REM Bacau

Condition: new, Year of construction: 2025, turning height: 2,800 mm, workpiece weight (max.): 30,000 kg, turning diameter: 3,300 mm, feed length Y-axis: 2,500 mm, feed length Z-axis: 1,500 mm, faceplate diameter: 3,000 mm, feed rate X-axis: 4 m/min, feed rate Y-axis: 4 m/min, feed rate Z-axis: 4 m/min, rotary table diameter: 3,000 mm, rapid traverse X-axis: 6 m/min, rapid traverse Y-axis: 6 m/min, rapid traverse Z-axis: 6 m/min, rotational speed (max.): 92 rpm, rotational speed (min.): 1 rpm, table load: 30,000 kg, table diameter: 3,000 mm, REM Vertical Turning Lathe TURNING DIAMETER SCR 33 MANUAL with DRO Special manufactured by REM for : CENTER AND EAST EUROPE MIDDLE EAST LATIN AMERICA DEVELOPING SHOPS , HIGHLIGHTS - UNBEATABLE PRICE - VERY EFFECTIVE MACHINE - GOOD FOR WORSHOPS IN SMALL AND MIDDLE RANGE OF PRODUCTION - NO GEARBOXES - NO CNC CONTROLL - NO EXPANSIVE TEHNOLOGIST AND WORKER Drgbnz - EASY MAINTENANCE AND - EASY OPERATE - EASY LEARN Technical Details: Faceplate Diameter (mm) 3000 Max. Turning Diameter (mm) + 300 Machining Height: 2800 mm Max. Work Piece Weight: 30 tons Conventional Control DIGITAL READ OUT for each axis

Condition: excellent (used), Year of construction: 1976, workpiece weight (max.): 50 kg, turning height: 3,000 mm, Faceplate Diameter 4770 mm Bxikzxxwpm Faceplate Speeds 0,33-32,8 RPM Max. Load on the face plate 80.000 kg Max torque faceplate 273 kNm Nominal turning diameter5000 mm Max. Turning diameter5300 mm Max. Turning height over faceplate 4000 mm Traverse path of the crossbar3600 mm Adjustment speed of the crossbar 500 mm / min Max. Slide stroke 2540 mm RAM Cross section (left) 250 x 250 mm Slide tilting +/- 30 ° Drive motor faceplate100 kW Machine length13.040 mm Machine width 11.465 mm Machine Height 11.340 mm Weight Of The Machine Ca. 106 t

Condition: repair required (used), Year of construction: 1979, Functionality: limited functionality, turning height: 4,000 mm, workpiece weight (max.): 100,000 kg, turning diameter: 15,000 mm, faceplate diameter: 6,300 mm, rotational speed (max.): 40 rpm, table diameter: 6,300 mm, power of the servo motor: 110,000 W, Vertical Turning Lathe: BERTHIEZ TM 500 SP •⁠ Year: 1979; Buqjrw38Oc •⁠ Faceplate diameter: 6300 mm; •⁠ Max. turning dia.: 15000 mm; •⁠ Max. turning Height: 4000 mm; •⁠ Max. workpiece weight: 100 tons; •⁠ Table max. rotation speed: 40 RPM; •⁠ Main motors power: 110 kW (2x55 kW) Visit and inspection possible with 24h prior schedulling. Price and more data available upon request.

Condition: new, Year of construction: 2025, operating hours: 5 h, Functionality: fully functional, workpiece weight (max.): 12,000 kg, travel distance X-axis: 1,900 mm, travel distance Z-axis: 1,400 mm, spindle motor power: 100,000 W, spindle speed (min.): 60 rpm, rapid traverse X-axis: 8 m/min, rapid traverse Z-axis: 8 m/min, turning diameter over cross slide: 2,200 mm, turning diameter: 2,200 mm, total height: 2,000 mm, feed rate X-axis: 8 m/min, Equipment: rotational speed infinitely variable, Machine Fresh from production Test and quaility controlled next 6 weeks Manufacturing year 2025 Ctklwfzhh3 WAIT FOR OFFERS

Condition: as good as new (ex-display), Year of construction: 2024, feed length Y-axis: 1,500 mm, feed length Z-axis: 1,250 mm, workpiece weight (max.): 12,000 kg, Nominal Turning Envelope Swing Diameter 1,650 mm Rrvsyfr2Z7 Machining Diameter 1,650 mm Machining Heights 1,500 mm Work Piece Weight Standard 8,000 kg W Crossrail Travels 950 mm Increment Of Elevating 200 mm Z-1,250 mm X - 1500mm WorkTable WorkTable Diameter 1.450 mm WorkTable Speed 1-250 rpm Power Continuous S1 60 kW Power 40% Operating S3 75 kW Torque Continuous S1 22,000 Nm Torque 40% Operating S3 31,000 Nm WorkTable Milling Speed 0.002 to 3 rpm Milling Torque Continuous S1 21,000 Nm Locking Table Torque 30,000 Nm Z-Axis Milling Ram 1250 mm Ram Size Turning Milling 230 by 230 mm Tool shank size 32 x 32 mm and 40 x 40 mm Tool tape size SK50 DIN 69871 Ram Milling Capability Ram Speed 0 to 2500 rpm Power Continuous S1 40 kW Torque Continuous S1 1.800 Nm

Condition: excellent (used), Year of construction: 2016, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,600 mm, travel distance Z-axis: 800 mm, table load: 25,000 kg, spindle diameter: 132 mm, spindle speed (max.): 2,500 rpm, total height: 50 mm, total length: 80 mm, total width: 50 mm, table length: 2,000 mm, table width: 1,750 mm, feed length W-axis: 10,000 mm, feed rate X-axis: 10 m/min, feed rate Y-axis: 10 m/min, feed rate Z-axis: 10 m/min, rotational speed (max.): 2 rpm, travel distance W-axis: 800 mm, rapid traverse Y-axis: 10 m/min, rapid traverse Z-axis: 10 m/min, workpiece weight (max.): 25,000 kg, power: 37 kW (50.31 HP), Machine full under power . Need new X axis telescopic covers Mfg by REM 2016 revised 2022 Control -- Fanuc 31 I A TECHNICAL FEATURES Milling and Boring Head Boring spindle diameter 132 mm Boring spindle tapered bore ISO 50 Speed ranges No 2 Spindle speed 0+2500RPM Tool clamping automatic Main motor power (regime S1) 37 KW (spindle motor) Rotary Table Dimensions 1750x2000 mm Table indexing 360.000x0.001 Fzhltp0 Indexing accuracy 6 seconds Maximum hydrostatic 25.000 kg Axes Travel X cross slide 2500 mm Z spindle 800 mm Y headstock 1600 mm W column back forth 1100 mm Feeds Feed axes selection automatic Work feed range on X, Y, Z 2 ÷ 10.000 mm/min Work feed range on W 2 ÷ 6.000 mm/min Work feed range on B 0.025-3 rpm Lead screws type on X, Y, Z ,W ball-screw Overall Dimensions length 7600 mm width 6000 mm height 5100 mm Weight (approx.) 44 tons Accessories - standard • Foundation leveling blocks • Technical documentation – operator, maintenance and programming Accessories - optional • Angle plates ( vincle)

Condition: as good as new (ex-display), Year of construction: 2012, operating hours: 1,000 h, Very little running time Technical data: Spindle diameter - 130mm Spindle Type - ISO 7:24 No50 Bd2Ao3Dpfpg Spindle Speed - 3000 RPM W axis - 800mm Y axis - 2000mm Z axis - 1600mm X axis - 4000mm Table size - 1800x2200mm Table loading capacity - 10.000kg General dimensions - 6800x6300x4600mm Machine Weight - 35000kg

Condition: used, Year of construction: 2004, First MCV 2000 - Vertical Machining Center with Fanuc 0i control. Dkewxt Specifications: Table dimensions: 2200 x 1000 mm X axis travel: 2050 mm Y axis travel: 1150 mm Z axis travel: 760 mm Spindle speeds: 12.000 rpm Work feed: 8.000 mm/min Rapid speed Z-axis: 15 m/min Rapid speed X - Y axis: 20 m/min Machine in stock, fast delivery

Condition: new, Year of construction: 2024, operating hours: 200 h, Functionality: fully functional, machine/vehicle number: SCR 44 2SF, Vertical Turning center SCR 44 – 2SF - Tech data Nominal Turning Envelope Faceplate Diameter 4.000 Machining Diameter 4.400 mm Machining Heights 2.000 mm Work Piece Weight 16,000 kg Nominal Travels X-Axis Rams Carriage 2,500 mm W-Axis Elevating Cross Rail 1,200 mm Indexing step 300 mm Z-Axis Ram vertical travel 1,250 mm Work Table Ehgegon WorkTable Diameter 4.000 mm WorkTable Speed 1 - 60(90) rpm Power Continuous S1 100 kW Torque Continuous S1 110,000 Nm WorkTable C axis 0.02 to 1.5 rpm Power Continuous S1 11 kW C axis Torque Continuous S1 55,000 Nm Locking Table Torque 80,000 Nm Z-Axis Milling Ram Ram Size Turning Milling 250 X 250 mm Turning / MillingTool type KM 63 - ISO 50 DIN 69871 Ram Milling Capability Ram Speed 0 to 2,500 rpm Power Continuous S1 40 kW Torque Continuous S1 1.400 Nm Toolchanger Number Of Tool Magazines 2 X ATC for 12 turning / milling tools Tool Storage 24 Axes Drives X1,2-Axes horizontal axis Power Continuous S1 5.5 kW Thrust Continuous S1 50,000 N Z-Axis Ram Power Continuous S1 5.5 kW Thrust Continuous S1 50,000 N W-Axis Cross-Rail vertical movement Power Continuous S1 11 kW Axes Rates X1,2 And Z1,2-Axes Feed Rates 0.02 to 10,000 mm/min W-Axis Elevating Rate 400 mm/min Coolant System Coolant Tank Capacity 2,000 L Coolant Pressure / Flow Rate: -internal coolant (milling) -external coolant (turning) Filtration unit: -type -filtration size 40 bar at 40 LPM 5 bar at 100 LPM Cartridge type 25 µm Horizontal Drilling Head For inside and outside drilling operations. Maximum speed 3.000 rpm Power 42 kW Toolholder tape ISO 50 DIN 69871 CNC Control -producer Sinumerik 840 Dsl Siemens Accuracy Positioning: X ±0.010 mm / m Z ±0.010 mm /m C ±3 arcsec Repeatability: X 0.020 mm Z 0.020 mm Overall dimensions Length x Width x Height 11,000 x 6,600 x 7,500 mm Weight 79.000 kg Minimum Fused Disconnect 140 KVA

Year of construction: 2016, operating hours: 7,000 h, Condition: as good as new (ex-display), machine/vehicle number: 0012, Technical data: 1. Capacities - Maximum turning diameter with either Vertical Head 3300 mm - Maximum machining height under Cross Rail, at least 2000 mm - Maximum weight of the workpiece 20 tons 2. Table - Table diameter 3000 mm - Speed (inf. Variable) 1- 110 RPM - Main motor drive (AC) 100 KW - 4 jaw chuck with reversible jaws 3. Vertical Heads - Straight Ram vertical travel (250X250 mm cross section) 1300 mm - Horizontal and Vertical travel by means of 10 mm pitch ball screws 4. Cross Rail - Vertical Travel 2000 mm - Cross Rail elevating motor 7.5 KW AC 5. Feeds - Feed ranges 0.1 – 5 mm/rev - Rapid traverse feed 8000 mm/min 6. Overall Sizes - Dimensions (approx.) L x W x H 6600 x 5.300 x 5.400 mm - Weight (approximate) 60 tons GEOMETRICAL TESTS (ISO 3655, ISO 230-1; VDI 3441 and ISO 230-2) Positioning accuracy -X and Z axes mm +/-0,015/1000 Positioning repeatability -X and Z axes mm 0,010 Miwie7Iv CNC Fanuc
