Used machining centers (vertical) X-axis travel 1700mm for sale (182)

Condition: good (used), Year of construction: 2000, CNC Machining Center IBARMIA ZV 40, L 2200 Year of manufacture: 2000 ————— Technical data: X-axis: 2200 mm Z-axis: 600 mm Y-axis: 600 mm WORK TABLE Number of T-slots: 5 Size of T-slots: 18 mm Distance between T-slots: 125 mm Minimum/maximum distance spindle nose/table (optional): 200 (800/1000) mm WORKING SPINDLE Tool holder: SK 40 DIN 69871 Pull stud for tool holder SK: DIN 69872 Tool clamping force SK: 12,000 N Inner bearing diameter: 80 mm Max. standard speed: 8,000 min⁻¹ DRIVE POWER Main spindle motor at 100% (intermittent): 29 (38.5) kW Constant power at standard version from: 1,500 min⁻¹ FEED Power in X, Y, Z at 100% (intermittent): 13,000 (16,000) N Rapid traverse rate in X, Y, Z: 30 m/min Max. working feed rate in X, Y, Z: 10 m/min PERFORMANCE Milling performance in steel St 60: 650 cm³/min Drilling performance in steel St 60: Ø 60 mm Thread cutting performance in steel St 60: M36 TOOL MAGAZINE Number of tool positions (optional): 24 (40–52) Tool length max.: 300 mm Tool weight max.: 10 kg Tool diameter max. with full magazine: 85 mm Tool diameter max. with free adjacent positions: 125 mm Tool management: Random Tool change time: 3.5 s Tool change time "chip-to-chip": 7 s GENERAL Structural paint in 2 colors: RAL gray 7037 / blue 5012 Electrical connection: 55 kW Operating voltage: 400 V / 50 Hz Compressed air connection: 6 bar Coolant pump: 0.75 kW Hedpfxjzv Sk Rs Andonu

Condition: excellent (used), Year of construction: 2003, functionality: fully functional, General Information Machine Type: Vertical Machining Centre, Travelling Column Control Unit (CNC): MAZATROL Fusion 640M Year of Manufacture: 2003 Number of Axes (Controlled): 3 (Standard), 4 (Optional with rotary table) Travels and Working Area X-Axis Travel (Longitudinal): 1740 mm Y-Axis Travel (Cross): 760 mm Z-Axis Travel (Vertical): 660 mm Table Length: 2000 mm Table Width: 760 mm Maximum Workpiece Weight (Table Load): 1400 kg Hsdpfx Ajx Ezntendsnu Spindle and Performance Spindle Taper: SK 40 (or ISO/BT 40) Maximum Spindle Speed: 12 000 min$^{-1}$ (rpm) Main Spindle Motor Power: 18.5 kW (Kilowatts) (Often a 10-min rating, continuous power may be lower) Rapid Traverse Rate (X-Axis): Up to 42 m/min (Metres per minute) Rapid Traverse Rate (Y/Z-Axes): Up to 36 m/min (Metres per minute) or 42 m/min (depending on configuration) Cutting Feed Rate: Up to 36 000 mm/min Tool Changer (ATC) Tool Magazine Capacity: 30 tools (Standard), 48 tools (Optional) Maximum Tool Weight: 8 kg Maximum Tool Length: 350 mm Maximum Tool Diameter (with adjacent tools): 80 mm Maximum Tool Diameter (without adjacent tools): 110 mm Machine Dimensions and Weight Machine Length (L): Approx. 4450 mm Machine Width (W): Approx. 3460 mm Machine Height (H): Approx. 3100 mm Machine Weight: Approx. 11 500 kg (11.5 tonnes) Coolant Tank Capacity: Approx. 450 l (Litres) Total Power Requirement: Approx. 46.7 kW Air Pressure Required: 5 - 9 bar

Condition: ready for operation (used), Year of construction: 2005, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 920 mm, controller manufacturer: HEIDENHAIN, total height: 7,870 mm, total width: 3,650 mm, table load: 9,000 kg, overall weight: 34,000 kg, spindle speed (max.): 3,800 rpm, product length (max.): 3,760 mm, number of axes: 3, This 3-axis HARTFORD HB 3150/S vertical machining centre was manufactured in 2005. It features a generous table size of 3000 x 1500 mm and impressive axes strokes of 3000 x 1500 x 920 mm. The machine has a maximum rotation speed of 3800 rpm and a forward speed of 10000 mm/min. If you are looking to get high-quality machining capabilities, consider the HARTFORD HB 3150/S machine we have for sale. Contact us for further details. Hnjdpfx Asy Al S Rendeu • Table dimensions (X/Y): 3000 x 1500 mm • Forward speed (feed rate): 10000 mm/min • Power requirement: 50 kVA

Condition: good (used), Year of construction: 2004, functionality: fully functional, travel distance X-axis: 2,500 mm, travel distance Y-axis: 900 mm, travel distance Z-axis: 900 mm, operating hours of spindle: 44,377 h, coolant supply: 40 bar, spindle nose: HSK 63, number of slots in tool magazine: 30, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, The machine is fully operational and can be inspected while powered on. Deckel Maho DMF 250 Year of manufacture: 2004 X-axis: 2500 mm Y-axis: 920 mm Z-axis: 820 mm B-axis: +/- 105° Work table: 3100 x 900 mm Spindle: HSK 63 Spindle speeds: 20 - 18,000 rpm Tool changer: 30 tools Control system: Heidenhain iTNC 530 Equipped with: - Chip conveyor - Coolant system through spindle, 40 bar - Operating manual Country of origin: Germany Motor power: 35 kW Machine dimensions (L x W x H): 6000 x 3800 x 2950 mm Machine weight: 25,000 kg Jakob Friedrich J. Friedrich Werkzeugmaschinen Mistelstrasse 18 75334 Straubenhardt Warehouse: Hjdpjzaq Ecefx Andsnu Auf der Hub 10 76307 Karlsbad-Ittersbach

Condition: good (used), Year of construction: 1999, functionality: fully functional, Vertical machining center Manufacturer: Johnford / Matra Model: FMC 850 Hsdpfxozkg Uyo Andjnu Year of manufacture: 1999 Hours: see image - 24-tool changer with double gripper - Table size: 1000x500mm - Spindle speed: 8,000 rpm - Travel: 800x450mm - Fanuc Oi control system - Machine is in working order and can be inspected while running.

Condition: excellent (used), Year of construction: 2003, functionality: fully functional, Technical Information for Mazak Corporation Mazak VTC-300C II: Model: Mazak VTC-300C II Machine type: Vertical CNC Machining Center Year of manufacture: 2003 Serial number: 162107 Accessories: Chip conveyor included Connected load: 28 kW Typical technical data for the Mazak VTC-300C II: Control: Mazatrol Fusion 640M / Mazatrol PC Fusion CNC Travel distances: X-axis: approx. 1,740 mm, Y-axis: approx. 760 mm, Z-axis: approx. 660 mm Table size: approx. 2,000 × 760 mm Table load capacity: up to approx. 1,400–1,500 kg Spindle taper: CAT 40 / BT40 Spindle speed: typically 10,000 rpm Main spindle power: approx. 18.5–22 kW Tool changer: 30 positions Rapid traverse: approx. 36 m/min Coolant system: included Machine weight: approx. 11,000–13,000 kg The machine is part of Mazak’s large VTC series and is particularly suited for: Hnodpfxoy St E Ro Andsu Large aluminum parts Steel machining Automotive production Fixture and series manufacturing

Condition: ready for operation (used), Year of construction: 2008, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,800 mm, travel distance Z-axis: 850 mm, spindle speed (max.): 22,000 rpm, number of axes: 5, This 5-axis OMV Active Five 3000 was manufactured in 2008. It features a fixed table with a tilting head, Heidenhain TNC-530 control, and a travel range of 3000 x 1800 x 850 mm. The spindle operates at 22,000 rpm with a HSK63A taper and a 30-position tool changer. If you are looking to get high-quality milling capabilities, consider the OMV Active Five 3000 machine we have for sale. Contact us for more information. • Head rotation: B 360° / A ±105° • Tool changer: 30 positions • Table size: 3100 x 1100 mm • Optical scales: Yes • Options/Features: • Torque motor head • Laser tool presetting • Laser measuring system Hodpjx D H Duofx Andonu

Condition: good (used), Year of construction: 1988, Vertical machining center available: 1272026 Hnjdpjzqdnwjfx Andsu

Condition: used, Year of construction: 2007, x-travel 3.600 mm y-travel 920 mm z-travel 820 mm Hodpfxjy Sbike Andsnu control iTNC530 Heidenhain B - axis +/- 90 x 1 ° C-axis 360 x 0,001 ° feed X/Y/Z-axis 1 - 20.000 mm/min rapid traverse X-axis 100 m/min rapid traverse Y-axis 60 m/min rapid traverse Z-axis 60 m/min spindle turning speed - stepless 20 - 10.000 U/min tool taper SK50 power capacity at 100 % load 32,00 kW power capacity at 40 % load 48,00 KW max. torque at 40% / 100% load 294 / 196 kW table surface area 4.200 x 900 mm number of T-slots 9 T-slot - distance 100 mm T-slots 1x 18H7 / 8x 18H12 table load capacity - central/maximum 4.200 kg tool magazin: 80 tool diameter 115 mm wotkpiece diameter with 2 vacant positions 160 mm tool length - max. 360 mm weight of tools max. 12,00 kg total power requirement 85,00 kW weight of the machine ca. 32,00 t dimensions of the machine ca. 11,50 x 6,60 x H3,30 m Vertical machining center with HEIDENHAIN iTNC530 control, swivel milling head, partition wall, tool rack magazine with 80 positions, chip conveyor, coolant system, NC-extension table Ø700mm, operating mode 4.

Condition: used, Year of construction: 2012, x-travel 2134 mm y-travel 1016 mm z-travel 762 mm CNC-control HAAS CNC Table dimensions 2134 x 914 mm max. table load 1814 kg spindle taper SK 50 spindle turning speed range 7500 U/min spindle motor 22,4 kW feed range 1270 mm/min rapid traverse 15,2 m/min tool change unit 30 Pos. coolant IKZ voltage 400 V weight of the machine ca. 13,2 t dimensions of the machine ca. 4,70 x 2,95 x 2,99 m - Serial No.:1099476 - Year of manufacture 11/2012 - Through spindle coolant TSC - 5-Axis pivotable rotary table HAAS TR310 (as new condition) Hodpfxox E Dn Ns Andenu PRICE FOR MACHINE WITHOUT ROTARY TABLE TR310: 82.000,- EUR

Condition: used, operating hours: 18,001 h, travel distance X-axis: 2,500 mm, travel distance Y-axis: 920 mm, travel distance Z-axis: 820 mm, nominal power (apparent): 82 kVA, controller manufacturer: Heidenhain iTNC 530, workpiece length (max.): 900 mm, workpiece width (max.): 900 mm, total height: 3,267 mm, total length: 4,523 mm, total width: 8,436 mm, rotational speed (min.): 12,000 rpm, spindle speed (min.): 12,000 rpm, number of slots in tool magazine: 80, Year of construction: 2004 CNC controller: Heidenhain iTNC 530 Axes X-axis travel mm: 2500 Y-axis travel mm: 920 Hnsdpfx Aneylw D Aodju Z-axis travel mm: 820 Worktable Number of pallets: 1 Table dimensions mm: 3100 Maximum workpiece size (D x H) mm: 900 Spindle Spindle speed rpm: 12000 Spindle drive power kW: 35/25 (40/100%ED) Cooling Tank capacity: 600 Tool system Tool holder: HSK-A 100 Tool magazine slots: 80 Tool changer: Pick-up With free neighboring places mm: 160 With occupied neighboring places mm: 100 Max. Tool Length mm: 250 Max tool weight kg: 12 Equipment Chip conveyor Rotating inspection windows Signal lamp Workarea light Air or water through spindle center RENISHAW Measuring probe Machine running times Under power: 61685 Spindle Working: 18001 Rated power kVA: 82 Basic machine dimensions / weight Length mm: 4523 Width mm: 8436 Height mm: 3267 Weight kg: 26000

Condition: used, Year of construction: 2005, functionality: fully functional, machine/vehicle number: 175849, travel distance X-axis: 1,740 mm, travel distance Y-axis: 760 mm, travel distance Z-axis: 840 mm, controller model: PC Fusion 640 M, total height: 4,450 mm, total length: 3,300 mm, total width: 2,900 mm, overall weight: 11,500 kg, spindle speed (max.): 12,000 rpm, 3-Axis Machining Center MAZAK - VTC 300C-II Manufacturer: MAZAK Model: VTC 300C-II Control: PC Fusion 640M Year of manufacture: 2005 Internal coolant supply (IKZ): 15 bar Table length: 2000 mm Table width: 760 mm Feed rate X-axis: 36,000 mm/min Feed rate Y-axis: 36,000 mm/min Feed rate Z-axis: 36,000 mm/min Tool holder: SK 40 Spindle power: 15 kW Spindle speed: 12,000 rpm Tool changer: 30 positions Internal coolant: Yes Number of controlled axes: 3 Chip conveyor: Yes Cooling unit: Yes Length: 4450 mm Hsdpfsyanuhsx Andsnu Width: 3300 mm Height: 2900 mm Can be inspected under power.

Condition: ready for operation (used), Year of construction: 2007, operating hours: 37,292 h, travel distance X-axis: 2,000 mm, travel distance Y-axis: 620 mm, travel distance Z-axis: 520 mm, controller manufacturer: HEIDENHAIN, controller model: iTNC 530, overall weight: 10,500 kg, spindle speed (max.): 8,000 rpm, spindle motor power: 18,500 W, number of slots in tool magazine: 30, tool weight: 8,500 g, number of axes: 3, This 3-axis HEDELIUS C60 - 2000 vertical machining centre was manufactured in 2007. It features an impressive X-axis travel of 2000 mm, Y-axis travel of 620 mm, and Z-axis travel of 520 mm. The machine is equipped with a powerful 18.5 kW spindle and a tool magazine capacity of 30 tools. If you are looking to get high-quality machining capabilities, consider the HEDELIUS C60 - 2000 machine we have for sale. Contact us for further details. • Pendulum operation area: 2 × 775 × 620 mm • Main spindle torque: 165 Nm (optional 198 Nm) Hnodpfx Ansyz Sptodsu • Tool holder: HSK A63 • Max tool length: 330 mm • Max tool diameter: 80 mm • Tool change time: approx. 3.0 s • Chip-to-chip time: approx. 6.0 s • Table: cast iron machine table with 5 T-slots DIN 650-18 • Coolant system: central coolant through spindle • Coolant tank capacity: 780 liters • Filter grade: 25 µm • Filter capacity: 130 l/min • Pump A: 20 bar / 30 l/min • Pump B: 2.5 bar / 150 l/min • Electrical connection: 3 × 400 V, 50 Hz • Total connected load: 20 kVA • Compressed air requirement: minimum 7 bar • Weight: 10500 kg • Machine enclosure: full enclosure with electric roller door • Positioning system: glass scales on X/Y/Z axes • Drive system: digital AC servo motors with ball screws • Programming: Heidenhain plain text and DIN/ISO Additional equipment • Chip conveyor: scraper belt type, discharge height approx. 1150 mm • Extraction system: MultiAir exhaust filter, 1200 m³/h • 3D probe: Renishaw RMP 60 • Repeatability: ±2 µm • Probe stylus length: 50 mm • Probe ball diameter: 6 mm • Vises (optional)

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, travel distance X-axis: 2,300 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain iTNC 530, spindle speed (max.): 12,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel range, X-axis: 2,300 mm Travel range, Y-axis: 800 mm Travel range, Z-axis: 600 mm Work area, fixed table Work area, X-axis: 925 mm Work area, Y-axis: 800 mm Work area, Z-axis: 600 mm Clamping area: 1,400 × 750 mm Work area, rotary table Work area, X-axis: 780 mm Work area, Y-axis: 800 mm Work area, Z-axis: 600 mm Clamping area: 800 × 630 mm Tool holder: SK 40 Tool magazine: 30 positions Spindle speed: 50–12,000 rpm MACHINE DETAILS Control system: Heidenhain iTNC 530 Spindle: Kessler motor spindle EQUIPMENT Hsdpfjz Epg Eex Andenu 6th axis prepared Handheld control unit Internal cooling system with filter system Filter system: 500 l Chip conveyor Blum laser 2 extraction systems Machine hood

Condition: ready for operation (used), Year of construction: 2000, travel distance X-axis: 2,200 mm, travel distance Y-axis: 600 mm, table width: 650 mm, table length: 2,600 mm, table load: 2,300 kg, overall weight: 12,000 kg, spindle speed (max.): 6,000 rpm, spindle motor power: 28,000 W, tool weight: 10,000 g, number of axes: 3, This 3-axis IBARMIA ZV 40 L2200 vertical machining centre was manufactured in 2000. It features an X-axis travel of 2200 mm, Y-axis travel of 600 mm, and Z-axis travel of 600 mm. The machine has a maximum table load capacity of 2300 kg and a rapid traverse rate of 30 m/min. If you are looking to get high-quality machining capabilities, consider the IBARMIA ZV 40 L2200 machine we have for sale. Contact us for further details. Hnedoy Umlpopfx Andju - X-axis travel in 2-station machining (shuttle operation): 720 mm- Z-axis travel (vertical): 600 mm (Optional: 800 mm)- Number of T-slots: 5- T-slots size: 18 mm- Distance between T-slots: 125 mm- Min./Max. distance spindle nose to table: 200 / 800 mm (Optional: 1000 mm)- Tool taper / holder: SK40 - DIN 69871 (Options: HSK A-63 DIN 69893 or HSK A-80 DIN 69893)- Pull stud for SK tool holder: DIN 69672- Clamping force of tool retention (SK): 12000 N (Options: HSK A-63: 18000 N / HSK A-80: 28000 N)- Inner bearing diameter: 80 mm- Max. standard spindle speed: 6000 rpm (Options: 4000 / 8000 / 10000 rpm)- Main spindle motor power at 100%: 28 kW (Intermittent: 38.5 kW)- Constant power for standard configuration from: 1500 rpm- Max. torque at 100%: 178 Nm (Intermittent: 245 Nm)- Feed force in X, Y, Z at 100%: 13000 N (Intermittent: 15600 N)- Rapid traverse rate in X, Y, Z: 30 m/min- Max. working feed rate in X, Y, Z: 10 m/min- Positioning tolerance Tp X(1000mm)-Y-Z: 0.015 mm- Max. positioning scatter Ps max.: 0.010 mm- Measuring system in X-Y-Z: Linear glass scales- Milling capacity in steel (St 60): 650 cm³/min- Drilling capacity in steel (St 60): Ø 60 mm- Tapping capacity in steel (St 60): M-36- Number of tool pockets: 24 (Options: 40 - 52)- Max. tool length: 300 mm- Max. tool weight: 10 kg- Max. tool diameter (full magazine): 85 mm- Max. tool diameter (adjacent pockets free): 125 mm- Tool management: Random- Tool change time: 3.5 s- Chip-to-chip tool change time: 7 s- Floor space requirement: approx. 17 m²- Coolant tank capacity: 370 liters- Machine length (Dimension A): 4200 mm- Textured paint structure (2 colors): RAL grey 7037 / blue 5012- Electrical connection: 55 kW- Operating voltage: 400 V / 50 Hz- Compressed air connection: 6 bar- Coolant pump power: 0.75 kW- Standard equipment: CE machine enclosure protection, chip conveyor, coolant tank, linear glass scales in X/Y/Z axes, vertical interior cladding along X-axis, workspace lighting, automatic centralized lubrication, hydraulic counterweight balance for spindle head, automatic pneumatic spindle cleaning, mobile control panel, rigid tapping (tapping without compensation chuck).- Factory options available: Internal coolant supply (IKZ), full machine enclosure, partition wall for shuttle operation, dividing heads/rotary tables for 1 or 2 additional machine axes, work tool touch probe, digitization systems, tool monitoring systems, portable electronic handwheel- depending on the requirements, parts in the Y-axis would need to be replaced or repaired

Condition: ready for operation (used), Year of construction: 2002, Make: HEDELIUS Type of machine: CB 80/2300 Hodpfx Anezh Huzjdsnu Year of manufacture: 2002 Control system: Heidenhain TNC 426 Machine's weight: 14.000 kg Tool holder: SK 40 spindel speed: 8.000 1/min x-travel: 2.300 mm y-travel: 800 mm z-travel: 600 mm Speed range: 8.000 1/min max. Table load: 2.800 kg Max. workpiece weight: 2.800 kg Operating time: 54.386 h Chip removal device: Ja Spindle operating time: 26.351 h Table dimensions: 2.900 × 750 mm Number of tools in the magazine: 30-fach

Condition: excellent (used), Year of construction: 2008, Vertical machining center Deckel Maho DMF 220 Linear Year of manufacture: 2008 Control: Siemens 840 D Technical specifications: CNC control: Siemens Sinumerik 840D Number of axes: 3 X-axis travel: 2,200 mm Y-axis travel: 560 mm Z-axis travel: 720 mm Max. clamping height: 600 mm Hnsdpsy Nbbzsfx Andju Table size (LxW): 2,600 x 600 mm Max. table load: 2,200 kg Guideway type: Linear guide Max. power: 35 kW Tool holder: SK40 Tool magazine capacity: 60 Tool change time: 9.6 s The machine was in active serial production until recently and was predominantly used for machining steel and aluminum. Equipment: ⦁ Partition wall for setup time optimization (parallel machining / setup in one cabin half) ⦁ Conveyor belt filter system for coolant processing ⦁ Automatic tool changer ⦁ Generous working area for complex components

Condition: good (used), Year of construction: 2000, Vertical machining center Machine type: Hartford HB-120 W Control: Mitsubishi Meldas control ( G-code programmable) Year: 2000 SPECIFICATIONS Travel X-Axis: 2.000 mm Y-Axis: 1.200 mm Z-Axis: 500 mm Spindle speeds: 50 - 4.000 rpm Spindle motor: 15 kW Tool: ISO 50 Tool capacity: 20 Hnedpfezkbt Rjx Andeu Table size: 2.100 x 1.200 mm Max. Table Load: 2.500 kg

Condition: new, Year of construction: 2026, functionality: fully functional, Working area in X – Y – Z mm: 4,200 – 2,200 – 100 • Continuous work table • Lateral and bottom reference stops • Gantry machine with Gandry system – Dual motorization • Milling unit with 4-axis electrospindle, HSD brand • Blade unit for 360° cutting via HSD electrospindle • Air cooling Hedpfjz Dp Rbox Andsnu • ISO 30 tool holder • Inverter • 10-position tool magazine • Control system: OSAI • Software

Condition: ready for operation (used), Year of construction: 2009, travel distance X-axis: 3,500 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 770 mm, overall weight: 29,000 kg, spindle speed (max.): 6,000 rpm, number of axes: 5, This 5-axis HEDELIUS RS 100 K MAGNUM was manufactured in 2009. It features a travel range of 3500 x 1000 x 770 mm and a rotary-tilting table with a 1200 kg max workpiece weight. The spindle operates at speeds up to 6000 rpm, and the machine includes a 50-tool capacity magazine. If you are looking to get high-quality milling capabilities, consider the HEDELIUS RS 100 K MAGNUM machine we have for sale. Contact us for more information. • Rotary-tilting table travel (X/Y/Z): 1000 / 1000 / 770 mm • Distance spindle nose to table: • Fixed table: 120–890 mm • Rotary/tilting table: 175–945 mm • Table surface: • Fixed table: 2100 × 1000 mm • Rotary/tilting table: 1000 × 800 mm • Table height from floor: • Fixed table: 950 mm • Rotary/tilting table: 895 mm • Max. workpiece weight: • Fixed table: 2000 kg • Rotary/tilting table: 1200 kg • Spindle diameter (front bearing): 90 mm Hodpjx D Im Rsfx Andonu • Tool taper: MAS 403-1982 BT50 • Feed rates (X/Y/Z): 0–30,000 mm/min • Max. feed force: 15,000 N • Tool magazine capacity: 50 tools • Max. tool diameter: 100 mm • Max. drill diameter: 70 mm • Power supply: 40 kVA, 50 Hz

Condition: used, Year of construction: 2001, travel distance X-axis: 2,000 mm, travel distance Y-axis: 820 mm, travel distance Z-axis: 850 mm, DAEWOO ACE V - 850 MACHINING CENTER CNC FANUC 18 - M TABLE SIZE: 2,000 mm x 800 mm TRAVEL: X: 2,000 mm Hjdsyup T Uspfx Andonu Y: 820 mm Z: 850 mm DISTANCE SPINDLE NOSE - TABLE SURFACE: 200 - 1,030 mm SPINDLE SPEED: 6,000 RPM MAXIMUM PERMISSIBLE TABLE LOAD: 3,000 kg TOOL MAGAZINE CAPACITY: 40 positions TAPER: ISO 50 DIN 69871 CHIP CONVEYOR MACHINE COMPLETE WITH ALL DOCUMENTATION YEAR OF FIRST INSTALLATION: 2001 MACHINE IS IN EXCELLENT CONDITION

Condition: good (used), Year of construction: 1998, Vertical Machining Center Mazak VTC-20C The machine is in fully operational condition and has undergone comprehensive service maintenance. You are welcome to inspect it. In 2025, the spindle of the MAZAK VTC-20C was overhauled. Please find some key details from the technical specification below. If you require any additional information, please do not hesitate to ask. Specification | Value ---|--- X-axis travel | 1,660 mm Y-axis travel | 510 mm Z-axis travel | 510 mm Distance from table surface to spindle nose | 180–690 mm Hnsdpfxjvurd Es Andou Distance from column front to spindle centerline | 550 mm Working table area | 2,000 × 510 mm Maximum table load (uniform load) | 1,000 kg Spindle speed | 40–7,000 rpm Spindle motor power – 10 min rating | 11 kW Spindle motor power – 30 min rating | 7.5 kW Spindle motor power – continuous | 5.5 kW Spindle taper | 7/24 taper No. 40 X-axis rapid traverse | 24,000 mm/min Y-axis rapid traverse | 24,000 mm/min Z-axis rapid traverse | 20,000 mm/min X-axis cutting feed rate | 1–5,000 mm/min Y-axis cutting feed rate | 1–5,000 mm/min Z-axis cutting feed rate | 1–5,000 mm/min Tool magazine capacity | 24 tools Tool selection system | Tool holder No. fixed-address system (automatic short-cut system) Tool shank | NT-40 Pull stud bolt | Yamazaki-made ANSI type Maximum permissible tool diameter | Ø80 mm Maximum tool diameter with adjacent pocket empty | Ø110 mm Maximum permissible tool length | 350 mm (from gauge line) Maximum permissible tool weight | 8 kg (including tool shank and pull stud bolt) Maximum total tool weight in magazine | 96 kg (average 4 kg × 24 tools) Machine weight | 7,215 kg Machine height from floor | 2,701 mm Required floor area | 4,000 × 2,990 mm

Condition: good (used), Year of construction: 2000, functionality: fully functional, travel distance X-axis: 2,050 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 520 mm, rotational speed (max.): 12,000 rpm, CNC control Heidenhain TNC 430 32-fold tool changer coolant device 2x chip conveyor measuring feeler The hole X-axis travel is 2050mm. You can work in one move 2 meters. A dividing wall is also with the machine. Then the X-travel will be split. Technische Daten / technical details: Hnedpou Hf Ryofx Andju X-Weg / X-travel 2050 mm Y-Weg / Y-travel 520 mm Z-Weg / Z-travel 520 mm Spindelaufnahme / spindle taper SK40 Drehzahlbereich / spindle speed 12000 UpM /rpm Werkzeugwechselmagazinplätze / number of tool places in changer 2x 32 Antriebleistung Spindel / drive capacity spindle 36 kW Gewicht ca. / weight 12800 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding.

Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 65086, travel distance X-axis: 2,900 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 700 mm, controller model: Heidenhain TNC530, spindle speed (max.): 6,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel range, X-axis: 2,900 mm Travel range, Y-axis: 1,000 mm Travel range, Z-axis: 700 mm Hnodjz Apdnjpfx Andou Spindle speed: 6,000 rpm Tool interface: SK40 Number of tool magazine positions: 24 MACHINE DETAILS Control system model: Heidenhain TNC530

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, CNC machining center Hedelius C50-1800 Hnsdpsyvgxxofx Andou Control: Heidenhain iTNC 530 Year of manufacture: 2008 Internal machine no.: 6 Travel paths: X axis: 1,800 mm Y axis: 510 mm Z axis: 480 mm Clamping area: 2x 1,000 x 510 mm Pendulum mode: 2 x 700 x 510 mm Spindle taper: SK 40 Tool magazine: 20 positions Celox spindle speed: 50 – 12,000 rpm Equipment - 3D Formingstar package - 3D Heidenhain measuring probe - Chip conveyor - Partition wall - LTA extraction system - Water tank, high-pressure pump 20 bar - Machine enclosure
