Condition: excellent (used), Year of construction: 2010, Functionality: fully functional, Control: CNC-3 D path control system incl. Siemens 840 D Shop Mill TFT color display TECHNICAL DATA Travel Range: X-axis (longitudinal) 1035 mm Gslhcewvqxcjcqkobp Y-axis (transversal) 560 mm Z-axis (vertical) 510 mm Table working area 1200 x 560 mm Drive power (40/100% DC) 13/9 kW Speed range 20 – 10,000 rpm Tool holder (DIN 69871-1) SK 40 A Tool changer with double gripper Chain magazine Magazine positions 30 EQUIPMENT/ACCESSORIES - Chip and splash guard cabin with sliding door, electrically interlocked, and work area lighting - Automatic tool changer (double gripper/chain magazine) ATC 30 - Central lubrication - Spindle lubrication - Heat exchanger (work spindle) - Coolant system with filtration unit, 600 l, 20 bar belt filter system - ICS: Internal coolant supply through the tool - Switch-over from coolant to compressed air blow - Rinsing gun - Rotating viewing window - Chip conveyor with coolant tank - Infrared probe TS 649 - Tool measurement system TT 140 - Electrical cabinet cooling - 4-color signal light - Installation elements - Documentation

Condition: good (used), Year of construction: 1987, Control: CNC control including color display Traub TX 8 D with graphical simulation system TECHNICAL DATA Turning diameter 140 mm Turning length 220 mm Spindle bore (max. bar diameter) 42 mm Chuck diameter 140 mm Swing diameter -over bed 390 mm -over cross slide 200 mm Slide travel -longitudinal 220 mm -cross 140 mm Main drive Drive power (S1/S6 100/40% ED) 16/24.6 kW Max. speed (infinitely programmable) 5600 rpm Number of cross slides 2 Gjlhccjwu Dtwsqkjbp Rapid traverse X and Z axis 16 m/min Feed force X/Z axis 2800/3800 N Number of turrets 2 Tool stations 2x 12 Number of driven tools (upper turret) 6 Drive power (S1/S6 40/10% ED) 1.4/2.7 kW Shank diameter (DIN 69880) 30 mm EQUIPMENT/ACCESSORIES  Full enclosure with sliding door, electrically interlocked and work area lighting  Parts discharge unit  Drive for turret tools  Counter spindle in turret S 1, speed 5000 rpm, clamping diameter up to 42 mm  Tool holder for cut-off side machining with 3 fixed tools, mounting diameter 25 mm  Coolant system with 2-stage centrifugal pump 2 x 1.5/6 bar, tank capacity 120 l  Chip conveyor  Each 1 axial and 1 radial driven tool  Several fixed tools  Leveling elements  Documentation

Condition: excellent (used), Year of construction: 1990, Control: CNC contouring control including color screen TRAUB TX 8 D TECHNICAL DATA Swing diameter over longitudinal slide: 560 mm Swing diameter over cross slide: 445 mm Turning diameter: 360 mm Turning length: 1000 mm Chuck diameter: 250/315 mm Spindle bore: 80 mm Drive power: 40 kW Speed range: up to 40 - 3150 rpm Tool carrier: Number of turrets: 1 Number of tool holders: 14 Z-axis: 1070 mm X-axis: 285 mm Tailstock: -Quill diameter: 100 mm -Quill stroke: 100 mm EQUIPMENT/ACCESSORIES Gelhccowfrhwoqkobp Hollow clamping cylinder -Tailstock including live center -Coolant system: 300 l, 2-stage pump 1.5/5 bar  Chip conveyor  Central lubrication (with VOGEL piston distributor)  Measuring arm for measuring tools in the work area  Machine light  Three-jaw power chuck ø 250 mm FORKARDT 1512577 including clamping jaws  Mounting elements  Documentation

Condition: excellent (used), Year of construction: 2011, CNC twin-spindle turning center Control: CNC path control including 19" TFT Siemens Sinumerik 840 D sl solution line with ERGOline control and with ShopTurn 3 G TECHNICAL DATA Max. turning diameter 340 mm Spindle distance 1470 mm Turning length 1135 mm Swing over bed 700 mm Gjlhcowcd S Njcqkebp Swing to tool carrier 2540 mm Travel paths: X1 – Tool carrier I 270 mm Y1 – Tool carrier I 120 mm Z1 – Tool carrier I 1200 mm X2 – Tool carrier II 195 mm Y2 – Tool carrier II 80 mm Z2 – Tool carrier II 1200 mm X3 – Counter spindle slide 180 mm Z3 – Counter spindle slide 1200 mm Main spindle Integrated spindle motor ISM 102 Drive power (100/40% duty cycle) 40/48 kW Torque (100/40% duty cycle) 570/680 Nm Speed range 0-4000 rpm Bar diameter 102 mm Draw tube inner diameter 104 mm C-axis and spindle brake (angular resolution) 0.001° Counter spindle Integrated spindle motor ISM 76 Drive power (100/40% duty cycle) 25/32 kW Torque (100/40% duty cycle) 280/380 Nm Speed range 0-5000 rpm Bar diameter 65/75 mm C-axis (angular resolution) 0.001° Slide 1 Tool carrier (direct drive) Number of tools 12 Tool holder diameter VDI (DIN 69880) 40 mm Maximum power (100/40% duty cycle) 10.9/14.2 kW Maximum torque (100/40% duty cycle) 26/34 Nm Speed range 40 – 10,000 rpm Slide 2 Tool carrier (direct drive) Number of tools 12 Tool holder diameter VDI (DIN 69880) 40 mm Maximum power (100/40% duty cycle) 10.9/14.2 kW Maximum torque (100/40% duty cycle) 26/34 Nm Speed range 40 – 10,000 rpm Slide 3 Rapid traverse speed X/Z axis 30/45 m/min Tool resolution Z axis 0.001° Feed force (40% duty cycle) X/Z axis 16/13 kN EQUIPMENT/ACCESSORIES  IRCO ILS-RBK 100/16 short-bar loader  Various main spindle reducers  NC-controlled workpiece retrieval device from both the main and counter spindles The device consists of an NC-controlled *Horizontal axis *Swivel unit *Vertical axis *2-jaw gripper for interchangeable gripper jaws  Conveyor belt for removing workpieces from the machine  8/20 bar coolant system with immersion cooler  Chip conveyor  Oil mist extraction  Control cabinet cooling unit (up to 40°)  Counter spindle slide  Easy-Tool monitor  1 collet chuck for quick-change clamping head size 100 for the main spindle  1 collet chuck for quick-change clamping head size 100, Nova Achsfix for the counter spindle  Approx. 40 various quick-change clamping heads size 100 (complete inventory)  Pneumatic tool changer, ø 100 mm  Approx. 50 various tool holders, fixed and driven (complete inventory)  Mounting elements  Documentation

Condition: excellent (used), Year of construction: 2019, Functionality: fully functional, load capacity: 1,200 kg, 4 pallet transport trolleys used - For pallets measuring 12000 x 800 mm - 4 corner guards - Load capacity 1200 kg - Loading area 1210 x 810 mm Gbolhccqevzqigskjp Can be sold individually.

Condition: excellent (used), Year of construction: 2006, travel distance X-axis: 500 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 400 mm, As an OPTION we can offer a workpiece storage Eco-Tower 60 and a handling system LANG Technik GmbH. Control: 3D path control including 15" TFT screen Siemens 840 D solutionline with ShopMill Open user interface TECHNICAL DATA Travel range. X-axis (longitudinal) 500 mm Y-axis (transverse) 450 mm Z-axis (vertical) 400 mm Drive power (40/100% ED) 35/25 kW Speed range 20 - 18000 1/min Tool holder SK 40 Gelhccqovtaxujksbp NC swivel rotary table Clamping surface ø 500 x 380 mm B-axis swivel range 0/+ 108° C-axis swivel range 300° Tool changer (chain magazine) Number of tool positions 60 EQUIPMENT/ACCESSORIES  NC swivel rotary table with B and C axes and absolute measuring system including drive cooling of the B and C axes  Chain magazine with 60 tool positions with double gripper  Infrared measuring probe Heidenhain TS 649  Laser tool measurement for measuring tool length and diameter Calibration mandrel with tool holder  Internal coolant supply, 40/80 bar switchable; Delivery rate 23 l/min/11 l/min, container size 980 l Paper belt filter  IKZ = internal coolant supply 40/80 bar  Rotating viewing window  Sealing air for linear measuring system  Coolant unit for spindle and drives  Active control cabinet cooling  Oil emulsion mist separator with electrostatic filter  Flushing gun for chip flushing  Blowing air through the center of the spindle, selectable via M function  Chip conveyor, designed for 60 magazine positions  Operating mode 4; Process monitoring in production  Absolute position measuring systems in all axes (X, Y, Z, B + C)  Preparation for automatic handling system (loading through side window)  Installation elements  Documentation

Condition: excellent (used), Year of construction: 2008, travel distance X-axis: 750 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 520 mm, As an OPTION we can offer a workpiece storage Eco-Tower 60 and a handling system LANG Technik GmbH. Control: 3D path control including 15" TFT screen Siemens 840 D solutionline with ShopMill Open user interface Golhccqsvtar Iskebp TECHNICAL DATA Travel range. X-axis (longitudinal) 750 mm Y-axis (transverse) 600 mm Z-axis (vertical) 520 mm Drive power (40/100% ED) 35/25 kW Speed range 20 - 18000 1/min Tool holder SK 40 NC swivel rotary table Clamping surface ø 700 x 500 mm B-axis swivel range 0/+ 102° C-axis swivel range 300° Tool changer (chain magazine) Number of tool positions 120 EQUIPMENT/ACCESSORIES  NC swivel rotary table with B and C axes and absolute measuring system including drive cooling of the B and C axes  Chain magazine with 120 tool positions with double gripper  Infrared measuring probe Heidenhain TS 649  Laser tool measurement for measuring tool length and diameter Calibration mandrel with tool holder  Internal coolant supply, 40/80 bar switchable; Delivery rate 23 l/min/11 l/min, container size 980 l Paper belt filter  IKZ = internal coolant supply 40/80 bar  Rotating viewing window  Sealing air for linear measuring system  Coolant unit for spindle and drives  Active control cabinet cooling  Oil emulsion mist separator with electrostatic filter  Flushing gun for chip flushing  Blowing air through the center of the spindle, selectable via M function  Chip conveyor, designed for 120 magazine positions  Operating mode 4; Process monitoring in production  Absolute position measuring systems in all axes (X, Y, Z, B + C)  Preparation for automatic handling system (loading through side window)  Installation elements  Documentation

Condition: excellent (used), Year of construction: 2001, Functionality: fully functional, turning length: 1,000 mm, turning diameter: 480 mm, •Turret overhaul in 2021 •Cooling lubricant pump with higher pressure/output in 2021 •Draw tube renewed and headstock re-bearing and ground in 2022 •Prepared for automatic insertion of parts using a robot cell Control: CNC control including color screen Siemens 840 D TECHNICAL DATA Swing diameter max. 550 mm Turning diameter max. 480 mm Turning length 1000 mm Gslhccevr Tkzsqksbp Spindle bore 78 mm Drive power (50%) 53 kW Speed range (1-stage) 30 – 4000 1/min Drum turret Number of holders 12, of which 6 are driven Cylindrical shaft holder 40 mm Speed range (2-stage) 20 – 2500 1/min Tailstock (hydraulic quill adjustment) EQUIPMENT/ACCESSORIES  Full enclosure including work area lighting  Automatic power-operated sliding door  C. axis  Tailstock dragged via program including various centering points  12-way drum turret  Turret drive device  Chip conveyor  Coolant device with reinforced pump, approx. 4 bar  Interface for automation  Various accessories  1 Heimbuch Spanntop SK 80, without collets  1 Schunk Rota NCF 315 three-jaw chuck  1 Schunk Rota NCF 250 three-jaw chuck  1 Schunk Rota NCF 250 two-jaw chuck  1 WTO impact head  2 driven tools CAPTO-Axial tool  2 driven tools CAPTO-Axial Radial tool  3 driven tools CAPTO-Radial tool  7 fixed tool holders  Installation elements  Documentation

Condition: excellent (used), Year of construction: 1997, travel distance X-axis: 600 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 400 mm, controller model: SIEMENS 810 M, table width: 375 mm, table length: 800 mm, rotational speed (max.): 6,000 rpm, Control: CNC path control incl. screen SIEMENS 810 M TECHNICAL DATA Travel range X-axis 600 mm Y-axis 400 mm Z-axis 400 mm Table work surface 800 x 375 mm Drive power 10 kW Speed range up to 6000 1/min Tool holder (DIN 69871) ISO 40 Gjlhcceuiyb Noqkobp Automatic tool changer Number of tool holders 18 Tool diameter max. 150 mm EQUIPMENT/ACCESSORIES  Enclosure with electrically secured doors  Automatic tool changer ATC 18  Spindle orientation  Coolant device Water tank with submersible pump 2.5 bar  Chip tray  2 mechanical/hydraulic clamping vices, jaw width 125 mm  3 D measuring probe, mechanical with tool holder  Approx. 30 various tool holders, some with tools  Machine feet  Documentation Tool length max. 210 mm Tool change time 3 sec Feed range of the axes 0 - 10000 mm/min

Condition: excellent (used), Year of construction: 1995, Functionality: fully functional, turning length: 1,500 mm, turning diameter: 500 mm, Control: Cycle control with 14" color screen Grundig Manual Plus TECHNICAL DATA circulation diameter - over bed 500 mm - over cross slide 290 mm Face travel 260 mm Center distance 1500 mm Drive power (100% ED) 11 kW Speed range 8 - 2800 rpm Spindle bore 70 mm Tailstock Gelhccqotqdpwekebp -Quill diameter 80 mm -Quill stroke 180 mm -Quill holder MK 5 Tool holder Multifix quick-change holder size C EQUIPMENT/ACCESSORIES  Manual turning with handwheels  Turning with work cycles  Automatic turning  Tailstock with various centers  Multifix quick-change holder size 6 incl. various cassettes (approx. 8 pieces)  Three-jaw chuck ø 315 incl. clamping jaws  Four-jaw chuck ø 250 incl. clamping jaws  Closed steady rest  Open steady rest  Splash and chip protection thanks to sliding doors  Protective cover for chuck  Coolant device  Chip tray  Work area lighting  Set-up elements  Documentation

Condition: excellent (used), Year of construction: 2017, Functionality: fully functional, Only aluminum was processed. Control: CNC 5-axis control SIEMENS 828 D Si Touch Screen PPU 290 LCD 15Shop Mill TECHNICAL DATA Travel range: X-axis 620 mm Y-axis 520 mm Z-axis 460 mm B-axis +110°/-50° C-axis 360° Clamping table Table diameter 650 mm Workpiece size max. 520 x 330 mm Workpiece weight max. 300 kg Drive power (100% ED) 9 kW Speed range up to 12000 1/min Tool holder SK 40 Tool changer Number of tools 60 EQUIPMENT/ACCESSORIES  5-sided machining  Automation ZERO Clamp, type Zerobot 100 V Automatic feeding of workpieces including 2 zero-point clamps  3 D measuring probe Workpiece measurement  Table probe tool measurement (Hexagon m&h)  Automatic tool changer ATC 60  Rotary table with B/C axis HEIDENHAIN encoder  Linear guides in the X, Y and Z axes  Control cabinet air conditioning unit  Spindle oil cooler (active)  Central lubrication LHL  Coolant system  Internal coolant supply IKZ 30 bar with double filter system  Chip flushing  Air through the spindle Gslstp T Npehccqkebp  Water gun/air gun  Chip conveyor (scraper belt conveyor)  Chip trolley  Ethernet, USB & RS 232 interfaces  Electronic handwheel  Work area lighting LED  3-color signal lamp LED  Machine set-up elements  Documentation

Year of construction: 2002, Condition: excellent (used), Functionality: fully functional, Control: CNC path control, incl. 15" TFT color flat screen HEIDENHAIN TNC 430 TECHNICAL DATA Working range X-axis (longitudinal) 880 mm Y-axis (transverse) 630 mm Z-axis (vertical) 630 mm Table clamping surface 1,250 x 700 mm NC top table (cover 18/L01) Clamping surface ø 700 mm Height 280 mm Can be used for horizontal and vertical machining NC swivel milling head (B-axis) Swivel range 103° (-91/+12°) Drive power (40/100% ED) 15/10 Kw Speed range up to 12,000 min-1 Tool holder (DIN 69871) SK40 EQUIPMENT/ACCESSORIES  Closed work area with revolving door, electrically fused, incl. machine light  NC swivel milling head (B-axis)  Motor spindle SK40/12,000 min.-1  Automatic tool changer (pick-up) ATC 32  3D measuring probe Heidenhain TS 642  Operating mode 4 (extended manual intervention)  Direct path measuring systems (resolution 0.001°)  Electronic handwheel  Production package, consisting of 600 l tank, rotating viewing window, chip flushing in the work area  IKZ-Internal coolant supply through the spindle 40 bar form AD  Spiral chip conveyor with chip ejector  External coolant nozzles switchable from water to blast air  Switch cabinet cooler  Support elements (3 wedge shoes, height-adjustable) Gslhccqsrby H Sekobp  Documentation

Condition: excellent (used), Year of construction: 1985, Control: CNC path control incl. screen Heidenhain TNC 155 TECHNICAL DATA Working range X-axis 630 mm Y-axis 500 mm Z-axis 460 mm Mounting height table vertical milling head max. 559 mm Clamping table Clamping surface vertical 397 x 550 mm Angular table table clamping surface 500 x 1000 mm Drive power 6.0/8.0 kW speed range 31,5 - 3150 rpm Tool holder (with feed groove) ISO 40/M 16 EQUIPMENT/ACCESSORIES  Swiveling vertical milling head, rotatable by 90°.  Vertical/horizontal machining Gjlhccsl Uxq Tjqksbp  Swiveling device for vertical milling head  Rigid angular table 1000 x 500 mm  Vertical quill  Automatic quick tool clamping, hydraulic for horizontal and vertical work spindle  Machine light  Automatic central lubrication  Coolant unit approx. 100 l  Chip collection tray under the milling table, removable  Electronic handwheel  Serial interface  Set-up elements  Documentation

Condition: excellent (used), TECHNICAL DATA Footprint 10.0 x 6.6 m total height 3,2 m drive-through height approx. 2.6 m hook height approx. 2.2 m 1 trolley 500 kg 1 trolley 250 kg Equipment/accessories - Supports for the crane field - cross connections - Connecting parts - Plug-in electrics - 1 trolley 250 kg - 1 trolley 500 kg Gbslhccqel Rb Nrokjp

Year of construction: 1998, Condition: excellent (used), Control: CNC-controlled and manually controlled PC P 2000 MMX-PCI Desktop ATX color screen 15", keyboard CNC-Turbo roughness for WINDOWS TECHNICAL DATA Hard stone test plate (DIN 876) length x width 1200 x 500 mm Accuracy grade 2 Flatness 16,6 µm Gbelhccqjlxyqcokop Weight 250 kg Linear feeder Waveline 60 Basic Probe length 60 mm Resolution 0.014 µm Measuring column Wavelift 400 CNC Travel 400 mm Positioning repeatability ˂ 10 µm Device dimension W x D x H 1.8 x 0.8 x 2.2 m Weight 600 kg EQUIPMENT/ACCESSORIES  Complete enclosure with electrically operated roller blinds with electrically operated roller blinds  hard stone plate 1200 x 500 mm  ISEL-feed axis with ball screw drive  Workpiece mounting plate  Linear feed unit Waveline 20/60  Measuring column Wawelift 400 CNC  Tilting unit KEG 60 at the measuring column, manual to the Waveline  Installation kit for roughness measurement  Probe and holder for roughness measurement  Device table  Emergency stop button on the instrument table  Maintenance unit for compressed air preparation  Air damping elements for mounting the hard stone plate  Documentation

Year of construction: 1999, Condition: excellent (used), Control: CNC-controlled and manually controlled PC P 2000 MMX-PCI Desktop ATX color screen 15", keyboard CNC-Turbo roughness for WINDOWS TECHNICAL DATA Hard stone test plate (DIN 876) length x width 1200 x 500 mm Accuracy grade 2 Flatness 16,6 µm Weight 250 kg Linear feeder Waveline 60 Basic Probe length 60 mm Resolution 0.014 µm Measuring column Wavelift 400 CNC Travel 400 mm Positioning repeatability ˂ 10 µm Gbolhjlxyp Hsccqkop Device dimension W x D x H 1.8 x 0.8 x 2.2 m Weight 600 kg EQUIPMENT/ACCESSORIES  Complete enclosure with electrically operated roller blinds  hard stone plate 1200 x 500 mm  ISEL-feed axis with ball screw drive  Workpiece mounting plate  Linear feed unit Waveline 20/60  Measuring column Wawelift 400 CNC  Tilting unit KEG 60 at the measuring column, manual to the Waveline  Installation kit for roughness measurement  Installation kit for contour measurement  Various probes and holders for roughness and contour measurements  Instrument table  Emergency stop button on the instrument table  Calibration set  Support prisms  Maintenance unit for compressed air preparation  Air damping elements for mounting the hard stone plate  Documentation

Year of construction: 1980, Condition: excellent (used), TECHNICAL DATA Grinding area L x W x H 700 x 400 x 500 mm working range: *longitudinal 780 mm *across 350 mm *vertical 500 mm table clamping surface 1020 x 300 mm table load max. 1400 kg magnetic clamping plate 700 x 300 mm drive power grinding spindle 11 kW grinding wheel dimension 400 x 80 x 127 mm vertical movement: *automatic rough infeed 5- 50 µm *automatic fine infeed 1 - 10 µm operating voltage 380 V/50 Hz total power 12,86 kW machine dimension L x W x H 2,5 x 1,7 x 2,5 m Machine weight 3100 kg EQUIPMENT/ACCESSORIES  Standard accessories  Electro-magnetic plate 700 x 300 mm  various grinding wheel flanges  grinding program with automatic dressing and dimensional compensation  multiple dressing unit  copy dressing unit  side dresser  ELESTA digital measuring device, 2 axes  Drive power 11 kW  Belt filter unit with magnetic separator Gbelhslmkydsccqkop  Documentation

Year of construction: 2006, Condition: excellent (used), Control: CNC path control incl. LCD color flat screen SIEMENS 840 D TECHNICAL DATA Working range x-axis 520 mm y-axis 300 mm z-axis 360 mm throat 350 mm table spindle nose min/max 200/560 mm rotary table diameter 1095 mm Gslsk N Dtmshccqkebp pallet swivel table 2 x (700x350) mm swivel range 2 x 180 ° drive power 11 kW speed range 36 - 12000 rpm Tool holder HSK 63 Automatic tool changer Number of tool places 42 EQUIPMENT/ACCESSORIES  180° pallet swivel table for loading and unloading during machining time  Automatic tool changer ATC 42, outside of chip and coolant area and coolant area  Closed work area  Coolant unit with high pressure pump  IKZ - internal coolant supply through the spindle 20 bar  Flushing gun  Work area exhaust  Chip conveyor  Switch cabinet cooler  Serial interface  Socket 220 V  Installation elements  Documentation

Condition: excellent (used), Year of construction: 1997, TECHNICAL DATA Number of bays 5 Bay width 2600 mm Bay load per compartment max. 2600 kg Geleir Iwuohccqksbp Max. bay load per bay 9540 kg Support profile INP 100 Total length 14 m Shelf height max. 750 mm Depth 0.9 m Height 4.6 m

Condition: excellent (used), Year of construction: 1975, The year of manufacture is estimated, but from the 70s. Partially overhauled, geometry checked (in tolerence range). TECHNICAL DATA center height 125 mm grinding diameter 250 mm grinding length 750 mm spindle power 3 kW Grinding headstock speed range 1500-2420 1/min grinding wheel dimension ø 400x50x127 mm Work headstock Speed range (infinitely variable) 25 - 450 1/min Rotatable 90 spindle cone MK 5 Tailstock Gslhcsid Sqwocqkobp Quill mount MK 3 Table feed (infinitely variable) 100 - 6000 mm/min inclination max. 10° EQUIPMENT/ACCESSORIES tailstock with cross fine adjustment coolant device Splash guard 1 flange with diamond grinding wheel 2 further flanges Set-up elements

Condition: like new (used), Position 1 TS 125 Magnum tower clamping system Jaw width 125 mm Clamping widths: 1 x 476 mm 2 x 226 mm 4 x 108 mm overall height 780 mm Clamping stroke per clamping slide 64 mm Clamping force 40 kN Price: 7.850,00 € + VAT. Position 2 4 pieces hydraulic vices Gelhsidl Rrsccqkjbp jaw width 125 mm overall length 400 mm Price per piece 850,00 EURO + VAT. Price for 4 pieces 3.000,00 EURO + VAT. Position 6 Preci Tool NC, type 125 jaw width 125 mm overall length 430 only 1 fixed jaw Price: according to bid position 8 HILMA machine vice with rotary plate mechanical/hydraulic clamping force 40 daN jaw width 125 mm overall length 430 mm Price: 850,00 € + VAT. Position 9 HILMA machine vice mechanical/hydraulic clamping force 50 daN jaw width 160 mm overall length 550 mm Price: 900,00 € + VAT. item 10 HILMA machine vice mechanical/hydraulic clamping force 25 daN jaw width 100 mm overall length 380 mm Price: 650,00 € + VAT. item 11 HILMA machine vice with rotary plate mechanical/hydraulic clamping force 40 daN jaw width 125 mm overall length 430 mm Price: 850,00 € + VAT. position 12 HILMA machine vice with rotary plate mechanical/hydraulic clamping force 50 daN jaw width 160 mm overall length 620 mm Price: 1.050,00 € + VAT. Position 26 HILMA machine vice (exhibition version) jaw width 125 mm overall length 430 mm Price: according to bid item 28 HILMA machine vice mechanical/hydraulic clamping force 25 daN jaw width 100 mm overall length 570 mm Price: 700,00 € + VAT. Position 32 Clamping angle clamping surface 160 x 420 mm Price: 150,00 € + VAT. Position 33 Clamping angle with HILMA vice jaw width 125 and load cell Price: 450,00 € + VAT.

Condition: like new (used), Position 1 TS 125 Magnum tower clamping system Jaw width 125 mm Clamping widths: 1 x 476 mm 2 x 226 mm 4 x 108 mm overall height 780 mm Clamping stroke per clamping slide 64 mm Clamping force 40 kN Price: 7.850,00 € + VAT. Position 2 4 pieces hydraulic vices jaw width 125 mm overall length 400 mm Price per piece 850,00 EURO + VAT. Price for 4 pieces 3.000,00 EURO + VAT. Position 6 Preci Tool NC, type 125 jaw width 125 mm overall length 430 Gbolhccjic Rnueqksp only 1 fixed jaw Price: according to bid position 8 HILMA machine vice with rotary plate mechanical/hydraulic clamping force 40 daN jaw width 125 mm overall length 430 mm Price: 850,00 € + VAT. Position 9 HILMA machine vice mechanical/hydraulic clamping force 50 daN jaw width 160 mm overall length 550 mm Price: 900,00 € + VAT. item 10 HILMA machine vice mechanical/hydraulic clamping force 25 daN jaw width 100 mm overall length 380 mm Price: 650,00 € + VAT. item 11 HILMA machine vice with rotary plate mechanical/hydraulic clamping force 40 daN jaw width 125 mm overall length 430 mm Price: 850,00 € + VAT. position 12 HILMA machine vice with rotary plate mechanical/hydraulic clamping force 50 daN jaw width 160 mm overall length 620 mm Price: 1.050,00 € + VAT. Position 26 HILMA machine vice (exhibition version) jaw width 125 mm overall length 430 mm Price: according to bid item 28 HILMA machine vice mechanical/hydraulic clamping force 25 daN jaw width 100 mm overall length 570 mm Price: 700,00 € + VAT. Position 32 Clamping angle clamping surface 160 x 420 mm Price: 150,00 € + VAT. Position 33 Clamping angle with HILMA vice jaw width 125 and load cell Price: 450,00 € + VAT.

Condition: good (used), Year of construction: 1983, Control: Positioning and linear control incl. screen HEIDENHAIN TNC 135 3-axis manual input control TECHNICAL DATA Working range X axis (longitudinal) from manual/automatic 410/390 mm Y-axis (transverse) from manual/automatic 310/290 mm Goljht Hbuohccqkjbp Z-axis (vertical) from hand/automatic 400/380 mm quill stroke vertical 63 mm Angular table clamping surface 700 x 285 mm drive power (at 1500 rpm) 2,2 kW speed range 45 - 2000 rpm Number of speeds 12 Step change (geometrically stepped) 1.4 Tool holder (DIN 2079) ISO 40 EQUIPMENT/ACCESSORIES operation by hand and by CNC program vertical and horizontal machining vertical milling head tiltable vertical milling head angle adjustable spindle sleeve feed vertical, manual angular table Coolant device Coolant and chip tray Chip splash guard in working area Set-up elements Documentation

Condition: excellent (used), Year of construction: 1996, Control: CNC path control incl. screen ZIMMER + KREIM TECHNICAL DATA Traversing range X-axis 570 mm Y-axis 400 mm Z-axis 415 mm C-axis 360 Resolution Gbelhohq A T Asccqkjp X, Y, Z 0.001 mm C 0,001 angular degree table clamping area 840 x 600 mm Dielectric over table 360 mm 4 T-slots 10 mm table load max. 1000 kg Distance table - quill 620 mm Automatic electrode changer Number of electrodes 50 Electrode weight - without rotation 100 kg Electrode weight - with rotation 15 kg Rapid traverse 800 mm/min EQUIPMENT/ACCESSORIES Pallet changer 6-fold Automatic electrode changer 50-fold C-axis ADAPTI MAT 04 - monitoring and regulation device PEG 90 - generator chuck EROWA IST with 3 receptacles Machine light Electronic handwheel Cooling unit for dielectric Automatic CO2 extinguishing system C-Box Zimmer + Kreim Purge distributor 14-fold Purge volume controller 15-fold 1 pallet pick-up system UPC 2 pallets Set-up elements Documentation

Condition: excellent (used), Year of construction: 1983, Control: Freely programmable control Grinding modes: External grooving External longitudinal grinding Internal grinding Straight grooving Oblique grooving Dressing from the front automatically programmed TECHNICAL DATA Working range centre height 125 mm centre width 650 mm grinding diameter min./max. 0,2/240 mm grinding length max. 650 mm Grinding length for plunge-cut grinding max. 80/100 mm grinding depth max. 170 mm Grindable bore min./max. 2.5/90 mm workpiece weight max. 80 kg Grinding headstock swivelling + 45 grinding wheel diameter 400 mm grinding wheel width 20 - 50 mm Spindle speeds 6 speed range 2130 - 1270 rpm Drive power 6,25 kW Motor speed 3000 rpm Work headstock spindle bore 30 mm Mounting inner cone MK 5 Swivelling capability 90 Roundness accuracy 0.0004 mm Spindle speeds 30 - 675 rpm Gbelhcoha Nktecqkep EQUIPMENT/ACCESSORIES Movable splash guard at the front Grinding headstock Swivelling work headstock Tailstock with fine adjustment, hydraulic retraction and insert for centres MK3 Protective hood for grinding wheels ø 400 x 50 mm width can be swung in Coolant system with paper belt filter 36 l/min at 0,4 bar Internal grinding device Three-jaw chuck with insert Magnetic chuck with insert Counter steady Adjustable diamond holder with dial gauge graduation 0.002 mm Hydraulically retractable dressing device with dial gauge graduation 0.002 mm Air lifting of the table with oil mist device Contact display and control SENSITRON Oil
