Condition: good (used), Year of construction: 2000, Functionality: fully functional, overall weight: 7,000 kg, Attached is the thermoforming machine, custom-built. ABS, PS, TPE, and HDPE sheets with a thickness of up to 12 mm have been thermoformed with this machine. It was used to make footwell mats, baskets, and trays for the automotive industry. Operating procedure? Open clamping frame, insert sheet, close clamping frame, table moves under the heater, when the set temperature is reached the table moves back and vacuum is applied, ventilation starts. Is temperature setting stepless or not? The temperature setting is stepless. A video can be provided on request. Is the machine hydraulic, electric, or pneumatic? I believe it was pneumatic. Does the machine have side guides or guide columns? I don’t know what you mean by that; what is supposed to be guided? Iaolhccqowtc R Ssqew Space requirements Table dimensions L x W x H approx. 14m x 3.5m x 3m Forming pressure, how many bar? Approx. 0.7 bar

Condition: good (used), Year of construction: 1991, Functionality: fully functional, Oven for plastic processing Isljwp Em Uohccqqsaw The oven can process thermo-plastics. Manufacturer: Reinhardt Model : VL Year of manufacture : 1991 No. : 8182 Connected load 50.2 kW Voltage 380 Volt Operating temperature 50 - 200 °C Carriage approx.: 2000 x 1200 mm W x D x 500 mm opening

Condition: good (used), Semi-automatic stone edge grinding machine with milling head Manufacturer: STEUP Model : STK-FT 8/4 P Year of manufacture: 1996 Grinding length 3200 mm Grinding depth 2500 mm and more 2 pcs. front stops swiveling Iajlhccswplfqoqqow Water and air supply 5 bar Milling head 200 mm diameter Accessories approx. 7 - 10 grinding bodies

Condition: good (used), Functionality: fully functional, machine/vehicle number: 874/96-05, CNC Bridge Saw Machine Manufacturer: STEUP Model: SUT 550N-EM Control: Steup TSX 32 with manual function and automatic operation (box and programmable up to 100 programs) No automatic lowering function for hard stone, 8 sets with 20 repetitions The machine is located in a stone processing business, which has closed due to age reasons. Saw length: 3200 mm Saw depth: 2500 mm Saw height: 80 mm Saw blade diameter: 500 mm, can also go up to 600 mm Islswpk Uqjhccqqeaw Saw blade bore: 60 mm Saw blade: 400 mm, material thickness 18-19 mm Speed: 1400 rpm 2 pcs. portable concrete foundations for smooth running

Condition: refurbished (used), Functionality: fully functional, Band saw fully automatic, hydraulic Enclosed is the machine description subject to a final inspection: During the overhaul, new spare parts worth 12,000 euros were installed by Kasto Service and the painting was carried out by a specialist company. Used KASTO band saw automatic machine TYPE KASTOtec AC 5 Year built 2000 Machine no. 6610 101 014 Voltage 400 V 50 Hz Saw blade dimensions: 7675 x 54 x 1.6 mm Including attached accessories: - Carbide package - Material feed 1,500 mm in one stroke - Special chip conveyor with brush - Drive for the machine roller conveyor - smooth clamping jaws (instead of serrated) Technical data: Cutting area: Round 530 mm Square 530 x 530 mm Flat 530 x 630 mm Smallest dimension to be sawn: 10x10 mm Smallest cut-off length: 6 mm Shortest remaining piece length in automatic operation: 35 mm Technical data: Material support height 700 mm Total weight 5,900 kg Total drive power 25 kW Saw motor 15 kW automatic feed length 1500 mm Cutting speed stepless 30 – 120 m/min Saw feed rate 0.5 - 300 mm/min Multiple feed length 9,999 mm Coolant: Volume of coolant tank 185 l, pump capacity at 10 m delivery height 20 l/min Paintwork: Machine light grey RAL 7035 textured finish Saw unit pure orange RAL 2003 textured finish Rjbmmoudwcaovvgleu Compressed air connection: approx. 6 bar/20 l/min required Description KASTOtec AC 5 Fully hydraulic high-performance band saw automatic in heavy construction for separating solid material, profiles, and tubes in all grades, including hard-to-machine materials such as titanium, Hastelloy, Inconel, etc. Machine frame in torsion-resistant welded construction, with integrated coolant tank Saw unit made of steel-mineral cast composite construction High-performance sawing technology requires the use of the latest machine-building materials. The use of mineral cast guarantees a high level of damping and the greatest smooth running of the saw band, even with difficult-to-machine materials. This results in shorter Iaslowpfqtohccqqow cutting times and longer saw band life.

Condition: like new (used), FLEXIBLE PIPE 50 mm diameter - impact-resistant - for concrete as protective pipe - for wood as protective pipe Outer diameter 50 mm Resistance: Temperature-resistant Compression strength: 750 N Color: Black Suitable for: Concrete, wood, screed Iaelhccown D Axjqqow Material: Plastic Material specification: PVC Standard: DIN EN 50086-2-2 Cross-section: EN 50 Temperature resistance: -5°C to 60°C Installation type: Flush-mount, surface-mount, in-wall Other properties: Flame-retardant, self-extinguishing Length: 25 m Weight (net): 5.4 kg

Condition: excellent (used), Functionality: fully functional, overall weight: 40 kg, pressure (max.): 8 bar, Year of construction: 2012, Mobile compressor Manufacturer: EINHELL Iaslhccqewn Dwvjqjw Type: BT-AC 400/50 Year of manufacture: 2012 Machine No.: 2012/07/EB039883 Tank 50 liters / 8 bar pressure capacity Motor 230 V / 50 Hz, 2.6 kW S2 30 / min. 2.4 kW S1 IP 20 Color blue

Year of construction: 1997, Condition: used, Welding turntable Manufacturer: PROTARC ZAAR UNIWELT Model: PF-150E Year of manufacture: 1997 Iaolhcown Dmkocqqow Stepless speed from 0.0 - 2.06 rpm. 200 V / 50 Hz

Condition: good (used), Functionality: fully functional, TIG welding machine Iaslhcjwn Di Eecqqew Manufacturer: Messer Griesheim Model POLYGOUDE 254

Year of construction: 2007, Condition: refurbished (used), Functionality: fully functional, Bogie hearth furnace Year of construction 2007 Technical data: Batch weight: max. 15 t. Usable size 3300 x 2200 x 1600 mm (LxWxH) Operating temperature max. 950 °C Iaolhccewnnzfeqqew Temperature uniformity. +/- 10°C at the end of holding time 6 pulse burners "System Löcher" furnace door on bogie including: Control cabinet and gas control section Ready for operation with installation and without freight

Condition: ready for operation (used), Functionality: fully functional, Peddinghaus Peddycut 275 6-way combined section steel shear Available immediately from site: Peddinghaus section steel shear Type Peddycut 275 Year of manufacture 1987 Pressure capacity 27 tons Table 400 x 250 mm Thrust 90 mm Power 10 mm Drive 1.5 kW Strokes/min 15 Flat steel 50 x 15 mm Angle steel 65 x 6 mm Round steel 28 mm Square bar 25 mm Knife pitch 175 mm Punch stroke 24 mm Punches 20 mm in 19 mm or 30 mm in 6.5 mm sheet Foot switch Various punches Iajlhowfdbpeccqqsw Transport: from site

Condition: good (used), Functionality: fully functional, Fezer rotating and pivoting vacuum suction table or assembly table, extendable with two suction plates (300 x 100 mm) For all dense workpieces, such as metal, wood, glass, stone, etc. Rotates 360 degrees and pivots up to 90 degrees, working height adjustable from 740 to 940 mm No pressure marks or scratches on the material due to the suction cups (approx. 300 mm long x 100 mm) - Shortest clamping times thanks to foot valve release and clamping - No obstruction during processing, the sides of the workpiece are completely free - The suctioned parts can be rotated or pivoted. - The suction plates are height-adjustable. - Applications include sawing, sanding, surface treatment, priming, and assembly. Iaelewcluljhccqqsw - Suction holding force at 80%: 100 mbar. Operating vacuum horizontally approx. 120 kg, parallel 60 kg. Manufacturer: Fezer Type: ATS /E Suction plate size: 300 x 100 Number of suction plates: 2 Height-adjustable support column Pivoting and adjustable suction head Workpiece support: 730 to 180 mm x 2 Without vacuum generator (stationary air connection) Operating pressure: 3 - 6 bar Flow rate: 4.2 m³/h

Condition: ready for operation (used), Functionality: fully functional, Pillar Drill with Mobile Base Huvema HU 16A Drill Capacity 16 mm MK2 Chuck Thrust 180 mm Spindle Stroke 90 mm Speeds 1420 rpm 12 Distance Spindle Nose to Table 455 mm Column Diameter 80 mm Line Voltage 220 V Power 0.37 kW Dimensions without base: L x W x H 350 x 630 x 1090 mm Weight 80 kg Ielhswahkksccqqsaw

Condition: ready for operation (used), Functionality: fully functional, travel distance X-axis: 1,020 mm, travel distance Y-axis: 762 mm, travel distance Z-axis: 600 mm, Vertical machining center Manufacturer: HURCO Bebmmvyoubcvtjhwslf Type: BMC 40 / 50 Iaolhccqowag Tqoqow Travel: X-axis 1020 mm Y-axis 762 mm Z-axis 600 mm Table load: 1500 kg Table size 1465 x 870 mm Spindle speeds 30 - 4000 RPM 30-station tool changer Tool-to-tool speed 8 sec. 2000 RPM Spindle mount SK 40 Voltage 400 Drive power 11.2 kW Weight 8000 kg Dimensions L x W x H = 3860 x 3315 x 2775 mm

Year of construction: 2025, Condition: new, Hydraulic C-frame press (punch press) Year of manufacture: 2025 Capacity: 100 tons at 230 bar Control / key switch: Ielhccjwag Rijqqsaw 1. Manual setup mode without light sensor 2. Automatic (at full speed) with light sensor Main cylinder: Ø 230 mm Auxiliary cylinders: 2 x Ø 50 x 30 mm Auxiliary guide: 2 x Ø 50 mm Motor: 11 kW – 15 hp Pump: 16 cc – 23 liters / ASC – Helical gear pump Speed: Forward 110 mm/sec – Return 200 mm/sec Pressure phase: 9 mm/sec Installation height: 500 mm Stroke length: 400 mm. Push plate: 750 x 600 mm. – with T-slots Table top: 750 x 600 mm. – with T-slots Table height: 850 mm. (Floor to table top edge) ----- Hydraulic accessories: Hydraulic control block & accessories: REXROTH Pressure adjustment via PLC. (20 – 100 tons) Speed adjustable via PLC. Air cooler Feed valve NG.63 Control accessories: Siemens S7-1200 Blsbjftg Sgsmmvyhwof Main control box Foldable control panel With side safety door (doors can be moved backwards) SICK 750 + 150 mm light sensors. Ruler for adjusting the stroke length 7" PLC screen – Siemens Movable two-hand control Alarm indicator for faults (light & sound) ----- • The press complies with the EN693 Machinery Directive • Hydraulic two-way valves • Dual-channel fused control system • Safety PLC – SICK • Operating instructions & parts list (German) • Warranty: 24 months ----- Oil capacity: 190 liters (Tank volume: 205 liters) Total weight: approx. 5,500 kg. Overall dimensions: 1300 x 2000 x 2750 mm. Delivery time: 2 - 3 weeks from stock. Paint finish: Light gray & dark gray The machine is available immediately in 2 - 3 weeks. Freight: approx. €2,000 from Konya to Germany

Condition: used, Year of construction: 1990, Functionality: fully functional, TIG welding machine Manufacturer: Messer Griesheim Model: 300 DC with hose package and torch Area of application: TIG - 2 stroke TIG - 4 stroke TIG - spot welding TIG - pulse welding tg with setting of pulse time for all metals except aluminum / stick electrode welding Welding performance at 35% duty cycle: 300 A Welding performance at 60% duty cycle: 230 A Iaelhccqsv Ini Doqow Welding performance at 100% duty cycle: 180 A Workpiece cable 50 mm² NSLFFÖÜ Electrical connection: 380 volts Fuse: 35 amps 15.2 KVA at 300 A Cooling type: F Insulation class: F External dimensions: 950 x 500 x 850 mm high used in good condition

Condition: used, Functionality: fully functional, machine/vehicle number: 9880147, Plasma cutting device, plasma cutting machine MESSER GRIESSHEIM type Plasmastar HA 95 Cutting Setting ranges A/V 45/110 IPower 95 / 110 II l 2 Cutting current 70% ED 45 A - 60% ED 95 A Input current 380 V Input power 11.2 A I level 23 A II level Mains connection 16.6,6,6 mm² Slow-blow fuse 63, 35, 25 A Nominal frequency 50 / 60 Hz Protection class IP 23 Cooling type F Insulation class F Ijlhccqsv Im Rtjqoaw Length x width x height 760 x 470 x 850 mm Weight 160 kg Workpiece power 25 mm Setting range 2 levels Hand torch PHC 95/140 Mains connection 380 volts, 50 Hz, 32 Amp. connector - Water cooled - 8 meter hose package length Ps2Lh - Operating instructions

Condition: good (used), Functionality: fully functional, Workbench 1500 x 700 mm x 800 mm with multiplex wooden panel 40 mm 2 drawers Islhccjv Dc T Njqqjaw 2 tool compartments as drawers

Condition: good (used), Functionality: fully functional, We are looking for company liquidations of sheet metal processing machines Iajljvzl H Tshccqqsw

Condition: good (used), Functionality: fully functional, machine/vehicle number: 804, roller length: 2,550 mm, sheet thickness (max.): 16 mm, sheet thickness steel (max.): 16 mm, overall weight: 12,500 kg, bending length: 2,500 mm, 3-roll hydraulic plate bending machine 2500 x 16 mm Manufacturer: KUMLA Type: PV 7 H Serial no.: 804, overhauled in 1987 The machine is of a very robust design and has only been used in single-shift operation. Max. bending length: 2500 mm Max. sheet thickness: 16 mm Cone bending device Top roll diameter: 324 mm Bottom roll diameter: 305 mm Hydraulic roll adjustment Iajlhccsvxbm Reqqsw Dimensions: L x W x H = 5000 x 1600 x H 1900 mm Working height: 1000 mm Additionally, a staircase platform around the machine can be purchased.

Condition: good (used), Machine housing Dimensions 2x1200 mm wide, 3000 mm long, platform height 70 mm, Iaelhccqjvvxcwjqow Total length 3500 mm, total width 2500 mm, total height 1800 mm Railing can be unscrewed Steps made of checkered sheet Weight per part 290 kg

Condition: new, Year of construction: 2024, Functionality: fully functional, TRtech Prime 31100 Press Brake 1 EUR 52,500.00 EUR 52,500.00 Bending Force: 100 ton Bending Length: 3100 mm Distance Between Columns: 2600 mm Stroke: 265 mm Daylight: 490 mm Throat Depth: 410 mm Table Height: 900 Table Width: 110 mm Free Fall Speed: 120 mm/s Pressing Speed: 10 mm/s Return Dpeed: 110 mm/s X Axis Stroke: 750 mm Engine Power: 11 kW Width: 1780 mm Height: 3960 mm Length: 2850 mm Iaolovd Aavjhccqqsw App. Weight: 8500 kg Number of Axis: X, R, Z1, Z2, Y1, Y2 Safety Cages with Switch CNC Controlled Hydraulic Dynamic Crowning System Control Unit: STEP Rock 22 Servo Motor Backgauge: X, R, Z1, Z2 Segmented Die Segmented Punch Sliding Front Arms ( T-Slot and stopper ): 2 pieces Payment conditions: BY SWIFT: %40 pre-payment in advance, rest before loading TOTAL EUR 52.500,00 Delivery time: EX-Works OSM Makina, 12 weeks after the reception of order SEAL AND SIGNATURE PROFORMA INVOICE Bill To Frank Pelka Maschinen GmbH Dorfstr. 11 57271 Hilchenbach Germany

Condition: new, Functionality: fully functional, Year of construction: 2024, TRtech ORGM-3004 Reducer Guillotine Shear 1 EUR 30.500,00 Cutting Length: 3100 mm Cutting Capacity for 450 N/mm² (MS): 4 mm NC Back Gauge Range : 750 mm Cutting line lightning & shadow illumination Raer safety covers with photocell Squaring arm with T slot, stoper and ruler Cutting unit counter Front sheet holding arms: 3 pcs Finger protection cages Table with ball transfer Cutting gap adjustment Motor Power : 7,5 kW Height : 1380 mm Width : 2300 mm Length : 3700 mm Cutting Angle : 1° 30' Weight Approx. : 4000 kg Options Return to sender & Rear pneumatic sheet support system 1 EUR 3.300,00 EUR 3.300,00 Payment conditions: BY SWIFT: %40 pre-payment in advance, rest before loading TOTAL EUR 33.800,00 Delivery time: EX-Works OSM Makina, 8 weeks after the reception of order Iajlhcjvdz Rtjcqqsw SEAL AND SIGNATURE Delivery time: EX-Works OSM Makina, 8 weeks after the reception of order

Year of construction: 2018, Condition: good (used), Welding table Manufacturer: FPM Type : 1800 x 1600 mm x 40 thick and 850 mm high with 5 pcs. feet diameter 100 mm Ielhccot R U D Asqqoaw The surface is straight and not uneven

Condition: good (used), Year of construction: 1991, 1 piece Hydr. hole punch MUBEA type HP 1000 / 760. Year of manufacture 1991 Punching force 100 tons With punching saddle for K 60-K260 and various tools, manually operated linear punching unit (raster rail 4 m) swiveling and digital display, carriage clamping and foot switch Iaolhccqjtv Hzveqsw Dimensions L x W X H 1930 x 780 x 1980 mm Projection 760 mm Working height 1135 mm Hole 40 in 22 mm Stroke 0 - 70 strokes Number of strokes at full stroke 11 strokes Drive power 8.5 kW Weight 3800 kg 3600 kg Used, ready for operation
