Used Broaching & slotting & drawing machines for sale (176)

Year of construction: 1991, condition: ready for operation (used), y 018 Broaching Machine – Vertical Manufacturer: Hönnema Typ: HSR 9/1250 RST Machine number: 166/HM 510275 Ljdpfxohf A I Nj Ah Esru Year of manufacturing: 1991 Force: 9 Tons Stroke: 1.250 mm Area required: approx. 230 x 120 cm With automatic feed External broaching possible with device

Condition: excellent (used), functionality: fully functional, Slotting machine Urpe model M-300 G of tilting head, Slotting of course of 0-300mm of travel, number of blows per minute 30-35-40, distance of the tool to the column 500mm, distance adjustable from the table to the ram 425 -585mm, max distance between tool and body 450mm, table surface 800x325mm, long table travel 550mm, rec transv 265mm, motor pot 5.5cv, estimated weight 1850kg, with Chuck Lrjdpfxovdknze Ah Eou

Condition: ready for operation (used), Vertical - broaching machine Rausch Type RSIZ 6 / 1000 S Condition is used technical data: Lsdpfx Aodyp Rmjh Ejru Working range : up to 1000 mm Cutting speed 3 to 5 m/min Return speed 10 m/min Interior: largest workpiece diameter 600 mm Outer chambers: area of the clamping plate 600 x 340 mm Coolant device Tensile force measuring device Automatic central lubrication Spindle protection by spring band spirals Chip conveyor shut-off counter Dimensions: 1.05 m x 0.9 m x 4.3 m Weight 1200 kg Self-collection or forwarding. We will be happy to help you organize an inexpensive forwarding agent. You are welcome to visit us for a viewing. You will receive a proper invoice. A net invoice can also be issued for foreign customers. Prerequisite is a valid VAT number. Subject to prior sale. Company names and trademarks are the property of their owners and serve only to identify and describe the products. The machines and tools are sold as is. The installation and electrical connection of the machine/device must be carried out or checked by a trained specialist. Deviations from technical data and errors in the description of the item may occur and are reserved.

Year of construction: 1991, condition: excellent (used), Slotting machine Elmass, suitable for keyways up to 14mm width. Maximum working stroke 200mm. With this Elmass system, thanks to the bore-guided tool, it is possible to push even extra-long keyways. Lrodpfx Ajld S S Ssh Eju Tools for standard bores of diameter 6-50mm, slot widths of 2-14mm are available. This tool system is also suitable for blind holes. Thanks to the 400mm rotary table, multiple keyways can also be cut.

Condition: good (used), Grooving machine - Joint length: 300 mm - Groove width: max. 32 mm - Smallest bore: 40/17/6 mm - Cutting speed: 5 m/min - Face plate diameter: 360 mm - Driving power: 1,1 PS - Weight: approx. 220 kg - Outer dimensions: approx. 780 x 400 x 120 mm Good condition fully functional can be inspected and tried on site. Shipping also abroad. Lrsdemidmzspfx Ah Esu Viewing : Basically, I would like to point out that to avoid misunderstandings, the item is welcome to be inspected and tested under power before purchase. Please ask questions before buying to avoid ambiguity. For general questions or to make an appointment for a viewing, I am, at the phone number below or above, always available. Errors in the description and subject to prior sale. VAT is shown separately on my invoices. Shipping with forwarding agent.

Condition: new, functionality: fully functional, Year of construction: 2025, overall weight: 11,000 kg, total length: 80,510 mm, total width: 42,180 mm, total height: 2,500 mm, LASER fr metal sheet and tube cutting Lrjdpfx Ajxlk U Hsh Eeu

Year of construction: 1963, condition: used, machine/vehicle number: 18135, Broaching Machine – Horizontal Manufacturer: Forst Typ: RIW 100/2200 Force: 100 Tons Stroke: 2.200 mm It is possible to buy the Crane - see offer no Y941 Lrjdpfxobrcy Ns Ah Eju

Condition: new, Year of construction: 2025, Machine for machining various internal and external surfaces, mainly keyways. Widely used in repair shops and tool shops, in single and small batch production. Machine for machining various internal and external surfaces, designed for precise work, especially grooves. It is widely used in overhaul shops and tool shops, both in unit and small batch production, making it a versatile tool for various industries. Main features of the machine: Hardened and ground guides: ensure maximum durability and precision, guaranteeing longevity and high quality machining. Ljdpfxeuyhxmo Ah Eeru Tilting chisel head of +/- 30°: Allows flexibility in machining surfaces at different angles, increasing the versatility of the machine. Built-in lubrication system: Automatic lubrication of the workpieces, which reduces friction, increases machine life and minimises the need for manual maintenance. Adjustable stroke speed per minute - 6 settings: Allows the speed to be adjusted to suit the specific material and type of machining being carried out, improving accuracy and efficiency. This machine is ideal for both small batch production shops and those that need high precision when overhauling or reconditioning tools. Thanks to modern features such as the ability to adjust the speed, users can easily adapt the operation of the machine to their individual needs, increasing efficiency and saving time. Technical specifications Maximum stroke 125 mm Minimum number of strokes 60 / min. Maximum number of strokes 350 / min. Number of speed steps 6 Head rotation 90º Table dimension 500x200 mm Table travel X/Y 220 mm Z axis travel 200 mm Motor power 0.37 kW Overall dimensions 800 x 750 x 1550 mm Weight 290 kg Knife shank dimensions Ø 10 / Ø 16 mm or 16 mm square shank

Condition: like new (used), Year of construction: 2022, functionality: fully functional, total length: 2,900 mm, total height: 1,500 mm, total width: 1,600 mm, type of input current: three-phase, For sale is a Maqford BEA2 forming machine. Working length 150-1500mm, sheet thickness max. 2.0mm, pipe diameter 120-600mm. Including a set of packages for individual diameters. Lredpowmniajfx Ah Eeu

Condition: excellent (used), Utilaj de rectificat in coordonate Ledpfxjw Nmiie Ah Ejru

Year of construction: 2013, operating hours: 3,710 h, condition: excellent (used), functionality: fully functional, machine/vehicle number: -, Cold rolling line DEM MTO 760/2 Year 2013 Motor hours: 3710 Units and components: 1. SVV/2 twin vertical axis coil decoiler 2. RD 140/1 mechanical scale breaker 3. SA-CLR lubrication unit 4. MTO 760/2 2-block cold rolling machine 5. BOM 1250 horizontal axis winder 6. Electrical cabinet Lsdpfx Ahevduwms Ejru 7. Operator control panel. We will answer any additional questions in writing.

Year of construction: 1989, condition: excellent (used), machine/vehicle number: 0435532, MACHINE DATA Machine type Hobbing Cutter – Gear cutter Manufacturer TOS Model FO-10 Year 1989 Lredpfx Aod R Ri Ueh Eju Serial Number 0435532 Condition Very good-almost new Yet in operation Max Module 14 Min Module 1.5 Max diam. 1500mm Max Width 450mm From Z9 teeth until Z448 Main drive 12 Kw Weight 9800Kg Original color RAL 6017 Book operation – service Dimensions L 3200 – W 1800 – H 2530 Full extra accessories – parts – all module cutters Ready to work without any expensive PRICE 70.000€

Year of construction: 1992, condition: used, machine/vehicle number: 148, Broaching Machine – Vertical Hard Broaching Machine Manufacturer: Forst Typ: RISZ 6,3 x 1000 x 320 Machine number: 148 Year of manufacturing: 1992 Force max.: 80 kN Lrjdpodnk T Aefx Ah Eeu Stroke max.: 1.000 mm Weight: approx. 10 Tons (Machine+Control Cabinet+Hydraulic aggregate)

Condition: used, BROACHING MACHINE Ledpfjt Hr Dfox Ah Eoru

Condition: ready for operation (used), Romanian Slotters MH500, M 320 And M 200 Lrodpfx Ahjtz S Hce Eou Stroke 500mm, 320mm and 200mm

Condition: used, Technical details: max. ram stroke: 250 mm workpiece diameter - max.: 80 mm Lrodpfx Aew Au I Ieh Eeu max. workpiece length: max. 900 total power requirement: 1,5 kW weight of the machine ca.: 2,1 t

Year of construction: 2011, condition: excellent (used), functionality: fully functional, Tool travel : 0-315 mm Strokes per minute : 14 - 60 Ram adjustment : 235 mm Swivel angle of head : ±45° Head to table distance : 510 mm Tool to column distance : 460 mm Diameter of rotating table : 450 mm Lredjvfctfspfx Ah Eju Diameter of central hole of rotating table : 80 mm Number of fixed positions of rotating table : 24 Longitudinal travel of worktable : 265 mm Transverse travel of worktable : 200 mm Self-breaking main motor : 4 kW / 5.5 h Weight : 1310 kg Overall dimensions : 1000 x 1500 x 2250 mm

Condition: good (used), overall weight: 10,364 kg, Year of construction: 2019, 2019 GENERAL BROACH 10-30 GBTU VERTICAL TABLE UP BROACH Equipped with: Retriever Shuttle Table Chip Conveyor Auto Load Grayco Lube AB Panelview Coolant Tank & Pump Specifications: Capacity: 10 Ton Stroke: 30" Table Up 1″ Puller / Retriever Hydraulic Power Unit Chip Conveyor Lrodpfxertrzae Ah Esu Machine Dimensions (approx.): 165″ x 48″ x 60″ Machine Weight Total (approx.): 22,800 lbs. Machine Column (approx.) : 13,000 lbs. Base w/ Chip Conveyor (approx.): 4,700 lbs. Electrical Panel (approx.): 600 lbs. Hydraulic Power Unit (approx.): 4,500 lbs.

Year of construction: 1995, condition: used, machine/vehicle number: 20225, Color: green Slighty used! DIN 1415 Lrodsbrcmfspfx Ah Esu Impetus electromechanic

Condition: used, Year of construction: 2007, Technical details: pulling force - max.: 9 t Lrjdpow Duggefx Ah Eeu max. ram stroke: 2000 mm max. workpiece diameter: 900 mm total power requirement: 25 kW FRÖMAG electromechanically driven internal vertical broaching machines FSR guarantee economy and efficiency thanks to their special design features. Economy and efficiency. The drawbridge of the machine is designed so that broaching tool holders can be accommodated in accordance with market requirements. can be accommodated. The ball screws used to drive the drawbridge as well as the additionally hardened and ground round guides in conjunction with the together with the adjustable three-phase motors ensure that the machine runs very smoothly. Accessories such as feeds, shim controls, sliding tables, etc. make machine operation easier and enable machine operation and enable automation and integration into linking systems. *

Year of construction: 1948, condition: used, Technical details: max. ram stroke: 450 mm table diameter: 800 mm min. ram stroke: 65 mm workpiece height max.: 600 mm ram adjustment: 600 mm no. of ram strokes: 18; 22; 28; 35; 45; 56 Hub/min. cross feed of the table: 800 mm longitudinal feed of the table: 1000 mm table rotation: 360 ° feed: Tisch: pro Hub: 0,14 - 0,22 - 0,35 - 0,56 - 0,9 -1,4 mm/Hub total power requirement: 7,8 kW Lrsdpfx Aeu Ng Tbeh Eou weight of the machine ca.: 6,25 t dimension machine xH: 2,8 x 1,9 x 3,0 m other features: Ram: -the ram is adjustable in the projection of 900mm -throat of bed = 700mm Tool clamp by means of bracket clamp (dimensions 350 x 250mm) Accessories: 1piece 3-jaw chuck Ø 250mm *

Condition: used, Year of construction: 2000, Technical details: pulling force - max.: 2,5 t max. ram stroke: 1000 mm max. workpiece diameter: 40 mm Broaching speed: 60 m/min. return speed: 20 m/min. total power requirement: 24 kW weight of the machine ca.: 6 t Lodpfx Ahew Dugae Esru dimensions of the machine ca.: 1,7 x 2,4 x 4,77 m clamping plate: 320 mm

Condition: used, Year of construction: 1954, Technical details: max. ram stroke: 220 mm workpiece diameter - max.: 400-450 mm total power requirement: 1,5 kW Lsdpsv Ty R Djfx Ah Eeru work table:: 650x250 mm ram adjustment: 100 Manuell mm no. of ram strokes: 45/78/125 table adjustment: 400 längs mm table adjustment: 150-170 quer mm table adjustment: ca. 360 vertikal mm tool - head swivelling: +/- 10 Grad total power requirement: 1,5 kW weight of the machine ca.: 0,9 t dimension machine xH: 1,2 x 0,9 x 1,8 m

Year of construction: 1948, condition: used, Technical details: max. ram stroke: 180 mm adjustment of stroke: 100 mm no. of ram strokes: 45 / 73 / 125 Hub/min distance table/ram: 400 mm Lredju Ng Tnjpfx Ah Eju work table:: 650 x 250 mm total power requirement: 2,0 kW voltage: 380 V dimension machine xH: 1,3 x 1,0 x 1,9 m VERTICAL BROACHING MACHINE for the machining of keyways on flanges and/or bushes table adjustment: lengthwise=420 mm manual / 400 mm automatic, crosswise=150mm; vertical=300mm mechan. Drive The stroke is adjusted on the crank disk by means of a threaded spindle. Inclined position of the ram guide with ram 10° Rotation of the drive disk per min. = 400 rpm. The machine does not comply with the legal safety requirements of the UVV (UVV = accident prevention regulations) . Sold as is, without test. *

Year of construction: 1963, condition: used, Technical details: max. ram stroke: 150 mm workpiece diameter - max.: 250 mm slot width: 50 mm feed speed: 10 m/min. adjustment of stroke: ja mm voltage: 380 V work table:: Ø 250 mm total power requirement: 6,0 kW weight of the machine ca.: 1,05 t dimension machine xH: 1,2 x 0,8 x 1,6 m Ledpfxeu Ng T Uo Ah Ejru Application: For the internal grooving of flanges Drawing needle specifications: -total length = 650mm -Width = 10; 20; 30; 50mm -Drawing length = approx. 150mm Lubrication takes place via the drawing needles. Equipment: 4 different drawing needle guides (5; 22; 32 and 50mm) 50 different flange holders 23x drawing steel holders shank 18mm; 12x shank 22mm; 7x shank 26, 30, 40 and 45mm incl. accessories see photo i.D. *
