clamping elements Automatic tool magazine with 8 places in a protected housing, for drilling, milling and thread cutting tools, Lrelhccjvy E Ibjqlei angle head and disc milling cutter, max. Ø 200 mm, + 2 places for 2 angle heads Tool holder ISO 30 In pendulum operation (2 zone machining) the working stroke per zone is limited to 3500 mm

Condition: used, Year of construction: 2005, computer-controlled 3-axis double mitre saw, cutting length 5000mm, saw blade diameter 500mm Lrslhccqjvxac Djlsi with minimum quantity lubrication

Condition: new, Year of construction: 2025, Speeds: Level 1: 37-185 rpm Level 2 150-750 rpm Torque in Nm 165+42 Holder size 2 diameter 31 Lrslhccevu Uhtjqlji Capacity M3-M24 Working range R = 1800mm Working height (without wheels) 805mm Includes: Ball-bearing, wear-free parallel arm radius: 1800mm 400V/3ph hydraulic system Clamping table 800x600mm with 3 T-slots 19mm Working and return speeds can be set separately electronically (using a frequency converter) Digital depth setting D-Touch, work cycle of your choice Manual: direction of rotation right/left using push buttons Automatic: digital input of depth, the direction of rotation is reversed at the set depth. Digital speed display (in the D-Touch control) Micro spray system for tool lubrication (integrated in the machine head) Quick-change holder for Bilz thread cutting holder with slip clutch, among others incl. 1 set of running wheels 1 set of thread cutting holder M4-M22/24 1 piece reducing ring for M4

Condition: good (used), Year of construction: 1998, with micro spray device Roller conveyor supply 3m, removal approx. 6m with measuring device Chip drawer Dimensions of the saw blades: 2950 x 27 x 0.9 mm Maximum cutting capacity: 280 mm Maximum jaw opening: 280 mm Height of the jaws: 130 mm 2 cutting speeds Pivoting cut from 0 to 60° Lrslevrdu Rshccqlei Automatic lowering Manual jaw clamping Lubricant pump Voltage: 380 V Width: 900 mm Depth: 1900 mm Total height in raised position: 1900 mm Weight: approx. 650 kg

Condition: good (used), Year of construction: 1996, Hecht electronic length stop with positioning control Positiomat 535 Stop roller conveyor 7000mm long, 300mm wide Aluminum stop adjustable via servo motor Lrjlhccqovnq Rqoloi Simple positioning with chain dimensions Additional feed roller conveyor with 5000mm long, 300mm wide, including adjustable side guide rollers. Both roller conveyors are electronically height-adjustable

Year of construction: 2002, Condition: good (used), 4-axis machining center With the Comet, aluminum profiles, PVC materials and steel profiles up to 3 mm can be processed at any angle from 0-180°. Travels: X - axis: 6300 mm Y - axis: 525 mm Z - axis: 335 mm A - axis: 0° - 180° (infinitely variable) max. profile length with reclamping: 12000mm max. profile cross-section: 250x200mm with a tool length of tool length of 80mm Positioning: X - axis: 80 m/min Y - axis: 60 m/min Lrolhcsu Rry Nscqloi Z - axis: 30 m/min A - axis: 10,800 °/min High-frequency milling motor 7 kW (at 21000 rpm) up to max. 24000 rpm, water-cooled Automatic tool changer with 8 + 1 places, HSK 40E collets, max. tool diameter 50mm, max. tool length 160mm With 8 clamps

Condition: new, Year of construction: 2024, Functionality: fully functional, Folding length 3020 mm Press force 320 t Infeed speed 140 mm/s Bending speed max. 10 mm/s Retraction speed 130 mm/s Y-axis stroke 400 mm Installation height 650 mm throat depth 450 mm free column passage 2555 mm Machine length 3785 mm Machine width 2290 mm Width without support arms 1740 mm total height 3100 mm Height of machine table 920 mm Motor power 22 kW Oil tank 300 l Machine weight 14450 kg (Data may vary depending on equipment) Standard equipment: Lolhjuf Nr Asccqlori 3 CNC axes (Y1, Y2, X) Double-guided press beam, stable and precise Stable back gauge, double-guided Stop fingers double-guided on linear guide Sliding front arms with height adjustment Side and rear protective covers Lower die adapter rail 60 mm Man. Top tool clamping system (Promecam system) Foot switch with emergency stop switch 380 V, 50-60 Hz, 3 phases LED lighting Additional equipment: CNC control Delem DA 66t R-axis backgauge CNC controlled CNC controlled crowning Fiessler Akas 2M laser safety device 2 additional stop fingers (4 in total) 1 set of upper and lower tools - Further machining lengths and thicknesses are available with corresponding accessories! -

Condition: new, Year of construction: 2024, Semi-automatic sawing sequence with workpiece clamping-sawing-raising to set height after cutting is complete Ljlet D Azcjhccqljri Stepless hydraulic cutting pressure and feed monitoring on the saw blade back. This ensures optimum conditions for every sawing task, i.e. constant pressure for solid material and constant feed for thin-walled profiles. Particularly suitable for universal use with different cross-sections, materials and frequently changing mitre cuts The machine control system complies with CE standard 89/289 Technical data: Cutting range in mm round/flat 90° 325/500 x 300 45° 300/300 x 300 30° 200/200 x 200 45° 300/300 x 300 Rapid traverse lowering of the saw frame via pushbutton to material edge Manual miter adjustment from 45°-90° - 30°, infinitely variable according to scale The miter pivot point is the intersection point between the saw blade and fixed clamping jaw, therefore no change in the length dimension when changing the angle position Hydraulic full-stroke workpiece clamping - CETOP hydraulic system The material is clamped in parallel at 90° for every angular position of the saw frame Complete coolant system with electric immersion pump Central machine operation Saw blade drive with limit switch Movable band guide arm, adjustment to material width Saw band deflection roller carbide guide Rotating chip cleaning brush Saw blade tensioning with torque wrench Paintwork silver-grey/ blue-grey (RAL 7001/ RAL 7031) Remaining piece length: 60mm Cutting speed: AC frequency-controlled drive 15-150 m/min infinitely variable on the control panel Drive unit Saw band 3,0kW ; 400V, 50Hz Hydraulics 1.1kW Coolant pump 0.1kW Saw frame feed: Infinitely variable up to 300mm/min, hydraulically controlled Saw blade tension: Mechanical with torque wrench Saw blade dimensions: 4200x34x1.1mm Working height: 750mm (without set-up elements) Weight: 850kg Dimensions (LxWxH): 1450x2350x1350mm

Condition: new, Machine for grinding, deburring, rounding and polishing, manual, mobile use with vacuum system, alternatively also with magnetic system, starter kit and 1 brush CE-certified, designed with double emergency stop circuit and reset system Weight 445 kg Dimensions 1435x1100x1510mm high Working height 950 mm Work surface 1280x780 mm Minimum workpiece dimensions 20x20mm Maximum workpiece height 120 mm Maximum width of workpiece: unlimited length, with maximum width 780 mm Lrjlhccqst Dpxbjlji Maximum workbench load 100 kg Operation: Double manual operation Number of work stations 1 Quick holder for brush M14x2 left-hand thread M14x2 right-hand thread for abrasives Brush design Disk brush Ø150mm with quick-change system Various brush variants possible, depending on material, we will be happy to advise you. Bia2Qk2S2I Brush power 0.75kW frequency-controlled motors Brush motor speed 150 - 1500 r.p.m. Workbench Carpet / Special friction design Vacuum system fixation in the workbench (standard) Vacuum system kW 2.2 kW Also available with additional magnets as an option (available from stock) Electrical values Voltage V 400 V (3L+N+PE) Frequency Hz 50 Hz Current A 10 A Power kW 6 kW Plug-in device CEE 400 V / 16 A (5-pole)

Condition: new, Year of construction: 2024, 2-column guided band saw in semi-automatic design with stepless mitre adjustment on both sides 30° - 45° - 90° - 135° With patented mitre system (ERP no. 0491120) Particularly suitable for universal use with different cross-sections cross-sections, materials and frequently changing miter cuts. Center of rotation remains unchanged at every angle setting, thus exact length measurement at 90° and in the miter area. MEBA Eco-Saw-Innovation 2000 The universally applicable MEBA 335 DG mitre band sawing machine is ergonomically perfected and has an optimum price-performance ratio. Simple central operation. The machine control system complies with CE standard 89/289 Technical data: Cutting range: round/flat 90° 335/500x335 45° right 330/305x335 30° right 180/170x335 45° left 305/305x335 Cutting speed: AC frequency-controlled drive 15-150 m/min infinitely variable on the control panel Drive unit - Saw band 3 kW ; 400 V, 50 Hz - Hydraulics 0.55kW - Coolant pump 0.11kW Saw frame feed: infinitely variable up to 300 mm/min, hydraulically controlled Saw blade tension: Mechanical with torque wrench Saw blade dimensions: 4400 x 34 x 1.1 mm Working height: 750 mm (without set-up elements) Weight: 1320 kg Bfpzm8E9K3 Dimensions (LxWxH): 1450 x 2350 x 1900 mm Subject to technical changes. Basic equipment of the MEBA 335 DG-500 Semi-automatic sawing sequence with workpiece clamping-sawing-up to set height after cutting is complete MEBA high-performance package: Infinitely variable hydraulic cutting pressure and feed monitoring on the saw blade back. This ensures optimum conditions for every sawing task, i.e. constant pressure for solid material and constant feed for thin-walled profiles. Manual mitre adjustment, digital reading with 0.1° accuracy Rapid traverse lowering of the saw frame via pushbutton up to the material edge Patented double mitre system (ERP no. 0491120) Unique double mitre bandsaw with which mitres on both sides can be set simply and economically by swivelling the saw frame and the material support. Automatic movement of the clamping vices and digital miter adjustment The material clamping vise moves automatically in the direction of flow according to the desired miter, so the material is always clamped at right angles, close to the saw band. The mitre pivot point is the intersection point between the saw blade and the fixed clamping jaw, which means that the length dimension does not change when the angle position changes. Hydraulic full-stroke workpiece clamping. Quick material clamping. The material is clamped in parallel at 90° for every angular position of the saw frame. Ljljt Dpw Rjhccqlsri Stable two-column linear saw frame Saw blade set at a 3° angle to the material support surface. Central machine operation Saw frame clearance height adjustment Movable band guide arm, adjustment to material width Saw blade deflection roller carbide guide Rotating chip cleaning brush Saw blade tension with torque wrench Operating instructions and spare parts list CETOP hydraulic system Coolant system (approx. 100 ltr.).

Year of construction: 2006, Condition: good (used), 3-axis / 5-sided machining with ISOLA soundproof cabin for aluminum, PVC and steel profile bars The machine has two processing zones and 2 tool magazines, which can be used individually in pendulum mode or both together for loading over the entire processing length (multi-part operation). The clamps can be positioned on the left and right independently of the processing head. Travel paths: Lrjlhcetp Ucmscqlsi X - axis: 7000mm Y - axis: 300mm (+ 113mm of the movable work table) Z - axis: 350mm P - axis: 3500mm (for left-hand clamp positioning) H - axis: 3500mm (for right-hand clamp positioning) 8 clamping elements (4 clamps per machining zone) 12 tool holders (6 holders per changer magazine/machining zone) incl. Camplus software 2 angle heads

Year of construction: 2010, Condition: excellent (used), Functionality: fully functional, The QUADRA L1 consists of an automatic loading magazine and a gripper feed for profile lengths of up to 7500 mm. The feed transports the profile bar to the processing unit, which is equipped with 6 spindle motors and can carry out drilling and milling operations around the profile. The sawing module has 3 axes and is equipped with a saw blade with a diameter of 600 mm. The finished part is transferred from the machining area to the unloading table by means of an unloading unit, where it is transported to the unloading position by means of driven belts. The processing area is completely enclosed and can optionally be fitted with sound-absorbing mats. Automatic loading magazine with a maximum capacity of 15 profiles with a width of 100 mm. The profiles are transported to the gripper position by a belt conveyor. Automatic 3-axis CNC feed unit. Based on profile data, the unit positions itself in the pick-up position depending on the length and profile cross-section in order to feed the bar for processing. Lelhcjrpk Syecqlori The gripper clamps the profile bar at a predefined position based on the drawing. A 600 mm saw blade enables a large cutting range to be covered thanks to the 3-axis movement option.

Condition: new, metric thread diameter (min.): 3 mm, metric thread diameter (max.): 24 mm, Model RE16 to M16, model RE24 to M24 - ball bearing mounted wear-free parallel arm with radii of 1270 or 1800mm - Connection 230V / 1Ph - Infinitely variable speed adjustment - Digital speed display - digital depth control with memory for 5 programs - quick-change holder according to DIN standard Lrslhcsrb Akmjcqlei Options: Micro spray system for model 1800 Cast iron table Wheels for cast iron table Multifunctional head for cutting at any angle

Condition: new, Year of construction: 2024, travel distance Y-axis: 600 mm, travel distance Z-axis: 450 mm, - Simple graphic programming, including GoTo function in manual mode - Machining lengths from 3000 - 16500mm, depending on version - Free programming in DIN/ISO (G commands) - 2-axis interpolation for X/Y-axis, including arcs - 3-axis linear interpolation (X/Y/Z) - 3-axis interpolation (X/Y/Z) for helical milling and thread milling - Rapid traverse X-axis = 30 m/min., Y-axis = 25 m/min. Main spindle BT 40 - 5 bearings, diameter 110/60 mm (3x angular contact ball bearings 7212, 2x deep groove ball bearings 6212) - Suitable for both high axial and radial loads = drilling and milling - Maximum tool length : 290 mm - Maximum tool diameter : 88 mm Lrslhccqorb Afaoloi Guide X-axis - 2 pieces 45 mm linear guides with 2 full ball bearing carriages each X-axis drive - helical precision rack, travel 3,000 to 16,500 mm Y-axis guide - 2 35 mm linear guides, each with 2 fully spherical carriages Y-axis drive - Ball screw diameter 25 mm, travel 600 mm Z-axis guide - 2 35 mm linear guides, each with 2 fully spherical carriages Z-axis drive - Ball screw diameter 32 mm, travel 450 mm Standard version Automatic tool changer with 10 positions, mounted in the machine column

Condition: new, Year of construction: 2024, metric thread diameter (min.): 3 mm, metric thread diameter (max.): 16 mm, overall weight: 500 kg, feed length X-axis: 3,000 mm, feed length Y-axis: 1,500 mm, feed length Z-axis: 200 mm, torque: 24 Nm, spindle speed (max.): 3,000 rpm, spindle speed (min.): 50 rpm, power: 0.005 kW (0.01 HP), The CMA 3-axis controlled tapping center is designed for the post-processing of laser-cut sheet metal parts and complete processing of small parts and tubes, for example. The machine offers the following processing options: - Thread cutting - Drilling (standard / with chip breaking / hollow profile cycle) Loljrbz T Nshccqljri - countersinking - Flow drilling (with optimum feed curve) - reaming - Simple graphical programming - Import of 2D DXF or DWG files - Machine table according to System 28 (similar to Demmeler and Siegmund welding tables, among others) - Radial compensation of the tool by means of patented tool holder (accessory) - Tool probe for length measurement and as a breakage detector - Intuitive safety system using light barriers Standard version: Automatic tool changer with 10 positions, mounted on the machine portal

Condition: new, Year of construction: 2024, Folding length 3020 mm Pressing force 135 t Infeed speed 140 mm/s Bending speed max. 10 mm/s Lslhccjq Rdtqoqleri Retraction speed 130 mm/s Stroke 320 mm Installation height 550 mm Projection 450 mm X-travel 750mm X- speed 300mm/sec. R- travel 250 R- speed 100mm/sec. free column passage 2555 mm Machine length 3730 mm Machine width 2300 mm total height 2850 mm Machine table height 900 mm Motor power 15 kW Oil tank 190 l Machine weight 9500 kg (technical data may vary depending on equipment) Standard equipment: 3 CNC axes (Y1, Y2, X) Double-guided press beam, stable and precise Stable back gauge, double-guided Manual stop fingers double-guided on linear guide Sliding front arms with height adjustment Side and rear protective covers Lower die adapter rail 60 mm Man. Top tool clamping system (Promecam system) Manual crowning Foot switch with emergency stop switch 380 V, 50-60 Hz, 3 phases LED lighting Recommended options: Dener control unit DA 66T Fiessler AKAS 2M laser finger guard + FPSC Safety PLC (manual) X-R axis with servo motors CNC crowning for high bending accuracy 2 additional stop fingers - Further processing lengths and thicknesses are available with corresponding accessories! -

Condition: new, Year of construction: 2024, Functionality: fully functional, Folding length 3020 mm Press force 220 t Infeed speed 140 mm/s Lrjlhceq D Dzlecqlei Bending speed max. 10 mm/s Retraction speed 130 mm/s Stroke 350 mm Installation height 600 mm Projection 450 mm X-travel 750mm X- speed 300mm/sec. R- travel 250 R- speed 100mm/sec. free column passage 2555 mm Machine length 3730 mm Machine width 2290 mm total height 3055 mm Height of machine table 820 mm Motor power 22 kW Oil tank 300 l Machine weight 11500 kg (technical data may vary depending on equipment) Standard equipment: 3 CNC axes (Y1, Y2, X) Double-guided press beam, stable and precise Stable back gauge, double-guided Manual stop fingers double-guided on linear guide Sliding front arms with height adjustment Side and rear protective covers Lower die adapter rail 60 mm Man. Top tool clamping system (Promecam system) Manual crowning Foot switch with emergency stop switch 380 V, 50-60 Hz, 3 phases LED lighting incl. the options: Delem control unit DA 66T Fiessler AKAS 2M laser finger guard + FPSC Safety PLC (manual) X-R axis with servo motors CNC crowning for high bending accuracy 2 additional stop fingers - Further machining lengths and thicknesses are available with corresponding accessories! -

Condition: new, Year of construction: 2023, Functionality: fully functional, Energy-saving, precise and fast press brake Driven by Sevo motors and ball screw Bending length 1300 mm Pressing force 40 t Stroke 150 mm Installation height 375 mm X-path 440 mm X- speed 1000mm/sec. R- stroke 150mm R- speed 100mm/sec. Y- infeed speed 150 mm/s Leleq D Dv Dohccqleri Bending speed max.20 mm/s Retraction speed 150 mm/s Motor power 2x3.8 kW Machine length 1880 mm Machine width 2435 mm Total height 2320 mm Machine weight 3400 kg Standard equipment: European clamping system (Promecam) top 60mm die holder at the bottom Stable X + R axis back gauge CNC controlled 2 pcs. Back gauge fingers manually adjustable on linear guide Foot pedal with emergency stop button incl. the options: DA66T control unit Fiessler AKAS 2M laser finger guard + FPSC Safety PLC (manual) 1 set of upper tools for the entire bending length: Angle (°): 85° H: 104,65 R: 0,8 Max T/m: 100 Material: C45 1 set of lower tools for the entire bending length: Type: Die Multi-V (4-fold) Angle (°): 85° H: 60 V: 16 - 22 - 35 - 50 Max T/m: 80 Material: C45

Year of construction: 2007, operating hours: 4,470 h, Condition: excellent (used), Functionality: fully functional, Very well-maintained machining center with only 4,470 operating hours! 3-axis / 5-sided machining with ISOLA soundproof cabin for aluminum, PVC and steel profile bars The machine has two machining zones and 2 tool magazines, which can be used individually in pendulum mode or both together for loading over the entire machining length (multi-part operation). The clamps can be positioned on the left and right independently of the processing head. Travel paths: X - axis: 7000mm Y - axis: 300mm (+ 113mm of the movable work table) Z - axis: 350mm P - axis: 3500mm (for left-hand clamp positioning) H - axis: 3500mm (for right-hand clamp positioning) 8 clamping elements (4 clamps per machining zone) 12 tool holders (6 holders per changer magazine/machining zone) ISO30 ER20 holder Lrelhccqeqv Dv Seloi

Condition: new, Year of construction: 2025, Deburring and fine grinding machine with 3 working stations: Sanding belt - Brushing station - Sanding belt Effective maximum working width: 1150mm Standard workpiece thickness: 0,8 - 150mm digital workpiece thickness display on control panel, accuracy 0,1mm adjustable pressure rollers before and after the work stations Sanding belt insertion on the left Sanding belt centering by electronically controlled photocell, emergency stop in case of skew or belt breakage Infinitely variable feed speed of the carpet incl. options: Preparation of the machine base for forklift loading suction collector in galvanized sheet for machine with 3 working units plus 1 external unit Vacuum device to increase the adhesion of small or slippery workpieces on the feed carpet. With perforated feed table and carpet as well as powerful electric fan and soundproofed outlet according to CE standard, 5,5kW 2x Grit-Set for electronic fine positioning of the contact rollers Adjustment and display (0.01mm) on the control panel, stand-by position with pneumatic reset of the contact roller in case of emergency stop Frequency controlled drive motors for grinding belt cutting speed, motor power per unit 11kW Electronic adjustment of brush unit HMI Vision - PLC control with visualization of the various machine machine settings via color touch screen Storage possibility of up to 250 grinding programs Lelhcspwh Tfjcqlori

Condition: new, Year of construction: 2025, Speed 17/34 rpm. for saw blades up to 350 mm diameter. With pole-changing three-phase motor, 1.4/1.9 kW, stationary base frame with built-in coolant device and chip drawer Cutting range: Flat 90° 170 x 100 mm Flat 45° 120 x 100 mm Flat 30° 85 x 100 mm (right only) Square 90° 100 mm Square 45° 95 mm Square 30° 85 mm (right only) Round 90° 120 mm Round 45° 120 mm Round 30° 100 mm (right only) Technical data: Length 895 mm Width 665 mm Height 1750 mm Weight 300 kg Support height 900 mm additionally available as an option available: Micro spray device Roller conveyors and length measuring devices Lrolhccsllvpwoqlei For this purpose we recommend our coolant concentrate, which has been tried and tested for decades for "Eisele" saws, our micro spray oil and high-quality circular saw blades for your special needs. Ask us without obligation!

Condition: new, Year of construction: 2024, Cutting range 90 round 260mm Lelhccoh Tnd Asqljri flat 300x260mm smallest diameter 5mm NC-controlled, automatic material insertion with hydraulic material full stroke clamping Easy operation by NC-control with plain text display Material advance function without reclamping of the material for short sections Stable, linear guided feed gripper with servo positioning for highest accuracy Automatic adjustment of the belt guide to the material width incl. the accessories driven chip brush, synchronous to the belt speed separately installed control panel 7" CE panel, networkable, 1000 data sets storable, history memory for various functions and data, etc.
