Condition: used, Year of construction: 2012, functionality: fully functional, machine/vehicle number: 709863, overall weight: 828 kg, Specifications (Hot and Cold Side) PS max: 10bar TS min: 0°C TS max: 110°C V: 39L Rcsdpfx Ahswrh I He Usk PT: 13bar Fluid group:2 The Funke plate heat exchanger FP405-61-1-N-0 is a high-quality device that efficiently transfers heat between two media. Its innovative design allows effective and reliable heat transfer in various industrial applications. The heat exchanger is characterized by its robust construction and easy handling, ensuring a long service life and low-maintenance operation. It is ideal for use in heating, cooling, or process systems where efficient energy use and precise temperature control are required.

Condition: refurbished (used), Year of construction: 2018, functionality: fully functional, High-precision wire EDM machine Redjxq Akwepfx Ah Usck GF CUT 1000 Year of manufacture: 2018 Travel (X/Y/Z): 220 x 160 x 100 mm Travel (U/V): +/- 40 mm Max. taper: 3° at 80 mm height Wire diameter: 0.07 mm to 0.20 mm Best achievable surface finish: Ra=0.08 µm Max. workpiece dimensions: 300 x 200 x 80 mm Max. workpiece weight: 35 kg Includes AGIEJOGGER handbox for convenient machine setup 15" LCD color screen with lift-up keyboard and mouse AGIEVISION control Includes AGIESETUP 3D Includes AGIEDUO twin-wire system for automatic switching between two wire diameters Machine dimensions: 1400 x 1900 x 1970 mm Machine weight: 2700 kg The machine is cleaned, completely overhauled, and thoroughly tested by our specialists. We are happy to set up the machine at your location and provide thorough training on both operation and control.

Year of construction: 1990, condition: used, Weigl ER - 1500 Brief description: Start hole eroding machines Waldmann & Rcsdpfonzh Ivjx Ah Uok Description: Immediately available from site : Start hole eroding machines Waldmann & Weigl Type ER - 1500 Year of manufacture 1990 table size 500 x 500 mm installation height 400 mm twist drill 0,1 - 20 mm taps M 2 - M 20 electrodes 1 - 12 mm drilling machine Interkrenn Economy 280 S height adjustment 700 mm throat 180 mm quill stroke 80 mm speed range 120 - 2580 rpm Tool holder MK 2

Condition: used, Year of construction: 1975, Technical details: table length: 430 mm table width: 270 mm x-axis: 300 mm y-axis: 240 mm z-axis: 250 mm total power requirement: 2 kVA weight of the machine ca.: 0,72 t weight: Schaltschrank: ca. 200 kg space requirements of the machine approx.: L:0,9 x B:1,0 x H:2,1 m START HOLE EROSION MACHINE - size of cooling pond: 1000 x 510 x 900mm - incl. electric cabinet: 600 x 550 x 1400mm Machine is on sale as is, without been checked and will be sold as is! i.D. Rcedpfxsu Nu Elo Ah Uek *

Condition: used, Year of construction: 2017, Suitable for the complete machining of rotationally symmetrical workpieces with cutting edges made of ultra-hard cutting materials. The workpieces can be picked up on the fly or between the centers (option). Accesories: Total enclosure HR workpiece magazine (round magazine) for up to 16 workpieces up to 130 mm in diameter, 20 kg, or up to 8 workpieces up to 230 mm in diameter, 20 kg. Magazine disk for 16/8 HSK63-A,E workpieces with a diameter of 130/230 mm, up to 20 kg. Adapter to the A axis for HSK63-A,E. Automatic fire extinguishing system. N181 extraction system with 500 m³/h air flow. Automatic cover flap. Automatic central lubrication. Measuring probe. Cooling unit for dielectric fluid including cooling unit. HSK-A63 test mandrel. Verfahrweg Z1-Achse: 195 mm Verfahrweg A1-Achse: 360° Workpiece diameter: up to 320 mm workpiece length: up to 500 mm workpiece weight: up to 25 kg mandrel: SK 50 diameter wire: 0.1 - 0.25mm Travel X1 axis: 535 mm Travel Y1 axis: 300mm Z1 axis travel: 195 mm A1 axis travel: 360 ° C1 axis travel: 180 ° Rcedpsw Nilmsfx Ah Ujk Connected load approx.: 5kVA (400V / 50HZ) mass: 4100 kg Dimensions W x D x H approx.: 2549 x 3163 x 2709 mm colour: RAL 7047 telegrey 4, RAL 7045 telegrey 1. Travel C1 axis: 180 °

Condition: excellent (used), Year of construction: 2021, operating hours: 5,874 h, functionality: fully functional, travel distance X-axis: 620 mm, travel distance Y-axis: 420 mm, travel distance Z-axis: 400 mm, workpiece weight (max.): 1,500 kg, total height: 2,520 mm, total width: 2,530 mm, total length: 2,470 mm, table width: 100 mm, distance table to quill: 660 mm, table length: 600 mm, For sale is a very well-maintained Exeron EDM313 Redjxxy Rdspfx Ah Uock Model EDM 313 Travel X x Y x Z 620 x 420 x 400 mm Machine table 1,000 x 600 mm Tank 1,070 x 670 mm Table/quill distance min./max. 160/560 mm (660 mm)* Maximum electrode weight 50/250 kg Maximum workpiece weight 1,500 kg Tank fill height 400 mm Overall dimensions W x D x H 2,530 x 2,470 x 2,520 mm Generator current 60 A/120 A Power supply 400 V, 3AC, 50 (60) Hz Power consumption without chiller 8 kVA/10 kVA

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, workpiece weight (max.): 1,500 kg, travel distance X-axis: 500 mm, travel distance Y-axis: 350 mm, travel distance Z-axis: 300 mm, No reserve price – guaranteed sale to the highest bidder! The payment deadline for the machine is 20/11/2025! Placing a bid obligates the buyer to collect the machine within the period from 01/12/2025 to 05/12/2025! TECHNICAL DETAILS Travel X-axis travel: 500 mm Y-axis travel: 350 mm Z-axis travel: 300 mm Work Table Table dimensions: 780 mm x 630 mm Table load capacity: 1,500 kg Rodsxnkbljpfx Ah Ujck Taper: 10° / 150 mm U/V-axis travel max.: 30 mm Maximum workpiece dimensions: 1,050 mm x 800 mm x 295 mm MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 2,800 mm x 2,460 mm x 2,100 mm Weight: 3,500 kg

Condition: refurbished (used), Year of construction: 2006, functionality: fully functional, AGIECUT Classic 2S Year of construction 2006 Travels: X= 350 mm, Y= 250 mm, Z= 256 mm Travels U/V axis: +/- 70 mm Maximum taper: 30° at 100 mm height Maximum workpiece dimensions: 750 x 550 x 250 mm Maximum workpiece weight: 200 (in bath) / 450 (without bath) kg Achievable surface quality: Ra: 0.20 µm Maximum cutting rate: 300 mm²/min Available wire diameters: 0.20 - 0.33 mm Water bath machine with automatic wire threading and rethreading after wire breakage Rcedouzvkgepfx Ah Usk With manual front door (accessible from 1 side) Incl. AGIEJOGGER handbox for convenient set-up AGIE IPG generator AGIEVISION control unit Dimensions (length x width x height): 1640 x 2040 x 2220 mm Net weight: 2580 kg Our machines are cleaned and overhauled after receipt of order. A test cut with the best surface finish is then carried out for acceptance. You receive a 6-month warranty on the machine. We are happy to offer you commissioning and training on site.

Condition: excellent (used), Year of construction: 2015, operating hours: 5,090 h, functionality: fully functional, machine/vehicle number: T0298, workpiece weight (max.): 850 kg, travel distance X-axis: 500 mm, travel distance Y-axis: 350 mm, travel distance Z-axis: 250 mm, workpiece height (max.): 245 mm, workpiece length (max.): 670 mm, type of input current: three-phase, table width: 960 mm, input frequency: 50 Hz, Equipment: cooling unit, The Sodick VZ500L is a wire-cut EDM (Electrical Discharge Machining) machine from Sodick, designed for electro-erosive machining of metals. This is a wire-type machine equipped with linear drives, enabling precise cutting of intricate shapes at an angle based on CAD files (e.g., DXF, STEP, IGES). Main features: Redpsx Ekcysfx Ah Usck Type: Wire-cut EDM Manufacturer: Sodick Model: VZ500L Drives: Linear Working range (X x Y x Z): 500mm 350mm 250mm Maximum workpiece dimensions: 960mm 670mm 245mm Maximum workpiece weight: 850 kg Capabilities: Angular wire cutting (based on 3D models) Additional features: Automatic wire feeding (AWF) Immersion in dielectric fluid

Condition: good (used), Year of construction: 1986, Table size: 600 x 350 mm Travel X-axis: 340 mm Y-axis: 260 mm Head adjustment travel: 200 mm Quill stroke (servo): 210 mm Max. workpiece weight: 500 kg Siegfried Volz Machine Tools Rcjdpfx Ahery Tq Do Ujk Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Condition: used, Year of construction: 2023, Wire erosion / EDM Travel distance X: 400 mm Travel distance Y :300 mm Travel distance Z: 250 mm max. workpiece size X: 850 mm max. workpiece size Y: 610 mm max. workpiece size Z: 250 mm max. workpiece weight: 500 kg Rodpjxdnkiofx Ah Ujck table size X: 630 mm table size Y: 493 mm with AWF ( Automatic Wire Feeding ) U / V axis: 150x150mm generator: 40 Ampere

Condition: ready for operation (used), Year of construction: 2007, operating hours: 11,560 h, functionality: fully functional, workpiece weight (max.): 500 kg, travel distance X-axis: 350 mm, travel distance Y-axis: 250 mm, travel distance Z-axis: 220 mm, No minimum price – guaranteed sale to the highest bidder! Payment deadline for the machine is 20/11/2025! Placing a bid commits you to collect the machine within the scheduled period from 01/12/2025 to 05/12/2025! TECHNICAL DETAILS Travel distances: X-axis travel: 350 mm Y-axis travel: 250 mm Z-axis travel: 220 mm U-axis travel: +/- 32 mm V-axis travel: +/- 32 mm Max. workpiece dimensions: 800 x 600 x 215 mm Max. workpiece weight: 500 kg Worktable dimensions: 590 x 514 mm Rapid traverse rate of worktable: 1,300 mm/min Electrode wire diameter: 0.1–0.3 mm Max. wire feed speed: 23 m/min Electrode wire tension: 0.5–25 N Max. taper angle: 15° (at 100 mm workpiece height) MACHINE DETAILS Dimensions & Weight: Dimensions (L x W x H): 2,500 x 2,100 x 2,100 mm Weight: 2,000 kg Rcjdpfx Ahsxni T Ho Ujk Operating hours: Machining time: 11,560 h Control total on-time: 65,288 h

Condition: excellent (used), Year of construction: 2019, operating hours: 4,247 h, functionality: fully functional, machine/vehicle number: T1284, workpiece weight (max.): 1,500 kg, travel distance X-axis: 600 mm, travel distance Y-axis: 420 mm, travel distance Z-axis: 370 mm, total height: 2,570 mm, total length: 1,852 mm, total width: 2,825 mm, workpiece height (max.): 400 mm, workpiece width (max.): 750 mm, workpiece length (max.): 550 mm, type of input current: three-phase, table width: 750 mm, overall weight: 5,350 kg, table length: 550 mm, table height: 400 mm, empty load weight: 5,350 kg, table load: 1,500 kg, input voltage: 400 V, input frequency: 50 Hz, The Sodick AG60L die-sinking EDM was manufactured in 2019. It features a ceramic table measuring 750 x 550 mm and can handle a maximum workpiece weight of 1,500 kg. The machine is equipped with a linear motor, glass scales, and a remote control unit, which enhance both precision and operator convenience. We invite you to purchase the Sodick AG60L die-sinking EDM. Please contact us for further details about this machine. Axis travel (X/Y/Z): 600 / 420 / 370 mm Equipment includes: replaceable paper filter, SEC-10 (C-axis), SGF2 Nano Wear Unit, fire extinguisher, TMM3 Power Generator, dielectric cooling unit, 15" TFT touchscreen, linear motors (X, Y, Z axes), glass scales (X, Y, Z axes), ceramic work area, remote control. Machine dimensions (LxWxH): 1852 x 2825 x 2570 mm / Machine weight: 5,350 kg Rcodpox Ekb Nefx Ah Usk Max. workpiece weight: 1,500 kg / Ceramic table size (W x D): 750 x 550 mm Distance floor-to-table: 850 mm / Max. electrode weight: 50 kg Dielectric fluid level (min-max): 150 – 400 mm / Dielectric capacity: 465 liters

Condition: used, Year of construction: 2020, Wire erosion / EDM Rcedpew H Aw Eefx Ah Uek Travel distance X: 600 mm Travel distance Y :400 mm Travel distance Z: 270 mm max. workpiece size X: 920 mm max. workpiece size Y: 700 mm max. workpiece size Z: 215 mm max. workpiece weight: 5000 kg submerged cooling unit

Condition: not inspected (used), Year of construction: 2003, functionality: unexamined, machine/vehicle number: 2228, travel distance X-axis: 310 mm, travel distance Y-axis: 270 mm, travel distance Z-axis: 270 mm, table load: 500 kg, controller model: MF 10-SE, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel distances and axes Travel distance - X: 310 mm Travel distance - Y: 270 mm Travel distance - Z: 270 mm Travel distance - C: ∞ Active axes: X, Y, Z, C Workpiece and working area Workpiece clamping plate: 550 × 350 mm Grid - T-slot: 80 mm Work tank (L × W): 770 × 520 mm Fluid height: max. 310 mm Table load: max. 500 kg Electrode weight: max. 5 kg Control and generator Pulse generator: EroForm 60 A Controller: MF 10-SE Filtration system and dielectric fluid Filtration system: none Filling volume: approx. 400 l Rodpfxsxnbbvs Ah Uock Software data Software version: V2.24 PLC version: V0393 Drive software version: V310 MACHINE DETAILS Machine weight (incl. dielectric fluid): 2,000 kg Weight generator/controller: 300 kg (included in machine weight) EQUIPMENT EROWA ER-007521 clamping system 4-position pick-up changer Fork type H5.62.11 Automatic polarity switching DVM quick-fill valve PLC CPU type 725 Machine prepared for connection to 313 Flushing distribution (manual) Kissling limit switch array Onboard tooling Central lubrication Bielomatik AB-H (manual) Hirschmann C-axis H8.26ILAC50.1 Temperature monitoring inactive CO₂ fire extinguishing system, 5 kg, K&B No. 03476, FB 703

Condition: used, Year of construction: 2014, Wire erosion / EDM Travel distance X: 400 mm Travel distance Y :300 mm Travel distance Z: 250 mm max. workpiece size X: 600 mm max. workpiece size Y: 470 mm max. workpiece size Z: 240 mm max. workpiece weight: 500 kg Rodpsw H Awxjfx Ah Ujck table size X: 860 mm table size Y: 690 mm with AWF ( Automatic Wire Feeding ) U / V axis: 150 x 150 submerged cooling unit

Condition: not inspected (used), Year of construction: 2001, functionality: unexamined, travel distance X-axis: 620 mm, travel distance Y-axis: 420 mm, travel distance Z-axis: 400 mm, table load: 1,500 kg, travel speed (max.): 5,000 mm/min, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Machine Data Installation footprint: 6.5 m² Length: 2,600 mm Width: 2,500 mm Height: 2,500 mm Machine weight (with control cabinet, without dielectric fluid): < 4,500 kg Generator connection power 60 A: 12 kVA Mains voltage: 400 V Rated current: 32 A Protection – 60 A generator fuse or circuit breaker: K-characteristic Working current according to generator – min./max.: 60/100 A Working Area and Load Capacity Permissible workpiece dimensions: 950 × 550 × 360 mm Max. permissible table load: 1,500 kg Max. permissible electrode weight with pneumatic chuck – static: 50 kg Max. permissible electrode weight directly on the spindle: 250 kg Min. distance between table and electrode holder: 150 mm Max. distance between table and electrode holder: 450 mm Max. permissible electrode weight, each centric holder: 800 kg Static: 50 kg Rotating: 35 kg Indexing/eroding: 25 kg Max. mass moment of inertia: 800 kg/cm² Work Tank Fluid level from table (liquid height): 300 mm Internal height: 350 mm Internal width: 850 mm Internal length: 450 mm Clamping Plate Length: 600 mm Width: 1,000 mm T-slots (per DIN 650) – Width: 12 H8 mm T-slot spacing: 100 mm Traverse Paths and Speeds Travel – X: 620 mm Travel – Y: 420 mm Travel – Z: 400 mm Travel speed: 5,000 mm/min Display resolution: < 1 µm Positioning accuracy X-axis: < 10 µm Positioning accuracy Y-axis: < 10 µm Positioning accuracy Z-axis: < 10 µm Dividing accuracy C-axis type: Hirschmann without RON: < 0.01° Dividing accuracy C-axis type: Hirschmann with RON: < 0.005° Compressed Air and Dielectric Fluid Compressed air supply – with cartridge filter: 500 l/h Compressed air consumption – intermittently (gap filter and clamping device): approx. 20 l/min Dielectric capacity – max.: approx. 900 l Gap Filter System – backflushable Filter unit: 1 Filtration rating: 1 µm Filter capacity: 60–0 l/min Pump power consumption: 0.55 kW Cartridge Filter System Number of cartridge filters: 3 Rcjdpfx Aoxna Ubeh Uek Filtration rating: 5 µm Filter capacity: 50–0 l/min Pump power consumption: 0.55 kW MACHINE DETAILS Exeron S313 MF CEE socket/plug: not specified C-axis rotation speed: not specified Max. fill volume: not specified Weight of generator and control unit: not specified EQUIPMENT Exeron S313 MF with C-axis Pneumatic clamping system Backflushable gap filter system Cartridge filter system Dielectric fluid tank Clamping plate according to DIN 650 Integrated generator and control unit

Condition: used, Year of construction: 2002, Wire erosion / EDM Travel distance X: 750 mm Travel distance Y :500 mm Travel distance Z: 400 mm max. workpiece size X: 1050 mm max. workpiece size Y: 750 mm max. workpiece size Z: 400 mm max. workpiece weight: 1500 kg Rcedpfow Ei Stjx Ah Uek U / V axis: 770 x 520 mm generator: 60 Ampere Linear drives

Condition: not inspected (used), Year of construction: 1997, functionality: unexamined, machine/vehicle number: 9710C365, workpiece weight (max.): 250 kg, travel distance X-axis: 320 mm, travel distance Y-axis: 220 mm, travel distance Z-axis: 180 mm, controller model: FANUC SERIES 16-W, No reserve price – guaranteed sale to the highest bidder! The payment deadline for the machine is November 20, 2025! Placing a bid obligates you to collect the machine on time between December 1, 2025 and December 5, 2025! TECHNICAL DETAILS Rjdpfjxnl Umjx Ah Ueck Travel distances Travel X-axis: 320 mm Travel Y-axis: 220 mm Travel U-axis: 120 mm Travel V-axis: 120 mm Travel Z-axis: 180 mm Max. workpiece weight: 250 kg Feed rate in X and Y axes: 900 mm/min In U, V and Z axes: 450 mm/min Table dimensions: 530 x 330 mm MACHINE DETAILS Control: FANUC SERIES 16-W Dimensions & Weight Dimensions (L x W x H): 4,000 x 2,000 x 2,400 mm Weight: 3,000 kg EQUIPMENT Coolant tank

Condition: used, Year of construction: 2008, Diesinking / EDM Travel distance X: 550 mm Travel distance Y :400 mm Travel distance Z: 350 mm table size X: 700 mm table size Y: 500 mm Rcsdpfjw Ektfjx Ah Uek max. electrode weight: 80 kg max. workpiece weight: 1000 kg tool changer: 5 -time cooler C-Axis

Condition: not inspected (used), Year of construction: 2000, functionality: unexamined, machine/vehicle number: 573251, travel distance X-axis: 525 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 450 mm, table width: 730 mm, table length: 630 mm, No reserve price – guaranteed sale to the highest bidder! The payment deadline for the machine is 20/11/2025! Placing a bid obligates you to collect the machine on time between 01/12/2025 and 05/12/2025! TECHNICAL DETAILS Travel distances Travel distance X-axis: 525 mm Travel distance Y-axis: 400 mm Travel distance Z-axis: 450 mm Travel path for electrode change and loading position: 675 mm Traverse speed X, Y, Z: max. 2,000 mm/min Work table Support surface: 730 × 630 mm Load capacity: 1,000 kg T-slots: 5 Integrated C-axis Speed (adjustable): 1–20 rpm Measuring resolution: 0.001° Work tank Version: tank lift controlled Internal dimensions: 750 × 650 × 420 mm Maximum dielectric fluid height: 375 mm Programmable/automatic: yes Work head Max. head load: 100 kg Distance from tool carrier plate to work table min./max.: 135/585 mm Dielectric fluid supply Filtration system: 4 cartridges (integrated) Filter area: 2 m² Total volume of dielectric fluid: 400 l Rcodpfx Aexniwroh Uek MACHINE DETAILS Dimensions & weight Dimensions (L x W x H): 2,500 x 1,500 x 2,500 mm Weight: 4,400 kg Weight: 200 kg Electrical data Connected load: 25 kVA Fusing: 25 A Operating voltage/frequency: 400/50 V/Hz EQUIPMENT 20-position electrode changer Automatic central lubrication Pick-up disc magazine CO₂ fire extinguishing system according to DIN 14497 Compressor cooler

Condition: used, Year of construction: 2003, Wire erosion / EDM Travel distance X: 350 mm Travel distance Y :250 mm Travel distance Z: 256 mm max. workpiece size X: 750 mm Redpfew Ekr Isx Ah Ujck max. workpiece size Y: 550 mm max. workpiece size Z: 250 mm max. workpiece weight: 450 kg with AWF ( Automatic Wire Feeding )

Condition: used, Year of construction: 2003, Diesinking / EDM Travel distance X: 400 mm Travel distance Y :300 mm Travel distance Z: 300 mm table size X: 550 mm table size Y: 470 mm max. workpiece weight: 500 kg electrode changer: 30 - time generator: 70 Ampere cooler HSJ technology (High Speed Jump) Mitsubishi control system - 64 bit CNC CO2 fire extinguishing system Integrated cartridge filter system Programming station software MultiProg Rjdpfx Aswmn U Nsh Ujck Dielectric cooler

Condition: used, Year of construction: 2004, Wire erosion / EDM Travel distance X: 350 mm Travel distance Y :250 mm Travel distance Z: 256 mm Rcjdpfx Ahowf I Ims Uok max. workpiece size X: 750 mm max. workpiece size Y: 550 mm max. workpiece size Z: 250 mm max. workpiece weight: 200 kg submerged cooling unit The machine has been serviced annually by the manufacturer.

Condition: used, Year of construction: 2006, Diesinking / EDM Travel distance X: 700 mm Travel distance Y :500 mm Rcedpev D Nr Eefx Ah Uok Travel distance Z: 400 mm max. workpiece size X: 750 mm max. workpiece size Y: 1100 mm max. workpiece size Z: 370 mm max. electrode weight: 80 kg max. workpiece weight: 2000 kg electrode changer: 15 - time C-axis generator: 104 Ampere
