Condition: good (used), Year of construction: 1990, Year of construction 1990 Control type CNC Sanding length 600 mm Sanding width 200 mm Workpiece height 375 mm Table load 100 kg Grinding wheel dimensions 250x25x51 mm Run at 1-24 m/min Kljdsi Hn U Uopfx Abvep Speed 4200 rpm Drive motor 5 kW Total power requirement 7.5 kW Machine weight approx. 3.2 t Space requirement approx. 3.7 x 2.1 x 2.1 m

Condition: good (used), Manufacturer Jung Type HF 50 RD Control conf. Klsdpfsip Dnfsx Abvop Axis displacement X axis 500 mm Y axis 200 mm Z axis 400 mm grinding spindle Speed variable 1000-4000 RPM To belong Cooling oil system with belt filter settings. Variable speed Sony digital 2-axis Magnetic plate

Condition: good (used), GR. Grinding length: 500mm GR. Grinding width: 200mm Table movement - longitudinal movement: approx. 600mm space requirement: 1800 x 1400 x 1650 mm approximate weight. 1500kg Kledpoin Np Ejfx Abvop With cooling system

Condition: good (used), grinding length: 400 mm, grinding width: 150 mm, Table length 400 mm Table width 150 mm Grinding length 400 mm Grinding width 150 mm Execution: hydraulic Max. distance from table to spindle-centreline 350 mm Table speeds: stepless from .00 m/min up to 0.0 m/min Automatic vertical feed: from 0.00 0 mm up to 0.013 mm Kledpfx Aevga Suobvop Diameter of grinding wheel 00 mm Width of the grinding wheel 16 mm Grinding wheel speeds: from 800 rpm Voltage 50 Hz 3x 380 Volt Grinding spindle motor .30 HP Machine's weight about 900 kg Overall dimensions machine: Length 1300 mm Width 1 00 mm Height 1500 mm

Condition: good (used), Year of construction: 1984, CNC Optical Profile Grinding Machine Kledpfxop R Rm Ij Abvjp Wasino GLS-130AS 1984

Condition: good (used), Year of construction: 1980, grinding length: 400 mm, grinding width: 150 mm, Jumag surface grinding machine (Jung) JM 400 Year of construction: 1980 Sanding length: 400 mm Sanding width: 150 mm Clamping area: 400 x 150 mm GR. Distance to table grinding spindle. 400 mm Grinding wheels: 200x 16 x 50.8 mm Table longitudinal feed hydr. variable Table cross feed manual/automatic. Grinding head electrically and manually height-adjustable electric quick adjustment 300 mm/min Sanding spindle motor: 1.5 KW - 2850 rpm Kodpfx Abjtmtnaevelp Connection: 380V 50Hz 14A Weight: approx. 1000 kg Space requirement: approx. 2200 x 1500 x 1700 mm

Condition: ready for operation (used), Year of construction: 2005, spindle speed (max.): 8,000 rpm, overall weight: 3,800 kg, workpiece diameter (max.): 250 mm, travel distance X-axis: 400 mm, travel distance Y-axis: 310 mm, tool weight: 50,000 g, number of axes: 5, This 5-axis Michael Deckel S22 was manufactured in 2005. It features a maximum grinding wheel diameter of 150 mm and a spindle speed range of 300 to 8000 rpm. The machine has a robust weight of 3800 kg and includes a cooling/filtration system from Transor Filter GmbH. If you are looking to get high-quality internal grinding capabilities, consider the Michael Deckel S22 internal grinding machine we have for sale. Contact us for further details. • Operating voltage: 3 × 400 V • Electrical connection: 3P / N / PE • Frequency: 50 / 60 Hz • Nominal current: 25 A • Fuse protection: 32 A • Power consumption: 15 kW Klodpjyr H Idsfx Abvsp • Control voltage: 24 V DC • Spindle speed: 300 – 8000 RPM • Control: Michael Deckel S22 • Grinding spindle speed: continuously variable • Direction of rotation: right and left • Working speed: 40 m/s • Max grinding wheel diameter: 150 mm • Grinding wheel width max: 20 mm • Grinding heads: cylindrical and conical • Max diameter: 125 mm • Width: 50 mm • Clamping and grinding range • Max workpiece diameter: approx. 250 mm • Max workpiece length: approx. 900 mm • Max grinding length: approx. 400 mm • Max grinding length in work programs: approx. 320 mm • Tool holder taper: SK50 • Max tool weight: 50 kg • X-axis travel: 400 mm • X-axis feed: 12 m/min • Y-axis travel: 310 mm • Y-axis feed: 12 m/min • Machine weight: 3800 kg Additional equipment • Cooling/filtration system: Transor Filter GmbH (2007)

Condition: good (used), Year of construction: 1967, functionality: fully functional, machine/vehicle number: 3671, power: 0.55 kW (0.75 HP), • Manufacturer: Haarmann • Model: DMPU • Machine type: Universal tool grinding machine • Application: Grinding of drills, milling cutters, turning tools, cutting tools • Design: Compact cast construction, low vibration Motor • Power: 0.55 kW • Speed: 1400–2800 rpm • Voltage: 380 V • Frequency: 50 Hz Grinding unit • Grinding wheel diameter: 125–150 mm • Drill grinding range: approx. 3–20 mm • Cutter grinding range: depending on clamping devices • Angle adjustment: manual, finely adjustable • Rests: adjustable, usually on both sides Dimensions & weight Klsdpsyvpwqsfx Abvep • Dimensions: approx. 500 × 400 × 350 mm • Weight: 35–55 kg Year of manufacture: 1967

Condition: used, working area 12-60 mm speed 60/120 m/min Bar length 4000 mm Feed 0-5 mm/U rolling power 500-40000 N weight 1200 kg total power requirement 3 kW Centerless roller burnishing machine with additional equipment up to 105 mm diameter The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. Kljdpfoytx Niox Abvsp About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: not inspected (used), functionality: unexamined, Two machines are being sold as a package for spare parts. Centerless grinding machines ----- 1* Manufacturer: NOMOCO, Type: M100 E Machine no.: 5069 Year: 1977 Max. grinding diameter: 100 mm Max. grinding length: 180 mm Grinding wheels: Ø 400 mm Max. wheel width: 180 mm Weight: 3,200 kg ----- Manufacturer: NOMOCO, Type: M100 Machine no.: 2338 Year: 1974 Machine is equipped with a stack magazine, feed through a pusher. Machine is set up for plunge grinding. Conversion to through-feed grinding possible. ----- * The concentricity testing device is not included in the scope of delivery. The machine has been disconnected from the power supply, i.e., it cannot be demonstrated under power. Removal and loading are at the buyer’s expense. For prices, please refer to the "Documents" section, or send an inquiry by email. A forklift for loading is not available, but can be arranged if required. Ksdeyc N D Nopfx Abvolp

Condition: refurbished (used), Year of construction: 2021, operating hours: 850 h, functionality: fully functional, In addition to the listed and depicted machines, we have many other machines and accessories (blasting systems, conveyor belts, and small machines) available from stock. The machines can be purchased or rented. Contact us for (free) advice regarding vibratory finishing, barrel & blasting technology. Klodpswfdbcsfx Abvjp

Condition: used, Year of construction: 2009, internal diameter max. 600 mm grinding depth max. 800 mm grinding length max. 600 mm control Siemens 840 D grinding diameter - internal max. 600 mm grinding diameter - cylindrical max. 800 mm workpiece length - max. 380 mm external grinding length max. 600 mm travel - x1 axis 150 mm travel - z1 axis 1100 mm travel - x2 axis 470 mm travel - z2 axis 800 mm workpiece spindle 8,5 kW turning speed range - stepless 1-795 U/min Equipment / Accessories: Workpiece spindle unit (U/B1/L adjustment): - Travel (U-axis): 300 mm - Swivel angle (B1 axis): -0,5°/+12° - Drive power of the workpiece spindle: 8.5 kW - Speed range (infinitely variable): 1-795 rpm - Set-up speed (jogging): 10 rpm - Spindle head size A 8 according to DIN 55026 - Through-hole 58.5 mm - Workpiece diameter max. 830 mm - Workpiece length (overhung clamping) max. 800 mm - Workpiece length (clamped between centers) max. 800 mm - Load capacity at spindle head max. 6100 N Internal grinding device (Z1/X1/B2): - Travel (Z1 axis): 1100 mm Kjdewp S Tnopfx Abvelp - Travel (X1 axis): 150 mm - Swivel angle (B2 axis): 270° - Manual longitudinal adjustment of internal grinding axis on table: 780 mm - Drive power of the internal grinding spindles (infinitely variable) Belt-driven grinding spindles: 7.5 kW - Grinding block mounting hole (diameter): 100 mm / 125 mm - Mounting length of sanding block: 220 mm - Sanding diameter: max. 600 mm - Sanding depth: max. 800 mm External and surface sanding device (Z2/X2): - Travel (Z2 axis): 800 mm - Travel distance (X2 axis): 470 mm - Swivel angle (B2 axis): 270° - Drive power of the external grinding spindles: 7.5 kW - Grinding block mounting hole: Ø 140 mm - Sanding diameter: max. 800 mm - Sanding length max. 600 mm - Grinding wheel dimensions: max. Ø 450 x 50 x Ø 127 mm

Condition: used, Year of construction: 2001, grinding length 4200 mm grinding width 1300 mm workpiece height 550 mm Control Siemens 840D passage width 1300 mm electro-magnetic table 4200 x 1300 mm grinding height 550 mm grinding motor 306 kW grinding motor turning speeds up to 370 U/min grinding motor feed, infinitely variable 0,5-35 m/min coolant flow rate 2000 l/min weight of the machine ca. 50 t dimensions of the machine ca. 11,21 x 5,25 x 3,85 m Klsdethumuepfx Abvjp Equipment / Accessories: - segment head - diameter 1400 mm - for segment dimensions 120/106 x 41 x 250 mm - number of segments: 1 set = 26 pieces - grinding motor adjustment - in steps: 0,002 - 1 mm - continuous: up to 5 mm/min stepless

Condition: used, Year of construction: 2012, Lot consists of: (1) CNC vertical grinding + hard turning center Technical Details: Ksdjym Sazopfx Abvolp max. workpiece internal diameter 10 - 200 x 150 mm, 2 work spindles, 4 machining stations, CNC SIEMENS SINUMERIK 840D, tool turrets, chip conveyor, rapid traverse: X/Z: 90/30 m/min

Condition: new, Precision Heavy Duty Cylindrical Grinder Working Capacity: Max Length: 4000mm Kljdjytnh Iepfx Abvop Max Diameter: 550mm Max Weight: 1,000kg Center Height: 280mm Grinding Wheel Size: φ710×50~100×φ203.2 Grinding Wheel Speed: 890 RPM Main Spindle (5 steps by belt): 25~165 RPM Main Spindle Taper: MT#5 Tailstock Quill Taper: MT#5 Tailstock Quill Stroke: 30mm Table Swing Angle: 1° 30' Power: Grinding Wheel + Inverter 15HP Main Spindle + Inverter 3HP Hydraulic Pump Motor 3HP Cooling Pump 1/4HP Lubricant Motor 1/2HP

Condition: used, Year of construction: 2001, Lot consists of: (1) CNC Vertical-Spindle Surface Grinding Machine Technical Details: X / Z 950 / 200 mm, grinding wheel diameter 400 mm, grinding spindle feed: 0 - 30 m/min, 10 kW, workpiece spindle 6.3 kW, CNC Siemens Sinumerik 840D, weight approx. 5 tons, dimensions (LxWxH) approx.: 2.4 x 2 x 2.3 m Kodpfjym Rkfex Abvjlp The machine is currently in storage. Images shown do not necessarily reflect its current condition while in storage.

Condition: used, CNC Universal Tool Grinding Machine SCHÜTTE Type BU 400 CNC 4 Machine - defective - without control system Machine not operational - electrically non-functional - without CNC controller Serial No.: Year of manufacture: 1990 4 axes (X, Y, Z, and R) Table clamping surface 1300 x 250 mm Distance between centers 700 mm Center height 155 mm Grinding length (X-axis) max. 400 mm Grinding width (Y-axis) max. 260 mm Grinding spindle speed max. 6000 rpm Grinding spindle drive 3 kW Power supply 380 Volt, 50 Hz, 25 Amp. Klodpfx Ajd Rmcmsbvsp - CNC control system removed Required space L x W x H 3800 x 2400 x 2300 mm Weight 3000 kg Machine not functional, CNC control is missing. Mechanically in good condition, ideal for control retrofit Suitable as a spare parts donor or for rebuild with new control system

Condition: used, Guideway and surface grinding machine WMW FRITZ HECKERT Aschersleben type SZ 1000 x 1250 x 3000 / 344 make no. 13.2236.2 year of construction 1989 nominal grinding area 3000 x 1250 mm table clamping area 3240 x 1000 mm grinding length max. 3300 mm Machining width 1250 mm Machining height 1250 mm grinding wheel diameter (surface grinding support) max. 600 mm grinding wheel width (flat grinding support) max. 100 mm grinding wheel diameter (swivel support) max. 450 mm Mains connection 400 Volt, 50 Hz - grinding support swiveling, drive power 16,5 kW, infinitely variable speed - grinding support for surface grinding, drive power 15 kW, infinitely variable speed - new electrical control, based on SIEMENS S7 from year 2001 - new electric control cabinet beside, year of construction 2001 - infinitely variable grinding wheel speed at both grinding supports - swiveling wheelhead for guideway and profile grinding - swivel-mounted and height-adjustable control panel - coolant system adjacent Kjdpfxehv A A De Abvolp - Hydraulic system adjacent - oil circulation lubrication adjacent - Various grinding wheels and holders space requirement complete L x W x H 11900 x 7700 x 4600 mm weight 45 ton. very good condition

Year of construction: 2008, condition: ready for operation (used), overall weight: 3,800 kg, spindle speed (max.): 600 rpm, number of axes: 5, This 5s SAACKE UWIF cylindrical grinding machine was manufactured in 2008. It features a maximum spindle speed of 600 rpm and a powerful grinding spindle peak power of 16 kW. The machine supports a variety of workpiece sizes, with a maximum diameter of Ø 20 mm and a weight capacity of 1 kg. If you are looking to get high-quality grinding capabilities, consider the SAACKE UWIF cylindrical grinding machine we have for sale. Contact us for further details. • Workpiece carrier A-axis: Direct drive/hollow shaft motor; indexing accuracy ±15"; indexing possibilities 1–999; cumulative pitch error at 100 mm: 8 µm; speed max. 600 rpm Kedpfxjyiz R Uj Abvjlp • Tool holder: ISO 50 • Spindle clearance holding sleeve: max. 28 mm (with automatic clamping: Ø20 mm) • Nominal drive power: • Grinding spindle S1-100%: 7.5 kW; peak: 16 kW • X-axis longitudinal travel: 2 kW • A-axis workpiece carrier: 2 kW • Z-axis cross slide: 2 kW • Y-axis grinding head slide height: 2 kW • B-axis grinding head rotation (rotary table): 2 kW • Position measuring systems: • A-axis: Direct measuring system • B-, X-, Y-, Z-axis: Indirect measuring system • Resolution X/Y/Z: 0.0001 mm (0.1 µm) • Resolution A/B: 0.0001° • Electrical connection: 20 kW / 50 A; operating voltage 400 V, 50 Hz; control voltage 24 V; lighting voltage 230 V; backup fuse: separate supply from mains • Compressed air: 15–17 Nm³/h; pressure min/max 6/8 bar (600/800 kPa); quality ≥ Class 4 (ISO 8573-1) • Control & software: CNC NUM Axium Power 1050 with PC, program memory 512 k; NUMROTOplus software (dongle/hardlock required); zero points calibrated using enclosed measuring instructions (no marked reference points) Additional equipment • Workpiece changer options (automation): • Option 1: Pick-up design • Max. workpiece: Ø20 mm × 120 mm; 1 kg • Capacity per pallet: • Ø3.0–5.0 mm shank: 40 pcs • Ø5.1–8.0 mm: 32 pcs • Ø8.1–11.0 mm: 28 pcs • Ø11.1–14.0 mm: 24 pcs • Ø14.1–20.0 mm: 20 pcs • Option 2: Chain loader magazine (with gripper unit) • Capacity: 64 workpieces • Max. workpiece: Ø32 mm × 200 mm; 2.5 kg • Features: Chaotic loading of different workpieces; automatic changing of collets possible • Holding sleeves: Ø6, 8, 10, 12, 14, 16, 20 • External chain loader option: increases machine weight to approx. 3,800 kg and space to 3,000 mm × 1,875 mm • Coolant filter system (TRANSOR): To be provided by customer; air for backwashing approx. 700 Nl/min for 5 min every 6–9 hours

Year of construction: 2000, condition: ready for operation (used), number of axes: 2, This Parpas RUAP 700 was manufactured in 2000. A used cylindrical grinding machine, fully reconditioned and in excellent condition. Features include Siemens Sinumerik 840C control, 700 mm distance between centers, and a maximum workpiece diameter of Ø 360 mm. If you are looking to get high-quality grinding capabilities, consider the Parpas RUAP 700 machine we have for sale. Contact us for more information. Klodpfx Abjygmg Novep • Status: Excellent • Control: Siemens Sinumerik 840C • Distance between centers: 700 mm • Center height: 185 mm • Maximum workpiece diameter: 360 mm • Maximum table travel (Z-axis): 820 mm • Table feed speed (Z-axis): 0–10 m/min • Maximum wheelhead travel (X-axis): 500 mm • Wheelhead feed speed (X-axis): 0–10 m/min • Max wheel size (left): 508 x 203 x 76 mm • Max facing wheel size (right): 450 x 127 x 50 mm • Wheel motor power: 10 hp • Workpiece spindle speed: 0–600 rpm • Wheel spindle speed: 0–2,880 rpm • Workpiece spindle taper: ISO 50 • Tailstock internal taper: Morse 4

Condition: ready for operation (used), Year of construction: 2006, working width: 1,100 mm, overall weight: 2,460 kg, This CB Levigatrici belt sander was manufactured in 2006. It features a maximum working width of 1100 mm, operates on 400 V / 50 Hz, and has a total power of 48 kW. Weighing 2460 kg, it's a robust choice for your sanding needs. Consider the opportunity to buy this CB Levigatrici belt sander. Contact us for more information about this machine. • Grinding units: 3 • Electrical: 400 V / 50 Hz • Total power: 48 kW • Rated current: 94 A Kledpfx Ajygwuqsbvop • Note: The technical data and descriptions are copies of the order confirmation at the time. Data is for information purposes only and is not binding.

Condition: ready for operation (used), Year of construction: 2021, This SCM DMC SYSTEM belt sander was manufactured in 2021. It features a working width of 1,350 mm and belt feed speeds ranging from 2 to 16 m/min. Equipped with PRO SAND electronic control and a PLC terminal with a 10.4" LCD color display, it offers advanced user interface capabilities. The machine includes multiple working units for diverse sanding tasks and is powered by inverters for precise speed control. Contact us for more information about this machine. Additional equipment • Vacuum Motor: Powered by inverter up to 7.5 kW integrated into machine frame / Conveyor: Rubber-coated belt conveyor 50 Shore / Feed Belt Motor: 4 kW driven by inverter / Console: Integrated with PC eye-M and Maestro Pro Sand electronic control, Tele Service system, 21.5" LED LCD color display • Programs: 1999 Working Programs / Control System: Interactive troubleshooting, self-diagnosis, Full HD display with multi-touchscreen, Maestro Pro Sand software • Operating Temperature: +5 to 35°C/ Additional Features: Virtual keyboard, production report, display of electric and pneumatic diagrams, user manual. Klodpfxjyaqg Tj Abvop Machine Benefits Technical Machine Benefits • Working width: 1350 mm / belt feed speed: 2 to 16 m/min / control: pro sand electronic control / display: plc terminal with 10. 4" lcd color display • Sanding belt dimensions: 150 x 5000 mm / chevron belt dimensions: 140 x 4710 mm; 1370 x 2186 mm • Aggregate 1: tie 5000 working unit for extra table internal cross pad / automatic brake, linear blower, sanding belt cleaning system / aggregate 2: do19 orbiting unit for 19 rotating disc brushes / main motor: 1. 1 kw / rotating disc diameter: 125 mm / aggregate 3 & 4: bf300 working unit for brush roller / brush roller diameter: 300 mm / motor: 4 kw / aggregate 5: sc 2620 operating unit for super-finishing pad / chevron belt dimensions: 1370 x 2186 mm / sanding belt dimensions: 1370 x 2620 mm

Condition: ready for operation (used), Year of construction: 2013, operating hours: 20 h, working width: 650 mm, Belt sander manufactured in 2013. This FELDER FW 650 features a working width of 650 mm and a powerful 7.5 kW motor. It includes a variable feed speed ranging from 3.7 to 16 m/min and an automatic belt centering system. The machine comes with interchangeable sanding pads and a rubber contact roller. If you are looking to get high-quality sanding capabilities, consider the FELDER FW 650 machine we have for sale. Contact us for further details. • Sanding belt dimension: 670 × 1900 mm • Motor power: 7.5 kW (upgraded from 5.5 kW) • Voltage: 3 × 400 V • Duty type: S1 • Variable feed speed: 3.7–16 m/min • 1 combination aggregate • Interchangeable sanding pad • Rubber contact roller: 85 Shore • Electropneumatic sanding shoe • 2nd feed speed • Automatic belt centering • Automatic star-delta start (SD start) • Extraction connection: 120 mm • Control: Conventional (non-CNC) • Minimum transport height: 2370 mm • Minimum transport width: 2200 mm Additional equipment Kedpeyli H Asfx Abvjlp • Double-sided roller table extension • Abrasive belts included: • 670 × 1900 mm K80 (12 pcs) • 670 × 1900 mm K120 (12 pcs)

Year of construction: 2007, condition: ready for operation (used), travel distance X-axis: 650 mm, controller manufacturer: SIEMENS, controller model: 840D, overall weight: 29,000 kg, number of axes: 4, This 4-axis DANOBAT HG 91-3000-B8 was manufactured in 2007. It features a CNC control system by SIEMENS 840 D, a maximum grinding length of 3,000 mm, and can handle workpieces up to 5,000 kg. The machine offers a swivel angle from -30º to +180º and a cutting speed of 45 m/s. Consider the opportunity to buy this DANOBAT HG 91-3000-B8 cylindrical grinding machine. Contact us for more information about this machine. • Center height over floor: 1,604 mm • Center height: 525 mm • Max grinding length: 3,000 mm • Max grinding diameter: 850 mm • Max workpiece weight (between centers): 5,000 kg • Total machine weight: 29,000 kgX-axis (transversal carriage) • Effective travel: 650 mm • Max programmable speed: 6,000 mm/min • Min programmable speed: 0.01 mm/min • Min programmable increment (in diameter): 0.001 mm • Motor torque: 22 N·mZ-axis (longitudinal carriage) • Max programmable speed: 6,000 mm/min • Min programmable speed: 0.01 mm/min • Min programmable increment: 0.001 mm • Motor torque: 42 N·mB8 wheelhead Kedpfx Aboycuiwovelp • Swivel angle: -30° to +180° • Wheel dimensions: Ø760 x 80(100) x Ø304.8 mm • Cutting speed: 45 m/s • Power: 22 kWWorkhead • Spindle speed range: 10–120 rpm • Center cone: Morse 6 • Motor torque: 42 N·mHydraulic tailstock • Max taper correction: ±0.20 mm • Max center travel: 100 mm • Center cone: ASA 4Dresser • Location: Positioned on workhead and tailstock

Year of construction: 2008, condition: ready for operation (used), travel distance X-axis: 450 mm, travel distance Z-axis: 850 mm, overall weight: 12,000 kg, This STUDER S242 was manufactured in 2008, a cylindrical grinding machine known for its robustness and precision. It features a swing diameter of 180 mm, max workpiece weight of 20 kg, and grinding spindle speeds up to 50 m/s. The machine includes shaft automation, grinding wheels, and is still powered up and fully functional. Annual maintenance by Studer ensures reliability. For more information about this machine, please reach out to us. • Center distance: Small (2 cross slides) 400 mm; Long (2 cross slides) 800 mm; Long (3 cross slides) 800 mm Kjdpfx Absx D Iwvjvelp • Swing diameter: 180 mm • Max. workpiece weight: 20 kg • X-axis (cross slide) • Speed: 0.001–1,500 mm/min • Resolution: 0.00001 mm • Z-axis (longitudinal slide) • Max. travel: 850 / 1,600 mm • Speed: 0.001–25,000 mm/min • Resolution: 0.00001 mm • Turning turret • 8-station: Capto 6 fixed • 12-station: VDI 40 fixed • 8-station: VDI 30 driven fixed • Max. drive speed: 4,000 rpm • Drive power: 2.5 kW • Option: Active longitudinal measuring rod on turret (Capto or VDI) • Grinding spindle head • Mounting angle: -25° / +25° • Grinding speed: 50 m/s • Wheel size: Ø 400 x 50 (63) x 127 mm • Internal grinding attachment • Spindle positions on swiveling plate: 3 • Spindle position: 0° / +45° • Automatic positioning in 3 positions • Internal grinding spindle range: 1,200–120,000 rpm • Available spindle speeds: 24,000–120,000 rpm • Workpiece spindle head (fixed) • Speed range: 1–7,500 min⁻¹ • Drive power: 10.5 kW • Tool holder: MK4 / DIN 55026 A4 • Load during surface grinding: 500 Nm • Roundness accuracy: 0.0004 mm • Workpiece spindle stock (swivelable) • Swivel range: 0–10° • Resolution: 0.0001° • Speed range: 1–4,000 min⁻¹ • Drive power: 10.5 kW • Tool holder: MKS / DIN 55026 A6 • Load during surface grinding: 500 Nm • Roundness accuracy: 0.0004 mm • W-axis / Tailstock • Max. travel: 450 / 1,650 mm • Speed: 0.001–1,500 mm/min • Fine adjustment for cylindricity corrections: ±0.01 mm • Option: Quill recoil ±0.40 mm • Quill diameter: 60 mm • Mounting taper: MK4 • Quill travel: 45 mm • Optional synchronous tailstock: 1–7,500 rpm; drive power 10.5 kW; mounting taper MK4 / DIN 55026 A4 • Dressing • Standing dressing tool, holder with MK1 mount • Single-point diamond / shortened tile • Dressing spindle with axial drive on swivel holder: Ø 58 / 89 / 100 mm max • Dressing spindle with axial drive at the rear: Ø 100 mm max • Connection values • Total connected load: 45 kVA • Minimum air pressure: 5.5 bar • Total weight: 7,600 / 12,000 kg • Condition and service • Still powered up and fully functional • No roughing work • Annual maintenance by Studer Additional equipment • Shaft automation (included in scope of delivery) • Grinding wheels (included)
