Used Roll forming lines for sale (64)

Condition: new, Year of construction: 2025, Roll forming metal siding “double façade panel” machine SPM-2 Roll forming metal siding “double façade panel” machine SPM-2 is new design product of our company for façade and wall metal panels forming with the necessary configuration. These double façade panels are very popular in construction business of cladding residential buildings and industrial structures, for the construction of fences of various configurations, gazebos, roofing elements, etc. The SPM-2 metal siding production line is fully automatic and consists of a rolling part of the machine, an automation system and guillotine cutting shears at the machine exit. The line can have as additional parts a manual or automatic uncoiler for metal rolls, depending on the customer's needs. As standard version, this metal siding double façade panels roll forming machine SPM-2 makes a flat panel profile, but with the additional equipment, it is possible to roll panels with a microwave or rib shape profile. To start rolling, it is necessary to install a roll of metal to the decoiler and to put the end of the strip to the first rolling rollers of the equipment and feed it into them. After step by step, to put the metal to the next rollers, adjusting it if necessary. Lodoxghngopfx Ah Esru When metal comes to the cutting device of machine you need to feed metal into cutting knives and to make “zero” cut. After such step, equipment can move to automatic operation mode. The control panel of machine has the ability to set the number of tasks and the length of products, single tasks or to work in multitasking mode. After setting up necessary parameters the machine will automatically roll the metal cladding wall panels and cut them into necessary sizes. Thus, the customer will receive final product as quickly as possible and with the highest possible result. The roll forming speed is adjustable and can be up to 10-15 meters per minute. The SPM-2 metal wall cladding panels production line has special tools for punching out fastening holes on the side of the panel. It makes possible for the customer to get more interesting solution options and to offer a wider range of products to the end user. The rolling part of the machine has 18 pairs of forming steps, ensuring high quality of final product. You can get machine with protective cover or without it as per your request preferences. Specifications Material width (mm) 416 The material thickness (mm) 0,4-0,5 Engine power (kW) 3 + 1,1 Rolling speed (m/min) 10-15

Condition: ready for operation (used), Year of construction: 2017, functionality: fully functional, machine/vehicle number: LU0183, Roll forming line for solar profiles, both for trackers and fixed structures. High processing speed, with mechanical press and 10 CNC-controlled punching tools. Working speed up to 30 m/min. Working thickness from 0.8 to 3.0 mm and maximum strip width 450 mm. Ledpjwxfbwjfx Ah Eeru

Condition: good (used), Year of construction: 2009, Line for the production of "B" type energy-absorbing barriers, SIGMA posts and semi-closed channels For 460 x 4.2 mm strip. Weight of the whole set about 25,000 kg. The line includes the following sections: Strip uncoiler with hydraulic jack for new coils. 1 roller unit + guillotine. Lrodpfx Aet Ak Dpoh Eju Manipulator. Welding area. Rolling section: -rollers for profiling SIGMA post, -rollers for the "B" guide and the semi-closed channel. Bean punching machine. Punching machine for top holes. Punching machine for bottom holes. Controller with display. Instruments for SIGMA post. Instruments for semi-closed channel. Instruments for marking.

Condition: excellent (used), Roll forming machine for the production of facade trays, with cnc programmer and hydraulic cutting. Lrodpfxjwmf Nke Ah Esu

Year of construction: 2000, condition: excellent (used), AUSTRIAN & GERMAN BRAND TUBE LINE. For Steel and Galvanised tubes. Year - 2000. Thickness : 0.9 to 5 mm Lrsdpfofb U Hqex Ah Eeu Pipe range - 38 - 127 mm Speed - 100 m/min. Welding Section - 300 kw Round pipe size: 30, 35, 38, 40, 50, 60, 70, 80, 100, 120 Squaer size: 60x40, 80x40, 70x30, 100x40, 100x50, 100x60, 120x 40, 120x60

Condition: excellent (used), functionality: fully functional, sheet thickness steel (max.): 3 mm, sheet thickness (max.): 3 mm, outer diameter: 80 mm, HEAVY-DUTY HIGH-PERFORMANCE TUBE MILL OTO 80.3 QTC With complete Quick Tool Change System Made by OTO MILLS PRODUCTION RANGE • Diameter range 19mm – 80mm • Thickness 0.8mm to 3.2mm • Speed Max. 150 m/min • Working direction Left - Right Scope of supply: 1. Entry Line made OTO MILLS with: • Double Uncoiler OTOAD256 -PA • Double strip peeler for opening from top/bottom • Automatic strip joiner OTO GG254 • Floop vertical accumulator 2. OTO 80.3 QTC tube mill made OTO MILLS with: • Casted Iron stand • Bottom shaft height adjustable • Reinforced motor and gearboxes 2-speed transmission • Hydraulic nuts • Double length cooling tunnel • Motorised turk-head for fast adjustment 3. Quick change rafted system OTO QTC - 2nd set of cassettes off-line including : • 1 complete cassette for forming • 1 complete cassette for fin-pass • 1 complete cassette for sizing • Quick – plug automatic cardan connections 4. 150 m/min Flying saw – High Speed cold saw OTO TCCG160 with : • Carriage motion with 70kW motor • Cutting head motion with hydraulic control • AC Rotation of the blade 5. Automatic packer MAIR SQ.HEX.90.D.5.SL with emulsion draining and bundle weighting system • Possibility to make hexagonal and square/rectangular bundles Ledpfjvr Tntjx Ah Ejru • 5 modules for production of tubes 4-10m (12m for thickness >1.8mm) • Including emulsion draining, and weighting unit • 3 chains for finished bundle storage • Test tube zone, with cutting saw for the test tube 6. Automatic strapping unit SIGNODE M400 7. Zinc spraying METALISATION 250 • 1 metallisation cabin • 1 zinc spraying unit METALLISATION ENERGIZER 250 • 1 Zinc spraying gun ARCSRPAY 528E 8. Fume exhaust system • Fume exhaust conducts and exhaust covers on the required points a • Filter for fumes 9. Complete set of rolls (*See details) NEW PARTS SUPPLIED IN 2023/2024: 10. Thermatool CFI 350-VF Solid state welder with : • Automatch • Selectable frequency 250-400kHz • Thermaview control panel 11. Cooler PARKER, Model hyprechill Maxi 12. Inner scarfing hydraulical Blissenbach, with all the toolding for ID 30-50m 13. OPTRONIC CNC control unit for driving flying saw (Switzerland) 14. New Emulsion plant with : • Pump and heat exchanger • Fillters • Electrical controls and monitoring 15. New motor and electritical cabinet for accumulator 16. New motor and control for sizing section

Condition: new, Year of construction: 2023, Cut-to-length line 1250mm x2mm x10 t for cross cutting of coil metal with maximum width 1250mm, maximum metal thickness 2mm and maximum coil weight 10 tons. Line can be equipped with acceptance part with moving support for stainless steel or as standard acceptance table. Lrjdpfoqlbpgsx Ah Eju As an option we can offer used machines for your requirements. Also we produce slitting lines, roll forming lines. tube mills and other sheet metal and coil metal processing machinery

Condition: refurbished (used), ROLLFORMING MACHINE PRODUCING SQUARE PROFILES Ledpfx Aefgl Aqeh Eoru WITH 5 TONES OF TOOLS MADE IN ITALY

Condition: new, Year of construction: 2025, functionality: fully functional, total width: 1,000 mm, total length: 1,100 mm, total height: 750 mm, input voltage: 220 V, working width: 600 mm, infeed width: 650 mm, spindle motor power: 1,100 W, warranty duration: 24 months, power: 1.2 kW (1.63 HP), Equipment: CE marking, emergency stop, type plate available, DESTEK MAKİNE is the first and only company to establish a production facility in its field in Türkiye. All machines and hand tools we sell are produced in our own workshops using state-of-the-art CNC machinery from design to final product. With the strength we gain from production, we have been providing products and services to our valued customers in the standing seam roof & facade cladding sector for over 10 years. By conducting a thorough needs analysis with a customer-first approach, we bring all global technological innovations to our country simultaneously. Therefore, our vision can be summarized as: “ Whatever is Manufactured in the World, DESTEK MAKİNE can Produce the Same or Even Better ” With a solution-oriented engineering approach, an experienced team of experts in the field, and a reliable service network, we are here whenever you need us. Our company guarantees 100% customer satisfaction. Our commitment to quality is certified by: CE Conformity Certificate ISO 9001 ISO 14001 ISO 10002 ISO 45001 Every manufactured "DESTEK" standing seam machines goes through delicate tests. "DESTEK" Features - Standard standing seam height 25 mm Lrodpfxewzzlws Ah Esu - There is no problem of oil canning when working with the machine. - Automatic Cutting Guillotine (Standart) - Ribbing Attachments (Standart) - Dijital Counter (Standart) - Cabled Remote Controller (Standart) - Emergency Stop Button (Standart) - Forward and backward button (Standart) - Wrench Sets that will be required during use (Standart) - Weight: 260 kg - You can transport with small cars - You can lift it to the roof easily - You can seperate it to four pieces for carrying easily (Standart) - Material width adjusment (180 mm – 650 mm) (Standart) Please contact us for more information and prices.

Condition: good (used), Year of construction: 1992, Manufacturer - ERW Year - 1992 Range of round pipe - 21 - 76 mm Range of square pipe - 20x20 - 60x60 mm Sheet thickness - 0,8 - 3,5 mm Speed - 60 m/min. Lenght of line - 50 m Tools : square pipes - 25,32,38mm round pipes - 40, 51 mm Lrsdsdlqkqjpfx Ah Eeu Welding power - 180 KW Anode voltage - 14 kv Anode dissipation - 70 kw Frequency - up to 30 Mhz

Condition: used, Tube Mill OTO 89.6 QTC with Quick Change System Working range: · Diameter: 26.9 - 89 mm · Thickness: 1.5 – 6.3 mm (except strip joiner up to 4,5mm and flying saw up to 5mm) · Length: 4 - 12 m Tube mill OTO 89.6 QTC | Year 2008 with : · Off-line strip preparation · Full automatic entry line (MTM) · OTO 89.6 Forming line (OTO MILLS) · OTO 89.6 QTC Quick change system (OTO MILLS) · 450 kW HF welder (EMMEDI) · Cold flying saw (SEUTHE) · Automatic 3" chamfering (MAIR) · Automatic packing (MAIR) · Automatic strapping (MAIR / SIGNODE) SUMMARY OF SCOPE OF SUPPLY 1. Automatic Entry Line with off-line strip preparation, including:  Double Uncoiler with off-line tale shear  Pinchroll and straigthener  Automatic strip joiner  Horizontal accumulator with rotating table 2. 89.6 Heavy-Duty tube mill with:  Cast steel stand structure. Lredov Dinmopfx Ah Eou  18NiCrMo5 steel casehardened and ground shafts.  Independent Marking stand.  95 mm diameter shafts with cylindrical fit and drive key.  Upper shaft vertically adjustable (single point manual adjustment).  Hydraulic compensator in forming stands  4 Breakdown stands with 140kW AC Motor / 3 forming stands with 100kW AC Motor  4 Sizing stands with 140kW AC Motor 3. Quick change system OTO 89.6 QTC 4. 450kW HF welder 5. Double scarfing unit with bead chopper & scrap conveyor 6. SEUTHE TS90 cold flying saw 7. Automatic MAIR FINISHING & PACKAGING LINE with:  NDT Tube testing line  3" Tube chamfering MAIR TFA.3/12.5  Automatic packer MAIR  Automatic Signode strapping unit Tube diameter: 26.9 - 89 mm Tube square: 30x30 - 70x70 Tube rectangular: 40x20 - 100x40 Tube thickness: 1.5 – 6.3 mm (except strip joiner up to 4,5mm and flying saw up to 5mm) Tube length: 4 - 12 m Working direction: Right to Left Speed: 120 m/min Entry line: MTM Tube Mill: OTO MILLS 89.6 QTC Flying saw: SEUTHE TS90 HF Welder: EMMEDI TFU450 Packing unit: MAIR .6.D.F & SIGNODE M400TSM

Year of construction: 2023, condition: new, We offer brand new roll former automatic line for corrugated metal sheet production. Depends on customer preferences we can produce line for 10, 20, 35, 44 or 57mm profile high. Some of lines we have ready on stock. Lrsdpfxskhaadj Ah Eou Line is equipped with electric uncoiler up to 10t coils, roll forming part, cutting shear, sheet stacker for 10m length. Also we produce customized roll forming lines, metal tile lines, cut-to-length lines, slitting lines etc. To get more information about our machinery please contact our sales department

Condition: used, 8 STATIONS Lsdpfx Aj Dv I Aeh Ejru Technical characteristics: ROLLFORMER 8 STATIONS 400mm WIDTH

Year of construction: 1996, condition: excellent (used), The line is an original American-made line for upgrading sections of rollers for drawing profiles. The American-made line has a plate and a huge number of additional rollers for pulling pipes! - Year - 1996 - Line use pulsed TIG welding for argon blowing and it can be upgraded by laser and resistance. - Electric consumers 30 kW. - Profiles - stainless steel profiles ellipse, D profiles, hexagonal, square and rectangular pipes. - In profiles of all dimensions from sheet metal width 125 mm and thickness 1 to 2.5 mm. - Speed - 30-90 m/h - Cutting unit - cross section by hand or with a band saw. - Line length 12 to 15 meters. Lrodpfx Aoh Ni Duoh Eju

Condition: used, Stainless steel welding line MOD.70/120, made OLIMPIA 80 with tricathode welder & Seam bead roller & Orbital polishing Lsdpsvtn H Tjfx Ah Ejru Specifications: - Diameter : 35 – 120 mm - Thickness : 0.7 – 3.5 mm - Length : 3 – 6 m Tube diameter: 35 – 120 mm Thickness: 0,7 – 3,5 mm Tube length: 3 – 6 m

Condition: new, Year of construction: 2024, Soffit panel roll forming line was designed by our company to produce wall soffit panels with different lengths. Line has automatic system so you can put length of panels and numbers you need and machine will produce it in automatic mode and cut it automatically. Machine has special cutting shear to cut panels as well. Line can be equipped with manual or automatic decoiler as an option. So it can be effective solution for soffit panels production Lrsdpfx Ahjrqg U Do Eou

Condition: refurbished (used), ROLLFORMING LINE Lrodpfx Ahsg Rkv Eo Esu

Condition: new, Year of construction: 2025, Dura fence metal automatic roll forming machine MPF-1 auto Dura fence metal automatic roll forming machine MPF-1 auto can be efficient solution for companies who decide to increase or start production of metal picket durafence planks. A metal picket fence is a type of profile that you can get by rolling flat metal through the rolling rollers of a machine with further use in the process of metal fences manufacturing and installation. A dura fence (euro picket fence) has an attractive look and can be perfect part of any design without cluttering it up or loading it with unnecessary elements. A dura fence will be an excellent solution for the construction of houses, cottages or any other buildings. Dura fence metal roll forming line MPF-1 is fully automatic and can proceed metal fence planks production process in fully automatic mode. The line consists of following parts Automatic metal decoiler can work with rolls weight up to 1.5 tons and coil width up to 350 mm. Decoiler helps to feed metal into a roll forming machine, so you need to install roll to unwinder shaft, to adjust inner diameter of the roll and put the metal under the compensation mechanism of the machine. After you have to take it to roll forming machine. As an option, we can also make a line and equip it with a manual metal unwinder or install a line without it at all. Ledpotp H Erjfx Ah Ejru The rollformer part of the machine, consisting of rolling rollers of various diameters and configurations to roll metal and form the required profile. Guillotine shear for cutting final products of the machine. The guillotine works in automatic mode, giving the opportunity to cut fences with necessary length and quantity. Line automation system consist of a manual control panel, an automatic control panel and a stand with a display. The manual control panel allows you to set up the machine in manual mode and check it before automatic operation. The automatic control panel is used when the line is operating in automatic mode, allowing you to set the quantity and length of forming products and program their cutting with the line. Thus, using dura fence metal line MPF-1 auto, you can get a full automatic solution for the production of a metal fence profile, applying minimum efforts to production and receiving high-quality products with sizes and numbers you need. Specification: The material thickness maximum (mm) 0.55 Engine power (kW) 1.5+1.1+2.2 Rolling speed (m/min) 10-15

Condition: used, Year of construction: 2006, API tube mill 355mm x14mm (A3801) is line to produce pipes for petrol industries so can be perfect solution for your company to grow up API tube mill (Made in China), Forming machine is made in Japan OD 114–355mm wall thcikness: 4-14.3mm steel grade: N80 tube length:6-15m standard: API 5CT N80 scope of supply: – slitting line; – tube mill; – two end facing machines; – two hydro testers; – 1 tube straightening machine, rolls (OD 114.3, 139.7, 219.1, 273.05, 323.9, 339.72 , 355.6mm) machine was made in 2006, stopped running in 2016. used seam annealer and HF welder, brand: Thermatool. Used slitter, Chinese brand. thickness: 4–14mm, N80, Q235, hot rolled steel. max coil width 1600–1700mm. 2+5 leveler DC motor: 55kw slitter DC motor: 160kw Lodpfx Ahsv Hcwts Ejru scope of supply: – coil car; – uncoiler (with 4 colums); – hold down roll; – peeler table; 2+5 leveler; – shear; – conveyor and loop; – guiding device; – slitter; – tension unit; – recoiler with support arm; – coil car; – approximate 12 slitting blades; – electric cabinet, hydraulic system. slitter is for tube mill

Condition: new, Year of construction: 2025, Metal siding “Soffit” production line SPM-1 auto Metal siding “Soffit” production line SPM-1 auto is an excellent solution for companies with business in metal siding and metal decor elements production for various buildings and structures. Soffit profiles are very popular to arrange gables, cornices and attics, and without perforation, they can be part of cladding building facades of various configurations. Perforation holes provide additional ventilation of the under-roof space and, therefore, optimal conditions for the roofing system. Air circulation helps to avoid the formation of condensation and extra humidity, as well as corrosion of metal tiles or corrugated sheets. Metal siding Soffit SPM-1 auto is fully automatic line. This equipment can go as a separate automatic machine, consisting of a rolling mill with an automatic system and an automatic profile guillotine, or in combination with an uncoiler. The metal uncoiler can be manual for working with metal rolls up to 800 kg or automatic, with a loop converter and speed control for working with rolls up to 1500 kg. Specifications: Dimensions (mm) 6650x1200x1600 Weight, kg): 2900 Drive power rolling machine: 3 kW, 380V Drive power guillotine shears: 1.1kW Maximum thickness of sheet metal (mm.): 0.6 Forming steps number -18 Shaft diameter (mm) – 55 Rolling speed (m/min.): 10-15 Ledpfx Aswwip Ajh Eoru Automatic roll forming soffit panels production machine SPM-1 auto makes panels with unlimited length. The machine has 18 pairs of forming rolls, providing high quality of the final products. There is special perforating module on the final stands of machine, responsible for cutting out perforation holes during roll forming. It is possible to use the machine both with and without this module, thus it is possible to obtain panels both with and without perforation, depending on the customer’s needs. We use alloy tool steel for rollers of machine and make them on high-precision CNC turning equipment, ensuring high product standards. Guillotine profile shears is at the machine exit and has electric drive to work. The electric drive of the shears is a more reliable solution compared to pneumatic or hydraulic systems for working on cutting shears of other line manufacturers. The rolling speed of the line is 10-15 meters per minute with the possibility of programmatic adjustment of this parameter. Specifications: Material width (mm) 409 The material thickness (mm) 0,4-0,6 Engine power (kW) 3 + 1,1 Rolling speed (m/min) 10-15

Condition: new, Year of construction: 2025, Portable machine for standing seam system was designed to profile double standing seam panels that are used for installation of standing seam roofing systems. Main Technical Data: Size: 1600x850x1000mm Weight: 250 kg Motor Power: 1.5kw Voltage: 380V/50Hz/3PH or 220-240V/50-60Hz Forming Steps: 6 steps Forming Steel Thickness: 0.4-0.7mm Forming Aluminum Thickness: 0.7-1.0mm Height of Roofing: 25mm Material Width: 250-700mm Tolerance: +-1mm Lodpfx Ajf Ih Hceh Eoru Roller material: high grade 45# Material of principal axes: high grade 45# steel For this price we offer roll former roofing machine F3 +cross cutting knife +rolls for ribbed panels also you can get: - Rolls for ribbed panels - Floor decoiler - Hand seamers - Electric seaming machine -Punching press for clips Dimension: 160.00Sm x 85.00Sm x 100.00Sm Weight: 280.00Kg

Condition: new, Year of construction: 2025, Metal roof snap lock machine SLP-1 auto with side punching option is the latest project of our company in the direction of equipment for metal roofing production. Snap lock machine SLP-1 auto can produce click-seam panels with fixation holes and punch off side parts of the panels, it makes possible to bend the edge of the panel and join it to the roof elements after. Our machine is equipped with an automation system and make production in a fully automatic mode. This process comes following way: operator of machine put end of metal roll to the pulling rollers of the machine, which moves it to the rolling part of the equipment. At the beginning of the rolling process, two pneumatic punching presses from each side of machine make side cuts of panels. After cutting, the rolling process goes to the next rolling rollers. They gradually form the roofing panel profile and cut out fixation holes with special cutting tool rollers. After rolling, special automatic shear at the end of machine cut off the panel into length with necessary sizes. As machine cuts side parts of panels at the beginning of production process, so it cuts only flat part of panel in the end of production. It makes panel quality better and there are no any deformations as with a profile cutting happens, when guillotine shear has to cut not only flat part but also the lock part of panel. Specifications: Dimensions (mm): rolling machine 3000x1400x900 guillotine shears 400x1120x1130 Weight (kg): rolling machine 643 guillotine shears: 110 Drive power: rolling machine: 1.5 kW, 220V (or 380V on request) guillotine shears: 1.1kW Lodsuzv Tzjpfx Ah Eoru Maximum thickness of sheet metal (mm): 0.6-0.7mm Workpiece Width (mm): 250-700 Rolling speed (m/min): up to 10 Metal roof panel machine SLP-1 auto has an automation system so help to make minimum part of operator works - he just sets necessary number of panels and their length on the computer to produce, and the machine automatically rolls and cuts them. Therefore reducing the influence of the human factor, manufacturing errors are minimum and panels are all the same sizes and ready for further installation. SLP-1 auto click lock roll forming machine has easy width adjustment system, so to change machine from one panel width to another, the operator just needs to turn the adjustment wheel, so the readjustment takes a very short time for such operation. As additional options metal roof panel roll forming machine SLP-1 auto can have: Cutting knife to cut metal from coil at the end of the metal rolling process to reduce the amount of possible waste material; Ribbed panel rolls, to roll narrow or wide ribs in the center of the roofing snap lock panel; Microwave panel module- device to form small bends along the entire width of the roofing panel, making the appearance of the roof more interesting and eye-catching. Metal unwinder (can be floor-standing, manual console, automatic console).

Condition: new, Year of construction: 2025, Metal hemming machine HR-2 Metal hemming machine HR-2 is the next model in the production line after hemming roll former HR-1 model. Instead of HR-1 machine that can form 5-8 mm hem lock, metal hemming machine HR-2 can make 6-14 mm hem. Therefore, customer can get better products range depends on requirements, seven forming stands of machine makes it possible. Metal hemming machine HR-2 can make common sheet metal processing operation goes much more easier, with better quality and same repeatability. In standard way such operation can be perform with manual sheet metal bending machine, so two workers have to make bends step by step to get necessary product. Lrodpfx Ahsrklxvs Eou Metal hemming machine HR-2 can make such operation much more efficiently. You can roll both sides simultaneously or each side step by step. To make it gradually can be good idea when you have large variety of elements you need to produce with different widths so no reason to readjust width of machine for each operation. We use special tool steel to make rolls of machine so can provide longtime living period. Hemming rollformer HR-2 can make unlimited length panels and make customer’s work much easier. Therefore, you can save a lot of time with our metal hemming machine HR-2 and make your production process much more efficient.

Condition: new, Year of construction: 2025, NEW Snap lock roofing panel roll forming machine SL-1 Snap lock roofing panel roll forming machine SL-1 is designed and manufactured by our company as one of the flagman equipment for metal roofing panels production. Following machine makes standing seam roofing panels with self-closing lock on sides (snap lock). The main advantage of such lock system is the easy way of installation: to connect two panels with each other you just need to cover bottom part with top part and press it with some force, you will hear specific click noise at this very moment. That is why name of system is self-closing lock one. Comparing to standard standing seam roofing panels with mechanical lock which you need to close with special tools or equipment, snap lock panels are much easier to install and don’t require additional expensive devices for work. To fix panels at the roof frame you can use standard self-tapping screws, to make it possible, while rolling machine makes special fixation holes on one side of roofing panels. Such simple product design also helps to save costs and make installation process easier, not spending money on clips purchasing, comparing to the standard standing seam metal roofing with mechanical lock installation. So standing seam roofing with snap lock is easier to install, does not require high skilled employees and cut expenses for additional machines purchases. Total high of panels - 31mm As per order, we can also make machine for 26mm panels high. Machine has 10 pairs of forming rolls. One of the rolls has special punching parts so can cut fixation holes at roofing panel for further installation operations. Cutting tools are made from tools steel with heating and polishing, so have longtime working period. Maximum metal width can be 700mm, minimum 250mm. Snap lock roofing panel roll forming machine SL-1 is width easy adjustable one, so to adjust machine from one panel width to another you just need to rotate special handle. Lredpfx Ahjiuz T Io Eeu Rolling length – unlimited Rolling speed (m/min.): about 7 As extra options, you can get: - cross cutting knife; - length measuring device; - ribbed panel rolls; As per customer preferences snap lock roll forming machine can be equipped with automatization system and electric shears for panels cutting. Standard supply set of self-closing lock roll former machine SL-1 includes safety covers to protect working parts of machine from foreign objects. Snap lock machine can work with various types of metal: galvanized steel, copper, aluminum, color coated metal, etc.

Condition: new, Year of construction: 2025, total width: 1,000 mm, total length: 1,600 mm, total height: 950 mm, power: 1.5 kW (2.04 HP), Roof panel roll forming machine F3-27 with clip relief LLC “Evolutioner” designed roof panel roll forming machine F3-27 with clip relief for metal roof production of double standing seam profile. Standing seam roof is widely used in the manufacturing of various buildings and structures, in the reconstruction of ancient houses and architectural objects. Standing seam gives a beautiful appearance to the roof, pointing its uniqueness and aesthetic design. In modern construction, standing seam panels often decorate the facades of walls of various buildings. The roofing machine F3-27 allows you to roll metal roof panels of various lengths, the rolling length is unlimited. The machine is quite lightweight, which makes it possible to use it directly at the roof installation place and forming panels directly on site. Thus, there is no need to transport finished roof panels from the workshop to the roof installation place, avoiding their possible damage and saving money on transportation services. Technical details: Rolling length – unlimited; Forming steps: 7; Lock high (mm): 27 Metal roof panel machine F3-27 is equipped with width easy adjustable system, so to adjust the width of the panel you just need to turn the special wheel. As extra options with F3-27 roll forming machine you can get: - cross cutting knife; - length measuring device; - ribbed panel rolls; - radius panel rolls; - standing seam hand seamers; - electric seaming machine ESM-1; - sliding clip formers; - fixed clip formers; - floor decoiler; - ribbed panel forming machine RPFM; - automatic shear with automatic system; Lredsp Stgnopfx Ah Eju Portable roof panel machine F3-27 has six pairs of forming rolls to make a profile height of 27 mm and an additional stand for rolling clip relief. A relief clip is a special bend on the panel to hide sliding or fixed clips under it. Those clips are used to connect roof panel to the roof frame. In addition, we produce following metal roof panel machines: standing seam metal roof machine F3; roof panel machine F3-9 with clip relief; snap lock roof panel roll forming machine SL-1; automatic snap lock roof panel machine SL-1 auto;
